OWNER’S MANUAL
CT115 – 3pc COMBO KIT
2” BRAD NAILER, NARROW CROWN
STAPLER & 34°

CT115 – 3pc COMBO KIT
As part of the growing line of Craftex tools and equipment, we are proud to offer
the CT115 3pc Combo Kit (Brad Nailer, Narrow Crown Stapler, and Angle Finish
Nailer). The Craftex name guarantees Craft Excellence. By following the
instructions and procedures laid out in this owner’s manual, you will receive
years of excellent service and satisfaction. The CT115 Kit consists of
professional tools and like all power tools, proper care and safety procedures
should be adhered to.
TECHINAL INFORMATION & FEATURES
2” Brad Nailer
Narrow Crown Stapler
Adjustable Exhaust
Soft grip handle reduces fatigue
Touch-Strike security system
maintains safety for operator
Ideal for decor, furniture
assembly, interior, picture frames,
drawer assembly, upholstery and
more.
Nail/Brad Capacity: 18 Gauge
15 – 50mm
Working Pressure: 60-100 PSI
Av.Air Requirement: 3CFM / 85Lt /
min
Air Inlet: NPT ¼”
Staple Capacity: ¼” Crown,
18 Gauge upto 1”
Working Pressure: 60-100 PSI
Av.Air Requirement: 3CFM / 85Lt
/ min
Air Inlet: NPT ¼”
Soft grip handle reduces fatigue
Touch-Strike security system
maintains safety for operator
Ideal for decor, furniture
assembly, interior, picture frames,
drawer assembly, upholstery and
more.
34° Angle Finish Nailer
Adjustable Exhaust
Removable non-marring rubber
driver tip
Adjustable depth of drive
Quick release nosepiece for fast
clearing of jams
Soft grip handle reduces fatigue
Magnesium housing keeps unit
light weight
Nail Capacity : 15 Gauge upto
2 ½”
Required Pressure: 70 – 100 psi
Air Requirement: 5cfm
Air inlet: NPT 1/4"
2

CT115 – 3pc COMBO KIT
2” Brad Nailer Narrow Crown Stapler
34° Angle Finish Nailer
3

CT115 – 3pc COMBO KIT
GENERAL SAFETY INSTRUCTIONS
EXTREME CAUTION SHOULD BE USED IN OPERATING ALL POWER
TOOLS. KNOW YOUR POWER TOOL, BE FAMILIAR WITH ITS
OPERATION. READ THE OWNER’S MANUAL AND PRACTICE SAFE USAGE
PROCEDURES AT ALL TIMES.
•CONNECT your machine ONLY to the matched and specified power source.
•WEAR SAFETY GLASSES, RESPIRATORS, HEARING PROTECTION and
SAFETY SHOES when operating heavy machinery. Always wear safety glasses.
•DO NOT wear loose clothing or jewellery when operating machinery.
•A Safe Environment is important. Keep the area free of dust, dirt and other debris
in the immediate vicinity of the machine.
•BE ALERT! Do Not Use prescription or other drugs that may affect your ability or
judgement to safely use this machine.
•DISCONNECT the power source when making adjustments or repairs.
•NEVER leave an operating tool unattended.
•ALWAYS keep all safety guards in place and ensure their proper function.
•ALWAYS make sure that any tools used for adjustments are removed before
operating the machine.
•ALWAYS keep bystanders safely away while operating machinery.
•THINK SAFETY. WORK SAFELY. Never attempt a procedure if it does not
feel safe or comfortable.
4

CT115 – 3pc COMBO KIT
SPECIFIC SAFETY REQUIREMENTS
•When using compressed air, always follow the safety codes of
practice laid out by the compressor manufacturer.
•Damaged or split air hoses can cause a 'whip' hazard. Immediately
replace damaged air hoses.
•Ensure all air couplings are secure and tight.
•Do not try to modify the tool to accept fasteners other than those
specified.
•Only use this equipment for its intended use. Do not modify or
change its design.
•When tool is not in use always disconnect from the air supply.
•A competent person should only carry out maintenance.
•NEVER point the nail gun at people or yourself.
•When using this tool, safety clothing must be worn. Goggles,
gloves and earmuffs are recommended. Tie back long hair and do
not wear loose clothing.
•Do not allow children to use this tool. Never leave the tool
connected to the air supply before loading nails or staples.
5

OPERATING INSTRCUTIONS
NARROW CROWN STAPLER
1. To load the magazine
with staples,release the
magazine by squeezing
release trigger
2. Insert fasteners
into magazine. See
over leaf for
details.Then shut
magazine by pushing
fully upwards.
3. Check air supply is
at least 60 PSI.The gun
is now ready to use.
Press the head of the
gun onto the work
piece to be fastened
and squeeze the trigger
to fire staples.
6

BRAD NAILER
1. To load the magazine
with nails,release the
magazine by squeezing
click lever
2. Insert fasteners
into magazine. See
over leaf for
details.Then shut
magazine by pushing
fully upwards.
3. Check air supply is
at least 60 PSI.The gun
is now ready to use.
Press the head of the
gun onto the work
piece to be fastened
and squeeze the trigger
to fire nail.
7

34° ANGLE FINISH NAILER
8

9

34° ANGLE FINISH NAILER MAINTENANCE
10
