Cosori C3120-PC User manual

Model No.: C3120-PC
Electric Pressure Cooker
COSORI SUPPORT:
Mon - Fri 9:00 AM - 5:00 PM PST
[phone] | [e-mail]
Adjust
Slow
Cook
Yogurt
Start
Cancel
Delay
Time
Sauté
Steam
Keep
Warm
Warm

Thank you for purchasing the C3120-PC Personal Electric Pressure
Cooker by Cosori. We are dedicated to providing our customers
with high quality products to live life tastefully. Should you have any
questions or concerns about using your new product, feel free to
reach out to our helpful Customer Support Team at
[email protected]. We hope you enjoy your new product!
THANK YOU.

3
Table of Contents
Safety Information
Product Diagram
Control Panel
Button Functions
Before First Use
Setup
Water Test
Safely Releasing Pressure
Operation
Preparing to Cook
Preset Cooking Programs
Cooking Times
Manual Cooking Programs
Care & Maintenance
Basic Recipe Guide
Troubleshooting
Warranty Information
Customer Support
4
6
7
8
9
9
9
10
11
11
13
13
14
16
18
20
21
23
Package Contents
1 x Pressure Cooker
1 x Rice Spoon
1 x Ladle
1 x Measuring Cup
1 x Steaming Tray
1 x Tempered Glass Lid
1 x User Manual
1 x Extra Sealing Ring
Specifications
Power Supply: 120V / 60Hz
Rated Power: 800W
Capacity: 2.1 Qt (2 L)
Inner Pot Dimensions: 6.25 x 4 in. (15.8 x 10.1 cm)
Working Pressure: 10 PSI (70 kPa)
Keep Warm Temp.: 140-176°F (60-80°C)

4
IMPORTANT SAFEGUARDS
Please read, understand, and comply with all the instructions provided in this manual
before using the device. Failure to comply with the instructions given in this manual
and/or using the device in ways other than the ones mentioned in this manual may
result in serious injury and/or damage to the product.
Safety Use & Care
• DO NOT touch hot surfaces. Use handle and pot holders when necessary.
• To protect against electrical shock, do not immerse cord, plugs, or the unit in water
or other liquid.
• Close supervision is necessary when any unit is used by or near children.
• Unplug from outlet when not in use and before cleaning. Allow it to cool before
putting on or taking o parts.
• DO NOT operate the pressure cooker with a damaged cord or plug, after the unit
malfunctions or if it has been damaged in any manner. If the unit is malfunctioning,
please contact customer support.
• Using other accessories that are not compatible with the pressure cooker is not
recommended. Doing so may damage the unit or cause injury.
• The pressure cooker is intended for indoor use only.
• DO NOT place on or near a hot gas or electric burner and/or in a heated oven.
• Extreme caution must be used when moving the pressure cooker with hot oil or
other hot liquids inside.
• To disconnect the unit from a power source, press ‘Start/Cancel’, then remove the
plug from the outlet.
• Always check the pressure release valve and oat valve for any clogging before use.
• DO NOT place any object above the pressure release valve while the steam is being
released from the pressure cooker.
• DO NOT use the unit for anything other than its intended use.
• If you cook meat with a casing, such as sausage, swelling can occur when cooked
under pressure. Piercing the skin after cooking can lead to bursts of hot liquid.
• DO NOT lean over the pressure cooker at any time while it is cooking.
• This pressure cooker should not be used for any medical purposes. It is not
designed to reach the required temperature for sterilization.
• The silicone gasket creates a pressure seal between the lid and the pot. Keep the
gasket completely clean and free from any cracks or deterioration.
• DO NOT break the silicone gasket. Do not replace it with other rubber gaskets, or
use a tension belt to make it seal.
• It is extremely important to ll the pressure cooker with liquid prior to operation.
Never cook without liquid; doing so can cause the unit to overheat and damage the
safety mechanisms. In case of overheating, never remove the pressure cooker from
the heat source. Instead, shut it o immediately and let it cool.
• Make sure all parts of the pressure release valve and oat valve are clean and
properly assembled.
• DO NOT alter the safety mechanisms or attempt to repair the pressure cooker as
this will void the warranty. Please refer to the Care & Maintenance section on page
16 on how to maintain the pressure cooker.
• DO NOT place the unit close to ammable materials, heating units, or wet
environments.
Safety Information

