K100 AIR
RGB WIRELESS MECHANICAL GAMING KEYBOARD

ENGLISH
ENGLISH
1
A D HE IB C
P Q R
L M N
S
OF JG K
GETTING TO KNOW YOUR KEYBOARD
Charge the keyboard fully before first use by connecting the USB cable (S) to the keyboard USB Type-C port (Q)
and to an available USB 3.0 or better Type-A port on a compatible device including:
APROFILE KEY
BBRIGHTNESS KEY
CWINDOWS LOCK KEY
DWIRELESS INDICATOR
EENCRYPTION INDICATOR
FBATTERY INDICATOR
GMACRO INDICATOR
HNUM LOCK INDICATOR
I CAPS LOCK INDICATOR
JSCROLL LOCK INDICATOR
KWINDOWS LOCK INDICATOR
LMEDIA CONTROL KEYS
MMUTE KEY
NVOLUME ROLLER
OMACRO G-KEYS / WIRELESS FN KEYS
PSLIPSTREAM WIRELESS ADAPTER
QUSB TYPE-C PORT
RPOWER SWITCH
SUSB TYPE-C TO TYPE-A CABLE
BEFORE FIRST USE
Windows®PC Apple Mac®Microsoft Xbox One*
Microsoft Xbox Series X|S*
PlayStation 4**
PlayStation 5**
*Keyboard is compatible out of the box, see corsair.com/xbox-support for details.
**See Connecting to Sony PlayStation section.
Hold the ESC key while turning the power switch (R) to on, then release the ESC key after two seconds. The
keyboard will then power on normally and be reset to factory defaults.
FACTORY RESET

2
ENGLISH
TIPS AND TRICKS:
• If left on and idle, the keyboard will go to sleep to conserve battery (adjustable in iCUE)
• Reduce brightness or turn off backlighting to extend battery life (and increase charging speed)
• Charge as soon as possible when critically low charge to maximize battery longevity
• Always plug into a USB 3.0 port or better to ensure adequate charging current
The battery indicator (F) will denote charging status when plugged into a compatible device via USB cable.
Upon powering on the keyboard or using the check battery life shortcut below, the battery indicator (F) will denote
current battery charge level.
CHARGING & BATTERY LIFE
1. Plug in the SLIPSTREAM wireless adapter (P) to an available USB 2.0 or better
Type-A port
2. Slide the keyboard power switch (R) to on
3. Switch to SLIPSTREAM wireless mode (see below)
4. After SLIPSTREAM connects automatically, the wireless indicator (D) and
encryption indicator (E) both turn solid white for 3 seconds
NOTE: To complete pairing to a SLIPSTREAM wireless adapter, initiate adapter pairing in iCUE device settings.
CONNECTING VIA SLIPSTREAM WIRELESS
STATUS INDICATION INDICATOR
Fully Charged Solid Green
Charging Blinking Green
SHORTCUT STATUS INDICATION INDICATOR
FN +
Fully Charged Solid Green
High Charge Blinking Green
Medium Charge Blinking Amber
Low Charge Blinking Red
Critically Low Charge Pulsing Red
SHORTCUT FUNCTION STATUS INDICATION INDICATOR
FN + (Press) Switch to SLIPSTREAM
wireless mode
Connected Solid White (3 sec)
Disconnected Pulsing White

ENGLISH
3
1. Initiate Bluetooth pairing on the host device such as a phone or tablet (Bluetooth 4.0 or higher)*
2. Start Bluetooth host pairing on the keyboard, up to three devices can be paired (see below)
3. Input the code from the Bluetooth device screen on the keyboard if requested
4. When pairing completes, the wireless indictor (D) turns solid blue/cyan/magenta for 3 seconds
CONNECTING VIA BLUETOOTH®WIRELESS
NOTE: Wireless modes can be switched to at any time by pressing a wireless shortcut. Pressing the same
shortcut again will switch back to USB wired mode.
CONNECTING VIA USB WIRED
1. Connect the keyboard via USB cable to a USB 3.0 Type-A port or better
2. The keyboard will automatically switch to USB wired mode
3. Go to iCUE device settings to select up to 8,000Hz hyper-polling with
CORSAIR AXON*
*Polling rates higher than 1,000Hz are not support by Xbox or PlayStation consoles.
*Bluetooth host device must support standard keyboard HID input.
SHORTCUT FUNCTION STATUS INDICATION INDICATOR
FN + (Press) Switch to Bluetooth host 1 mode
Connected Solid Blue (3 sec)
Disconnected Pulsing Blue
FN + (Hold) Start Bluetooth host 1 pairing* Pairing Blinking Blue
FN + (Press) Switch to Bluetooth host 2 mode
Connected Solid Cyan (3 sec)
Disconnected Pulsing Cyan
FN + (Hold) Start Bluetooth host 2 pairing* Pairing Blinking Cyan
FN + (Press) Switch to Bluetooth host 3 mode
Connected Solid Magenta (3 sec)
Disconnected Pulsing Magenta
FN + (Hold) Start Bluetooth host 3 pairing* Pairing Blinking Magenta

