Craftsman 143.003508 User manual

SEARS
operator's
manual
MODEL NO. 143.003508
3.5 HORSEPOWER
10 INCH CUBIC (163 cc)
DISPLACEMENT
SOLID STATE IGNITION
CAUTION:
Read RULES for
Safe OPERATION
and INSTRUCTIONS
Carefully
ENGIN
• Operating
• Maintenance
•Repair Parts
_ CaliforniaProposition65WARNING: The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects or other reproductive harm.
Sold by SEARS, ROEBUCK AND CO., CHICAGO, IL 60684 U.S.A.
and SEARS CANADA, INC., TORONTO, ONTARIO, CANADA
I
PrintedinU.S.A. 4-1-00 181-1228-11

[ lllllllllt4lilimll J
MODELAND
D.O.M. DECAL
STARTER
HANDLE
OIL FILLPLUGAND DIPSTICK
RECOIL STARTER
FUEL
SPARK PLUG WIRE
SPARK PLUG
MUFFLER
AIR
31HECONTROL
CARBURETOR
BoI-rOM OF ENGINE
QIL DRAINPLUG
Figure 1
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED COULD A
ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND
FOLLOW ALL INSTRUCTIONS IN THIS MANUAL AND ANY PROVIDED WITH THE EQUIPMENT ON WHICH
THIS ENGINE IS USED BEFORE A'FrEMPTING TO OPERATING.
THESE SYMBOLS MAY APPEAR ON THE ENGINE:
I,.'1 I,.,_LOFF FOLL ----l--
FAST SLOW STOP C.OKE PR,MER
NOTE: EngineswhicharecertifiedtocomplywithCaliforniaand U.S.
EPAemissionregulationsfor SORE(SmallOffRoadEquipment),are
certifiedto operate on regularunleadedgasoline,and includethe
following emissioncontrolsystems:EngineModification(EM), and
Three-wayCatalyst(TWC) (ifsoequipped).
OIL & FUEL RECOMMENDATIONS
TO OPERATE ENGINE, YOU WILL NEED THE FOLLOWING:
(_) A CLEAN, HIGH QUALITY, DETERGENT OIL.
Be sure original container is marked:
A.P.I. service "SF"-"SJ".
FOR SUMMER (ABO_;E 32°F;0°C) USE SAE 30 OIL.
Using multigrade oil will increase oil consumption.
FOR WINTER (BELOW 32°F;0°C) USE SAE 5W30 OIL.
(SAE 10W is an acceptable substitute.)
DO NOT USE SAE lOW40 OIL.
OIL SUMP CAPACITY: 21 ounces (1-1/4 U.S. pints)
.62 liter
(_) A FRESH, CLEAN, UNLEADED REGULAR,
UNLEADED PREMIUM, OR REFORMULATED
AUTOMOTIVE GASOLINE ONLY. DO NOT USE
LEADED GASOLINE,
NOTE: DO NOT USE GASOLINE CONTAINING METHANOL
(WOOD ALCOHOL). Gasoline containing up to 10% ethanol or
grain alcohol ("Gasohol"), or up to 15% MTBE (Methyl Tertiary
Butyl Ether), may be used but requires special care when engine
is unused for extended pedods.
See "STORAGE" instructions of Page 4.
NOTE: Use clean oil and fuel and store in approved, clean
covered containers. Use clean fill funnels.
Never use "stale" gasoline leftover from last season or stored for
long periods. Page 1
IMPORTANT
KEEP THIS MANUAL HANDY AT ALL TIMES FOR FUTURE
REFERENCE. READ IT CAREFULLY AND FAMILIARIZE
YOURSELF WITH THE OPERATING, MAINTENANCE AND
SAFETY INSTRUCTIONS. THIS MANUAL ALSO CONTAINS A
COMPLETE PARTS LISTING.
BEFORE STARTING
X) READ ALL INSTRUCTIONS PROVIDED WITHTHE EQUIPMENT
ON WHICH THIS ENGINE IS USED.
(_) CHECK OIL LEVEL:
IMPORTANT: NEVER RUN ENGINE UNLESS OIL LEVEL IS
BETWEEN "FULL" AND "ADD" MARKS ON
DIPSTICK.
CHECK OIL LEVEL OFTEN DURING ENGINE BREAK-IN.
NEVER RUN ENGINE UNLESS OIL FILL PLUG ISTIGHTENED
SECURELY INTO OIL FILL HOLE,
A. POSITION EQUIPMENT SO ENGINE IS LEVEL.
B. Clean area around oil fill plug (see Figure 1).
C. Remove oil fill plug and dipstick.
D. Wipe dipstick clean, insert it into oil f hoe and t ghten
securely.