5
• Check and wash the anti-clog lter and pressure release valve regularly to avoid
blockage.
• DO NOT open the lid when the oat valve is up.
• DO NOT put anything on or use other objects to replace the pressure release valve.
• Never use a towel to clog the gap between the lid and edge of the Housing.
• The bottom of the inner pot and heating plate should be kept clean. Do not put the
inner pot on other heat sources. Do not replace the inner pot with other containers.
• Only use wood or plastic ladles or spoons to prevent the stainless steel pot from
wearing out.
• DO NOT attempt to move the pressure cooker while it is cooking; wait until it cools
down to move it. Move the unit using the built-in handle; do not try to hold it from
the lid handle.
• DO NOT disassemble the unit on your own or try to replace with parts from
dierent brands.
• Make sure air/pressure discharges completely before opening the lid.
• Clean and properly place water the collection cup and lid before each use.
• You may experience some smoke coming out the unit during the rst few uses due
to the initial heating of the materials; this is normal.
• DO NOT let power cord hang over the edges of tables or counters, or touch hot
surfaces.
• A short power supply cord is provided to reduce injuries resulting from
entanglement and tripping. If an extension cord is used, the electrical rating of the
cord must be at least 120V/20A. The extension cord must be arranged so that it will
not hang over the edge of a table or counter where it can be pulled or accidentally
tripped over.
SAVE THESE INSTRUCTIONS.
HOUSEHOLD USE ONLY
DO NOT
use any other lid.
DO NOT touch the
lid or stainless steel
surface while heating
or cooking.
When moving,
hold the pressure
cooker by its
handles.
Keep out of reach
of infants and
young children.

6
1. Control panel
2. Float valve
3. Float valve sealing ring
4. Pressure release valve
5. Pressure release button
6. Valve reset button
7. Lid handle
8. Handles
9. Housing
10. Inner pot
11. Sealing ring
12. Anti-clog lter
13. Measuring cup
14. Water collection cup
15. Ladle
16. Rice spoon
17. Tempered glass lid
18. Steaming tray
15
16
18
17
13
CUPm l
40
80
120
160
3
4
1
2
1
4
2
Product Diagram
14
1
12
10
8
9
5
4
6
7
11
3

7
1. Digital display
2. Adjust indicator
3. Pressure indicator
4. Warm indicator
5. Cooking programs
6. Adjust button
7. Slow Cook button
8. Yogurt button
9. Start/Cancel button
10. Menu button
11. Decrease value
12. Increase value
3 4
2
1
13. Delay Time button
14. Sauté button
15. Steam button
16. Warm button
Pressure
Adjust
Slow
Cook
Delay
Time
Start
Cancel
Yogurt
Warm
Sauté
Steam
Keep
Warm
Meat/Stew Porridge
Rice Multigrain
Bake Poultry
Beans Soup
Control Panel
6
7
8
9
16
15
14
13
5
1011 12

