Craftsman 143.996514 User manual

SEARS
operator's
manual
MODEL NO. 143.996514
6.5 RESERVE POWER
12 CUBIC INCH (185 cc)
DISPLACEMENT
SOLID STATE IGNITION
CAUTION:
Read RULES for
Safe OPERATION
and INSTRUCTIONS
Carefully
NGIN
•Operating
•Maintenance
• Repair Parts
A
Pdnted In U.S.A.
California Proposition 65 WARNING: _he engine exhaust from this product contains chemicals [
known to the Stateof California to cause cancer, birthdefects or other reproductive harm. I
Sold by SEARS, ROEBUCK AND CO., CHICAGO, IL 60684 U.S.A.
and SEARS CANADA, INC., TORONTO, ONTARIO, CANADA
2-1-99 181-1177-11

MODELAND
D.O.M. DECAL
STARTER
STARTER HANDLE
SCREEN
OIL FILL AND DIPSTICK FUEL FILL
CAP
/
FFUEL TANK
CLEANER
PRIMER
OIL FILL PLUG
AND DIPSTICK
LEVERS &
LINKAGE
CARBURETOR
MUFFLER BO*I'i'OM OF ENGINE
Figure 1
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED COULD
ENDANGER THE PERSONAL SAFETY AND/ORPROPERTY OF YOURSELF AND OTHERS. READ AND 41t
FOLLOW ALL INSTRUCTIONS IN THIS MANUAL AND ANY PROVIDED WITH THE EQUIPMENT ON WHICH
THIS ENGINE IS USED BEFORE ATrEMPTING TO OPERATING.
THESE SYMBOLS MAY APPEAR ON THE ENGINE:
MBB
OFF FULL
FAST BLOW STOP CHOKE
ENGINES WHICH ARE CERTIFIED TO COMPLY WITH CALIFORNIA AND IMPORTANT
U.S. EPA EMISSION REGULATIONS FOR ULGE ENGINES: Arecoltifled to
O_ta on regularunleaded geaoilca. Include the toilowlng emissioncontrol KEEP THIS MANUAL HANDY AT ALL TIMES FOR FUTURE REF-
system(s): EM, TWC (if so equipped): Do not Include any user adjustable ERENCE. READ IT CAREFULLY ANO FAMILIARIZE YOURSELF
features -therefum no other adjustments am needed. WITH THE OPERATING, MAINTENANCE AND SAFETY INSTRUC-
OIL & FUEL RECOMMENDATIONS
TO OPERATE ENGINE, YOU WILL NEED THE FOLLOWING:
(_ A CLEAN, HIGH QUALITY, DETERGENT OIL.
Be sure original container is marked: A.P.I, service "SF" - "SJ'.
FOR SUMMER (ABOVE 32q=; 0aC) USE SAE 30 OIL
TIONS. THIS MANUAL ALSO CONTAINS A COMPLETE PARTS
LISTING.
BEFORE STARTING
Using mul_rade bll will increase oil consumption. _READ ALL INSTRUCTIONS PROVIDED WITH THE EQUIPMENT ON
FORWINTER(BELOW32aF;0eC)USESAESW30OIL( SAE10wIsen 0WHICH THIS ENGINE IS USED.
acceptable subetltute.)
DO NOT USE 10W40 OIL.
OIL SUMP CAPACITY: 21 ounces (1-1/4 U.S. pints)
.62 liter
(_ A FRESH, CLEAN, UNLEADED REGULAR, UN-
LEADED PREMIUM, OR REFORMULATED AUTO-
MOTIVE GASOLINE ONLY. DO NOT USE LEADED
GASOLINE.
THIS ENGINE IS EQUIPPEDWITH A FEDERALLY MANDATEDMECH*.
ANISM WHICH STOPS THE ENGINE. DO NOT INTERFERE WITH OR
BYPASS THIS MECHANISM. PARTS OF THE MECHANISM MAY BE
SUBJECT TOWEAR AND MUST BECHECKED ONCE AYEAR BY AN
AUTHORIZED SEARS ROEBUCK AND'CO. (OR SEARS CANADA,
INC.) @ERVICE CENTER. IN THE EVENT THE MECHANISM FAILS
FOR ANY REASON, YOU MUST NOT USE THE ENGINE UNTIL
CORRECTED BY AN AUTHORIZED SEARS ROEBUCK AND CO. (OR
SEARS CANADA_ INC.) SERVICE CENTER.
NOTE: OONOTUSEGASOUNECONTAININGMETHANOL(WDOD ,_ DISCONNECTSPARKPLUG WlREFROMSPARKPLUGAND AT.
ALCOHOL). GasolinecontainingUpto 10% ethanolor grainak:ohoi iK_ TACHITTO RETAININGPOST(seeFigure6 on Page3).
( Gssohol), orupto 15% MTBE(MethylTertiaryButylEther),maybe
usedbut requiresspecialcarewhen englne!s unusedfurextended _'_j INSTALL ENGINE BRAKE CABLE AND STARTER ROPE:
pededs. BRAKE CABLE (see Figure 2):
See "STORAGE"instructionsof Page5. Attach enginebrake cable to brake mechanism as shown.