E. Re,move o.ilfill plug and check oil level. If level is not up,
to FULL marl_on diPsticK, add recommended o ,unt
itis. POUR SLOWLY. WiDe dipstick c ean each t me o
level is checked. DO NOT FILL ABOVE =FULL" MARK
ON DIPSTICK.
F. Replace oil fill plug and tighten securely.
See "MAINTENANCE" section for any future oil level and oil change
instructions (see Page 2). 181-1228-11

BEFORE STARTING (Continued)
FILL FUEL TANK with gasoline as specified inthe preceding
"OIL & FUEL RECOMMENDATIONS" item 2.
NEVER MIX OIL WITH GASOLINE
Never use =stale" gasoline left over from lastseason or stored for
long periods.
_L NEVER FILL FUEL TANK INDOORS. NEVER FILL FUELTANK
WH EN ENGINE IS RUNNING OR HOT. DO NOT SMOKE WHEN
I
[ FILLING FUEL TANK.
._ NEVER FILL FUEL TANK COMPLETELY. FILL TANK TO 1/2"
BELOW BOTTOM OF FILLER NECK TO PROVIDE SPACE
l FOR FUEL EXPANSION. WIPE ANY FUEL SPILLAGE FROM
ENGINE AND EQUIPMENT BEFORE STARTING ENGINE.
._ANY LIQUEFIED PETROLEUM (LPG) OR NATURAL GAS
FUEL SYSTEM MUST BE LEAKPROOF AND MEET ALL i
I APPLICABLE CODES AND REGULATIONS. i
(_) CHECK THE FOLLOWING:
_A. BE SURE EQUIPMENT IS IN NEUTRAL GEAR WITH 1
CLUTCHES, BELTS, CHAINS AND SAFETY SWITCHES /
DISENGAGED. (FOLLOW EQUIPMENT MANU- /
FACTURER'S INSTRUCTIONS.) THIS SHOULD PLACE|
ANY SAFETY SWITCHES IN SAFE STARTING POSITIONo i
B. Be sure spark plug wire isattached to spark plug (see Figure
1).
STARTING
,_ NEVER RUN ENGINE INDOORS OR IN ENCLOSED, POORL_
VENTILATED AREAS. ENGINE EXHAUST CONTAIN_
CARBON MONOXIDE, AN ODORLESS AND DEADLY GA!
(CARBON MONOXIDE IS ALSO PRESENT IN ENGINI
EXHAUST FROM LIQUID PETROLEUM (LPG) AND NATURAL
GAS FUEL SYSTEMS).
d_k KEEP HANDS, FEET, HAIR AND LOOSE CLOTHING AWA_
FROM ANY MOVING PARTS ON ENGINE AND EQUIPMENT
,_ WARNING: TEMPERATURE OF MUFFLER AND NEARB_
AREAS MAY EXCEED 150°F (65°C). AVOID THESE AREAS.
(_ Move ENGINE CONTROL (see Figure 1) to HI Position.
(_) START ENGINE WITH PRIMER:
1. Move equipment controlto =FAST" or =START" ifso equipped
(see equipment manufacturer's instructions).
2. The carburator on your engine has been completely adjusted
at the factory. When starting a cold engine, push primer button
firmly with your thumb 3 times, allowing primer bulb to
return completely to original position between pushes (figure
1). Below 55°F additional primes may be needed.
NOTE: Do notuse primerto restarta warm engine aftera short
shutdown.
3. Operate equipment control to release engine brake if so
equipped (see equipment manufacturer's instructions).
4. a) RECOIL STARTERS: Grasp starter handle (figure 2) and
pull rope out slowly untilyou feel drag. Let rope rewind slowly.
Pull rope with rapid, full arm stroke. Return rope slowly to
original position.
NOTE: Ifengine fails to start after three pulls, repeat steps
2-3 above.
ENGINE SPEED: Engine speed is controlled by the ENGINE
CONTROL see Figure 1).
ENGIN E CONTROL should be inHI positionfor highgrass conditions
and for most efficient bagging inheavy grass conditions, and in LOW
position for light grass, tdmming and for fuel economy.
STOPPING
_) Move ENGINE CONTROL (see Figure 1) to STOP.
(_) AFTER ENGINE IS STOPPED:
._A. DISCONNECT SPARK PLUG WIRE FROM SPARK PLU(
AND ATTACH IT TO RETAINING POST (see Figure 3).
._B. NEVER STORE ENGINE WITH FUEL IN TANK INDOOR!