8
Starts or cancels any cooking process; also cancels any
selections that are made.
The warming function keeps food warm for up to 24 hours
when the unit is nished cooking. Press the ‘Keep Warm’
button, then the ‘Start/Cancel’ button to turn on the Warm
Mode. The display will show “bb,” indicating that the unit is in
the warming mode.
NOTE:
• DO NOT cook foods using the warming mode.
• The pressure cooker will automatically switch to this mode
when your food has nished cooking.
Press the ‘Delay Time’ button to adjust the start time of your
cooking. Use the ‘+’ and ‘-’ buttons to set your desired time,
then use the ‘Menu’ button to select your cooking function.
Press ‘Start/Cancel’ when you are ready to start. The unit
will beep when it starts cooking. You can preset the pressure
cooker for up to 24 hours.
This function allows you to select a pre-programmed cooking
time for most cooking programs on the pressure cooker.
1. Select a cooking program. The Adjust indicator will
default to Normal time. (E.g., Select the Rice program and
the display will show “00:10”.)
2. Press the ‘Adjust’ button to select Less, Normal, or
More. The appropriate light for each setting will light
up, indicating that the cooking time has been changed
accordingly. (E.g., For the Rice program Less is 7 minutes,
Normal is 10 minutes, and More is 13 minutes.)
3. Close the lid and press the ‘Start/Cancel’ button.
4. See page 13 for cooking times for the pressure cooker’s
dierent cooking programs.
NOTE:
• The adjust function will automatically turn o when you
manually select a cooking time.
• The adjust function does not work with the Sauté and
Yogurt functions.
Press the ‘Menu’ button to cycle through the pressure
cooker’s dierent presets. Once you have selected your
preset, use the ‘+’ or ‘-’ buttons or the ‘Adjust’ button to add
or subtract the total cooking time. Press the ‘Start/Cancel’
button to start cooking.
Start
Cancel
Keep
Warm
Delay
Time
Adjust
Menu
Button Functions

9
3. Check that the silicone sealing ring is snugly t on the inside of the lid.
4. Remove any accessories or plastic packaging inside the the pressure cooker.
5. Wash the inner pot and all accessories with warm soapy water and dry all parts
thoroughly with a clean dry cloth.
Water Test
The water test will help you get acquainted with how to operate the pressure cooker
and checks if the pressure cooker is properly operating.
1. If the lid is not already opened, grip the lid handle and twist it counterclockwise so
that lines up with the white mark at the top of the control panel. Pull up on
the handle to open the pressure cooker.
2. Place the cleaned inner pot back into the pressure cooker. Pour 2 cups of water
into the inner pot.
Before First Use
Setup
1. Remove all plastic packaging from the outside of the pressure cooker.
2. Grip the lid handle and twist it counterclockwise so that lines up with the
white mark at the top of the control panel. Pull up on the handle to open the
pressure cooker.
OPEN
Pressure Release Buttons
Press the release button to release any residual pressure remaining
in the pressure cooker after cooking has nished.
Press the pressure valve reset button to reset the pressure release
valve when all of the residual pressure in the cooker has been
released.

10
Before First Use (cont.)
Safely Releasing Pressure
CAUTION:
• DO NOT lean over the pressure cooker or place exposed skin over the pressure
release valve when releasing the pressure inside the pot.
• DO NOT open the lid until the pressure inside the pot has been completely
released. For your safety, the lid will remain locked until the oat valve drops
down.
• DO NOT, under any circumstance, force the oat valve down while it is still up.
There are 2 ways to release the pressure inside the pot after cooking has nished.
Natural Release:
1. Allow the pressure cooker to rest for about 10–15 minutes.
2. After that time, press the pressure release button to release any remaining
pressure.
3. Open the lid once the oat valve has gone down. Remember to press the valve
reset button after releasing all of the pressure inside the pot.
Quick Release:
1. Press the pressure release button immediately after cooking has nished.
2. Allow the pressure to release until the oat valve goes down.
3. Open the lid once the oat valve has gone down. Remember to press the valve
reset button after releasing all of the pressure inside the pot.
NOTE:
The quick release method is not suitable for foods that have a large liquid volume
or a high starch content (e.g., soups, porridge, fruit jams). It is recommended to use
the natural release method when cooking liquids such foods. Immediately releasing
pressure may result in food spraying out through pressure release valve.
3. To close the lid, place it back down onto the pressure cooker housing. Grip the lid
handle and twist it clockwise so that lines up with the white mark at the top
of the control panel.
4. Plug in the pressure cooker and press ‘Steam.’
5. Press ‘Start/On’ to start cooking. The display will show “00:05” to indicate that
the pressure cooker is heating up. Trace amounts of steam will release from
either valve until the oat valve pops up during this initial heating process. Once
the unit reaches optimal cooking pressure, the unit will beep once and the display
will show “P0:05.”
6. When the cooking program has nished, the pressure cooker will beep 5 times.
Press ‘Stop/Cancel’ to set the pressure cooker to standby mode.

