Craftsman 139.53918D User manual

Owner's Manual/Manual Del Propietario
I:RRFTSMR
315MM= GARAGE DOOR OPENER
ABRIDOR DE PUERTA DE COCHERA 315MN_,
For Residential Use Only/Solo para uso residencial
Model/Modelo 139.53918D
m
G3
m
Z_
O
Read and follow all safety rules
and operating instructions before
first use of this product.
Fasten the manual near the garage
door after installation.
Leer y seguir todas las reglas de
seguridad y las instrucciones de
operacion antes de usar este
producto por primera vez.
Guardar este manual cerca de la
puerta de la cochera.
Periodic checks of the opener are
required to ensure safe operation. Se deben realizar revisiones
periodicas del abridor de puertas
para asegurar su operacion
segura.
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A
www.sears.com/craftsman

TABLE OF CONTENTS
Introduction 2.7
Safety symbol review and signal word review ......... 2
Preparing your garage door ....................... 3
Tools needed .................................. 3
Planning .................................... 4-5
Carton inventory ............................... 6
Hardware inventory ............................. 7
Assembly 8.11
Assemble the rail and install the trolley .............. 8
Fasten the rail to the motor unit ................... 9
Install the idler pulley ............................ 9
Install the belt and attach the belt cap retainer ....... 10
Set the tension ................................ 11
Installation 11-26
Installation safety instructions .................... 11
Determine the header bracket location ............. 12
Install the header bracket ....................... 13
Attach the rail to the header bracket ............... 14
Position the opener ............................ 15
Hang the opener .............................. 16
Install the control console ....................... 17
Install the battery .............................. 18
Install the lights ............................... 18
Attach the emergency release rope and handle ...... 18
Electrical requirements ......................... 19
Install The Protector System ®(safety sensors) .... 20-22
Fasten the door bracket ...................... 23-24
Connect the door arm to the trolley ............. 25-26
Adjustment 27-29
Program the travel limits ...................... 27
Setting the force ............................. 28
Test the safety reversal system ................. 29
Test The Protector System ®(safety sensors) ...... 29
Operation 30-36
Operation safety instructions ................... 30
Using your garage door opener ................. 30
Using the wall-mounted control console .......... 31
Care of your opener .......................... 32
To open the door manually .................... 32
Battery backup .............................. 33
Having a problem (Troubleshooting) ............. 34
Diagnostic chart ............................. 35
LCD motion detecting control
console messages ........................... 36
Programming 37.38
To add or reprogram a hand-held remote control ...37
To erase all codes from motor unit memory ....... 37
3-Function remotes .......................... 37
To add, reprogram or change a
Keyless Entry PIN ........................... 38
Repair Parts 39-40
Rail assembly parts .......................... 39
Installation parts ............................. 39
Motor unit assembly parts ..................... 40
Accessories 41
Warran ty 41
Repair Parts & Service Back Cover
INTRODUCTION
Safety Symbol Review
and Signal Word Review
This garage door opener has been designed and tested to offer safe service provided it is installed, operated,
maintained and tested in strict accordance with the instructions and warnings contained in this manual.
Mechanical
Electrical
When you see these Safety Symbols and Signal Words
on the following pages, they will alert you to the
possibility of serious injury or death if you do not
comply with the warnings that accompany them. The
hazard may come from something mechanical or from
electric shock. Read the warnings carefully.
When you see this Signal Word on the following pages, it
will alert you to the possibility of damage to your garage
door and/or the garage door opener if you do not comply
with the cautionary statements that accompany it. Read
them carefully.