OR IN ENCLOSED, POORLY VENTILATED AREAS
WHERE FUEL FUMES MAY REACH AN OPEN FLAME
SPARK OR PILOT LIGHT AS ON A FURNACE, WATEI
HEATER, CLOTHES DRYER OR OTHER GAS APPLIANCE,
ROPE GUIDE
Figure2
fr
SPARKPLUG
3WIRE
RETAININGPOST
Figure3
MAINTENANCE
,_ WARNING: TEMPERATURE OF MUFFLER AND NEARBYI
AREAS MAY EXCEED 150°F (65°C). AVOID THESE AREAS. I
O
@
CHECK OIL LEVEL:
Check oillevel everyfive(5)operatinghoursoreachtime engine
isused.See "_ CHECKOILLEVEL"in"BEFORESTARTING"on
Page 1.
CHANGE OIL:
Change oil after first two (2) operating hours and every 25
operating hours thereafter, more often if operated in extremely
dusty or dirty conditions. Change oil while engine isstillwarm from
recent runninc.
,_A. DISCONNECT SPARK PLUG WIRE FROM SPARK PLUG
AND ATI'ACH IT TO RETAINING POST (see Figure 3).
B. Position equipment so engine oil drain plug is lowest point on
engine.
C. Remove oil drain plug and oil fill plug to drain oil (see Figure
1).
D. Replace oil drain plug and tighten securely.
E. Fill oil sump with recommended oil. See "OIL & FUEL
RECOMMENDATIONS" and "CHECK OIL LEVEL" on Page
1.
F. Replace oil fill plug and tighten securely.
G. Connect spark plug wire to spark plug.
H. Wipe up any spilled oil and/or gasoline.
NOTE: Ifitisdifficulttoreach the oildrain plug. drain fuel. Remove
oil fill plug and tip mower on its side. Drain oil into a suitable
container.
Page 2 181-1228oll

MAINTENANCE (Continued)
(_) AIR CLEANER (see Figure4):
NEVER RUN ENGINE WITHOUT COMPLETE AIR CLEANER
INSTALLED ON ENGINE.
Replace filter once ayear or more often ifused in extremely dusty
or dirty conditions.
DO NOT ATTEMPT TO CLEAN OR OIL FILTER.
Replacement filters are available at any Sears Roebuck and Co.
(or Sears Canada, Inc.) Service Center. To install new filter,
proceed as follows:
A. Turn cover to the left (counterclockwise) and remove it and
filter from flange. Discard filter.
B. Clean cover and flange thoroughly.
C. Insert new filter into cover.
D. Position cover and filter against flange with tab on cover
inserted into lower left corner of slot in flange.
E. Push cover firmly against flange and turn it to the right
(clockwise) as far as it will go. Be sure retainers are locked
around flange.
SLOT
FLANGE RNCOVER
_' TO THE LEFT
w(COUNTER-
CLOCKWISE)
TO REMOVE
RETAINER
3OVER
TAB
TO THE RIGHT
(CLOCKWISE)
TOTIGHTEN
MAINTENANCE (Continued)
(_) SPARK PLUG (see Figure 5):
This spark ignitionsystem meets allrequirements of'theCanadian
Interference-Causing Equipment Regulations. This engine
complies with all current Australian and New Zealand limitations
regarding electromagnetic interference.
Check spark plug yearly or every 100 operating hours.
A. Clean area around spark plug.
B. Remove and inspect spark plug.
C. Replace spark plugifelectrodes are pitted,burned orporcelain
is cracked. For replacement use Champion RJ-19LM or
equivalent.
NOTE: A resistor spark plug must be used for replacement.
D. Check electrodes gap with wire feeler gauge and set gap at
.030 if necessary.
E. Install spark plug, tighten securely.
ELECTRODES
,030 GAP
Figure 5
(_ COOLING SYSTEM (see Figure1):
IMPORTANT: Frequentlyremoveanygrassclippings,dirtand
debrisfrom coolingfins,air intakescreenand leversandlinkage
(seeFigure1).Thiswillhelpensureadequatecoolingandcorrect
enginespeed.
(_) CHECK ENGINE AND EQUIPMENTOFTEN FOR LOOSE NUTS, I
BOLTS AND ATTACHMENTS, AND KEEP THESE ITEMS
n' TIGHTENED,
Figure 4
Page 3 181-1228-11

ADJUSTMENTS
DO NOT MAKE UNNECESSARY ADJUSTMENTS. FACTORY
SETTINGS ARE SATISFACTORY FOR MOST APPLICATIONS AND
CONDITIONS. IF ADJUSTMENTS ARE NEEDED, PROCEED AS
FOLLOWS:
CARBURETOR
If you think your carburetor needs adjusting, see your nearest
SEARS, ROEBUCK AND CO. (OR SEARS CANADA, INC.)
SERVICE CENTER. Engine performance should not be affected
at altitudes up to 7,000 feet. For operation at higher elevations,
contact your nearest SEARS, ROEBUCK AND CO. (OR SEARS
CANADA, INC.) SERVICE CENTER.