11
Preparing to Cook
NOTE:
• Thoroughly wash the inner pot before each use.
• The minimum amount of ingredients needed to cook in the pressure cooker is ⅕ of
the capacity of the inner pot, which is roughly 1 cup.
1. Open the lid and remove the inner pot from the pressure cooker.
2. Prepare food according to recipe directions and place food and liquids into the
pot. Food and water should not exceed ⅘ height of the pot. If the food easily
expands in water, do not let it exceed ⅗ height of the inner pot.
3. Before placing pot back into the pressure cooker, be sure to wipe down the
bottom of the pot and the surface of the heating plate with a dry cloth. Make sure
the unit is o when placing the pot back into the pressure cooker housing.
4. Place the pot back into the pressure cooker and close the lid. Turn the lid handle
counterclockwise so that is lined up with the white mark at the top of the
control panel.
Operation

12
5. Once the lid is locked in, make sure the pressure release valve is level.
6. Attach the water collection cup onto the back of the pressure cooker by aligning
the top of the cup with the guides on the pressure cooker. Secure the cup by
gently pressing until it snaps into place.
7. Plug the pressure cooker into an electric power supply. The LCD will show “--:--”
and the unit will go into standby mode.
Porridge
Soup
Operation (cont.)

13
Preset Cooking Programs
1. If the unit is not already plugged in, connect it to a power source. The unit will
beep, indicating it is in standby mode.
2. Press the ‘Menu’ button to select a preset cooking program on the pressure
cooker. Keep pressing ‘Menu’ to cycle through the dierent cooking programs.
You can also press ‘Steam,’ ‘Yogurt,’ ‘Sauté,’ and ‘Slow Cook’ to select their
respective cooking functions.
3. (OPTIONAL): Before pressing the ‘Start/Cancel’ button, you can customize your
cooking time by using the ‘Delay Time’ button to change the cooking start time
and use the ‘Adjust’ or ‘+’ or ‘-’ buttons to extend or shorten your cooking time.
4. Press the ‘Start/Cancel’ button to start cooking. The unit will beep when it
reaches the optimal cooking pressure and the display will read “P0” along with the
programmed cooking time.
5. When cooking has nished, the pressure cooker will beep 5 times and will
automatically go into the Warm Mode.
6. It is recommended to wait at least 10-15 minutes before opening the pressure
cooker. Refer to the Safely Releasing Pressure section on page 10.
Program/
Function
Default time
(minutes)
Min. Time Max. Time
Meat/Stew 40 1 1:40
Rice 10 1 1:40
Bake 40 1 1:40
Beans 20 1 1:40
Porridge 20 1 1:40
Multigrain 40 1 1:40
Poultry 20 1 1:40
Soup 25 1 1:40
Steam 5 1 1:40
Yogurt 8 hours 6 hours 12 hours
Sauté 5 1 20
Slow Cook 4 hours 2 hours 12 hours
Delay Time 0 0 24 hours
NOTE: Some steam may come out of the pressure release valve, along with
occasional sputtering; this is normal.
Steam Sauté
Yogurt Slow
Cook
Porridge
Soup
Cooking Times