Preparing your garage door
Before you begin:
• Disable locks.
• Remove any ropes connected to garage door.
• Complete the following test to make sure your garage
door is balanced and is not sticking or binding:
1. Lift the door about halfway as shown. Release the
door. If balanced, it should stay in place, supported
entirely by its springs.
2. Raise and lower the door to see if there is any
binding or sticking.
If your door binds, sticks, or is out of balance, call a
trained door systems technician.
To prevent possible SERIOUSINJURYOR DEATH:
•ALWAYScall a trained door systems technician if garage
door binds, sticks, or is out of balance An unbalanced
garagedoor may not reversewhen required
•NEVERtry to loosen, move or adjust garagedoor, door
springs, cables,pulleys, brackets or their hardware,all of
which are under EXTREMEtension
•DisableALL locks and removeALL ropes connectedto
garagedoor BEFOREinstalling and operating garagedoor
openerto avoid entanglement.
To prevent damageto garage door and opener:
•ALWAYSdisablelocks BEFOREinstalling and operating the
opener
•ONLYoperategarage door opener at 120V,60 Hzto avoid
malfunction and damage
Sectional Door
One-Piece Door Tools needed
During assembly, installation and adjustment of the
opener, instructions will call for hand tools as
illustrated below.
Stepladder
Level (Optional)
Pencil
Tape Measure
Wire Cutters
Drill 3/16" 5/16" and
5/32" Drill Bits
ts Scre wd rive r
Hack Saw
Claw Hammer
Adjustable End Wrench

Planning
Identify the type and height of your garage door. Survey
your garage area to see if any of the conditions below
apply to your installation. Additional materials may be
required. You may find it helpful to refer back to this page
and the accompanying illustrations as you proceed with
the installation of your opener.
Depending on your requirements, there are several
installation steps which may call for materials or
hardware not included in the carton.
• Installation Step 1 - Look at the wall or ceiling above
the garage door. The header bracket must be securely
fastened to structural supports.
• Installation Step 5 - Do you have a finished ceiling in
your garage? If so, a support bracket and additional
fastening hardware may be required.
• Installation Step 11 - Depending upon garage
construction, extension brackets or wood blocks may
be needed to install sensors.
• Installation Step 11 -Alternate floor mounting of the
safety reversing sensor will require hardware not
provided.
Do you have an access door in addition to the garage
door? If not, Model 139.53702 Emergency Key
Release is required. See Accessories page.
Look at the garage door where it meets the floor. Any
gap between the floor and the bottom of the door must
not exceed 1/4" (6 mm). Otherwise, the safety reversal
system may not work properly. See Adjustment Step 3.
Floor or door should be repaired.
SECTIONAL DOOR INSTALLATIONS
• Do you have a steel, aluminum, fiberglass or glass
panel door? If so, horizontal and vertical
reinforcement is required (Installation Step 12).
• The opener should be installed above the center of the
door. If there is a torsion spring or center bearing plate
in the way of the header bracket, it may be installed
within 4 feet (1.22 m) to the left or right of the door
center. See Installation Steps 1 and 12.
• If your door is more than 7 feet (2.13 m) high, see rail
extension kits listed on Accessories page.
SECTIONAL DOOR INSTALLATION
Horizontal and vertical reinforcement
is needed for lightweight garage doors
(fiberglass, steel, aluminum, door with
glass panels, etc.). See page 23 for details.
\ Header Wall
\\ i
Rail
Extension Spring.
OR
Torsion Spring
FINISHED CEILING /
Support bracket &
fastening hardware
is required.
See page 16.
Centerline I I
iof Garage I i !
Door j _I ...... _!
Wall-
mounted
Door
Control
Safety Reversing Sensor
Gap between floor
and bottom of door
must not exceed 1/4" (6 mm).
Safety
Reversing
Sensor
Door
O
eader
fall
arage
oor
Header
Bracket Trolley
Stop Bolt
CLOSED POSITION
Trolley
Garage
Door
Spring
Door
Bracket
Curved
Door
Arm
Belt
Emergency Release
Rope & Handle

