CPS FX3030 User manual

FX3030 SERIES REFRIGERANT RECOVER /
RECYCLE / VACUUM AND RECHARGE UNIT
OPERATION MANUAL
Models: FX3030
Covered under US Patent
8,082,750 and other patents
pending.
Certified by ITS under J2911
to meet SAE J3030 for R-134a
and R-1234yf.
Certified by ITS under
SAE J2911 to meet high volt-
age compressor service per
SAE J3030.

Table of Contents
Specifications 2
General Safety 3
Icon Library 4-5
First Time Start Up 6
Theory of Operation 7-8
Other Functions 9
Maintenance and Care 10-11
Parts List and Warranty 11
A/C Database End-User License Agreement 12-13
Unit Consists Of:
Specifications
•FX3030 Automotive Refrigerant Management Center
• Low and High side service hoses R-134a and R1234yf
• Low and High side R-134a and R1234yf Service Couplings
• Tank Refill Adapters - Two for R134a and one for R1234yf.
• 41 cubic Inch CPS filter drier (Replacement part number FX3030X1)
• 1 lb (454 gram) check weight
• Operation manual
• 1 Roll 2.25” x 50” Thermal Paper
• Built-in Refrigerant Identifier
• 50lb DOT Tank/Filter and Hose Sets for R134a (Installed) and R1234yf
End user to provide:
• Refrigerant oil/dye injection system
• Refrigerant
FX3030 Specifications
Power 115V 60Hz 1Ph
Compressor 2/3 HP Twin Cylinder Oil-less
Vacuum Pump 50 Micron Rated 6 CFM
Gauges 3.5” Low side, 30 in/Hg to 250 psi; High Side, 0 to 600 psi
Hoses 120” barrier type
Refrigerant R-134a | R1234yf
Storage Tank Assemblies 2 x 50 lb DOT with processor controlled heat band
Display 7” Touch Screen with 256 color graphical display
Printer 2.25” Thermal Printer
Construction Sheet metal frame adorned by injection and rotary molded plastic. Two handle bars, 4” front casters and 10” foam-filled rear tires
for exceptional maneuverability

Only qualified service personnel should operate this unit. Most states, countries, etc... may require the user to be licensed. Please check with
your local government agency.
DANGER – this unit’s recovery tanks contains liquid refrigerant. Overfilling of a recovery tank may cause a violent explosion resulting in
severe injury or even death. Do not disable the overfill safety features. Always make sure the correct tank is on the scale.
DANGER - Only use the recovery tanks provided with this unit. See distributor for replacement tanks.
DANGER - Avoid breathing refrigerant vapors and lubricant vapor or mist. Breathing high concentration levels may cause heart arrhythmia,
loss of consciousness, or even cause suffocation.
DANGER - Electrical shock hazard!!!! Always disconnect power source when servicing this equipment.
DANGER - DO NOT USE COMPRESSED AIR TO PRESSURE TEST OR LEAK TEST THE UNIT OR VEHICLE AIR CONDITIONING SYSTEM.
Mixtures of air and refrigerant are combustible at elevated pressures. These mixtures are potentially dangerous and may result in fire or
explosion causing personal injury or property damage.
CAUTION - all hoses may contain liquid refrigerant under pressure. Contact with refrigerant may cause frostbite or other related injuries. Wear
proper personal protective equipment such as safety goggles and gloves. When disconnecting any hose, please use extreme caution.
CAUTION - avoid breathing refrigerant vapors and/or lubricant mist. Exposure may irritate eyes, nose, throat, and skin. Please read the
manufacturers Material Safety Data Sheet for further safety information on refrigerants and lubricants.
CAUTION - do not use this equipment in the vicinity of spilled or open containers of gasoline or other flammable substances. Make certain
that all safety devices are functioning properly before operating the equipment.