ENGLISH
4
NOTE: Available functions may be limited depending on gaming console support and application.
The keyboard also has a special mode to support Sony PlayStation 4 and 5 via SLIPSTREAM wireless and USB
wired modes that can be activated via shortcut.
Download iCUE from corsair.com/downloads and install on a Windows PC or Apple Mac
to connect all of your CORSAIR iCUE compatible products together in a single interface,
giving you complete control of everything from lighting to powerful macros.
When iCUE is running the keyboard operates in software mode and is controlled by iCUE.
CONNECTING TO SONY PLAYSTATION
SOFTWARE MODE
When iCUE is not running or the keyboard is connected to a device that does not support iCUE, the keyboard
operates in hardware mode which uses profiles and settings saved to the onboard storage.
With iCUE and AXON Hyper-Processing Technology, you can create as many
custom profiles as can fit onto the 8MB of onboard storage. Each profile can store
complex backlighting effects (up to 20 layers), actions & macros, and settings.*
HARDWARE MODE
*The number of lighting effects layers per profile and total number of profiles that can be saved to onboard storage
will vary based on complexity.
SHORTCUT FUNCTION INDICATION INDICATOR
FN + (Hold for 5 sec) Switch to PlayStation mode Blinks White (5 sec) then Solid White
FN + (Hold for 5 sec) Switch back to standard mode Pulses White (6 sec) (On-key)

ENGLISH
5
SHORTCUT LIGHTING EFFECT
FN + ` Reset to onboard stored effect
FN + - Reduce effect speed*
FN + = Increase effect speed*
FN + [ Rotate effect left*
FN + ] Rotate effect right*
The keyboard features many onboard functions to change profiles, adjust backlighting, lock the windows key, and
control media playback, and adjust volume with convenient hotkeys.
Keyboard lighting effects can be controlled via the onboard shortcuts below when iCUE is not running or the
keyboard is connected to a device that does not support iCUE.
ONBOARD FUNCTIONS
ONBOARD LIGHTING
*Temporarily disables automatic backlighting adjustment.
*Functions supported on select effects.
With iCUE you can program Win Lock to not only disable the Windows key, but
other key combinations that could interrupt your game, as well as create new
profiles and assign unique colors.
The keyboard features adaptive brightness where backlighting intensity will automatically
change based on ambient light sensing to ensure great visibility in all environments and
maximize battery life. This can be disabled by manually adjusting brightness or via iCUE.
SHORTCUT LIGHTING EFFECT
FN + 1 Spiral Rainbow
FN + 2 Rain
FN + 3 Rainbow Wave
FN + 4 Visor
FN + 5 Type Lighting (Per-key)
FN + 6 Type Lighting (Ripple)
FN + 7 Color Shift
FN + 8 Color Pulse
FN + 9 Color Wave
FN + 0 Static Color (Press to cycle colors)
HOTKEY FUNCTION
Cycle through available profiles
Manually adjust backlighting brightness in 20% decrements*
(Hold for 2 sec) Re-enable adaptive brightness
Disables key (Win Lock)
(Hold for 2 sec) See Macro Recoding section

ENGLISH
6
MACRO RECORDING
Macros can be recorded at any time via the below process. In hardware mode your macros are recorded to onboard
storage and in software mode your macros are recorded to the current iCUE profile.
NOTE: Saving a macro to a key or existing shortcut will overwrite that function until cleared.
*Hotkeys and wireless/console onboard functions cannot be recorded over with onboard macro recording.
With iCUE you can edit recorded macros and assign additional actions to keys.
Macro
Recording Process
Hold
(2 seconds)
>
Press keys to record
>
Press
>
Press any key or FN +
key combination to save
Recording
Indication Pulses
White > Blinks White > Rapidly Blinks White Hold to cancel
(2 seconds)
Macro Clearing
Process
Hold
(2 seconds)
>
Press
>
Press any key or
FN + key combination
to clear
Recording
Indication Pulses
White >Rapidly Blinks White Hold to cancel
(2 seconds)
Keys that can be recorded:
• Standard keys
Macros can be recorded to:
• Any standard key
• G-keys
• FN + key*

