Cossiga Linear Square Canopy User manual

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 1
LS SQAURE GANTRY ASSEMBLED EXPLODED DIAGRAM AND PARTS
front track
front channel
rear bottom
channel
rear top
channel
typical lug
and plastic
washers
Perspex rear
doors
door
handels
front glass
side glass
top glass
corner
holder
side glass
U channel
When using lugs a white washer is to be
placed on each side of the glass.
Lugs should be screwed in finger tight.

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 2
Put the two side glass U channel
pieces on each side line up with
front and side edges. This is also
a guide for front glass track.
Position rear track. Remove
double sided tape and stick
down.
1. 2.
align with side edge

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 3
Position side glass. Use plastic
U shaped holders in the U
channel. Screw in lugs on side
placing a white rubber washer
on each side of glass.
Position top glass. Screw in lugs
on top placing a white rubber
washer on each side of glass.
3. 4.

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 4
Position black corner holders
pieces - connect to top and side
glass. There is a left and a right
holder piece.
Position front track - same as
rear track. Remove double sided
tape and stick down.
5. 6.
Left
Right

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 5
Insert front glass into front channel. There
are some small square clear plastic pieces
that need to go on to the glass before it is
pushed into glass channel.
Now the front glass is complete with channel,
it is lifted and placed into front track. The front
glass should be able to pivot forwards and
back - roughly on 45 degree angle.
Carefully support glass
during installation.
7. 8.

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 6
Front glass needs to be fully upright, then
locking spring lugs inserted to secure. Place
a white washer on the inside of the glass.
Rear top track is fitted to top glass - Place
three locating screws into three holes across
the top glass with nuts underneath. use white
washers each side of glass.
9. 10.

Contact us on COSSIGA.COM
LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS
Page 7
Perspex doors are then placed in
tracks.
11. Note: For LS4 /5 /6 units fit the top glass
support bar in the centre and on top of the
light box.
12.