CAUTION- to reduce the risk of fire, avoid the use of extension cords thinner than NO. 16 awg. (1,5mm2). The following table references
extension cord wire size vs. maximum length:
CAUTION- do not use this equipment in the vicinity of spilled or open containers of gasoline or other flammable substances. Make certain that
all safety devices are functioning properly before operating the equipment.
CAUTION- This equipment should be used in locations with mechanical ventilation that provides as least 4 air changes per hour.
CAUTION- RISK OF INJURY, the equipment should only be operated by certified personnel.
CAUTION- Use only CPS certified hose assemblies on this unit. The hose assemblies are made to proper length, contain shut offs where
required and have direct affect on the proper operation of this equipment.
CAUTION- R-1234yf is a Class A2L flammable refrigerant. Use in well ventilated areas. Minimize leakage from the unit. Periodically check unit
for leaks.
INTRODUCTION
GENERAL SAFETY
The CPS FX Series Refrigerant Management Centers are designed to revolutionize A/C equipment ease and endurance. From the seven inch
256 color touch screen display, to the patented and patent-pending oil-less compressor and motorized ball valves, we are confident the FX
Series equipment will quickly impress you with its ease of use and superior functionality.
There are many features built into the FX Series equipment. Below are the most noteworthy:
• A/C System Capacities Database—provides refrigerant/oil type and capacities for most vehicles sold in North America since 1994.
• Multiple Language Support—the FX series comes standard in English. Other languages will be made available and easily installed via
an SD card.
• Heated tank—to help reduce the times the vehicle AC system must be started in order to complete charging, we have added a tank
heating blanket to every FX machine.
• Care and Maintenance—the FX Series designers made ease of maintenance a priority. The vacuum pump oil drain and fill ports are
accessible from the outside — no disassembly is required. The refrigerant filter is located on top of the tank and machines Graphical
User Interface walks you through the filter replacement process.
CPS is pleased to bring to the automotive technician the many innovations commercial HAVC/R technicians have enjoyed for years. We hope
you will enjoy using your new FX Series Refrigerant Management Center.
Cord Gauge (awg) Cord Length (Ft)
16 10
14 20
12 25

ICON LIBRARY
ICON NAME DESCRIPTION IMAGE
AIR PURGE Tap to select AIR PURGE
AIR PURGE The AIR PURGE icon indicates that the
unit is purging air from the tank
AMERICAN Tap to select AMERICAN Units
BAR Tap to select BAR
BOTH COUPLERS Tap to select BOTH couplers
° C Tap to select CELSIUS
CALIBRATION Tap to select CALIBRATION
CHANGE TANK The CHANGE TANK icon notifies the
user to change the tank
CHANGE UOM Tap to change the unit of measurement
CHARGE Tap to perform a CHARGE service
CHARGE
COMPLETE
Indicates that the CHARGE service is
COMPLETE
Charge Low Side Press to select Low Side Charging
CHECK SCALE
COMPLETE
The SCALE CHECK COMPLETE notifies
users that a scale check is complete
Close Ball vale Press to close ball valve
CLOSE COUPLER
The CLOSE COUPLER icon notifies
the user to close the coupler during a
recharge service
CLOSE HP Notifies the user to CLOSE HP valve
during a CHARGE service
CLOSEVALVE Notifies user to CLOSE VALVE
COMPLETE Indicates that a given operation is
COMPLETE
CONNECT HP Notifies user to connect HP port
during tank refill
CPS FILTER CPS FILTER
DATABASE Tap to access the vehicle DATABASE
DISCONNECT
COUPLERS
Notifies the user to DISCONNECT
COUPLERS
DRAIN OIL The DRAIN OIL icon notifies the user
that oil is draining from the vehicle
ERROR Displays when there is an ERROR
° F Tap to select FARENHEIGHT
FAILED Indicates that a given operation FAILED
FILTER Displays the current status of the filter
life.