NOTE:Usedean oil and tual and storeIn approved,cleancovered WARNING: Use onlytho cable screwthat came withtheengine
contaicam,Useclean fillfunnels, brakecable. Ifthecable screwhasbeen lost,gota newone t_om
Neveruse"stale"gasolineleltoverfromlastseasonorstoredforlong a Sears, Roebuck and Co. (or Sears Canada, Inc.) Service
Center. Any cable screwused mustbe the same lengthas the
periods, odginalcable screw.
Page 1 181-1177-11

BEFORE STARTING (Continued) BEFORE STARTING (Continued)
STARTER ROPE:
A. Dopingsmowercontrolbar(seeFigure3) againstmowerhandle _J
and hold itinthisposition.
B, Pullat least2 feet of starter ropeout of Stader and tie aslipknotat
starterto prevent starter rope horn rewindingback Intostarter.
C. Slide rope stop(see Figere2) ontostarterropeand feed starterrope
through rope guide on mower handle (see Figure 4).
D. Feed starter rope throughstarter handid(eae Figure5) and ite a isft
hand knot, leaving 1/2 inch to 1 inch of stader rope extending
beyond left hand knot. DO NOT PULL LEFT HAND KNOT INTO
STARTER HANDLE YET.
E. With starter handle resting on rope guide (see Figure 4), check
starter rope for slack. If there is any slack, pull more starter rope
through starter handle end rai_.ata _hand Imotto eliminateslack.
F. Untie slip knotat starter,
G, Pult left hand knot into starter handle,
H. Position rope stop 2 to 3 inches from starter (see Figure 2) and
fasten it to starter robe by gdpplng it with pliers and forcing staple
through starter rope untilstaple iseven withoutside of rope stop.
(_ CHECK OIL LEVEL:
IMPORTANT: NEarERRUNENGINEUNLESSOIL LEVELIS
BETWEEN"FULL" AND"ADD" MARKSON
DIPSTICK.
CHECK OIL LEVEL OFTEN DURING ENGINE BREAK-IN.
NEVER RUN ENGINE UNLESS OIL RLL PLUG IS TIGHTENED
SECURELY INTO OIL RLL HOLE.
A. POSITION EQUIPMENT SO ENGINE IS LEVEL.
B. Clean area around oilfill plug (see Figure 1).
C. Remove oilfill plug and dipstick.
D, Wipe dipstickclean, insert it intooll fillhole and tighten securely.
E. Remove oil till plug and ched( oil isvai. If levoi is not up to "FULL"
mark on dipstick,add ranommandedoil,untilit is,POUR SLOWLY.
Wipe dipstickclean each time oil level Ischecked. DO NOT FILL
ABOVE "FULL" MARK ON DIPSTICK.
F. Replace oil fill plug and tighten sanumly. See "MAINTENANCE"
sectionfor any future oillevel and oil change Instructions (see Page
3)
STARTER
ROPE STOP 2TO3
INCHES
STARTER
ROPE
FILL FU EL TAN K withgasolineas specifiedInthe preceding
"OIL & FUEL RECOMMENDATIONS," item 2.
NEVER MIX OIL WITH GASOUNE
Never use"stale"gasolineleftoverfromlastseasonor storedfor
long pededs.
_EVER RLL FUELTAN KINDOORS, NEVER FILL FUELTANK
WHEN ENGINE ISRUNNING OR HOT, DO NOT SMOKE WHEN
FILLING FUEL TANK.
A NEVER FILL FUEL TANK COMPLETELY. FILL TANK TO 1/2"
BELOW Bo'n'OM OF FILLER NECK TO PROVIDE SPACE
IFOR FUEL EXPANSION. WIPE ANV FUEL SPILLAGE FROM
ENGINE AND EQUIPMENT BEFORE STARTING ENGINE.
4_kAHY LIQUEFIED PETROLEUM (LPG) OR NATURAL GAS
FUEL SYSTEM MUST BE LEAKPROOF AND MEET ALL
[APPLICABLE CODES AND REGULATIONS.
(_) CHECK THE FOLLOWING:
A. BE SURE EQUIPMENT IS IN NEUTRAL GEAR WITH
CLUTCHES, BELTS, CHAINS AND SAFETY SWITCHES I
DISENGAGED. (FOLLOW EQUIPMENT MANUFACTUR-
ER S INSTRUCTIONS.) THIS SHOULD PLACE ANY SAFE-
TY SWITCHES IN SAFE STARTING POSIT ON.
B. Be sum sparkplugwire isattached tosparkplug(see Figure
1).
MOWER
CONTROL
BAR \MOWER
Figum 3
STARTER ROPE
HANDLE
MOWER
NO SLACK
PERMISSIBLE
Figure4
STARTER
HANDLE
LEFT
HANDED
KNOT
1/2 TO 1 INCH
Figure 5 181-1177-11
Figure2 Page 2

STARTING
_NEVER RUN ENGINE INDOORS OR IN ENCLOSED, POORLY
VENTILATED AREAS. ENGINE EXHAUST CONTAINS CAR-
BON MONOXIDE, AN ODORLESS AND DEADLY GAS (CAR-
BON MONOXIOE IS ALSO PRESENT IN ENGINE EXHAUST
FROM UQUID PETROLEUM (LPG)AND NATURAL GAS FUEL
SYSTEMS).
_k KEEP HANDS, FEET, HAIR AND LOOSE CLOTHING AWAY
FROM ANY MOVING PARTS ON ENGINE AND EQUIPMENT.