Planning (Continued)
ONE-PIECE DOOR INSTALLATIONS
• Generally, a one-piece door does not require
reinforcement. If your door is lightweight, refer to the
information relating to sectional doors in Installation
Step 12.
• Depending on your door's construction, you may need
additional mounting hardware for the door bracket
(Step 12).
Without a properly working safety reversal system, persons
(particularly small children) could be SERIOUSLYINJURED
or KILLEDby a closing garagedoor.
• Thegap betweenthe bottom of the garage door and the
floor MUST NOTexceed 1/4"(6 mm). Otherwise,the safety
reversal system may not work properly.
• Thefloor or the garage door MUSTbe repairedto eliminate
the gap.
ONE-PIECE DOOR WITHOUT TRACK
FINISHED
_-'_ Header Wall
drt1 I
Safety Reversing Sensor
& fastening
hardware is required.
See page t6,
I
Rail
/
Access
Door
Safety Reversing
Sensor
Gap between floor
and bottom of door must not exceed 1/4" (6 mm).
Wall-mounted
Door Control
_eader
Vail
Motor Unit
CLOSED POSITION
Trolley Stop Bolt Belt Trolley
i
i
Straight
Door Door
Arm Arm
Garage
Door
Emergency
Release
Rope & Handle
ONE-PIECE DOOR WITH TRACK
let
Reversing
Gap between floor Sensor
iSafety and bottom of door
Reversing Sensor must not exceed 1/4" (6 ram),
Header
Wall
CLOSED POSff[ON
Trolley Stop Bolt Belt Trolley
I --
S'_-Head_r Curved
Bracket Door Arm _j- /
idh,. °°°°°°1°°°°°)_
Door I
_////'_ Bracket Straight
"//A Door
///'A-- Garage Arm
_/I Door
Rail
-- Emergency
Release
Rope &
Handle

Carton Inventory
Your garage door opener is packaged in one carton
which contains the motor unit and all parts illustrated
below. Accessories will depend on the model purchased.
If anything is missing, carefully check the packing
material. Parts may be stuck in the foam. Hardware for
assembly and installation is shown on the next page.
Save the carton and packing material until installation
and adjustment is complete.
;Z:z :b
:::?b- -_ i a!
,% ._ ,,,
Motion Detecting
Control Console (LCD)
SECURITY÷ ®
3-Function Remote Control (2)
Belt Cap Retainer Trolley
Battery
SECURITY+ ®
Keyless Entry
Rail
Center/Back
Sections
Motor Unit with 2 Light Lenses
Idler Pulley
Belt
Rail
Fron! (header) /_¢v2
Safety Reversing
Sensor Bracket (2)
Header Bracket Door Bracket
The Protector System _
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
Curved Door
Arm Section
2-Conductor Bell Wire
White & White/Red
Safety Labels
and
Literature
Hanging Brackets
Straight Door
Arm Section

Hardware Inventory
Separate all hardware and group as shown below for the assembly and installation procedures.
ASSEMB_ HARDWARE
©
Spring/Trolley Nut (1) Lock Nut Lock Washer Nut
1/4"-20 (2) 3/8" (1) 3/8" (1)
Bolt 1/4"-20x 1-3/4" (1)
FTrolley Threaded Shaft (1)
i
S5
Master
Link (2) Idler Bolt (1)
INSTALLATION HARDWARE
Carriage Bolt
1/4"-20xl/2" (2) Wing Nut
1/4"-20 (2)
Lag Screw
5/16"-9xl -5/8" (2)
Lag Screw
5/16"-18xl -7/8" (2)
Carriage Bolt
5/16"-18x2-1/2" (2)
o]
Clevis Pin
5/16"x1-1/2" (1)
O
Ring
Fastener (3)
llllllll[_
Hex Bolt
5/16"-18x7/8" (4)
©
Nut 5/16"-18 (6)
©
Lock Washer 5/16" (7)
Screw
6ABx1-1/4" (2)
Handle
Insulated
Staples (30)
Screw 6-32xl" (2)
Drywall Anchors (2) Spacer (2)
o] I_ o_
Clevis Pin Clevis Pin
5/16"x1" (1) 5/16"x1-1/4" (1)
Rope