14
Manual Cooking Programs
The following cooking programs have no pressure applied when selected.
Slow Cook: This program allows you to use your pressure cooker like a traditional slow
cooker.
1. Open the pressure cooker and detach the lid. Only use the glass lid for this
feature.
2. Connect the pressure cooker to a power source.
3. Place your ingredients in the inner pot and place the glass lid on top.
4. Press the ‘Slow Cook’ button.
5. Press the ‘Adjust’ to select a preset cooking time and temperature (see table
below).
NOTE: After pressing ‘Slow Cook,’ you can also press the ‘+’ or ‘-’ buttons to
manually adjust the cooking time anywhere from 2 to 12 hours. Please note that the
temperature cannot be adjusted when manually setting the cooking time.
6. Press ‘Start/Cancel’ to start cooking. The pressure cooker will beep 5 times the
programmed cooking time has nished counting down and will automatically
switch to the Warm Mode.
Sauté: This function allows you to sauté or simmer ingredients inside the inner pot.
1. Open the pressure cooker and detach the lid. Only use the glass lid for this
feature.
2. Connect the pressure cooker to a power source.
3. Press the ‘Sauté’ button and adjust the cooking time anywhere from 1 to 20
minutes using the ‘+’ or ‘-’ buttons.
4. Press the ‘Start/Cancel’ button and place the ingredients you wish to sauté into
the inner pot.
5. The pressure cooker will beep 5 times when the programmed cooking time has
nished counting down. Carefully remove your ingredients from the inner pot, or
add additional ingredients if you are still cooking.
Yogurt: This program allows you to hold milk at a stable temperature to create fresh
yogurt at home.
1. Pasteurizing the Milk
a. Place the inner pot into the housing. Pour the necessary amount of milk
according to your recipe into the inner pot.
b. Press ‘Sauté’ then press ‘+’ to set the cooking time to 10 minutes.
c. Press ‘Start/Cancel.’ Heat the milk until it reaches 180°F (95°C).
d. Once the milk reaches the proper temperature, press ‘Start/Cancel’ to turn o
the Sauté program.
e. Allow the milk to cool below 115°F (46°C).
Less Normal More
Time 8 hours 6 hours 4 hours
Temperature 193°F (89°C) 200°F (93°C) 204°F (95°C)

15
2. Yogurt Incubation
a. Add in yogurt starter or fresh yogurt to your cooled milk.
b. Press the ‘Yogurt’ button and use ‘+’ and ‘-’ to select a cooking time anywhere
from 6 to 12 hours (the default time is 8 hours).
c. Press ‘Start/Cancel’ to start the incubation process.
d. When the Yogurt program is complete, the pressure cooker will beep 5 times
and go into standby mode.
e. Open the lid and serve your yogurt directly from the pressure cooker, or place
your yogurt into containers and chill in the refrigerator.
NOTE: If your yogurt is too thin, run it through a strainer before serving.

16
OPEN
UNHINGE
1. Unplug the power cord and allow pressure cooker to completely cool before
cleaning.
2. Wipe the housing of the pressure cooker with a clean cloth. Do not immerse the
cooker into water or spray with water.
3. Remove water collection cup and pour out any excess water inside. Clean
collection cup with a damp towel and place it back onto the pressure cooker.
4. Detach the lid from the pressure cooker body by lifting up the hinge and then
twisting the lid to . Lift up the lid to remove it from the pressure cooker body.
5. Thoroughly wash and rinse all parts of the lid including the pressure release valve,
anti-clog lter, and oat valve. Wipe dry with a clean cloth.
6. Remove the sealing ring from lid and wash with warm soap and water. Rinse
thoroughly with warm water. See Sealing Ring Installation on how to remove and
install the sealing ring.
7. Clean the inner pot with a sponge or non-metallic soft brush, and dry with a clean
cloth.
8. If necessary, wipe down the control panel with a damp cloth, and dry immediately
with a clean, dry cloth.
Sealing Ring Installation
NOTE: Make sure sealing ring has no cracks or is damaged.
Removal
1. Lift up the hinge, then twist the lid to .
2. Remove the lid from the pressure cooker.
3. While holding the lid in place, gently pull out the sealing ring.
Care & Maintenance