_kWARNING TEMPERATURE OF MUFFLER AND NEARBY
AREAS MAY EXCEED 150OF(65aC).AVOID THESE AREAS.
(_) Moveenginecontrol(see Figure1) toHI Position.
"(_) START ENGINE:
A. The carburetor onyourengine hasbeen completelyadjusted
at the factory. For each Initialstad, push pdmerbulbfirmly
with your thumb 5 tlmse, allowing primer bulb to ratum
completelyto originalpos,Jonbetween pushes. Repeat the
above for each starteroperationas necessary.
NOTE: DO NOT USE PRIMER TO RESTART A WARM
ENGINE AFTER A SHORT SHUTDOWN. _.
E. Operate mower controlto releaseenginebrake.
C. Grasp starter handle (see Figure4) and pull ropeout,slowly,
until it pullsslightlyharder. Let rope rewindslowly.Then pull
rope witha rapidfullarmstroke.LetroperewindSLOWLY. Do
notletstarterhandlesnapbackagainstropeguide(see Figure
4).
D. Repeat instructionsB and C ifnecessary, untilenginestarts.
NOTE: Ifangine doeanotstart,repeatinstructionsA,B,C and
D until itstarts.
ENGINE SPEED: Engine speed iscontrolledby the enginecontrol
(see Figure 1). Engine controlshouldbe in HI positionforhighgrass
conditions and far most efficientbaggingin heavy grass conditions,
and in LOW positionforlightgrass, tdmmingand forfuel ecormmy.
STOPPING
(_See mower manufacturer'sinstructions.
(_ AFTER ENGINE IS STOPPED:
_kA. DISCONNECT SPARK PLUG WIRE FROM SPARK PLUG
AND AI"rACH IT TO RETAINING POST (see Rgure 6).
_kB. NEVER STORE ENGINE WITH FUEL IN TANK INDOORS
OR IN ENCLOSED, POORLY VENTILATED AREAS,
WHERE FUEL FUMES MAY REACH AN OPEN FLAME,
SPARK OR PILOT LIGHT AS ON A FURNACE, WATER
HEATER, CLOTHES DRYER OR OTHER GAS APPU-
ANCE.
SPARK
PLUG
RETAINING POST
SPARK
PLUG WIRE
MAINTENANCE
_kWARNING TEMPERATURE OF MUFFLER AND NEARBY
AREAS MAY EXCEED 150OF(65"C)•AVOID THESE AREAS- ]
CHECK OIL LEVEL:
Checkoil level everyfive(5)operating hoursor eachtime engine
isused.See *3 CHECK OIL LEVEL"in"BEFORE STARTING" on
Page 2.
(_) CHANGE OIL:
Change oil after first two (2) operating hours and every 25
operating hours thereafter, more often ff operated in extremely
dustyordirtycond'dioos.Change oilwhileengineisstillwarmfrom
recent running.
_I=A. DISCONNECT SPARK PLUG WIRE FROM SPARK PLUG I
AND A'I'rACH IT TO RETAINING POST (see Figure 6).
B. Poaltionequipmentso engineolldrainplugis lowestpeint on
engine.
C. Remove oildrainpingand oiltill plugto drainoil (see Figure
1).
D. Replace oil drainplug and tightensecurely.
E. Fill oil sumpwith reonmmendedoil. See "OIL& FUEL REC-
OMMENDATIONS" and "CHECK OIL LEVEL" on Page 1.
F. Replace oil till plugand tighten securely.
G. Connect spark plugwire to spark plug.
H. Wipe up anyspilledoil and/or gasoline.
NOTE: If it is difficultto reach the oil drain plug, drain fuel.
Removeoiltillplug and tipmoweronitsside. Drainoil
intoa suitablecontainer.
_) AIR CLEANER (seeFigure7):
,_ NEVER RUN ENGINE WITHOUT COMPLETE AIR CLEANER ]
INSTALLED ON ENGINE. ]
Replacetilterenosayear ormore oftenffusedinextremelydusty
or dirty conditions.
DO NOT ATTEMPT TO CLEAN OR OIL FILTER.
Replacementtiitem are availableat any Seam Roebuckand Co.
(or Sears Canada, Inc.) Service Center. To install new tilter,
proceedas follows:
A. Tum cover to the right(clockwine)to ramove It and ramove
paperfilter fromflange. Discard tilter.
B. Clean cover and flange thoroughly.
C. Insertnew paperfilter Into cover.
Do Line up tabs on coverwith slotson flange.
E. Push cover firmly against flange and tam it to the left
(counterclockwise)untilcover lockssecurelyinplace. Cover
should be invertical position.
TURN COVER TO THE
SLOT FLANGE PAPER RIGHT (CLOCKWISE)
FILTER TO REMOVal _
TABS Irbmf
_I_JRN COVER TO THE LEFT
(COUNTERCLOCKWISE) TO
TIGHTEN
Figure7
Figure6 Page 3 181-1177-I I

MAII ITENANCE (Continued)
(_ SPARK PLUG (see Figure 8): ,%
This spark ignitionsystemmeets all requirementsof the Cana-
dian Interference-CausingEquipment Regulations. This engine /
complieswithallcurrentAustralianand New Zealand limitations
regardingelectromagneticinterference.
Check spark plugyearlyor every 100 operating hours.