ICON NAME DESCRIPTION IMAGE
FILTER CHANGE Displays when a filter change is
required
FILTER CHANGE Tap to CHANGE FILTER
FILTER CHANGE Tap to CHANGE FILTER
FULL CYCLE
COMPLETE
Indicates that the FULL CYCLE service
is COMPLETE
GRAMS Tap to select GRAMS as UOM
HELP Tap to launch the HELP Menu
HELP Provides Firmware version
HIGH COUPLER Tap to select the HIGH SIDE coupler
only
HOME Tap to launch the HOME screen
INJECTION Notifies the user to INJECT oil and/or
dye at this point in the service
INTERNATIONAL TAP to select INTERNATIONAL UOM’s
KGCM2 Tap to select KGCM2
KGS Tap to select KGS as UOM
KPA Tap to select KPA
LANGUAGE Tap to select LANGUAGE
LBS Tap to select LBS as UOM
LBS:OZ Tap to select LBS:OZ as UOM
LEAKCHECK Indicates that a LEAK CHECK is being
performed
LOW COUPLER Tap to select the LOW SIDE coupler
only
MAINTENANCE Tap to launch the MAINTENANCE
menu
MAINTENANCE
FILTER CHANGE Tap to CHANGE FILTER
MANIFOLD Tap to launch the MANIFOLD function
METRIC Tap to select METRIC UOM’s
MPA Tap to select MPA
NOT NOW Tap to postpone suggested operation
Open Ball Valve Press to Open Ball Valve
OZ Tap to select OZ as UOM

ICON LIBRARY
ICON NAME DESCRIPTION IMAGE
PLACE WEIGHT Notifies user to PLACE WEIGHT on
the scale
PRINT Tap to PRINT a report of the service
PSIG Tap to select PSIG
PT Tap to select PRESSURE
TRANSDUCER
PURITY PURITY
QUIT Tap to quit the current function
R1234yf Tap to select R1234yf Refrigerant
R134a Tap to select R134a Refrigerant
R22 Tap to select R22 Refrigerant
R407 Tap to select R407 Refrigerant
RECOVERY Tap to perform an RECOVERY service
RECOVERY
COMPLETE
Indicates that the RECOVERY service
is COMPLETE
REFRIGERANT REFRIGERANT
REFRIGERANT
CHANGE Tap to CHANGE REFRIGERANT
REGISTER Tap to REGISTER unit
RELAY Tap to select RELAY
REMOVE WEIGHT Notifies user to REMOVE WEIGHT
from scale
SAE Tap to select SAE
SAE CHARGE Tap to perform a SAE CHARGE service
SAE CHARGE
COMPLETE
Indicates that the SAE CHARGE service
is COMPLETE
SCALE Tap for SCALE functions
SCALE CHECK Tap to perform SCALE CHECK
SCALE CHECK The SCALE CHECK icon notifies users
that a scale check is in progress
FULL
CALIBRATION Tap to perform full calibration
SCALE ZERO Tap to RE-ZERO the scale
SERVICE Tap to select SERVICE
SERVICE HOSES
BEING FLUSHED
Indicates that the SERVICES HOSES
are BEING FLUSHED
ICON NAME DESCRIPTION IMAGE
SET TIME Tap to SET TIME
SETTINGS Tap to launch the SETTINGS screen
SETUP Tap to launch the SEUP menu
SPEAKER Tap to enable sound
START AC Notifies user to start vehicle and turn
on AC during service
TANK Indicates the level of refrigerant in the
TANK
TANK FULL Notifies user that TANK is FULL
TANK HOSE
TANK REFILL Tap to perform a TANK REFILL
Tank Tare Setup Press to change tank weight and WC
TANKS REFILL
COMPLETE
Indicates that the TANK REFILL is
COMPLETE
TARE Tap to select TARE
TURN UPSIDE
DOWN
Notifies user to TURN TANK UPSIDE
DOWN during tank refill
UNIT Tap to select UOM
UPDATE Tap to UPDATE
UPGRADE Tap to select UPGRADE
UPKEEP Tap to launch the UPKEEP menu
VACUUM Tap to perform a VACUUM service
VACUUM
COMPLETE
Indicates that the VACUUM service is
COMPLETE
VOLUME Tap to Choose VOLUME UOM
WARNING The WARNING icon appears to caution
users of a potential hazard
WEIGHT Tap to Choose WEIGHT UOM
ZERO Tap to RE-ZERO the pressure
transducer
ZEROING Indicates that the unit is ZEROING

FIRST TIME START UP
1. Remove the black tank cover on the back of the unit by unscrewing the two thumb screws located on each side of the cover. Remove the
protective packaging from between the storage tank and the scale. See Figure A below.