(_ ENGINE SPEED
,_NEVER TAMPER WITH ENGINE GOVERNOR WHICH IS
FACTORY SET FOR PROPER ENGINE SPEED.
OVERSPEEDING ENGINE ABOVE FACTORY HIGH SPEED
SETTING CAN BE DANGEROUS.
CHANGING OF ENGINE-GOVERNED SPEED WILL VOID
ENGINE WARRANTY.
STORAGE 7
_k NEVER STORE ENGINE WITH FUEL IN TANK INDOORS OR /
IN ENCLOSED, POORLY VENTILATED AREAS, WHERE FUEL
FUMES MAY REACH AN OPEN FLAME, SPARK OR PILOT j
LIGHT AS ON A FURNACE, WATER HEATER, CLOTHES |
DRYER OR OTHER GAS APPLIANCE. |
IFENGINE ISTO BE UNUSED FOR 30 DAYS OR MORE, PREPARE
AS FOLLOWS:
(_) DRAIN FUEL SYSTEM:
A. Remove all gasoline from carburetor and fuel tank to prevent
gum deposits from forming on these parts and causing possible
malfunction of engine.
_lb DRAIN FUEL INTO APPROVED CONTAINER OUTDOORS,
AWAY FROM OPEN FLAME. BE SURE ENGINE IS COOL.
DO NOT SMOKE.
B. Run engine until fuel tank is empty and engine stops due to
lack of fuel.
NOTE:
NOTE:
If "Gasohol" has been used, complete above
instructions and then put 1/2 pint of unleaded
gasoline into fuel tan k and repeat above instructions.
Fuel stabilizer (such as STA-BIL) is an acceptable
alternative in minimizing the formation of fuel gum
deposits during storage. Add stabilizer to gasoline
in fuel tank or storage container. Always follow mix
ratio found on stabilizer container. Run engine at
least 10 minutes after adding stabilizer to allow itto
reach carburetor,
STORAGE (Continued)
(_ CHANGE OIL:
Changeoilifithasnotbeenchangedinthelastthree(3)months.
See "CHANGE OIL"instructionsin"MAINTENANCE" section.
(_ OIL CYLINDER BORE:
A. Remove spark plug. Squid one (1) oz. (30 ml) of clean engine
oil into spark plug hole.
B. Cover spark plug hole with a rag.
C. Crank engine over, slowly, several times.
A AVOID SPRAY FROM SPARK PLUG HOLE WHENI
CRANKING ENGINE OVER SLOWLY. J
D. Install spark plug. Do notconnectspark plug wire.
(_) CLEAN ENGINE:
Remove any clippings, dirt, or chaff from exterior of engine.
GENERAL
Just as your automobile needs professional mechanical maintenance
from time to time, so does your Craftsman engine. Replacement of the
spark plug and air cleaner is made necessary by NORMAL use.
Professional Air-Cooled Engine Service is as close as your nearest
Sears Roebuck and Co. (or Sears Canada, Inc.) Service Center.
A yearly check-up or tune-up by Sears is agood idea to avoid
breakdowns or delay.., do it at the end of the season, then you're
ready for the next. We even prepare it for storage for you.
Page 4 181-1228-11

TROUBLESHOOTING
THE FOLLOWING MAY HELP AVOID A DELAY IN YOUR WORK OR
SAVE THE EXPENSE OF A SERVICE CALL.
ENGINE FAILS TO START OR STARTS WITH DIFFICULTY
CAUSE
Controls not in start position.
Spark plug wiredisconnected from sparkplug.
Sparkplug fouled.
Spark plug porcelain cracked.
Insufficient fuel.
Water or dirt in fuel.
Improper carburetor adjustment
ENGINE LACKS POWER
CAUSE
Dirty air cleaner.
Improper carburetor adjustment.
Lack of lubricaiton.
ENGINE MISSES UNDER LOAD
CAUSE
Spark plug fouled.
Spark plug porcelain cracked.
Improper spark plug gap.
Improper carburetor adjustment
REMEDY
Move ENGINE CONTROL or equipment control to "HI" or
START postion. See "STARTING" instructions in this
manual.
Connect SPARK PLUG WIRE to SPARK PLUG.
Remove SPARK .PLUG and clean it. See "SPARK
PLUG" instructions in "MAINTENANCE" section in this
manual.
Install new spark plug,
Fill FUEL TANK per "BEFORE STARTING" instructions.
!Drain FUEL TANK and re-fill with clean, fresh gasoline.
:See "BEFORE STARTING" instructions in this manual.
Adjust carburetor (if applicable). See "ADJUSTMENTS"
section in this manual.
REMEDY
Replace or clean air cleaner per "AIR CLEANER"
instructions in "MAINTENANCE" section in this manual,
Adjust carburetor (if applicable). See "ADJUSTMENTS"
section in this manual.