A. Clean area aroundspark plug.
B. Remove and inspectspark plug.
C. Replace sparkplug ifelectrodesare p_ed, bumed or
porcelainiscracked,For replacementuseChampionRJ19LM,
or equivalent.
NOTE: A resistorsparkplug must be usedfor replacement.
D. Check electrodesgap withwire feeler gauge and sat gap at
.030 ifnecessary.
E. Installspark plug, tighten securely.
ELECTRODES
_CELAlN
.030GAP
Figure8
(_ COOLING SYSTEM:
IMPORTANT: Frequently remove any grass clippings,dirtand
debrisfromcoolingtins, air intakescreen and levers and linkage
(see Figure 1). This will help ensure adequate cooling and
correct engine speed.
®
,_ CHECK ENGINEAND EQUIPMENT OFTEN FOR LOOSE NUTS, 1
BOLTS AND ATTACHMENTS, AND KEEP THESE ITEMS |
I TIGHTENED" /
ADJUSTMENTS
STORAGE
NEVER STORE ENGINE WITH FUEL IN TANK INDOORS OR
INENCLOSED, POORLY VENTILATED AREAS, WHERE FUEL
FUMES MAY REACH AN OPEN FLAME, SPARK OR PILOT
LIGHT AS ON A FURNACE, WATER HEATER, CLOTHES
DRYER OR OTHER GAS APPLIANCE.
IF ENGINE IS TO BE UNUSED FOR 30 DAYS OR MORE,
PREPARE AS FOLLOWS:
DRAIN FUEL SYSTEM:
A. Remove allgasolinefrom carburetorend fuel tankto prevent
gum depositsfrom formingonthese parts and causingpossi-
ble malfunction of engine.
_lh RAIN FUEL INTO APPROVED CONTAINER OUTDOORS, i
AWAY FROM OPEN FLAME. BE SURE ENGINE IS COOL.
DO NOT SMOKE.
B. Runengineuntilfueltankis emptyand enginestopsduefolsck
of fuel.
NOTE: Fuelstabilizer (such as STA-BIL) is an acceptable
altemative in minimizingthe formation of fuel gum deposits
dudngstorage. Addstabilizer togasOlineinfuel tankorstorage
container. Alwaysfollowmix ratiofound onstabilizercontain-
er. Run engine at least 10 minutes after adding stabilizerto
allow itto reach carburetor.
!_) CHANGE OIL:
Changeoilififhasnotbeenchangedinthelastthroe(3)months.
See"CHANGEOIL"instructionsin"MAINTENANCE"sectionon
Page3.
(_) OIL CYLINDER BORE:
A. Remove sparkplugand pour one (1)oonce(30 ml)of engine
oil intospark plug hole.
B. Cover spark plug hole witha rag.
C. Crank engine over, slowly,severaltimas.
Ij AVOID SPRAY FROM sPARK PLUG HOLE WHEN I
CRANKING ENGINE OVER SLOWLY.
D. Replace spark plug.
(_) CLEAN ENGINE:
Remove any clippings,did, or chafffrom extedorofengine.
GENERAL
DO NOT MAKEUNNECESSARY ADJUSTMENTS. FACTORY SET-
TINGS ARE SATISFACTORY FOR MOST APPLICATIONS AND
CONDITIONS. iF ADJUSTMENTS ARE NEEDED, PROCEED AS
FOLLOWS:
(D CARBURETOR
If you think your carburetorneeds adjusting, see your nearest
SEARS, ROEBUCK AND CO. (OR SEARS CANADA CENTER).
Engine performance should not be affected at altitudes up to
7,000 feet. For operation at higher elevations, contact your
nearest SEARS, ROEBUCK AND CO. (OR SEARS CANADA,
INC.) SERVICE CENTER.
(_) ENGINE SPEED
,_ NEVER TAMPER WITH ENGfNE GOVERNOR WHICH IS FAC-
TORY SET FOR PROPER ENGINE SPEED. OVERSPEEDING
IENGINE ABOVE FACTORY HIGH SPEED SETnNG CAN BE
DANGEROUS,
CHANGING OF ENGINE-GOVERNED SPEED WILL VOID EN-
GINE WARRANTY. Pa
Justas your automobileneeds professionalmechanical maintenance
fromtimetotime,sodoesyourCraftsmenengine. Replacementofthe.
spark plug and air deener is made necessary by NORMAL use.
ProfessionalAir-Cooled Engine Service isas close as your nearest
Sears Roebuckand Co. (or Sears Canada, Inc.) Service Center.
A yearly check-up or tune-up by Sears is agood idea to avoid
breakdownsor delay.., do it at the end ofthe season, then you're
ready forthe next. We even prepare It forstorage foryou.
je 4181-1177-11

TROUBLESHOOTING
THE FOLLOWING MAY HELP AVOID A DELAY IN YOUR WORK OR
SAVE THE EXPENSE OF A SERVICE CALL.
ENGINE FAILS TO START OR STARTS WITH DIFFICULTY
CAUSE
Controlsnot in start position
Spark plugwire disconnectedfrom spark plug.
Spark plugfouled.
Spark plugporcelain cracked.
Insufficientfuel.
Water or dirtin fuel.
Impropercarburetoradjustment
ENGINE LACKS POWER
CAUSE
Dirtyaircleaner.
