CPI BNA6 ADVANCE User manual

V2.0 EN
User Guide
BnA6 Advance™ & BNR Advance™
Note Validator & Note recycler

Intended use and Compliance
BNA6 Advance & BNR Advance Note Validator and Note Recycler
2
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
Intended use and Compliance
Before using the BNA6 Advance & BNR Advance note validator and note recycler for the first time, please carefully read this user guide, and
in particular the safety instructions, at least once. This is to ensure that the contents of this user guide have been understood and the reader
knows how to operate the note validator and note recycler.
Intended use
The BNA6 Advance & BNR Advance note validators and note recyclers are intended to be integrated as a peripheral within a host machine.
Both, note validators and note recyclers are designed to validate, denominate, and store banknotes. Beyond that, the BNRrecycle banknotes
collected in recycling modules as change. Use the BNA6 Advance & BNR Advance note validator and note recycler exclusively for this
purpose. Under no circumstances can the manufacturer be held liable for any damage or loss resulting from improper use of the equipment.
Technical specifications
Voltage operating range
24
V DC -10% +20%
Ripple
300
mVpp max.
UL
current input rating
5
A
Current consumption
Peak at 24
V DC (when using loading module): 8 A–9 A
During extreme conditions
(at 21.6 V DC and 0 °C): up to 10 A
Standby
(at 24 V DC): 0.5 A (12 W)
Inrush current protection
Internally limited to 9 A nominal
during power on
Temperature range
0
°C to 60 °C (32 °F to 140 °F)
Relative humidity
(RH)
85% at +40
°C (104 °F) (non-condensing)
Compliance
BNA6 Advance & BNR Advance note recycler has been evaluated and is compliant with UL/CSA/IEC 62368-1, audio/video, information, and communications technology equipment – Part 1: Safety
requirements and UL-756 standard for safety coin currency changers and actuators.
BNA6 Advance & BNR Advance
note recycler is designed and complies with the following European directives:
2014/30/EU
electromagnetic compatibility directive
2014/35/
EU low voltage directive directive
2011/65/EU
amended 2015/863/EU restriction of hazardous substances directive
The BNR & BNA6 meet
Class B radiated emissions limits in accordance with EN55032:2015
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.

BNA6 Advance & BNR Advance Note Validator and Note Recycler
Table of Contents
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
3
Table of Contents
1About this user guide ............................................................................................... 5
1.1 Text conventions..............................................................................................................................5
1.2 Additional helpful documents ...........................................................................................................5
2About note validator and note recycler ...................................................................... 6
2.1 Models ............................................................................................................................................ 6
2.1.1 BNA6 note validator models ....................................................................................................................... 6
2.1.2 BNR note recycler models.......................................................................................................................... 7
2.1.3 Bezel versions............................................................................................................................................ 8
2.1.4 Cash box versions...................................................................................................................................... 8
2.2 Features ..........................................................................................................................................8
2.3 Principal modules ............................................................................................................................8
2.3.1 Acceptance module ................................................................................................................................... 9
2.3.2 Recycling module(s) (note recycler only) ................................................................................................... 9
2.3.3 Loading module (note recycler only) ........................................................................................................ 10
2.3.4 Cash box.................................................................................................................................................. 10
2.4 Main components .......................................................................................................................... 11
2.4.1 Key locks ................................................................................................................................................. 13
2.4.2 Status LEDs ............................................................................................................................................. 13
3Install..................................................................................................................... 15
3.1 Unpacking the note validator or note Recycler.................................................................................15
3.2 Parts included................................................................................................................................15
3.3 Assembling the note validator/recycler ...........................................................................................16
4Operate .................................................................................................................. 18
4.1 Getting BNA6 Advance & BNR Advance note validator and recycler ready for initial operation ..........18
4.2 Note validator/recycler behavior during power-up and reset ............................................................19
4.3 Operating BNA6 Advance & BNR Advance note validator and note recycler .....................................20
4.3.1 Unlocking and relocking interlock system................................................................................................. 20
4.3.2 Opening and closing chassis flaps............................................................................................................ 20
4.3.2.1 Opening and closing top (acceptance module) flaps ...................................................................................................................... 21
4.3.2.2 Opening and closing lower rear (spine) flap................................................................................................................................... 22
4.3.3 Removing and reinstalling cash box.......................................................................................................... 23
4.3.4 Removing, opening, and reinstalling optional loading module (note recycler only) .................................... 24
4.3.5 Removing and reinstalling recycling module(s) (note recycler only).......................................................... 27
4.3.6 Removing and reinstalling acceptance module ......................................................................................... 29
4.4 Handling cash................................................................................................................................31
4.4.1 Emptying BNA6 Advance & BNR Advance note validator and note recycler cash box.................................. 31
4.4.2 Refilling loading module of BNR Advance note recycler ............................................................................ 34