Fill oil sump to proper level. See "BEFORE STARTING"
instructions section in this manual.
REMEDY
Remove SPARK PLUG and clean it. See "SPARK
PLUG" instructions in "MAINTENANCE" section in this
manual.
Install new SPARK PLUG.
Regap SPARK PLUG electrodes. See "SPARK PLUG"
instructions in "MAINTENANCE" section in this manual.
Adjust carburetor (if applicable). See "ADJUSTMENTS"
section in this manual.
Page 5 181-1228-11

SEARS, ROEBUCK AND CO.
Federal and California Emission Control Systems Limited Warranty
Small Off-Road Engines
CALIFORNIA & US EPA EMISSION CONTROL
WARRANTY STATEMENT
The U. S. Environmental Protection Agency ("EPA"), the California Air Resources
Board ("CARB") and Sears, Roebuck and Co. are pleased to explain the Federal
and California Emission Control Systems Warranty on your new small off-road
engine. In California, new 1995 and later small off-road eogmes must be
designed, built and equipped to meet the State's stringent anti-smog standards
In other states, new 1997 and later model year engines must be designed, built
and equipped, at the time of sale. to meet the U.S. EPA regulations for small non-
road engines. Sears, Roebuck and CO. wilt warrant the emission control system
on your small off-road engine for the periods of time listed below, provided there
has been no abuse, neglect, unapproved modification, or improper maintenance
of your small off-road engine.
Your emission control system may include parts such as the carburetor, ignition
system and exhaust system Also included may be the compression release
system and other emission-related assemblies
Where a warrantable condition exists, Sears, Roebuck and Co. wil_ repair your
small off-road engine at no cost to you for diagnosis, parts and labor
MANUFACTURER'S EMISSION CONTROL SYSTEM
WARRANTY COVERAGE
Emission control systems on 1995 and tater model year California small off-road
engines are warranted for two years as hereinafter noted. In other states, 1997
and later model year engines are also warranted for two years. If, during such
warranty period, any emission-related part on your engine is defective in materials
or workmanship, the part will be repaired or replaced by Sears, Roebuck and Co.
OWNER'S WARRANTY RESPONSIBILITIES
As the small off-road engine owner, you are responsible for the performance of
the required maintenance listed in your Owner's Manual, but Sears, Roebuck and
Co. will not deny warranty solely due to the lack of receipts or for your failure to
provide written evidence of the performance of all scheduled maintenance.
AS the small off-road engine owner, you should, however, be aware that Sears,
Roebuck and Co. may deny you warranty coverage if your small off-road engine
or a part thereof has failed due to abuse, neglect, improper maintenance or
unapproved modifications
You are responsible for presenting your small off-road engine to a Sears,
Roebuck and Co. Authorized Service Outlet as soon as a problem exists. The
warranty repairs should be completed in a reasonable amount of time, not to
exceed 30 days
Warranty service can be arranged by contacting either aSears, Roebuck and Co
Authorized Service Outlet, or by contacting Sears, Roebuck and Co at
1-800-473-7247
IMPORTANT NOTE
This warranty statement explains your rights and obligations under the Emission
Control System Warranty ("ECS Warranty") which is provided to you by Sears,
Roebuck and Co. pursuant to California law. See also the Sears, Roebuck and
Co. Limited Warranties for Sears, Roebuck and Co. which is enclosed therewith
on a separate sheet and also is provided to you by Sears, Roebuck and Co. The
ECS Warranty applies only to the emission control system of your new engine.
TO the extent that there is any conflict in terms between the ECS Warranty and
the Sears, Roebuck and Co. Warranty, the ECS Warranty shall apply except in
any circumstances in which the Sears, Roebuck and CO. Warranty may provide a
longer warranty period. Both the ECS Warranty and the Sears, Roebuck and Co
Warranty describe important rights and obligations with respect to your new
engine.
Warranty service can only be performed by a Sears. Roebuck and Co. Authorized
Service Outlet At the time of requesting warranty service, evidence must be
presented of the date of sale to the original purchaser The purchaser shall pay
any charges lor making service calls and/or for transporting the products to and
from the place where the inspection and/or warranty work is perfarmed The
purchaser shall be responsible for any damage or loss incurred in connection with
the transportation of any engine or any part(s) thereof submitted for inspection
and/or warranty work
If you have any questions regarding your warranty rights and responsibilities, you
should contact Sears, Roebuck and Co at 1-800-473-7247
EMISSION CONTROL SYSTEM WARRANTY
Emission Control System Warranty ("ECS Warranty") for 1995 and later model
year California small off-road engines (for other states, 1997 and later model year
engines):
AAPPLICABILITY: This warranty shall apply to 1995 and later model year
California small off-road engines (for other states, 1997 and later model year
engines). The ECS Warranty Period shall begin on the date the new engine or
equipment is delivered to its original, end-use purehaseL and shall continue for 24