Impropercarburetor adjustment.
Lackof lubdcaiton.
ENGINE MISSES UNDER LOAD
CAUSE
Spark plugfouled.
Spark plugporcelain cracked.
Improperspark pluggap.
Impropercarburetoradjustment
REMEDY
Move ENGINE CONTROL orequipment controlto "HI"or
START postion. See "STARTING" instructionsinthis
manual.
ConnectSPARK PLUG WIRE to SPARK PLUG.
Remove SPARK PLUG and clean it. See "SPARK
PLUG" instructionsin "MAINTENANCE' sectioninthis
manual.
Installnew spark plug.
FillFUEL TANK per "BEFORE STARTING" instructions.
Drain FUEL TANK and re-fill withclean, fresh gasoline.
See "BEFORE STARTING" instructionsinthis manual.
Adjustcarburetor (ifapplicable). See "ADJUSTMENTS"
sectioninthis manual.
REMEDY
Replace orclean air cleaner per "AIRCLEANER'
instructionsin "MAINTENANCE" sectioninthis manual.
Adjustcarburetor(if applicable). See "ADJUSTMENTS"
sectioninthis manual.
Fill ellsump to proper level. See "BEFORE STARTING"
instructionssectionInthis manual.
REMEDY
Remove SPARK PLUG and clean It. See "SPARK
PLUG" Instructionsin "MAINTENANCE" sectioninthis
manual.
Installnew SPARK PLUG.
Regap SPARK PLUG electrodes. See "SPARK PLUG"
instructionsin "MAINTENANCE" sectionin thismanual.
Adjustcarburetor(ifapplicable). See "ADJUSTMENTS"
sectioninthis manual.
Page 5 181-1177-11

SEARS, ROEBUCK AND CO.
Federal and California Emission Control Systems Limited Warranty
Utility and Lawn and Garden Engines
CALIFORNIA & US EPA EMISSION CONTROL
WARRANTY STATEMENT
The U. S. Environmental Protection Agency ('EPA*), the California Air Resources
Board ("CARB_ and Seam, Roebuck and Co. are pleased to explain the Federal
and California t=missionControf Systems Warranty on your new utilityOrlawn and
garden equipment engine. In Caiiforrda, new 1995 and later utility and lawn and
garden equipment engines must be designed, built arid equipped to meet the
State's ctdngant anti-srpa_l standards. In other states, new 1997 and later model
year engines must be designed, built and equipped, at the gme of sale, to meet
the U.S. EPA regulations for small non-road engines. Sears, Roebuck and Co.
will warrant the emission control system on your utility or lawn and garden
equipment engine for the pednds of time listed below, provided there has been no
abuse neglect unapproved modification, or improper maintenance of your utility
or lawn and garden equipment engine.
Your emission control system may Include parts such as the carburetor, ignition
system and exhaust system. Also included may be the compression release
system and other emission-miatsd assemblies.
Where a warrantable condition exists, Seem, Roebuck and Co. will repair your
utili or lawn and garden equIwnent engine at no cost to you for diagnosis parts
MANUFACTURER'S EMISSION CONTROL SYSTEM
WARRANTY COVERAGE
Emission contr_ systems on 1995 and later model year Catifomla udility and lawn
and garden equipment engines are warranted for two yearn as hereinafter rmteq.
In other elates. 1997 and later modelelyelarengines are also warranted for two
years. If. dudng such warranty pednd, any emisaion-mlathd part on your engine
is defective in matethds or workmanship, the part will ha repaired or replaced by
Seam, Roebuck and Co.
OWNER'S WARRANTY RESPONSIBILITIES
As the utilityor lawn and garden equipment ermine owner, you are responsrole for
the performance of the required maintenance listed in your Owner's Manual, but
Sears, Roebuck and Co. wilt not deny warranty solely due to the lack of receipts
or for your failure to provide written evidence of the performance of all schequtsd
maintenance.
As the utilityor lawn and garden equipment engine owner, you should, however,
be aware that Sears, Roebuck and Co. may deny you warranty coverage if your
ufflby or lawn and garden equipment ora pad thereof has failed due to abuse,
neglect, improper maintenance or unapproved modifications.
You are responsible for presenting your utility orlawn and garden equipment
•'ne to a Seam, Roebuck and Co. Authorized Service Outlet as soon as a
_lam exists. The warranty mpehe should be completed in 8 reasonable
amount of time, not to exceed 30 days.
Warranty service can be arranged by contacting either a Sears, Roebuck and CO.
Authorized Service Outlet, or by contacting Sears, Roebuck and Co. at 1-800-
473-7247.
IMPORTANT NOTE
This warranty statement explains your rights and Obligations under the Emission
Control System Warranty ('ECS .wan-duty') which isprovided to you by Sears,
RoeblJCkand CO. pumuard to California law. See also the Seam, Roebuck and
Co. Umlted Warranties fix Seam, Roebuck and CO. w_ch ic enclosed Vtmmwifh
on a separate sheet and also is provided to you by Seam, Roebuck and Co.
ECS Warranty applies only to the emission control sys_m of your now engine.
To the extent that there is any conflict in terms between the EC$ Warranty and
the Sears, Roebuck and CO.Warranty, the ECS Warranty shall Itpply except in
any ct r_.-umstencesIn which the Sears, Roebuck and Co. Wamlnfy may provide a
longer warranty pedod. Seth the ECS Warranty and the Seam, Roebuck and Co.