Figure A: Shipping support to be removed before start up.
2. Plug the unit into the proper power source. Push the blue lighted power switch. All functions will be operated directly from the 7” Touch
Screen.
3. Press the key to enter your shop information into your unit. This information will appear on certain screens and on print outs.
Pressing will cause the unit to proceed with set up without personalizing your unit. Selecting will cause the unit to ask you later
if you want personalize your FX3030.
4. When personalization has been completed, press OK and the unit will proceed through self-calibration. When complete, the Home
screen will appear.
5. A “NO PRESSURE DETECTED IN THE TANK!” message will appear. Hit Continue to proceed.
6. A “STILL NO PRESSURE DETECTED!” message will appear. Hit Continue to proceed.
7. The main menu will appear. Hit the icon and refer to the Operators Manual for further instructions on how to fill the tank.
Congratulations, your FX Series Refrigerant Management Center is ready to use.
Note: Each time the machine is turned on it MUST be disconnected from a vehicle

THEORY OF OPERATION
FX Series Refrigerant Management Centers feature a touch screen graphical user interface that makes operation a breeze. In this section, we
will cover each operation and what the machine is actually doing. While the screen provides much of this information during operation, the
descriptions below will offer more detail than can be displayed.
Recovery
Select “Recovery” if you want to recover and recycle refrigerant currently in the vehicle prior to opening the system for repair. This process
will begin by checking the refrigerant in the vehicle system. If the refrigerant is at least 98% pure R1234yf or R-134a, recovery will
commence automatically. If the refrigerant is less than 98% pure, the recovery function will not be allowed and the machine will vent the
hoses to prevent internal contamination of the machine and storage tank.
The recovery process creates a vacuum on the vehicle system, pulling the refrigerant into a distillation chamber. The chamber has a coil
inside that is heated by compressor outlet gas. This process distills the refrigerant (turns it to gas) and separates liquids and debris from the
refrigerant. The refrigerant passes through the chamber and compressor and is condensed into a liquid before coming to rest in the internal
storage tank.
The process ends when the machine detects that the system is void of refrigerant. The machine will display the amount recovered through-
out the process and at the end. The ending amount may be printed by pressing the icon visible on the Home screen after recovery is
completed.
Vacuum
Select “Vacuum” if the vehicle system is void of refrigerant and is ready to be recharged. Evacuating the vehicle utilizes the FX Series’ 6 CFM
vacuum pump to pull air and boil moisture from the AC system. A specific vacuum time may be selected, or one of the preset times may be
used. If a vacuum time of 15 minutes or greater is selected, vacuuming will be followed by a 2 minute leak test (vacuum decay test).
Charge
Select “Charge” to refill the vehicle system to its designed capacity. Enter the desired charge amount. An A/C Database feature is built into
the FX3030, This can be accessed by pushing the key.
The charging sequence begins with a 10-minute vacuum leak test. This is an SAE requirement in SAE J2843 (R1234yf systems only). If the
system passes the vacuum leak test, the machine will charge the system to 15% of the selected charge. At this time, an electronic leak detec-
tor meeting SAE J2913 for R1234yf is used to leak test the evaporator(s). After performing the leak test, the user will select the appropriate
answers to the displayed questions and proceed with charging. The FX3030 will continue allowing the remaining 85% of the charge. The
FX3030 is equipped with a heat blanket to assist in completing charging, but if the FX3030 cannot complete a charge due to pressure equal-
ization, it will notify the user to close the high side coupler and start the vehicle. This process will quickly complete the charge.

