Corsair COMMANDER PRO User manual

INSTALLATION GUIDE
ONE COMMANDER. TOTAL CONTROL.
COMMANDER
PRO
COMMANDER
PRO

COMMANDER PRO
Specifications
Package Contents
x1 CORSAIR Commander PRO
x2 RGB LED hub cables
x4 Thermal sensors
x4 Fan extension cables
x2 Mounting tape
x1 Installation guide
Commander PRO
Unit dimension (L x W x H) 133mm x 69mm x 15.5mm
Power input
Logic 2.97V to 3.63V
4.5V to 5.5V
Fan 11.4V to 12.6V
RGB LED 4.5V to 5.5V
Cable
USB 440mm
SATA power 465mm
Thermal sensor 610mm
Fan extension 610mm
RGB LED hub 485mm
RGB LED channels Two 3-pin connector
Max. power for RGB LED channels 4.5A
Max. power per fan header (combined) 1A per port (4.5A combined)
69mm
15.5
mm
133mm
Congratulations!
Congratulations on the purchase of
your new CORSAIR Commander PRO!
The CORSAIR Commander PRO grants superior and
accurate hardware control with a compact,
all-in-one device. It is fully compatible with CORSAIR
LINK devices through two internal USB 2.0 headers,
monitors four temperature inputs, and controls up to six
fan connectors and two RGB LED channels. Accurately
monitor how your system reacts when you push it to
the limits. Manage your fans without pressing knobs or
switches through the intuitive CORSAIR LINK software.
Synchronize your RGB lighting eects with the optional
HD RGB fans, SP RGB fans, and individually addressable
RGB LED strips to light up your build.

COMMANDER PRO
Installation
1. Turn your system off for the installation of your
Commander PRO.
4. Connect the thermal sensors to the 2-pin headers
labeled Temp 1-4".
2. Locate an area to mount your Commander PRO.
Adhere it onto the desired location with the double-
sided tape.
3. Connect any 3-pin or 4-pin fans you wish to control
into the 4-pin headers labeled "Fans 1-6. The
included fan extension cables can be used
if necessary.
TIP: The thermal sensors are designed to measure ambient temperatures, so for
the most accurate results, they should not directly touch components.
You may find it useful to mount the thermal sensors near air intake and exhaust
points, and if your PC case has multiple compartments, you can try placing each
of the sensors in its own compartment. Since the thermal sensors can easily be
repositioned, you can try various locations and use what works best for you.
5. OPTIONAL: Connect the individually addressable
RGB LED strips (sold separately) to the 3-pin
connectors labeled LED 1-2". Alternatively, connect
your HD/SP RGB fans to the Commander PRO via
the RGB LED hub (sold separately) using the
supplied RGB LED hub cables.
WARNING!
Please refrain from mounting the strips on components
(HDD, SSD) that are sensitive to magnets.
6. Connect your LINK hardware such as the Lighting
Node PRO (sold separately) into an available 9-pin
USB 2.0 header on the Commander PRO.
Ensure that these devices are properly powered
(see device manual).

COMMANDER PRO
7. Plug the USB cable from the Commander PRO into
an available internal USB 2.0 header on your PC’s
motherboard (refer to your motherboard manual
for location).
8. Connect the SATA power connector to any available
SATA connector from your power supply.
9. For the full CORSAIR LINK experience, please
download our latest CORSAIR LINK software.