Warranty descdbe important rights and obligations wi_ respect to your new
engine.
Warranty sendce can only ha performed by a Sears, Roebuck and Co. Authorized
Service Outlet. At the dine of requsstJngwarranty service, evidence muct be
presented of the date of sale to the odg*net purchaser. The purchaser shall beLy
any charges for making service calls and/or for transporting the pmducla to and
from the place where the inspection and/or warranty work is performed. The
purchaser shall be responalble fix any damage or loss incurred in connection with
the ttanpporlation of any engine or any pad(s) thereof submitted for inspection
end/or warranty work.
if you have any questions regarding your warranty dghts and responsibilities, you
should contact Sears, Roebuck and Co. at 1-800-473-7247.
EMISSION CONTROL SYSTEM WARRANTY
Emission Contrct System Warrant./{'ECS Warranty*) for 1995 and later model
year California utilityand lawn anogarden equipment engines {for other states.
1997 and later model year engines):
A. APPLICABILITY: This warranty shall apply to 1995 and later model year
Cutifomia utilityend lawn and garden equipment engines (for nthar stathe. 1997
and later model year engines. The ECS Warranf'yPednd shall begin o(i the date
the new engine or equipment is delivered to its onginai, end-use purchaser, and
Shall €ontinue for 24 consecutive months thereafter.
B. GENERAL EMISSIONS WARRANTY COVERAGE: Seam, Roebuck end Co.
warrants to the odgthai, *rod-use purcheser of the new engine Or equipment and
to each subsequent purchaser that each of itsutility and lawn and garden
equipment ang,nes is:
Cosi ned, built and equ_ so as to conform with all applicable
1. re_u_ifons adoptnd by te_oedAirResouroes Board pumuant to ifs authority in
Chapters 1 and 2, Part 5, Division 26 of the Health and Safety Code, and
2. Free from defects In matodals and workmanship which, at any time dudng
the ECS Warranty Period, will cause awarranted emissid_s-relatsd part to
fail to be identical inall mutedai msbects to the part es described in the
engine manufacturer's pp_icatio_ for certification.
C. The ECS Warranty only pertains to emissions-related parts on your engine, as
follows:
1. Any warranted, emisalof_-miated pads which are not scheduled for
replacement es rraquired mainthnance inthe Owner'e Manual shall be
warranted forthe ECS Warranty Period. If any such part laifs dudng the
ECS Warranty Period, it shall be rep_md or replaced by Sears, Roebuck
and CO. according to Subsection 4 below. Any such bert repaired or
replaced under the ECS Warranty shall be warranted for any remainder of
the ECS Wamaety Pedod.
2. Any warranted, emissidns-mlsted pad which is scheduleq only for regular
Inspectionas spectflaisdin the Owner's Manual shall ha warra_ed for the
ECS Warranty Period. A statement In euch wdtten instructions to the
effect of "mprdror replace its necessary', shall not reduce the ECS
Wsrranty Period. Any such pad repaired or replaced under the ECS
Warranty shall be warranted forthe remainder of the ECS Warranty
Pednd.
3. Any warranted, emisclons-related pad which Is scheduled for replacement
as reqreulreq maintenance in the Owner's Manual, shall be wm.uffeq for the
period of lime prior to the find Ichequtsd mplaoement point fix that bert. if
the part fails prior to the first scbedcted replacement, the _ ehaa ha
repaired or replaced by Sears, Roebuck and CO. according to Subsection
4belOW. Any such emlsdions*ndsted p_1 repaired orreplaced under the
ECS Warranty, shall be warranted for the ranmindar ofthe ECS wm'ranty
Pedod pdor to thefind schequted replacement pulnt for such emissions-
related pad.
4. Repair or replacement of any warranted, emisalons-mlated pad under this
ECS Warranty shall ha performed at no charge to the owner at a Seam,
Roebuck and Co. Authodzeq Senrice Outlet.
5. The owner shall not be charged for dlagnoutic labor which leads to the
determination that aBpart covered bythe ECS Warranify is_lsin feet defective,
provided that such dlagnsatki work Is performed at aSears, Roebuck and
CO. Authorized Service Outlet.
6. Sears, Roebuck and Co. shall be liable for damages to other original
•Ine components or ed modifications proximate caused b a
_aln_draunder warranty oa_°n_m_kision-mlatsd pert covere_ by the E_Ys
Warranty.
7. Throughout the ECS Wan-anty Period Sears Roebuck and Co. shall
maintain a supply of warranted emission-relateq parts sufficient to meet
the expected demand fix euchemisalon-mlalad parts.
8. Any Sears, Roebuck and CO.authorized and approved emisalon-mlated
replacement bed r_ be useq _ the perfm of any ECS wammty
mainthnance or mpmr and will be prowooldedwithout chaargatto the owner.
Such Use,halt not reduce Sears, Roebuck and CO. ECS warranty.
ct'_igutions.
9, Unapprovnd add-on or modified parts may not be used to modi:l'byOr mpplr
a Sears, Roebuck and CO. engine. Such use voids thle ECS Warranty and
shall he sufficient grounds for disallowing an ECS Warranty claim. Sears,
Roebuck and Co. shall not be liable hereunder for failures of any
warranted parts of aSeari, Roebuck and Co. engine canard by the use of
such an unapproveq add-on or modified pert.