consecutive months thereafter
B. GENERAL EMISSIONS WARRANTY COVERAGE: Sears, Roebuck and Co.
warrants to the original, end-use purchaser of the new engine or equ;pment and
to each subsequent purchaser that each of its small off-road engines is:
1. Designed, built and equipped so as to conform with al! applicable
regulations adopted by the Air Resources Board pursuant to its authority in
Chapters 1 and 2, Part 5, Division 26 of the Health and Safety Code, and
2. Free from defects in materials and workmanship which, at any time during
the ECS Warranty Period. will cause a warranted emissions-related part to
fai! to be identical in all material respects to the part as described in the
eogme manufacturer's application for certification
C. The ECS Warranty only pertains to emissions-related parts on your engine, as
follows:
1.
2.
Any warranted, emissions-related parts which are not scheduled for
replacement as required maintenance in the Owner's Manual shall be
warranted for the ECS Warranty Period. If any such part fails during the
ECS Warranty Period, it shall be repaired or replaced by Sears, Roebuck
and Co, according to Subsection 4 below. Any such part repaired or
replaced under the ECS Warranty shall be warranted for any remainder of
the ECS Warranty Period.
Any warranted, emissions-related part which is scheduled only for regular
inspection as specified in the Owner's Manual shall be warranted for the
ECS Warranty Period. A statement in such written instructions to the
effect of "repair or replace as necessary", shall not reduce the ECS
Warranty Period. Any such part repaired or replaced under the ECS
Warranty shall be warranted for the remainder of the ECS Warranty
Period
3.
4.
5.
6.
7
8
g.
Any warranted, emissions-related part which is scheduled for replacement
as required maintenance in the Owner's Manual, shall be warranted for the
period of time prior to the first scheduled replacement point for that part If
the part fails prior to the first scheduled replacement, the part shall be
repaired or replaced by Sears. Roebuck and Co according to Subsection
4 below. Any such emissions-related part repaired or replaced under the
ECS Warranty, shall be warranted for the remainder of the ECS Warranty
Period prior to the first scheduled replacement point for such emissions-
related part.
Repair or replacement of any warranted, emissions-related part under this
ECS Warranty shall be performed at no charge to the owner at a Sears,
Roebuck and Co. Authorized Service Outlet
The owner shall not be charged for diagnostic labor which leads to the
determination that a part covered by the ECS Warranty is in fact defective,
provided that such diagnostic work is performed at a Sears, Roebuck and
CO. Authorized Service Outlet.
Sears, Roebuck and Co shall be liable for damages to other original
engine components or a proved modifications proximately caused by a
failure under warranty ofPa_nemission-related part covered by the ECS
Warranty.
Throughout the ECS Warranty Period, Sears, Roebuck and CO. shall
maintain a supply of warranted emission-related parts sufficient to meet
the expected demand for such emission-related parts
Any Sears, Roebuck and Co. authorized and approved emission-related
replacement part may be used in the performance of any ECS Warranty
maintenance or repair and will be provided without char'ge to the owner.
Such use shall not reduce Sears, Roebuck and Co. EC_ Warranty
obligations.
Unapproved add-on or modified parts may not be used to modify or repair
a Sears, Roebuck and Co. engine. Such use voids 1his ECS Warranty and
shall be sufficient grounds for disallowing an ECS Warranty claim, Sears,
Roebuck and Co. shall not be liable hereunder for failures of any
warranted parts of a Sears, Roebuck and Co eoglne caused by the use of
such an unapproved add-on or modified part
EMISSION-RELATED PARTS INCLUDE THE FOLLOWING:
1 Carburetor Assembly and tts Internal Components
a) Fuel filter
b) Carburetor gaskets
c) Intake pipe
2. Air Cleaner Assembly
a) Air filter element
3. Ignition System, including:
a) Spark plug
b) ignition module
c) Flywheel assembly
4 Catalytic Muffler (if so equipped)
a) Muffler gasket (if so equipped)
b) Exhaust manifold (if so equipped)
5 Crankcase Breather Assembly and its Components
a) Breather connection tube
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. 10122/99 EpA/CAR B
Page 6181-1228-11

CRAFTSMAN 4-CYCLE ENGINE MODEL: 143.003508
O-370K
9OO
4OO
135
370B
370C
11o_ _\325
103_
101
126
125 /
262J"_
178 73
j 287
298
,285
300
Page 7 181-1228-11

CRAFTSMAN 4-CYCLE ENGINE MODEL:143.003508
Ref.
No.