THEORY OF OPERATION
OTHER FUNCTIONS
Refrigerant Change
This feature allows the user to switch between R-134a and R1234yf refrigerants for use in differently equipped vehicles. The “Refrigerant
Change” icon first appears on power up as well as in the settings menu.
1. Select the “Refrigerant Change” icon to begin to change refrigerants. Select the refrigerant to be used (Figure 1). Follow the directions
on the screen to remove the back cover and close valves 1 and 2. The screen will remain on until a small purge and a 3-5 minute deep
vacuum is performed on the system to remove any remaining traces of the old refrigerant.
2. Disconnect the heater blanket and ground wire.
3. Remove the tank by using a 9/16” wrench to disconnect the old tank’s liquid feed hose and the vapour return hose from the flush block
(Figure 2).
4. Once the old tank is removed, install the new tank with the red hose on the left side and the filter parallel to the FX unit. Use the same
wrench to attach the two new hoses to the filter bracket. Open all valves and check for leaks. CPS is not responsible for lost refrigerant.
5. Attach the new tank’s heater blanket, reattach the ground wire and reinstall the back cover.
6. On the front of the unit, remove the service cover with a Philips head screwdriver. Loosen the nuts with a 9/16” wrench and replace the
service hoses (Figure 3).
7. Reinstall the service cover and refer back to the screen. The unit will now go through the refrigerant identification process to ensure
proper changeover(Figure 4).
Full Cycle
Select “Full Cycle” to recover, recycle, vacuum, leak check and charge the vehicle AC system. The display will prompt you to enter the vehicle
charge amount. As in the “Charge” sequence, the database may be used to retrieve the charge amount for most vehicles sold in North
America.
The full cycle process begins with a refrigerant purity test and the vehicle system. This is required for SAE2843 for R1234yf only. If the
system passes the purity test, the machine will proceed with recovery.
The Full Cycle process continues after recovery with pre-charge vacuuming and leak testing. Leak testing is required under SAEJ2843 for
R1234yf systems. The system is first vacuumed. After vacuuming, the 5-minute vacuum test is performed. If vacuum is held, the unit will
proceed to adding 15% of the selected charge amount to the system. Using a SAE J2913 approved leak detector, inspect the evaporator(s)
for leaks and answer the displayed questions. If the system passes leak detection, the machine will continue charging the remaining 85%. If
the leak tests fail, the machine will recover any refrigerant and return to the Home screen. After the leak is repaired, the process can be run
again. The results may be printed by pressing the icon visible on the Home screen after Full Cycle is complete.
Tank Refill
Select “Tank Refill” to add refrigerant to the internal storage tank. It is suggested that at least 4.5 lbs or 2 kg of refrigerant be available in the
storage tank to begin any operation. If less is observed, choose this operation to add refrigerant to the internal tank. This operation transfers
refrigerant in the liquid state to the internal storage tank. The Refrigerant amount transferred in this mode is not counted toward the filter life.
Start by connecting the red hose to the liquid port on the cylinder. For virgin cylinders with one port, turn tank upside down once connected
and tank valve is opened. The Unit will then go through the refrigerant identification process. If the new refrigerant is determined to be con-
taminated, the unit will purge the sample and not allow the Tank Refill function to continue. If the refrigerant is determined to be acceptable,
follow the directions on the display until the process is completed.
Figure 1 Figure 2 Figure 3 Figure 4

Change Units
This function will be displayed when setting the charge amount. It allows
you to change from the defaulted unit of measure to that on the J639 tag
on the vehicle. For instance, the machine default was set to lbs:oz and the
vehicle tag provides refrigerant capacity in grams. Use this feature to
change the unit of measure to grams for this charge only.
