Cradlepoint IBR600B User manual

©2005-2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 1
Quick Start Guide /COR IBR600B Series
+ Cloud-managed
+ Integrated LTE/
HSPA+ Modem
+ SIM-Based Auto-
Carrier Selection
+ Dual-SIM
+ Semi-ruggedized
Metal Housing
+ Two Ethernet Ports
(LAN/LAN or WAN/
LAN)
+ WiFi and Non-WiFi
Versions Available
+ Integrated Mounting
+ Dock Compatible
COR IBR600B Key Features:
COR IBR600B Series
FOR M2M & IoT NETWORKING
Go to cradlepoint.com/IBR600B to learn more.
AC Power Adapter WiFi Antennas
(on applicable models)
Modem Antennas
(on applicable models)
WHAT’S INCLUDED:
THANK YOU FOR CHOOSING
CRADLEPOINT
Cradlepoint is the leading provider of secure
cloud-managed 3G/4G/LTE networking solutions
for the Distributed Enterprise with hundreds
or thousands of locations. Our broad family
of high-performance routers are designed for
deployment in mission-critical applications
that require 24x7 connectivity.
Always Connected. Always Protected.

DEVICE DETAILS
Model numbers:
*IBR650B feature only
Accessories:
+ COR Extensibility Dock
+ MC400 Modem
+ Multiple Antenna Options
IBR600B-LP4
IBR650B-LP4
GETTING STARTED
Setting Up the Router
+ Purchase a data plan. Insert the SIMs.
+ Plug the power supply into an electrical outlet.
+ Connect WiFi (2.4) and modem antennas (finger tight only).
+ Connect the power supply to the IBR600B.
+ Ensure SIM door is shut or router will not turn on.
Quick Start Guide /COR IBR600B Series
©2005-2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com
2

Access the Administration Pages
To make conguration changes to your router, open the
IBR600B’s GUI-based administration pages.
1. Connect to the router
via Ethernet or WiFi.
For WiFi, the default
SSID is found on the
product label on the
bottom of the router.
2. Open a browser window
and type “cp/” or
“192.168.0.1” in the
address bar and press return/enter.
3. When prompted for the Administrator password,
type the default eight character password found on
the product.
4. Upon log in for the first time, you are automatically
directed to the First Time Setup Wizard to configure
Admin Password, Time Zone, WiFi Security, APN and
WAN failure check.
+ Administrator
Password
+ Time Zone
+ WiFi Network Name*
+ Security Mode
+ Access Point Name
(APN)
+ Modem
Authentication
+ Failure Check
FIRST TIME SETUP WIZARD
When you log in to the local administration pages
for the first time, you will be automatically directed
to the First Time Setup Wizard, which will walk you
through basic steps to customize your Cradlepoint
IBR600B/650B. You have the ability to configure any of
the following:
If you are currently using the router’s WiFi network,
you will need to reconnect your devices to the
network using the newly established wireless
network name and password.
To return to the First Time Setup Wizard after your
initial login, select ‘System > Setup Wizards’ on the
left navigation bar and First Time Setup in the drop-
down menu.
To restore the router to its factory default settings,
press and hold the RESET button on the side of
the device for ten seconds. Reset returns the login
password to the default password and resets all
configuration changes.
Quick Start Guide /COR IBR600B Series
©2005-2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 3
Deploy and Manage the
Intelligent Network with
Cradlepoint Enterprise Cloud
Manager (ECM)
Cradlepoint’s network management
and application platform, Enterprise
Cloud Manager, integrates cloud
management with your Cradlepoint
devices to improve productivity,
increase reliability, reduce costs, and
enhance the intelligence of your
network and business operations.
To learn more and begin a free
30-day trial:
[e-mail]
cradlepoint.com/ecm

ACTIVATE YOUR MODEM
A Cradlepoint router requires a data subscription
to a wireless broadband data plan to connect
to a wireless network. Wireless broadband data
plans are available from wireless carriers such as
AT&T, Verizon and T-Mobile. Carriers offer several
different types of data plans and Cradlepoint
works with most (Mobile broadband, M2M, and
router pricing plans; private and public APNS; and
static or dynamic IP address). To add or transfer a
line of service you will need to provide a unique
identifier such as IMEI/MEID from the Cradlepoint
modem. Data plans require a SIM that is supplied
and provisioned by the wireless carrier and
inserted into the Cradlepoint router or modem.
For more information on activation see
cradlepoint.com/activation.
UPDATING FIRMWARE
Cradlepoint regularly creates new firmware
packages. You may need to update firmware to
use the IBR600B with new modems and to access
our latest features.
1. Log into the administration pages. You may
have changed the Administrator Password
when you used the First Time Setup Wizard.
2. Select ‘System > System Control’ on the left
navigation bar, then ‘System Software’ in the
dropdown menu.
3. Find the ‘Firmware Upgrade’ section. This
displays the current firmware version that is
installed and indicates if updated firmware is
available.
4. Click ‘Automatic (Internet)’ if new firmware
is available. The IBR600B will download and
install the firmware and automatically reboot
itself. A status monitor will appear and
indicate when this process is complete. This
process may take several minutes depending
on your Internet connection speed.
If your device does not have an active Internet
connection, you need to download the latest
firmware from cradlepoint.com/firmware to your
desktop. Then use the ‘Manual Firmware Upload’
option.
ROUTER COMMUNICATION /
DATA USAGE
The factory default configuration of the router
is set to communicate with Cradlepoint and
other resources at regular intervals to access
the latest firmware and modem updates, clock
synchronization (NTP), and Enterprise Cloud
Manager (ECM) membership. Such communication
may result in data usage and applicable charges
regardless of whether the router uses a wired or
wireless Internet connection. To avoid such data
usage and potential charges, consult the following
Knowledge Base article:
knowledgebase.cradlepoint.com/articles/Support/
Router-Communication-Data-Usage
Quick Start Guide /COR IBR600B Series
