Cosori CMT-R161S User manual

1
User Manual
Smart Meat Thermometer

2
GETTING TO KNOW YOUR
SMART MEAT THERMOMETER
Meat Thermometer Diagram
A
F I
G
J
H
B
C
E
D
PROBE
A. Ambient Temperature Sensor
B. Handle
C. Insertion Line
D. Internal Temperature Sensor
E. Probe
F. Battery Level Indicator / Bluetooth®Indicator
G. Battery Level Button
H. Charging Case
I. Magnets
J. Battery Compartment
MODEL: CMT-R161S
Temperature Range :
Internal Temperature Sensor: 0°–100°C / 32°–212°F
Ambient Temperature Sensor: 32°–572°F / 0°–300°C, ≤ 90% RH
Bluetooth
®
Frequency Range:
2402–2480MHz
Maximum transmit power: < 10dBm (E.I.R.P.)
Water-resistant level of Probe: IP67

3
Battery Level Button
Bluetooth®Indicator
• Flashing Red Indicator: Thermometer lost connection
with the charging case.
• Flashing Green Indicator: Thermometer is connected
to charging case.
Probe FCC ID:2ARBY-CMTP Dock FCC ID:2ARBY-CMTB
• Press while the thermometer is in the charging case to
check the thermometer’s battery level.
• Red Battery Level Indicator: The thermometer is under
charging.
• Green Battery Level Indicator: The thermometer
is fully charged and ready for use.
• Press while the thermometer is not in the charging
case to check the charging case’s battery level.
• Red Battery Level Indicator: The charging
case needs a new battery. (See Replacing the Battery,
page 11).
• Green Battery Level Indicator: The charging case’s
battery is sucient.
Note:
•Do not use the thermometer outside of the
recommended temperature ranges.
•Always insert the thermometer up to the insertion line
to avoid damaging the product or causing injury.

4
GETTING STARTED
1. Remove the insulation strip and charge the
thermometer for 1 hour. [Figure 1.1]
3. Push down on the thermometer and pull to remove
from the charging case to turn on Bluetooth®pairing.
[Figure 1.2]
Note: Review the manual and VeSync app for basic safety
precautions and complete operating instructions.
Note: Place the thermometer back in the charging case to
turn o Bluetooth®pairing.
2. Open the VeSync app. If you already have an account,
tap Log In. To create a new account, tap Sign Up.
Figure 1.2
4. Tap +to add the device. Tap Kitchen, then select
COSORI Smart Meat Thermometer and follow the
in-app instructions to complete setup.
Figure 1.1

5
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
& WARNINGS
Follow basic safety precautions when using your meat thermometer.
Read all instructions.
Key Safety Points
General Safety
• Use caution when removing the thermometer
after cooking. Use heat-resistant gloves or oven
mitts to remove the thermometer or allow food to
cool before removing.
• The thermometer is only intended to measure the
temperature of meat during cooking.
• It is recommended to use USDA-recommended
safe minimum internal temperatures to cook
dierent meats to avoid food poisoning caused by
raw or undercooked meat and seafood.
• Do not hit the probe tip against hard surfaces to
avoid causing damage.
• Do not use in hot oil, microwave ovens, deep
fryers, or pressure cookers.
• Always insert the thermometer up to the insertion
line to avoid damaging the product or causing
injury. [Figure 1.1]
• Do not exceed an internal temperature of 212°F
/ 100°C and an ambient temperature of 572°F /
300°C. If temperatures exceed the allowed range,
or the thermometer directly touches open flame
or hot coal, you must wear eye protection before
removing the thermometer.
Figure 1.1

6
• Do not use in direct contact with charcoal or fire,
and make sure the thermometer is removed before
searing.
• Do not insert the thermometer directly under a
heat source to avoid burns.
• The charging case must be kept away from heat
sources such a grill cover.
• If the thermometer accidentally falls into a
cooking appliance, immediately turn o the
cooking appliance and close the lid/door.
Allow the thermometer to fully cool o before
removing.
• Do not bend the probe. The handle is able to
withstand normal twisting and pulling when
inserting into meat.
• Keep out of reach of children.
• Do not tamper with the thermometer’s internal
components.
• Do not dispose of any part of the thermometer in
a fire.
• Do not use your thermometer if it is damaged, not
working, or if the charging
case is damaged. Contact Customer Support (see
page 13).
• Not for commercial use. Household use only.
• If the equipment is used in a manner not specified
in the user manual, the protection provided by the
equipment may be impaired.
• The thermometer can be used with air fryers,
ovens, smokers, grills, BBQs, stoves, rotisserie
cookers, clay cookers, pizza ovens, and slow
cookers.
• Never use the thermometer with microwave
ovens, pressure cookers, freezers, or use for
boiling liquids, making candy, open flames, or
measuring room and human body temperatures.

7
• Do not use cleaning products that contain alcohol,
ammonia, benzene, or other abrasive chemicals to
clean the thermometer.
• The thermometer is water-resistant but not
waterproof. Store in a dry, cool place.
Do not soak in liquids, sinks, or moisture for
extended periods of time.
• The charging case is neither water-resistant nor
waterproof.
• Do not soak the probe in cold water immediately
after cooking.
• When installing or changing the charging case’s
battery, make sure to place the battery in the
correct polarity.
• Using a battery that is not alkaline may shorten the
operating life of the thermometer.
• Do not replace the battery while hands are wet or
while the thermometer is in a wet environment.
• To remove the batteries from your equipment,
reverse the procedure described in the owner's
manual for inserting batteries. For products with
a built-in battery that lasts for the lifetime of the
product, removal may not be possible for the user.
In this case, recycling or recovery centers handle
the dismantling of the product and the removal
of the battery. If, for any reason, it becomes
necessary to replace such a battery, this procedure
must be performed by authorized service centers.
In the European Union and other locations, it is
illegal to dispose of any battery with household
trash. All batteries must be disposed of in an
environmentally sound manner. Contact your
local waste-management ocials for information
regarding the environmentally sound collection,
recycling and disposal of used batteries.

8
WARNING: Danger of explosion if battery
is incorrectly replaced. To reduce risk of fire,
explosion or leakage of flammable liquid/gas, do
not disassemble, crush, puncture, short external
contacts, expose to temperature above 140°F (60°C),
sunshine, or the like, expose to extremely low air
pressure, or dispose of in fire or water. Replace only
with specified batteries.
SAVE THESE
INSTRUCTIONS
• Do not use to take your own temperature.
Do not poke the tip of the probe to your fingers
or body parts to avoid risk of injury.
• If the equipment is used in a manner not
specified in the user manual, the protection
provided by the equipment may be impaired.
• The thermometer will be hot during and after
use. Always use heat-resistant gloves or oven
mitts to handle the hot thermometer.

9
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any interference
received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FEDERAL COMMUNICATION
COMMISSION INTERFERENCE
STATEMENT - PART 15
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate this equipment.

10
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End
users must follow the specific operating instructions
for satisfying RF exposure compliance. To maintain
compliance with FCC RF exposure compliance
requirements, please follow operation instructions as
documented in this manual. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter. The availability of some specific
channels and/or operational frequency bands are country
dependent and are firmware programmed at the factory
to match the intended destination. The firmware setting is
not accessible by the end user.
FCC RADIATION EXPOSURE
STATEMENT
FCC SUPPLIER’S DECLARATION
OF CONFORMITY (SDOC)
Arovast Corporation hereby declares that this equipment is
in compliance with FCC requirements.
The declaration of conformity may be consulted in the
support section of our website, accessible from www.
cosori.com