Table of Contents
BNA6 Advance & BNR Advance Note Validator and Note Recycler
4
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
4.4.2.1 Quality requirements for banknotes ................................................................................................................................................ 35
4.5 Controlling BNA6 Advance & BNR Advance note validator and note recycler....................................35
4.5.1 Enabling/disabling banknote denominations ............................................................................................. 35
4.5.2 Returning new banknote denomination as change (note recycler only) ...................................................... 35
4.5.2.1 Readjusting loading module to new banknote size (note recycler only)........................................................................................... 36
5Troubleshoot.......................................................................................................... 37
5.1 Locating and fixing errors using status LEDs ..................................................................................37
5.2 Clearing banknote jam....................................................................................................................39
5.2.1 Clearing banknote jam in acceptance module’s feeder .............................................................................. 40
5.2.2 Clearing banknote jam in spine................................................................................................................. 41
5.2.3 Clearing banknote jam in passage from acceptance module to cash box ................................................... 42
5.2.4 Clearing banknote jam in note recycler loading modul .............................................................................. 42
6List of figures ......................................................................................................... 43

BNA6 Advance & BNR Advance Note Validator and Note Recycler
About this user guide
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
5
1About this user guide
This chapter is designed to help
the reader navigate easily within this user guide.
This user guide is meant for operators and describes the design and function of the BNA6 Advance & BNR Advance note validator and note
recycler. Afterwards, chapters 3 and 4 explain the necessary steps for unpacking, assembling, and operating the note validator/recycler.
Chapter 5 "Troubleshoot" and the appended list of figures reduce the search for specific explanations.
For more general information about this product and support, please visit our website: CranePI.com/support.
1.1 Text conventions
The following symbols are used throughout this user guide to call attention to safety messages and important information related to the note
validator/recycler.
Caution indicates a hazardous situation which, if not avoided, could resu
lt in minor or moderate injury.
Notice is used to address practices not related to physical injury
, such as property damage.
Special notes
are intended to facilitate the use of the product.
Short guide
s summarize a chapter and provide links to subsections.
References to a figure: A
number is the number of an item in a figure, a letter refers to a relevant work step in
a figure
.
In general, the
note validator and recycler images are realistic in color. However, the unit components to be
operated or moved
during instructions are highlighted in light blue just like their item numbers (see above).
Arrows showing a work step
are dark blue and so are the work steps letters (see above).
1.2 Additional helpful documents
Further documentation is available for the BNA6 Advance & BNR Advance note validator and note recycler, e.g. for service or retrofit work. All
documentation can be downloaded from the Crane Payment Innovations support web site as pdf file.