1
2
6
7
12
12A
12B
14
15
16
17
18
19
20
3O
4O
4O
4O
41
41
41
42
42
42
43
45
46
48
50
52
69
70
72
72A
73
75
8O
81
82
83
86
89
90
92
93
100
101
103
110
119
120
125
126
130
135
150
Part
No.
37280
26727
33734
36557
36775
36558
36694
28277
30589
34839A
31335
651018
36281
32600
37141
35544A
35545A
35546
35541
35542
35543
35547A
35548A
35549
20381
36777
32610A
27241
37032
29914
*35261
34311E
30572
28534
28833
27897
30574A
30590A
30591
30588A
650488
611004
611112
650815
650816
34443C
610118
651007
36230
*37028
36825
37288
37289
6021A
35395
31672
Ref. Part
Part Name No. No.
Cylinder (Incl. 2,20 & 150) 151 31673
Dowel Pin 151A 40017
Breather Element 169 *36783
Breather Ass'y. (Incl. 6 & 12A) 172 36784
Breather Tube 174 30200
Breather Cover & Tube (Incl. 12B) 178 29752
Breather Tube Elbow 179 30593
Washer 182 6201
Governor Rod (Incl. 14) 184 *26756
Governor Lever 185 36785
Governor Lever Clamp 186 34337
Screw, Torx T-15, 8-32 x 19/64" 200 35727
Extension Spring 202 36482
Oil Seal 203 31342
Crankshaft 204 651029
Piston, Pin & Ring Set (Std.) 205 651019
Piston, Pin & Ring Set (.010" OS) 206 610973
Piston, Pin & Ring Set (.020" OS) 207 34336
Piston & Pin Ass'y. (Std.) (Incl. 43) 209 30200
Piston & Pin Ass'y. (.010" OS) (Incl. 215 32410
43) 223 650451
Piston & Pin Ass'y. (.020" OS) (Incl. 224 *36786
43) 238 650932
Ring Set (Std.) 239 *34338
Ring Set (.010" OS) 241 35797
Ring Set (.020" OS) 245 35066
Piston Pin Retaining Ring 250 35065
Connecting Rod Ass'y. (Incl. 46) 260 36980
Connecting Rod Bolt 261 30200
Valve Lifter 262 650831
Camshaft (NCR) 275 36790A
Oil Pump Ass'y. 277 650988
Mounting Flange Gasket 285 35000A
Mounting Flange (Incl. 72 thru 83, 287 650926
306) 290 29774
Oil Drain Plug (Incl. 73) 292 26460
Oil Drain Plug 298 28763
Drain Plug Gasket 300 36916
Oil Seal 301 36246
Governor Shaft 305 35647
Washer 306 *36996
Governor Gear Ass'y. (Incl. 81) 307 35499
Governor Spool 309 650562
Screw, 1/4-20 x 1-1/4" 310 35648
Flywheel Key 313 34080
Flywheel
Belleville Washer
Flywheel Nut
Solid State Ignition
Spark Plug Cover
Screw, Torx T-15, 10-24 x 15/16"
Ground Wire
Cylinder Head Gasket
Cylinder Head
Exhaust Valve (Std.) (Incl. 151)
Intake Valve (Std.) (Incl. 151)
Screw, 5/16-18 x 1-1/2"
Resistor Spark Plug (RJ19LM)
Valve Spring
Part Name
Valve Spring Cap
Intake Valve Seal
Valve Cover Gasket
Valve Cover
Screw, 10-24 x 9/16"
Nut & Lock Washer, 1/4-28
Retainer Clip
Screw, 1/4-28 x 7/8"
Carburetor To Intake Pipe Gasket
Intake Pipe
Governor Link
Control Bracket (Incl. 202 thru 206)
Compression Spring
Compression Spring
Screw, Torx T-10, 5-40 x 7/16"
Screw, Torx T-10, 6-32 x 41/64"
Terminal
Throttle Link
Screw, 10-24 x 9/16"
Control Knob
Screw, 1/4-20 x 1"
Intake Pipe Gasket
Screw, 10-32 x 49/64"
Air Cleaner Gasket
Air Cleaner Collar
Air Cleaner Filter
Air Cleaner Cover
Blower Housing
Screw, 10-24 x 9/16"
Screw, 1/4-20 x 1/2"
Muffler
Screw, 1/4-20 x 2-5/16"
Starter Cup
Screw, 8-32 x 21/64"
Fuel Line
Fuel Line Clamp
Screw, 10-32 x 35/64"
Fuel Tank (Incl. 292 & 301)
Fuel Cap
Oil Fill Tube
"O"-Ring
"O"-Ring
Screw, 10-32 x 3/8"
Dipstick
Spacer
*Indicates Parts Included in
Gasket Set, Ref. No. 400.
Page 8 181-1228-11

CRAFTSMAN 4-CYCLE ENGINE MODEL: 143.00350
Ref.