ASSEMBLY STEP 1
Assemble the Rail and Install the Trolley
To avoid installation difficulties, do not run the
garage door opener until instructed to do so.
The front rail has a cut out "window"at the door end (see
illustration). The hole above this window is larger on
the top of the rail than on the bottom. A smaller hole
3-1/2" (8.9 cm) away is close to the rail edge. Rotate the
back rail so it has a similar hole close to the opposite
edge, about 4-3/4" (12 cm) from the far end.
1. Remove the straight door arm and hanging bracket
packaged inside the front rail and set aside for
Installation Steps 5 and 12. NOTE: Toprevent
INJURY while unpacking the rail carefully remove the
straight door arm stored within the rail section.
2. Align the rail sections on a flat surface as shown and
slide the tapered ends into the larger ones. Tabs along
the side will lock into place.
To prevent INJURYfrom pinching, keephandsand fingers
awayfrom the joints while assemblingthe rail.
3. Place the motor unit on packing material to protect the
cover, and rest the back end of the rail on top. For
convenience, put a support under the front end of
the rail.
4. As a temporary stop, insert a screwdriver into the hole
10" (25 cm) from the front end of the rail, as shown.
5.Check to be sure there are 4 plastic wear pads inside
the inner trolley. If they became loose during shipping,
check all packing material. Snap them back into
position as shown.
6. Slide the trolley assembly along the rail from the back
end to the screwdriver.
Trolley
End
9ered
End
)ered
End
Rails
(TO MOTOR UNIT)
Windo_
Cut-Out
Idler
Pulle
Screwdriver
Tabs
Front Rail I
(TO DOOR)
,ered
End

ASSEMBLY STEP 2
Fasten the Rail to the Motor Unit
•Insert a 1/4"-20xl -3/4 bolt into the cover protection bolt
hole on the back end of the rail as shown. Tighten
securely with a 1/4"-20 lock nut. Do NOTovertighten.
• Remove the two bolts from the top of the motor unit.
• Place the "U" bracket, flat side down, on the motor unit
and align the bracket holes with the bolt holes. Fasten
with the )reviously removed bolts.
• Align the rail assembly with the top of the motor unit.
Slide the rail end onto the "U" bracket, all the way to
the stops that protrude on the top and sides of the
brackeL
Toavoid SERIOUSdamageto garagedoor opener,use ONLY
those bolts/fasteners mounted in the top of the opener.
"U" Bracket
Bolt
Bolts _ Motor Unit
:Belt Pulley
Cover
Protection
Bolt Hole _
HARDWARE SHOWN ACTUAL SIZE
Lock Nut
Bolt 1/4"-20x1-3/4" 1/4"-20
I
Lock Nut
SLIDE RAIL TO STOPS
ON TOP AND SIDES
OF BRACKET
ASSEMBLY STEP 3
Install the Idler Pulley
• Lay the belt beside the rail, as shown. Grasp the end
with the hooked trolley connector and pass
approximately 12" (30 cm) of belt through the window.
Keep the ribbed side toward the rail, and allow it to
hang until Assembly Step 5.
• Remove the tape from the idler pulley. The inside
center should be pre-greased. If dry, regrease to
ensure proper operation.
• Place the idler pulley into the window as shown.
• Insert the idler bolt from the top through the rail and
pulley. Tighten with a 3/8" lock washer and nut
underneath the rail until the lock washer is
compressed.
• Rotate the pulley to be sure it spins freely.
• Insert a 1/4"-20xl-3/4 bolt into the trolley stop hole in
the front of the rail as shown. Tighten securely with a
1/4"-20 lock nut.
Lock Washer
3/8"
Bolt
Trolley
Stop Hole _p
Grease \\ | | __
-. _/side Pulley '\\ U _
Trolley
Connector Idler _.. Lock
Pulley i Nut
Idler Bolt
HARDWARE SHOWN ACTUAL SIZE
Bolt 1/4"-20xl-3/4" Lock Nut 1/4"-20 Nut 3/8" Lock Washer 3/8"