About note validator and note recycler
BNA6 Advance & BNR Advance Note Validator and Note Recycler
6
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
2About note validator and note recycler
This chapter describes
the BNA6 Advance & BNR Advance note validator’s and recycler’s:
•
models
•
main features
•
princicpal modules and components the note validator/recycler consists of
•
functional elements required for the operation of the note validator/recycler
The BNA6 Advance & BNR Advance note validator and recycler is designed to validate different banknotes of one currency inserted into the
device for specific properties. Only valid banknotes are accepted and transported to the cash box for storage purposes. Suspicious or
damaged banknotes will be rejected.
The note recycler is a note validator with one or two recycling modules and an optional loading module. Depending on its configuration, the
note recycler transports the banknotes accepted and to be returned to your next customers as change to one of the recycling modules. All
other banknotes accepted are directed to the cash box for storage purposes. The loading module is used to refill the recycling module(s) and
enlarge change capacity.
2.1 Models
The
note validator and note recycler is a modular payment system.
All models are equipped with
an acceptance module at the top and a
cash box
. The bezel attached to the acceptance module and the
cash
box
are available in different versions (see sub-chapters below).
In addition to t
he acceptance module and cash box, note recyclers
provide one or two
recycling modules depending on the recycling
capacity needed, which can even be expanded with a
loading
module
.
The
figures in this user guide exemplify a BNR4-
21 model
with two recycli
ng and a loading module (see Fig. 2).
Fig. 1: BNR6 Advance note validator Fig. 2: BNR Advance note recycler
2.1.1 BNA6 note validator models
The note validator models differ in the
capacity size of the cash box:
BNA6 Advance M note validator
(up to 1400 banknotes)
BNA6 Advance L note validator
(up to 2200 banknotes)
Fig. 3: BNA6 Advance M note validator Fig. 4: BNA6 Advance L note validator

BNA6 Advance & BNR Advance Note Validator and Note Recycler
About note validator and note recycler
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
7
2.1.2 BNR note recycler models
The note recycler models differ in the chassis size, recycling and cash box capacity, with the first digit of the model name defining the
number of optional recycling, loading modules, and cash box and the two digits following the hyphen specifying how many recycling and
loading modules are included. The last ‘M’ or ‘L’ letter reveals the cash box size. If no letter is appended, the note recycler provides a
standard S cash box (see chapter 2.1.4 “Cash box ”, p. 8).
BNR4.. chassis can include up to 4 modules (recycling/loading
module, cash box, cash box is always included), e.g.:
•..-21 providing 2 recycling and 1 loading module (see Fig. 5)
•..-10 providing 1 recycling and no loading module (see Fig. 6 ())
Fig. 5: BNR4-21 Advance note recycler Fig. 6: BNA4-10 Advance note recycler
BNR3.. chassis can include up to 3 modules (recycling/loading
module, cash box, cash box is always included), e.g.:
•..-11 providing 1 recycling and 1 loading module (see Fig. 7)
•..-10 providing 1 recycling and no loading module (see Fig. 8 )
Fig. 7: BNR3-11 Advance note recycler Fig. 8: BNR3-10 Advance note recycler
BNR2.. chassis can include up to 2 modules (recycling module,
cash box, cash box is always included):
•..-10 providing 1 recycling and no loading module (see Fig. 9)
•..-00 providing no recycling or loading module (see Fig. 10)
Fig. 9: BNR2-10 Advance note recycler
Fig. 10: BNR2-00 Advance note recycler

About note validator and note recycler
BNA6 Advance & BNR Advance Note Validator and Note Recycler
8
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
2.1.3 Bezel versions
Standard bezel in black or gray
Flush bezel
Fig. 11: Standard bezel Fig. 12: Flush bezel
2.1.4 Cash box versions
The
cash box is available in three different capacity
sizes:
S (up to 600 banknotes) (for note recycler only)
M (up to 1400 banknotes)
L (up to 2200 banknotes)
Fig. 13: S cash box Fig. 14: M cash box Fig. 15: L cash box
2.2 Features
Processing international multi-width “street” banknotes
Validating and accepting or rejecting banknotes of different currencies
Temporarily storing banknotes of current transaction for rapid change giving (escrow capacity of up to 15 banknotes)
Storing banknotes permanently in a cash box
Providing change to the consumer from note recycling module(s) (note recyclers only)
Powered by an 24 V DC power supply to be provided by the customer
Communicating with the host machine through a USB connection
2.3 Principal modules
The note validator consists of an:
Acceptance module
Cash box
Acceptance module
CashBox
Fig. 16: Note validator modules