No.
370A
370B
370C
370K
370R
380
390
400
Part
No.
36261
35169
37318
36695
37317
640262
590732
37029A
Ref. Part
Part Name No. No.
Lubrication Decal 416
Control Decal
Primer Decal (3X) 417
Starter Decal 900
Warning Decal
Carburetor (Incl. 184) 900
Rewind Starter
(NOTE: This engine could have
been built with 590738 starter).
Gasket Set (Incl. Items Marked *)
36085
650821
Part Name
Spark Arrestor Kit (Incl. 417)
(Optional)
Screw, 10-32 x 1/2" (Optional)
Replacement Engine 750822A,
order from 71-999
Replacement Short Block NONE
RPM High 2700 to 3000
RPM Low 2400 to 2700
*Indicates Parts Included in
Gasket Set, Ref. No. 400.
CARBURETOR NO. 640262
Ref. Ref.
No. No. Part Name
64O262
1 631615
2 631767
4 *631184
5*631183
6 640070
7*650506
16 631807
17 651(_5
18 630766
20 640018
20A 640200
25 631867
27 °631024
28 632019
29 *631028
30 *631021
31 6310P-2
35 640259
36 64O08O
36A 632766
37 *632547
40 640175
44 "27110A
47 *630748
48 *631027
60 632760B
Carburetor (Incl. 184 of Engine Parts
List)
Throttle Shaft &Lever Assembly
Throttle Return Spring
Dust Seal Washer
Dust Seal (Throttle)
Throttle Shutter
Shutter Screw
Fuel Fitting
Throttle Crack Screw/Idle Speed Screw
Tension Spring
Idle Restrictor Screw
Idle Restrictor Scrwe Cap (Black)
Float Bowl
Float Shaft
Float
Float Bowl "O" Ring
Inlet Needle, Seat, & Clip (Incl. 31)
Spring Clip
Primer Bulb/Retainer Ring
Main Nozzle Tube
CarburetorTube
"O"Ring, Main Nozzle Tube
High Speed Bowl Nut
Bowl Nut Washer
Welch Plug, Idle Mixture Well
Welch Plug, Atmospheric Vent
Repair kit (Incl. Items Marked *)
Page 9 181-1228-11

REWIND STARTER NO. 590732
-11
12
BL5
O--2
Ref. Part
No. No. Part Name
1
2
3
4
5
6
7
8
11
12
13
590732 Rewind Starter
i590599A Spdng Pin (IncL 4)
590600 Washer
590696 Reb_iner
590601 Washer
590697 Brake Spring
590698 Starter Dog
590699 Dog Spring
590700 Pulley Ass'y. (IncL 9 & 10)
590695 Starter Housing Ass'y, (40 degree
grommet)
590535 Starter Rope (Length 98" x 9/64" dia.)
590701 Starter Handle
STARTER NO. 590738
V--14
\
/
13
12
ml m--_
--8
Ref. Part
No. No. Part Name
3
6
7
8
11
12
13
14
590738
590740
590616
590617
590618A
590687A
590535
590701
590741
Rewind Starter (Optional)
Retainer
Starter Dog
Dog Spring
Pulley & Rewind Spring Ass'y.
Starter Housing Ass'y. (40 degree
grommet)
Starter Rope (Length 98" x 9/64" dia.)
Starter Handle
Locking Tab
Page 10 181-1228-11

SEARS
operator's
manual
MODEL NO. 143.004014
4.0 HORSEPOWER
10 CUBIC INCH (163 cc)
DISPLACEMENT
SOLID STATE IGNITION
CAUTION:
Read RULES for
Safe OPERATION
and INSTRUCTIONS
Carefully
How to ORDER Repair Parts
The Model Number can be found on a decal on the blower
housing (See Figure 1). Always mention the Model Number
when requesting service or repair parts for your Craftsman
Engine.
All parts listed hereip ma_ be ordered from any SEARS,
ROEBUCK AND CO. or SEARS CANADA, INC. retail or catalog
store. If the parts you need are not stocked locally, your order
will be electronically transmitted to a Sears Repair Parts
Distribution Center for expedited handling.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION AS SHOWN IN THIS LIST.
1. The PART NUMBER
2. The PART DESCRIPTION
3. The MODEL NUMBER
4. The NAME OF ITEM - ENGINE
"Your Sears merchandise has added value when you consider that Sears has
service units nationwide staffed with Sears trained technicians.., professional
technicians specifically trained on Sears products, having the parts, tools and
equipment to insure that we meet our pledge to you ... we service what we sell."
Sold by SEARS, ROEBUCK AND CO., CHICAGO, IL 60684 U.S.A.
and SEARS CANADA, INC., TORONTO, ONTARIO, CANADA
181-1228-11