Add Oil
This icon appears the end of the charge operation and is a reminder to add back the amount of oil that was removed during recovery. If you
had entered the amount of oil after charging, that amount will also appear with the icon. If not, check the oil discharge bottle to determine the
change in volume since the last recovery. Add this amount back to the system by using an oil and/or dye injection accessory.
Car System Health Mode
This mode allows for checking of system pressures and vent temperature before and after servicing the AC
system. System parameters can be printed while in this mode to provide a before and after comparison.
When entering the Car Health mode, the machine will prompt you to start the AC system. You can then
collect and print readings. If you plan to recover next, press the button. You will be taken to the
Home screen. If all is well, press and the machine will guide you through clearing the hoses of
refrigerant back into the AC system.
Change Unit of Measure or Language
Press the maintenance icon and select . This will take you to a screen to allow you to select
either or .
Air Purge
The FX series features automatic air purge at unit start up. An air purge may also be selected in the maintenance mode. Air purges reduce
“non-condensable gases” in the storage tank to an acceptable level and may take a few minutes to complete. Do not turn the machine off or
unplug the unit during an Air Purge cycle.
Loading new Firmware
From time to time firmware updates will become available. Should you need to install updated firmware; files will be sent to you to place onto
a USB stick. Go to the “Set up” mode and select “Update.” After selecting, the machine will guide you through the process, including telling
you when to insert the USB stick into the USB port. When complete, the machine will reset. When the Home screen appears, it is complete.
Refrigerant ID
Pressing this icon enables the user to use the FX3030 as a refrigerant identifier.
OTHER FUNCTIONS

MAINTENANCE AND CARE
Filter Changes
The filter/dryer has the capacity to dry 150lbs of recovered refrigerant. A filter life monitor is displayed on the Home
screen. When indicated the filter must be changed.
To change the filter:
1. Remove the black plastic tank cover. Have the filter reset code available before proceeding. It comes with each
new filter.
2. On the display Press the key and select . Then select
3. Follow the displayed directions. Replace the black tank cover when completed.
Scale Maintenance
Use this mode to check, tare or calibrate the internal tank scale. To access “Scale Maintenance”, press the icon, then select
Select the desired function and follow the on screen instructions. To perform the “Test” mode, you will need to remove the black plastic tank
cover and then use the 1lb test weight included with the system. The Test mode will alert the user to the need to re-calibrate the scale.
A requires lifting the tank while operating the display. It is best to have two people available for and
Use to reset the empty tank weight to zero, thereby enabling indication of the refrigerant weight. Calibration is suggested only if the
calibration test was off by more than .02lbs. Calibration may be performed by a service center. CPS technical support can also assist with
the process. Calibration requires a certified 25lb weight.
Pressure Transducer Maintenance
Use this mode if you suspect that the internal pressure transducer readings are inaccurate. The internal pressure transducers are used during
recovery, vacuum, air purge and in the manifold mode.
To enter this mode, press the maintenance icon. Then select PT. This will allow the transducer to be set, or calibrated. Calibration will
require a certified pressure source above 70 PSIG.
Follow the displayed direction for the select transducer maintenance function.
High Pressure Alert
The FX3030 will alert the user should a high pressure condition exist on the outlet side of the compressor. When such a condition is
detected, the compressor will be turned off and not allowed to restart until the high pressure condition is remedied. In such case, check that
the tank valves and hose ball valves to the tank and filter are all open. If all valves are open, then contact technical support to determine the
cause of the alarm.
Tank Overfill Limit
The FX Series’ 50lb internal storage tank is designed to contain a maximum of 38lbs of refrigerant. If this amount is exceeded, the user will
be alerted and system operations will be halted. Before normal operation can continue, the overfill condition must be remedied by moving
refrigerant from the FX tank to another storage tank or into a vehicle AC system. The charge function may be used to transfer internally
stored refrigerant to an external storage facility.