BNA6 Advance & BNR Advance Note Validator and Note Recycler
About note validator and note recycler
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
9
The note recycler consists of an:
Acceptance module
Cash box
One or two recycling modules
Optional loading module
2.3.1 Acceptance module
If the two insertion LEDs are green [1], the note validator/recycler is ready to
process banknotes inserted into the insertion slot [2]. In the acceptance
module [3], the banknotes pass sensors checking their material, properties and
dimensions. When the banknote properties do not correspond to the property
values programmed in this recycler, the banknote is returned through this same
slot [2] by default while the two top status LEDs are flashing green [1]. When the
banknote properties accord with the values programmed, the banknote is
transported to either one of the recycling modules [4] (if available) or the cash
box [5].
Depending on the individual validator/recycler configuration, only some instead of
all banknotes of a currency are supposed to be accepted. Some of them can be
disabled and will not be accepted.
The acceptance module bundler can temporarily collect and bundle up to
15 accepted banknotes of a current transaction. The host machine can thus decide
on either returning the bundled banknotes or transporting them to the cash box
following an appropriate command depending on a transaction cancellation or the
note recycler's change stock for instance.
2.3.2 Recycling module(s) (note recycler only)
The recycling modules [1] temporarily store banknotes, which are supposed to be
paid out as change to your next customers through the recycler's payout slot [2].
The two payout LEDs [3] are then flashing green. The note recycler is able to pay
out a bundle of up to 15 notes. Excess banknotes stored in the recycling modules
can be transferred to the cash box [4] for permanent storage. In case, a recycling
module is full, banknotes are transferred to the cash box automatically.
The upper recycling module is labeled A [5], the lower module is labeled B (see
module front label in Fig. 19).
Most of the applications require a minimum change stock to remain in the recycling
module(s) for the next day. This minimum stock varies depending on the recycler
customization and integration choices. It will not be transferred to the cash box
when the recycling module is empty to this defined level.
Depending on the change demand, the note recycler has one, two or even three
recycling modules. One recycling cassette is able to recycle up to 90 banknotes of
one or two different denominations. A note recycler with two recycling cassettes
thus allows flexible recycling of 180 banknotes of one to four different
denominations, a note recycler with three recycling cassettes even 270 of one to
six denominations.
Acceptance module
Cash box
Recycling modules
Loading module (option)
Fig. 17: Note recycler modules
Fig. 18: Note recycler with insertion slot, LEDs, acceptance module
Fig. 19: Note recycler with payout slot, LEDs, and recycling
modules

About note validator and note recycler
BNA6 Advance & BNR Advance Note Validator and Note Recycler
10
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
The individual recycler configuration determines
what denominations are to be directed to the recycling modules or to the cash box.
how many banknotes should remain in each recycling module as minimum change stock for the next day, which cannot be transferred to
the cash box.
You need the interlock system key to remove the recycling modules.
2.3.3 Loading module (note recycler only)
The optional loading module [1] of the note recycler is used to reload the recycling modules. For this, it
can be removed and filled with up to approx. 250 banknotes of the denominations stored in the
recycling modules. To guarantee proper operation, these banknotes have to be of the same size and
meet some quality requirements (see chapter 4.4.2.1 “Quality requirements for banknotes”, p. 35).
You need the interlock system key to remove the loading module from the note recycler and another
key to open the cassette for refilling purposes (see chapter 2.4.1 “Key locks”, p. 13).
2.3.4 Cash box
All banknotes accepted, which are not stored in the recycling modules temporarily, will be transported
to the cash box [1]. Here they are permanently stored in a secure and removable cash storage
cassette. You need the interlock system key to remove the cash box from the note recycler and
another key to open the cash box for emptying purposes.
The cash box may only be rein
serted in rearmed condition! Meaning that it has to be
opened and closed again before it can be reinserted.
Before removing
the cash box, please make sure, that you have access to either the key of
the cash box you want to remove or another
rearmed cash box (indicator is green) for
replacement purposes
.
Fig. 20: Note recycler loading module
Fig. 21: Note recycler cash box