EMISSION-RELATED PARTS INCLUDE THE FOLLOWING:
1. Carburetor Assembly and itsInlamal Components
a) Fuel filter
b) Carburetor gaskets
c) Intake pipe
2. Air Claaner Assembly
a) Air filterelement
3. Ignition System, including:
a) Spark plug
b) Ignition module
c) Flywheel assembly
4. Catalytic Muffler (if soequipped)
8) Muffler gasket (if so equipped)
b) Exhaust manifold {ifso equipped)
5. Crankcase Breather Assembly and itsComponents
It) _'euther connection tube
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Page 6 18%1177-11

CRAFTSMAN 4-CYCLE ENGINE MODEL:143.996514
I
I
I
I
1821_ 83/_
178
46
238 250
Page 7 181-1177-11

CRAFTSMAN 4-CYCLE ENGINE MODEL:143.996514
Ref. Part
No. No.
1 37266
2 26727
6 33734
7 36557
12 36775
12A 36558
12S 36694
14 28277
15 30589
16 34839A
17 31335
18 651018
19 36281
2O 32600
30 35801
40 40027
40 40028 "
41 40025
41 40026
42 40006
42 40007
43 20381
45 36777
46 32610A
48 27241
50 36778
52 29914
69 *35261
70 34311E
72
72A
73
75
8O
81
82
83
86
89
90
92
;go
101
103
110
119
120
125
126
130
150
151
151A
169
172
30572
28534
28833
27897
30574A
30590A
3O591
30588A
650488
611004
611112
650815
650816
34443B
610118
651007
37047
*36787
36825
37288
37289
6021A
35395
31672
31673
40017
*36783
36784
Ref. Part
Part Name No. No.
Cylinder (Incl.2,20 & 150) 174 302()0
Dowel Pin 178 29752
Breather Element 182 6201
Breather Ass'y. (incl.6 & 12A) 184 *26756
Breather Tube 185 36785
Breather Cover & Tube (Incl. 12B) 186 34337
Breather Tube Elbow 189 650839
Washer 191 36559A
Governor Rod (Incl. 14) 195 610973
Governor Lever 200 35727
Governor Lever Clamp 202 36482
Screw, Torx"1"-15,8-32 x'l 9/64" 203 31342
Extension Spdug 204 651029
Oil Seal 205 651019
Crankshaft 207 34336
Piston,Pin & Ring Set (Std.) 209 30200
Piston, Pin& RingSet (.010' OS) 215 35511
Piston& PinAss'y. (Std.) (Incl.43) 223 650451
Piston & Pin Aas'y. (.010" OS) (Incl. 224 "36786
43) 238 650932
Ring Set (Std.) 239 *34338
Ring Set (.010" OS) 241 36919
PistonPin Retaining Ring 245 36905
Connecting RodAss'y. (Incl. 46) 250 36920
Connecting ROdBoll 260 36980
Valve Ufter 261 30200
Camshaft (MCR) 262 650831
OIl Pump Ass'y. 263A 37184
Mounting Flange Gasket 275 36700A
Mounting Flange (Incl. 72 thru 83, 277 650988
306) 285 35000A
Oil DrainPlug (Incl. 73) 287 650926
Oil Drain Plug 290 29774
DrainPlug Gasket 292 26460
Oil Seal 298 28763
Governor Shaft 300 36916
Washer 301 36246
Govemor Gear Aas'y. (Incl. 81) 305 35647
Governor Spool 306 *36996
Screw, 1/4-20 x 1-1/4" 307 35499
Flywheel Key 309 650562
Flywheel 310 35643
BellevilleWasher 313 34080
Rywhea[ Nut 325 37152
Solid State Ignition 347 651038
Spark Plug Cover
Screw, TorxT-15, 10-24 x 15/16"
Ground Wire
Cylinder Head Gasket
Cylinder Head
ExhaustValve (Std.) (incl. 151)
Intake Valve (Std.) (Incl. 151)
Screw,5/16-18 x 1-1/2"
ResistorSpark Plug (RJIgLM)
Valve Spring
Valve Spring Cap
Intake Valve Seal
Valve Cover Gasket
Valve Cover
Pad Name
Screw, 10-24 x 9/16"
Nut & Lock Washer, 1/4-28
Screw, 1/4-28 x 7/8"
CarburetorTo Intake Pipe Gasket
Intake Pipe
GovernorLink
Screw, 114-20x 3/8'
S.E. Brake Bracket (Incl. 195)
Terminal
ControlBracket(IncL202 thru205)
CompressionSpdng
CompressionSpring
Screw,TorxT-10, 5.40 x 7/16"
Sm'ew,Torx"1"-10,6-32 x 41/64"
ThrottleLink
Screw, 10-24 x 9/16"
Control Knob
Screw, 114-20x 1'
Intake Pipe Gasket
Screw, 10-32 x 49/64"
Air Cleaner Gasket
Air Cleaner Collar
Air Cleaner Filter
Air Cleaner Cover
Blower Housing
Screw,10-24 x 9/16"
Screw, 1/4-20 x 1/2"
Stader Gdll
Muffler
i Screw, 1/4-20 x2-5/16"
StarterCup
Screw, 6-32 x 21164"
FuelUne
FuelUne Clamp
Screw, 10-32 x 35/64"
FuelTank (incl.292 & 301)
FuelCap
Oil RII Tube
"O"-Ring
"O"-Ring
Screw, 10-32 x 1/2"
Dipstick
Spacer
Spring Clip
Screw, 10-32 x 27/32"
*IndicatesParts IncludedIn
GasketSet, Ref. No.400.
