Costway HW57075 User manual

USER'S MANUAL
Storage Cabinet
HW57075

PRODUCT ASSEMBLY
1/7
28 pcs
35 pcs
3 pcs
28 pcs
6 pcs
4*30mm
4*40mm
30 pcs
1pc
1pc
13
-
-
Middle Shelf
Bottom Panel
Upper Divide
Panel
Lower Divide
Panel
Front Panel
Bottom
Connect Bar
Middle
Connect Bar
Upper Back
Panel
Lower Back
Panel
Top Connect
Bar
Hardwares List
Parts List

2/7
PRODUCT ASSEMBLY
Part List Assembly Overview
1
2
3
4
5
6
7
8
9
10
11
12
13

PRODUCT ASSEMBLY
3/7
Step 1
Step 2
a) Attach Upper Divide Panel (5) to Middle Shelf (2) by using Wood Dowel (C) and Screw (F) as shown. Do not
Overtighten.
b) Attach Middle Connect Bar (10) to Middle Shelf (2) by using Wood Dowel (C) and Screw (F) as shown. Do not
Overtighten.
.
a) Screw In Cam-bolt (A) into designated holes on Front Panel (8).
b) Insert Wood Dowel (C) into designated holes on Lower Divide Panel (7) as shown.
c) Attach (8) to (7) via Cam-bolts and Wood dowel.
d) Insert Cam-Lock (B) to the designated holes on (7), then turn clockwise to lock onto Cam-bolt. Do not
overtighten.
.
5
2
10
7
8

PRODUCT ASSEMBLY
Step 3
Step 4
4/7
a) Screw in Cam-bolt (A) into designated holes on Middle Shelf (2).
b) Insert Wood Dowel (C) to the designated holes Lower Divide Panel (7).
c) Attach (7) to (2) via Cam-bolts and Wood Dowels.
d) Insert Cam-Lock (B) to the designated holes on (7), then turn clockwise to lock onto Cam-bolt. Do not
overtighten.
a) Insert Wood Dowel (C) to the desiganted holes on Lower Divide Panel (7).
b) Attach Bottom Panel (3) to (7) via Wood Dowels, then screw in the Screw (F) as shown. Do not overtighten.
2
7
3
7

PRODUCT ASSEMBLY
Step 5
Step 6
5/7
a) Screw in Cam-bolt (A) to the designated holes
on Side Panels (4 & 6).
b) Insert Wood Dowel (C) to the designated holes
on (2, 3, 8 & 10) as shown.
c) Attach Side Panels (4 & 6) to (2, 3, 8 & 10) via Cam-bolts and
Wood Dowels.
d) Insert Cam-Lock (B) to the designated holes on (2, 3, 8 & 10),
then turn clockwise to lock onto Cam-bolt. Do not overtighten.
a) Screw in Cam-bolt (A) to the designated holes
on Bottom Connect Bar (9).
b) Insert Wood Dowel (C) to the designated holes
on (3, 4 & 6) as shown.
c) Attach (9) to (3, 4 & 6) via Cam-bolts and Wood
Dowels.
d) Insert Cam-Lock (B) to the designated holes on
(3, 4 & 6), then turn clockwise to lock onto
Cam-bolt. Do not overtighten.
A
B
C
A
B
C
4
6
5
9
3
2
8
10
4
6
3

PRODUCT ASSEMBLY
Step 7
Step 8
6/7
Attach Top Connect Bar (13) to (1) by using Wood
Dowel (C) and Screw (E).
1A
B
C
4
6
5
C
E
13
a) Screw in Cam-bolt (A) to the designated holes
on Top Panel (1).
b) Insert Wood Dowel (C) to the designated holes
on (4, 5 & 6) as shown.
c) Attach (1) to (4, 5 & 6) via Cam-bolts and Wood
Dowels.
d) Insert Cam-Lock (B) to the designated holes on
(4, 5 & 6), then turn clockwise to lock onto
Cam-bolt. Do not overtighten.

PRODUCT ASSEMBLY
Step 9
7/7
11
12
Attach Back Panel (11 & 12) by using Screw (D) as shown.
The assembly of the Storage Cabinet unit is complete.