BNA6 Advance & BNR Advance Note Validator and Note Recycler
About note validator and note recycler
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
11
2.4 Main components
Fig. 22: Note recycler front and rear view
Front and rear view
1. Latch button – open upper rear flap
2. Upper rear flap
3. Top flap
4. Latch – open top flap
5. Acceptance module
6. Insertion LEDs
7. Insertion slot
8. Payout LEDs
9. Payout slot
10. Interlock system lever – remove
loading module and cash box
11. Lock – release interlock system lever
12. Cash box handle – remove cash box
13. Cash box
14. Lock – open cash box
15. Loader handle – remove loading module
16. Lock – open loading module
17. Loading module (optional)
18. Recycling module
19. Recycling module
20. Latch – open spine
21. Spine status LED
22. Lower rear flap

About note validator and note recycler
BNA6 Advance & BNR Advance Note Validator and Note Recycler
12
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
Cash box
1. Cash box cover
2. Lock – open cash box
3. Indicator – ready for insertion state
4. Handle – remove cash box
Loading module (note recycler only)
1. Loading module cover
2. Banknote guide flap/limiter
3. Level flag
4. Latch – lift maximum level detection plate
5. Maximum level detection plate
6. Handle – remove loading module
7. Lock – open loading module
Fig. 23: Note recycler cash box
Fig. 24: Note recycler loading module

BNA6 Advance & BNR Advance Note Validator and Note Recycler
About note validator and note recycler
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
13
2.4.1 Key locks
To keep your cash safe the note validator/recycler units are secured by means of a
so-called interlock [1] system permanently installed inside of the metal chassis
guaranteeing that all cash modules are locked in place with a lock and a lever.
Beyond that, the loading module (note recycler only) and the cash box are equipped
with a separate lock [2and 3] to prevent them from being opened by unauthorized
personnel. In order to empty the cash box for accounting purposes or refilling the
loading module (note recycler only), the authorized attendant possessing the
appropriate key(s) as well as the interlock system key may remove and open these
modules using the loading module handle [4] or the cash box handle [5].
2.4.2 Status LEDs
The four status LEDs [1] on the front
bezel around the insertion and payout
slots seen during operation indicate the
expectation of cash to be inserted in
the insertion slot or withdrawn from
the payout slot.
Additionally, the note validator/recycler
cash box and spine, and each note
recycler module (loading, and
recycling module) have their own
LEDs/indicator [2] in the front or on the
backside indicating the status of the
module. If these LEDs/indicators are
green, the modules are ready to
operate.
Fig. 25: Note recycler key locks
Fig. 26: Note recycler status LEDs/indicators

About note validator and note recycler
BNA6 Advance & BNR Advance Note Validator and Note Recycler
14
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
Status LED Flashing code Meaning
Off Banknote insertion and acceptance disabled by host machine.
On Please insert banknote.
Flashing Rejecting banknote inserted. Please pull out banknote.
Flashing Paying out/returning/banknote(s). Please pull out banknote(s).
In chapter 4.2 “Note validator/recycler behavior during power-up and reset”, p. 19 you read how the status LEDs behave while the note
validator/recycler is powered up and in chapter 5.1 “Locating and fixing errors using status LEDs”, p. 37, how to remedy the cause of a
malfunction using the status LEDs.

BNA6 Advance & BNR Advance Note Validator and Note Recycler
Install
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
15
3Install
This chapter
•
provides information on unpacking the note validator/recycler
•
lists the scope of delivery
•
describes how to assemble the note validator/recycler
3.1 Unpacking the note validator or note Recycler
The note validator/recycler comes in two boxes.
1Unpack the boxes.
2Check the units for damages in transit.
3In case a unit damaged, please contact your CPI customer service.
Risk of damage t
o the note validator/recycler
Please keep the original packaging
and use it to transport the device. It is only in this way sufficiently
protected.
3.2 Parts included
BNA6 Advance note validator or BNR Advance note recycler
Acceptance module
Grounding cable
Keys