Page 8 181-1177-11

CRAFTSMAN 4-CYCLE ENGINE
Ref. Part
No; No.
370A 36261
370B 35167
370C 37199
380 640174
390 590739
400 36792B
416 36085
Ref. Pad
Part Name No. No.
LubdcationDecal
ControlDecal
Primer Decal
Carburetor (Incl. 184)
Rewind Starter
(NOTE: This engine could have
been builtwith 590702 starter).
Gasket Set (Incl. Items Marked *)
Spark Arrestor Kit (Incl.416)
(Optional)
417 650821
900
900
181-1177-11
MODEL: 143.996514
Part Name
Screw, 10-32 x 1/2" (Optional)
Replacement Engine750808C,
orderfrom71-999
Replacement Short Block750832A;
orderfrom71-999
Operator's Manual
*IndicatesParts Included In
Gakset Set, Ref. No. 400.
RPM High2900 to 3200
RPM Low 2450 to2750
;ARBURETOR NO. 640174
Rid. Part
No. No. Part Name
640174
1 631615
2 631767
4i*631184
5 *631183
6 640070
7 °650506
16 631807
17 651025
18 630766
20 640018
20A 640053
25 631867
27 "631024
28 632019
29 "631028
30 "631021
31 631022
35 36045A
36 64OO8O
36A 632766
37 *632547
40 640175
44_ 27110A
*630748
"631027
48A "631027
60 632760
Carburetor (Ind. 184 of Engine Parts Lisl
Throttle Shaft & Lever Assembly
Throttle Rstum Spdng
Dust Seal Washer
Dust Seal (Throttle)
Throttle Shutter
Shutter Screw
Fuel Fitting
ThrottleCrack Screwfldle Speed Screw
TensionSpring
Idle RestdctorScrew
, Idle RastrictorScrew Cap
Float Bowl
Float Shaft
Float
FloatBowl "O"Ring
Inlet Needle, Seat, & Clip (Ind. 31)
Spdng Clip
Pdmer Bulb/Retainer Ring
Main Nozzle Tube
CarburetorTube
"O" Ring, Main Nozzle Tube
High Speed Bowl Nut
Bowl Nut Washer
Welch Plug, Idle Mixture Well
Welch Plug, AtmosphericVent
Welch Plug
Repair kit (Ind. Items Marked *)
Page 9 181-1177-11

REWIND STARTER NO. 590739
V--14
/
13
12
jj I--7
RWI. Part
No. No. Pert Name
3
6
7
8
11
12
13
14
590739
590740
590616
590617
590618A
590638
590535
590701
590760
Rewind Starter
Retainer
Starter Dog
Dog Spring
Pulley& RewindSpdng Ass'y
Starter HousingAss'y (40 degree
grommet)
Starter Rope (Length 98" x 9/64"
dia.)
Starter Handle
Spdng Clip
STARTER NO. 590702
O_4
B5
O--2
Ref. Part
No. No. Part Name
1
2
3
4
5
6
7
8
11
12
13
59O7O2
590599A
5906OO
590696
590601
590697
59O698
590699
590700
590703
590535
590701
Recoil Starter
Spdog Pin (Incl. 4)
Wesher
Retainer
Washer
Broke Spdng
Starter Dog
Dog Spdog
Pulley& Rewind Spdng Ass'y.
Starter Housing Ass'y. (40 degree
grommet)
Starter Rope ( 98" x 9/64" die.)
Starter Handle
Page 10 181-1177-11

SEARS
operator's
manual
MODEL NO. 143.996514
6.5 RESERVE POWER
12 CUBIC INCH (185 cc)
DISPLACEMENT
SOLID STATE IGNITION
CAUTION:
Read RULES for
Safe OPERATION
and INSTRUCTIONS
Carefully
How to ORDER Repair Parts
The Model Number can be foundon adecal on the blower
housing(See Figure 1). Always mentionthe Model Number
when requestingservice or repair partsforyourCraftsman
Engine.
All parts listedherein may be orderedfromany SEARS, ROE-
BUCK AND CO. or SEARS CANADA, INC. retailor catalog store.
Ifthe partsyou need are not stocked locally,yourorderwillbe
electronicallytransmittedto a Sears Repair PartsDistribution
Centerfor expedited handling.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION AS SHOWN IN THIS LIST.
1, The PART NUMBER
2. The PART DESCRIPTION
3. TheMODEL NUMBER
4. The NAME ()F ITEM - ENGINE
"YourSears merchandise has added value when you considerthatSears has
service units nationwide staffed with Sears trainedtashnicians..,professional
techniciansspecificallytmioed on Sears products,-havingthe parts; teals and
equipmentto insurethatwe meetour pledgetoyou ...we servicewhat we sell."
Sold by SEARS, ROEBUCK AND CO., CHICAGO, IL 60684 U.S.A.
and SEARS CANADA, INC., TORONTO, ONTARIO, CANADA
181-1177-11