ASSEMBLY STEP 4
Install the Belt and Attach the Belt
Cap Retainer
1. Pull the belt around the idler pulley and toward the
trolley. The ribbed side must contact the pulley,
2. Hook the trolley connector into the retaining slot on
the trolley as shown.
3. With the trolley against the screwdriver, dispense the
remainder of the belt along the rail length toward the
motor unit and around the sprocket. The sprocket
teeth must engage the belt.
4. Check to make sure the belt is not twisted, then
connect it to the flat end of the trolley threaded shaft
with the master link, as illustrated:
• Push pins of master link bar through holes in end of
belt and trolley threaded shaft.
• Push master link cap over pins and past
pin notches.
• Slide clip-on spring over cap and onto pin notches
until both pins are securely locked
in place.
5. Insert the trolley threaded shaft through the hole in
the trolley. Be sure the belt is not twisted, and the
ribbed side faces the rail.
To avoid possible SERIOUSINJURYto fingers from moving
garage door opener:
• ALWAYSkeephand clear of belt pulley while operating
opener•
• Securelyattach belt pulley cover BEFOREoperating.
HARDWARE SHOWN ACTUAL S_ZE
Hex Screw 8x3/8"
Spring/Trolley Nut
6. Hold the belt at the trolley shaft as you thread the
spring nut by hand onto the shaft until finger tight /f
• the Do tools. _/
against trolley, not use any __
7. Remove the screwdriver. M,asterLink. _ _z_
bllp-un bprlng _'_._ / /_/.,_pv_*.-
8. Position the belt cap retainer over the motor unit _....<'<_-._/jy._
• Master Link Cap ->_._
sprocket as shown and fasten to the mounting plate J_J_
with 8x3/8" hex screws provided. __'_'"-'._'<,_,
"Pin
___,_/" Trolley Master
___) Threaded Link Bar
Sh t
_ __r_'_fO ,y Round
__'_" I Retaining
Oonnee,or
Idler Pulley
I'I
Belt Cap_
Retainer
Hex Screws
#8x3/8"
Motor Unit
Belt Pulley
Plate
10

ASSEMBLY STEP 5
Set the Tension
•Insert a screwdriver tip into one of the nut ring slots
and brace it firmly against the trolley.
• Place a 7/16" open end wrench on the square end.
Rotate the nut about 1/4 turn until the spring releases
and snaps the nut ring against the trolley.
This sets the spring to optimum belt tension.
You have now finished assembling your garage door
opener. Please read the following warnings before
proceeding to the installation section.
Square
End
S j
Trolley
Nut Ring
I AFTERRE'EASE
1-1/4"
(2.5 cm) (3.18 cm)
Nut Rin(
INSTALLATION
IMPORTANT INSTALLATION INSTRUCTIONS
To reduce the risk of SEVERE INJURY or DEATH:
1. READAND FOLLOWALL INSTALLATIONWARNINGS
AND INSTRUCTIONS.
2. Install garagedoor opener ONLYon properly balanced
and lubricated garagedoor. An improperly balanceddoor
may not reversewhen required and could result in
SEVEREINJURYor DEATH.
3. ALL repairsto cables,spring assembliesand other
hardware MUSTbe madeby a trained door systems
technician BEFOREinstalling opener.
4. Disable ALL locks and remove ALL ropes connectedto
garage door BEFOREinstalling openerto avoid
entanglement.
5. Install garagedoor opener 7 feet (2.1 m) or more above
floor.
6. Mount emergency releasehandle6 feet (1.8 m) above
floor.
7. NEVERconnect garage door openerto power source until
instructed to do so.
8. NEVERwear watches, rings or loose clothing while
installing or servicing opener.They could becaught in
garagedoor or opener mechanisms.
9. Install wall-mounted garagecontrol console:
•within sight of the garage door.
•out of reachof children at minimum height of 5 feet
(1.5 m).
• awayfrom ALL moving parts of the door.
10. Placeentrapmentwarning label on wall next to garage
control console.
11. Placemanual release/safetyreversetest label in plain
view on inside of garage door.
12. Upon completion of installation, test safety reversal
system. Door MUSTreverse on contact with a 1-1/2"
(3.8 cm) high object (or a 2x4 laid flat) on the floor.
13.To avoid SERIOUSPERSONALINJURYor DEATHfrom
electrocution, disconnect ALL electric and battery power
BEFOREperforming ANYservice or maintenance.
11