Install
BNA6 Advance & BNR Advance Note Validator and Note Recycler
16
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
3.3 Assembling the note validator/recycler
Before the note validator/recycler can be installed in the host machine the acceptance module has to be installed on
the top of the note validator/recycler chassis. This chapter and user guide only describes the assembly of the note
validator/recycler. Please refer to the separate Integration Manual to learn how to install the note validator/recycler
in the host machine.
Please pay attention to the following safety instructions when assembling the device:
Heavy object. The recycler/validator can weigh more than 25
kg (55 lb).
Risk of muscle strain or back injury.
Use lifting aids and proper lifting techniques when removing or replacing.
Electricity.
Risk of electricity hazard
Turn off power to the
machine before installing the note validator’s/recycler’s acceptance module or
removing the note validator/recycler
.
Risk of damage to the note validator/recycler
•
The note validator/recycler PCB is fitted with components that can be damaged by electrostatic
discharge. Please observe ESD precautions for components exposed to the risk of electrostatic discharge.
Installers should be properly grounded.
•
Keep water and other liquids away from the note validator/recycler. It is not suitable for use in areas
where there could be direct contact with water jets.
To install the acceptance module you need the interlock system key:
1Open interlock system and remove cash box (see chapter 4.3.3 “Removing and reinstalling cash box”, p. Error! Bookmark not
defined.).
2Pull green shockblocker lever [1] as far as it will go (to second stop) [A].
3Open spine flap (see chapter 4.3.2 “Opening and closing chassis flaps”, p. 20).
4Carefully place acceptance module on the top of the chassis [B] with its hood outside the chassis and its slotted holes [2] aligned with
the chassis’ pan-head pins [3].
Fig. 27: Releasing shockblocker lever
Fig. 28: Aligning acceptance model with chassis

BNA6 Advance & BNR Advance Note Validator and Note Recycler
Install
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
17
Fig. 29: Locking acceptance module into place
Fig. 30: Connecting acceptance module
5Lift rear green lever [4], hold it [C] and simultaneously slide acceptance
module towards the front as far as it will go and until it clicks into place [C].
The acceptance module is locked in place now.
6Push rear green lever [4] back [D], hold it and reconnect acceptance module’s
6-pin plug [5] to spine board’s connector [6] [D].
7Close spine flap again (see chapter 4.3.2 “Opening and closing chassis flaps”,
p. 20).
The rear of the acceptance module is flush with the chassis.
8Push green shockblocker lever [7] back in its initial position [E].
9Reinstall cash box (see chapter 4.3.3 “Removing and reinstalling cash box”,
p. Error! Bookmark not defined.) and relock interlock system (see
chapter 4.3.1 “Unlocking and relocking interlock system”, p. 20).
10 Connect note validator/recycler to the PC with the STS Advance support
software installed to test the device (see separate Service and Repair Manual
and support software user guide).
Fig. 31: Reinstall shockblocker lever

Operate
BNA6 Advance & BNR Advance Note Validator and Note Recycler
18
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
4Operate
This chapter describes
:
•
How to get validator/recycler ready for initial operation
•
How validator/recycler behaves while it is powered up and reset
•
How to operate note validator/recycler
–Unlock and relock interlock system
–Open and closing chassis flaps
–Remove and reinstall cash box
–Remove, open, and reinstall optional loading module (note recycler only)
–Remove and reinstall recycling modules (note recycler only)
–Remove and reinstall acceptance module
•
How to handle cash
–Emptying cash box
–Refilling loading module (note recycler only)
4.1 Getting BNA6 Advance & BNR Advance note validator and recycler ready for initial operation
Before running the note validator/recycler for the first time, please ensure that:
The acceptance module is installed correctly and connected to the spine (see chapter 3.3 “Assembling the ”, p. 16).
All flaps (one top flap and two rear flaps) are closed correctly (see chapter 4.3.2 “Opening and closing chassis flaps”, p. 20).
Cash box and optional loading module(s) are inserted correctly so that the interlock system is locked (see chapter 4.3.1 “Unlocking and
relocking interlock system”, p. 20),
Power and USB cable are connected correctly (see separate Integration Manual).
Chassis is grounded properly (see separate Integration Manual).
Host machine and note validator/recycler are powered up and the latter is reset (see chapter 4.1 “Getting BNA6 Advance & BNR Advance
note validator and recycler ready for initial operation”, p. 18).
Please pay attention to the following safety instructions when operating the device:
Risk of damage to the note validator/recycler
•
The note validator/recycler must not be operated in the presence of flammable gases, fumes, or water.
•
Keep water and other liquids away from the note validator/recycler. It is not suitable for use in areas
where there could be direct contact with water jets.

