Cradlepoint PS6SMC3000UE Assembly instructions

PS6MC300UE Parts List
1- PS6SMC3000UE USB & Ethernet Charging Cradle
1 - USB Type-A to Mini-B Cable (1 meter)
1 - Quick Connect Guide (this document)
Power
RJ45
USB
Spare Battery
Switch
Network USB
PS6SMC3000UE
Front
PS6SMC3000UE
Back
Charge the MC3000
MC3000
Mini-AB
Connector
Type-A
Connector
USB Type-A
to
Mini-B Cable
PS6SMC3000UE
Quick Connect Guide
USB &
Ethernet
Charging
Cradles
PS6SMC70UE
Front side Back side
Spare
Battery
Plug the barrel connector
into the Cradle’s Power
Connector
Plug the Standard 115V
Power Cord into the Power
Adapter
Power Adapter
Charge your
Spare Battery
Connect Power
Local
Host
Computer
NETWORK USB
Connect MC3000
Place the MC3000 into the cradle
Connect USB
For Local Communication:
Connect the USB Type-A connector to a Type-A
connector on the Host Computer.
Connect the USB Mini-B connector to the USB
connector on the cradle.
Connect Network
For Network Communication:
Connect one end of a standard Ethernet
cable to the cradle’s RJ45 connector and
the other end to your hub, router, switch,
or wall data outlet
Choose
Slide Selector Switch to
choose Network or USB
communication.
Part Number: 190131-002 Rev B
Problems?
Download the User’s Guide and
Troubleshooting Tips from the
CradlePoint website at:
www.cradlepoint.com
Still having problems?
Contact Technical Support at:
[email protected]

PS6SMC3000UE & PS6SMC70UE FCC Regulatory Compliancy
FCC Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
* Consult the dealer or an experienced radio or television technician for help.
Changes or modications not expressly approved by CradlePoint, Inc. could
void the user’s authority to operate the product.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
PS6SMC70UE Parts List
1- PS6SMC70UE USB & Ethernet Charging Cradle
1 - USB Type-A to Mini-B Cable (1 meter)
1 - Quick Connect Guide (this document)
Power
RJ45
USB
Spare Battery
Switch
Network USB
PS6SMC70UE
Front
PS6SMC70UE
Back
Charge the MC70
MC70
Mini-AB
Connector
Type-A
Connector
USB Type-A
to
Mini-B Cable
Spare
Battery
Plug the barrel connector
into the Cradle’s Power
Connector
Plug the Standard 115V
Power Cord into the Power
Adapter
Power Adapter
Charge your
Spare Battery
Connect Power
Local
Host
Computer
Connect MC70
Place the MC70 into the cradle
Connect USB
For Local Communication:
Connect the USB Type-A connector to a Type-A
connector on the Host Computer.
Connect the USB Mini-B connector to the USB
connector on the cradle.
Connect Network
For Network Communication:
Connect one end of a standard Ethernet
cable to the cradle’s RJ45 connector and
the other end to your hub, router, switch,
or wall data outlet
Choose
Slide Selector Switch to
choose Network or USB
communication.
Problems?
Download the User’s Guide and
Troubleshooting Tips from the
CradlePoint website at:
www.cradlepoint.com
Still having problems?
Contact Technical Support at:
[email protected]