INSTALLATION STEP 1
Determine the Header Bracket
Location
To prevent possible SERIOUSINJURYor DEATH:
•HeaderbracketMUSTbe RIGIDLYfastenedto structural
support on headerwall or ceiling, otherwise garagedoor
might not reversewhen required. DONOTinstall header
bracketover drywall.
• Concreteanchors MUSTbe usedif mounting header
bracketor 2x4 into masonry.
• NEVERtry to loosen, move or adjust garagedoor, springs,
cables,pulleys, brackets, or their hardware, all of which are
under EXTREMEtension.
• ALWAYScalla trained door systems technician if garage
door binds, sticks, or is out of balance.An unbalanced
garagedoor might not reversewhen required.
Installation procedures vary according to garage door
types. Follow the instructions which apply to your door.
1. Close the door and mark the inside vertical centerline
of the garage door.
2. Extend the line onto the header wall above the door.
You can fasten the header bracket within 4 feet
(1.22 m) of the left or right of the door center only
if a torsion spring or center bearing plate is in the
way; or you can attach it to the ceiling (see
page 13) when clearance is minimal. (It may be
mounted on the wall upside down if necessary, to
gain approximately 1/2" (1 cm).)
If you need to install the header bracket on a 2x4
(on wall or ceiling), use lag screws (not provided)
to securely fasten the 2x4 to structural supports as
shown here and on page 13.
3. Open your door to the highest point of travel as
shown. Draw an intersecting horizontal line on the
header wall above the high point:
• 2" (5 cm) above the high point for sectional door
and one-piece door with track.
• 8" (20 cm) above the high point for one-piece door
without track.
This height will provide travel clearance for the top
edge of the door.
NOTE: If the total number of inches exceeds the
height available in your garage, use the maximum
height possible, or refer to page 13 for ceiling
installation.
Header Wall Unfinished 2x4_
Ceiling q CEILINGOPTIONALHEADERFORMOUNTBRACKET
Vertical Centerline
of Garage Door 2x4 Structural
/' Supports
F
Header Wall
_*=T_L_2"(5 crn) Track
Highest Point
ofTravel
Door
Sectional door with curved track
_L Header Wall Track
_=="T_, 2" (5 cm)
_nt of Travel
Y
One-piece door with horizontal track
_Wall
DOlOr_ Hight st
_Hardw,are i i_ of Travel
One-piece door without track:
jamb hardware One-piece door without track:
pivot hardware
12

INSTALLATION STEP 2
Install the Header Bracket
You can attach the header bracket either to the wall
above the garage door, or to the ceiling. Follow the
instructions which will work best for your particular
requirements. Do not install the header bracket over
drywall. If installing into masonry, use concrete
anchors (not provided).
WALL HEADER BRACKET INSTALLATION
•Center the bracket on the vertical centerline with the
bottom edge of the bracket on the horizontal line as
shown (with the arrow pointing toward the ceiling).
• Mark the vertical set of bracket holes. Drill 3/16" pilot
holes and fasten the bracket securely to a structural
support with the hardware provided.
HARDWARE SHOWN ACTUAL SIZE
111111111
Lag Screw
5/16"-9xl -5/8"
Wall Mount
Optional
Mounting Holes
Header
- Wall-
2x4
Structural
Support
Horizontal
Line .-" /
J
i
Highest Point of
Garage Door Travel
Vertical
Centerlinee Door
Lag Screws
5/16"x9x1-5/8"
Spring
Garage
-- Door-
Centerline
of Garage Door
CEILING HEADER BRACKET INSTALLATION
• Extend the vertical centerline onto the ceiling as
shown.
• Center the bracket on the vertical mark, no more than
6" (15 cm) from the wall. Make sure the arrow is
pointing away from the wall. The bracket can be
mounted flush against the ceiling when clearance
is minimal.
• Mark the side holes. Drill 3/16" pilot holes and fasten
bracket securely to a structural support with the
hardware provided.
Ceiling Mounting Holes
__ -- Finished Ceiling --
/_ _ Vertical Centerline
__ __ _ / _ __ of Garage Door
Header
Bracket /_
6" (15 cm) Maximum
Door
Spring " Lag Screws
5/16"x9x1-5/8"
-- Header Wall --
Centerline
of Garage Door
13

//
//
//
//
//
Garage
Door
INSTALLATION STEP 3
Attach the Rail to the Header Bracket
NOTE: (Optional) With some existing installations, you
may re-use the old header bracket with the two plastic
spacers included in the hardware bag. Place the spacers
inside the bracket on each side of the rail, as illustrated.
• Position the opener on the garage floor below the
header bracket. Use packing material as a protective
base. NOTE: If the door spring is in the way, you will
need help. Have someone hold the opener securely on
a temporary support to allow the rail to clear the
spring.
• Position the rail bracket against the header bracket.
• Align the bracket holes and join with a clevis pin
as shown.
• Insert a ring fastener to secure.
0
\
\\
Mounting
Hole
Existing
Header Bracket
Existing 0
Clevis Pin
Spacer
Hole
)PTION W[TH
SOME EXISTING
INSTALLATIONS
Opener Carton or
Temporary
Support
HARDWARE SHOWN ACTUAL SIZE
oH @
C{evie Pin 5/16"xl -1/2" Ring Fastener
14