BNA6 Advance & BNR Advance Note Validator and Note Recycler
Operate
01_CPI_BNA6 Advance Note Validator
-BNR Advance Note Recycler_User Guide_V2.0_EN Published by CPI
19
4.2 Note validator/recycler behavior during power-up and reset
After powering up the note validator/recycler, in a next step, the validator/recycler has to be reset by the host machine. Depending on the
number of note validator/recycler modules the reset sequence takes approximately 15 to 25 seconds. Resetting the note validator/recycler,
automatically starts a function self-test checking the electro-mechanical system for failure. You will hear the transport motors running, belts,
and diverters being tested. Banknotes found in the transport system during the self-test will be sent to the cash box.
The
very first reset cycle may take up to one and a half minutes. This is to take the recycling modules from the initial
parked/t
ransport condition to the operational position, more details on the recycling modules’ parking can be found in the separate
S
ervice and Repair Manual.
During power-up and reset the status LEDs indicate the following:
Process step Status LED Flashing code Meaning
Powering up by
host machine
Regular, alternately for
15 seconds Device being powered up/rebooted
Regular Device being powered up/rebooted
Regular, but more slowly
along with spine,
recycling, and loading
module LEDs Device waiting for reset
Reset triggered by
host machine
Regular, still slowly along
with other LEDs for
another 15–25 seconds
(first reset cycle: up to
90 seconds) Device being reset and performing self-test
Device was reset successfully. All other module LEDs are
green now.
If the reset sequence does not start though triggered by the host machine, make sure that:
The power and USB cable is correctly connected.
All flaps are closed (see chapter 4.3.2 “Opening and closing chassis flaps”, p. 20).
Each module is correctly inserted so that interlock system is correctly secured and interlock key is removed (see chapter 4.3.1
“Unlocking and relocking interlock system”, p. 20).
(see chapter 5.1 “Locating and fixing errors using status LEDs”, p. 37)

Operate
BNA6 Advance & BNR Advance Note Validator and Note Recycler
20
Published by CPI 01_CPI_BNA6 Advance Note Validator-
BNR Advance Note Recycler_User Guide_V2.0_EN
4.3 Operating BNA6 Advance & BNR Advance note validator and note recycler
This chapter describes how to open the interlock system, chassis flaps, handle the cash box, acceptance module, as well as loading and
recycling module of a note recycler.
4.3.1 Unlocking and relocking interlock system
Unlock the interlock system whenever you want to remove the cash box, the note recycler’s loading or recycling
modules:
1Insert the key [1] in the lock, push and simultaneously turn it clockwise as far as it will go [A].
All four bezel LEDs start flashing green.
2Push the yellow interlock system lever [2] to the rear [B].
The lever shows its red marking. The cash box and note recycler loading module are no longer secured in place.
To secure the interlock system
1Push the yellow interlock system lever [1] back to the front [A].
2Turn the interlock system key [2] counter-clockwise [B], pull it out of the lock [C] and store it in a safe place.
The cash box and note recycler loading module are locked in place.
4.3.2 Opening and closing chassis flaps
The note validator/recycler has three chassis flaps allowing access to the banknote transport path can be opened using the yellow latches
and latch buttons to clear a banknote jam for instance.
Note recycler flaps can crush and cut.
Keep body parts clear when op
ening and closing the note recycler flaps.
Fig. 32: Unlocking interlock system Fig. 33: Relocking interlock system