7
ENGLISH
1
2
3
1
1
22
6
5
4
4
BATTERY REMOVAL INFORMATION
This product uses a rechargeable battery and safety guidelines must be followed in the event that the product is
disabled for disposal and recycling. To safely remove the battery for disposal and recycling, follow the numbered
steps with the below diagrams.
CORSAIR MEMORY, Inc. encourages customers to recycle used electronic hardware and rechargeable batteries in
accordance with local laws and regulations.
FCC ID: 2AAFMRGP0120 (Keyboard)
FCC ID: 2AAFMRGP0119 (Wireless Adapter)
IC: 10954A-RGP0120 (Keyboard)
IC: 10954A-RGP0119 (Wireless Adapter)

1
FRANÇAIS (EURO)
FRANÇAIS (EURO)
A D HE IB C
P Q R
L M N
S
OF JG K
Windows®PC Apple Mac®Microsoft Xbox One*
Microsoft Xbox Series X|S*
PlayStation 4**
PlayStation 5**
Maintenez la touche Echap enfoncée pendant deux secondes tout en activant le switch marche/arrêt (R). Le clavier
s’allume ensuite normalement et ses paramètres par défaut sont réinitialisés.
RÉINITIALISATION DES PARAMÈTRES PAR DÉFAUT
*Le clavier est compatible immédiatement, voir corsair.com/xbox-support pour plus de détails.
**Voir la section Connexion à la PlayStation de Sony.
Chargez entièrement le clavier avant la première utilisation en connectant le câble USB (S) au port USB Type-C (Q)
du clavier et à un port USB 3.0 disponible ou mieux, à un port Type-A sur un appareil compatible, par exemple:
AVANT LA PREMIÈRE UTILISATION
ATOUCHE DE PROFIL
BTOUCHE DE LUMINOSITÉ
CTOUCHE DE VERROUILLAGE WINDOWS
DVOYANT SANS FIL
EVOYANT DE CHIFFREMENT
FVOYANT DE BATTERIE
GVOYANT DE MACRO
HVOYANT VERROUILLAGE NUMÉRIQUE
I VOYANT VERROUILLAGE DES MAJUSCULES
JVOYANT VERROUILLAGE DU DÉFILEMENT
KVOYANT VERROUILLAGE WINDOWS
LTOUCHES DE COMMANDE MULTIMÉDIA
MTOUCHE SILENCE
NMOLETTE DE CONTRÔLE DU VOLUME
OTOUCHES G DE MACRO / TOUCHES FN
SANS FIL
PADAPTATEUR SLIPSTREAM WIRELESS
QPORT USB TYPE-C
RBOUTON MARCHE/ARRÊT
SCÂBLE USB TYPE-C VERS TYPE-A
PRÉSENTATION DU CLAVIER

2
FRANÇAIS (EURO)
RACCOURCI STATUT INDICATION VOYANT
FN +
Charge Complète Vert Fixe
Charge Élevée Vert Clignotant
Charge Moyenne Ambre Clignotant
Charge Faible Rouge Clignotant
Charge Très Faible Rouge Pulsant
RACCOURCI FONCTION STATUT INDICATION VOYANT
(Appuyer)
Passer en mode
SLIPSTREAM wireless
Connecté Blanc Fixe (3s)
Déconnecté Blanc Pulsant
STATUT INDICATION VOYANT
Charge Complète Vert Fixe
En Charge Vert Clignotant
REMARQUE: Pour réaliser l’appariement à un adaptateur SLIPSTREAM WIRELESS, lancez l’appariement de
l’adaptateur dans les paramètres du périphérique iCUE.
1. Connectez l’adaptateur SLIPSTREAM WIRELESS (P) à un port USB 2.0 ou mieux,
Type-A
2. Activez le switch marche/arrêt (R) du clavier
3. Passez en mode SLIPSTREAM WIRELESS (voir ci-dessous)
4. Une fois que SLIPSTREAM se connecte automatiquement, le voyant sans fil (D) et
le voyant de chiffrement (E) restent allumés en blanc pendant 3secondes
CONNEXION VIA SLIPSTREAM WIRELESS
CONSEILS ET ASTUCES:
• Si le clavier reste allumé et inactif, il se met en veille pour préserver la batterie (réglable dans iCUE)
• Réduisez la luminosité ou désactivez le rétroéclairage pour accroître l’autonomie de la batterie (et augmenter la
vitesse de charge)
• Chargez l’appareil dès que possible lorsque le niveau de charge est très faible pour maximiser la durée de vie de
la batterie
• Branchez-le toujours à un port USB 3.0 ou mieux pour garantir un courant de charge adéquat
En allumant le clavier ou en utilisant le raccourci de vérification d’autonomie de la batterie fourni ci-dessous, le
voyant de batterie (F) indiquera l’état de charge.
Le voyant de batterie (F) indique l’état de charge lorsqu’il est connecté à un appareil compatible via un câble USB.
CHARGEMENT ET AUTONOMIE DE LA BATTERIE
FN +