17
Installation
1. Line up sealing ring on top of metal ring.
2. Gently push down on sealing ring, ensuring that the metal ring is inside the sealing
ring’s groove as shown below. Continue pushing the sealing ring all around until it
is secured by the metal ring.
3. Place lid back onto pressure cooker by aligning with white mark at the top of
the control panel.
4. Twist the lid to and lower the hinge.
CLOSE
HINGE

18
Setting Time Quantity of
Ingredients
Quantity of
Liquid
Brown Rice Rice 13-15 minutes 1 c brown rice 1 ½ c water
Jasmine Rice Rice 3 minutes 1 c basmati or
jasmine rice
1 c water
White Rice Rice 4-6 minutes 1 c white rice 1 ½ c water
Steel Cut Oats Multigrain 20-25 minutes ½ c steel cut
oats
2 c water
Quinoa Multigrain 6 minutes 1 c quinoa 2 c water
Setting Time Quantity of
Ingredients
Quantity of
Liquid
Artichoke Steam 9-11 minutes 1 artichoke
cut in half
1 c water
Fingerling/Russet
Potatoes
Steam 19-23 minutes up to 18 oz 1 c water
Baked Potato Steam 25-30 minutes 14 oz (about
1-2 potatoes)
1 c water
Basic Recipe Guide
Rice / Grains
Vegetables / Produce

1919
Setting Time Quantity of
Ingredients
Quantity of
Liquid
Eggs Steam 7 minutes 6 eggs 1 c water
Chicken (bone-
in thigh and
drumstick)
Poultry 13-16 minutes 1 ¾ lbs
chicken
1 ½ c broth
½ c BBQ
sauce
Chili Verde
Chicken Breast
(boneless,
skinless)
Poultry 8 minutes 2 breasts
totaling 1lb
6 oz
16 oz chili
verde salsa
Frozen Chicken
Breast Tenders
Poultry 12 minutes 14 oz chicken
tenders
½ c water
BBQ Chicken
Breast (boneless,
skinless)
Poultry 13-15 minutes 2 breasts
totaling 1 lb
7 oz
1 c chicken
broth,
1 c BBQ
sauce
Beef Stew Meat/
Stew
Sauté meat, oil,
our, salt and
pepper for 10m;
then pressure
cook for 25
minutes
1 lb chuck
roast stew
meat cut into
one-inch
pieces
2 c broth
½ cup red
wine
Chickpeas Beans 10-13 minutes 1 c chickpeas
soaked
overnight (12
hours)
3 c water
Black Beans Beans 5-7 minutes 1 c soaked
black beans
(for 8 hours)
3 c water
Pinto Beans Beans 7-10 minutes 1 c soaked
pinto beans
(for 8 hours)
3 c water
Meats / Proteins

20
Problem Cause Solution
Lid not closing properly. Lid is not properly
positioned on body.
Properly position lid onto
the housing.
Sealing ring is not properly
installed.
Check sealing ring to
make sure it is properly
aligned inside the lid.
Float valve is being
blocked.
Check to make sure oat
valve is clean. Clean if
necessary.
Lid does not open. Float valve doesn’t fall
after pressure is released.
Check to make sure oat
valve is clean. Clean if
necessary.
Steam leaking from
pressure cooker lid.
No sealing ring. Install sealing ring.
Food sticking to sealing
ring.
Clean sealing ring.
Sealing ring is broken. Part needs to be changed.
Contact customer
support.
Lid is not closed in right
position.
Make sure lid is properly
closed.
Steam leaking from oat
valve.
Food sticking to oat
valve’s sealing ring.
Clean the oat valve’s
sealing ring.
Float valve’s sealing ring is
broken.
Contact customer
support.
Float valve not able to rise. Insucient amount of
food and water.
Put as much food and
water as noted on recipe.
Steam leaking from
pressure cooker lid or
pressure valve.
Contact customer
support.
Error Code E1 E2 E3 E4
Error Broken circuit
in sensor.
Short circuit in
sensor.
Unit is
overheating.
Signal switch
broken.
Troubleshooting