INSTALLATION STEP 4
Position the Opener
Follow instructions which apply to your door type
as illustrated.
SECTIONAL DOOR OR ONE-PIECE DOOR WITH
TRACK
A 2x4 laid flat is convenient for setting an ideal
door-to-rail distance.
• Remove foam packaging.
• Raise the opener onto a stepladder. You will need help
at this point if the ladder is not tall enough.
• Open the door all the way and place a 2x4 laid flat on
the top section beneath the rail.
• If the top section or panel hits the trolley when you
raise the door, pull down on the trolley release arm
to disconnect inner and outer sections. Slide the outer
trolley toward the motor unit. The trolley can remain
disconnected until Installation Step 12 is completed.
Iley
ReleaseArm _ I
ENGAGED RELEASED _d
To prevent damageto garage door, rest garage door opener
rail on 2x4 placedon top section of door.
ONE-PIECE DOOR WlTHOUTTRACK
A 2x4 on its side is convenient for setting an ideal
door-to-rail distance.
• Remove foam packaging.
• Raise the opener onto a stepladder. You will need help
at this point if the ladder is not tall enough.
• Open the door all the way and place a 2x4 on its side
on the top section of the door beneath the rail.
• The top of the door should be level with the top of the
motor unit. Do not position the opener more than 4"
(10 cm) above this point.
H Reader i'
L_ 2X4 is used to determine
the correct mounting height
from ceiling.
15

INSTALLATION STEP 5
Hang the Opener
Three representative installations are shown. Yours may
be different. Hanging brackets should be angled
(Figure 1) to provide rigid support. On finished ceilings
(Figures 2 and 3), attach a sturdy metal bracket to
structural supports before installing the opener. This
bracket and fastening hardware are not provided.
1. Measure the distance from each side of the motor unit
to the structural support.
2. Cut both pieces of the hanging bracket to required
lengths.
3. Drill 3/16" pilot holes in the structural supports.
4. Attach one end of each bracket to a support with
5/16"-18xl -7/8" lag screws.
5. Fasten the opener to the hanging brackets with
5/16"-18x7/8" hex bolts, lock washers and nuts.
6. Check to make sure the rail is centered over the door
(or in line with the header bracket if the bracket is not
centered above the door).
7. Remove the 2x4. Operate the door manually. If the
door hits the rail, raise the header bracket.
NOTE: DO NOT connect power to opener at this time.
HARDWARE SHOWN ACTUAL SIZE
Toavoid possible SERIOUSINJURYfrom a falling garage
door opener,fasten it SECURELYto structural supports of
the garage.Concreteanchors MUSTbe usedif installing any
brackets into masonry.
Figure 1
r' Supports
Measure ',
Distance
\
Bolt 5/16"-18x7/8" ',
Lock Washer 5/16"
Nut 5/16"-18
Lag Screws
5/16"-18xl -7/8"
Figure 2
Hidden _ __ _
Bracket Support _ _ __
(Not Provided) _ _ .... _ --_t_
_ FINISHED CEILING
_ Lag Screws
_ 5/16"-18xl-7/8" _J
(Not Provided)
Bolt 5/16"-18x7/8"
_ Lock Washer 5/16"
Nut 5/16"-18
Bolt 5/16"-18x7/8"
Lock Washer 5/16"
Nut 5/16"-18
Figure 3
Lag Screws _ _ _ _ _-
5/16"-18xl -7/8" _ _ _
Bolt 5/16"-18x7/8" "_\ ,/js/ Nut 5/16"-18
16

INSTALLATION STEP 6
Install the Control Console
Locate control console within sight of door, at a minimum
height of 5 feet (1.5 m) where small children cannot
reach, away from moving parts of door and door
hardware. If installing into drywall, drill 5/32" holes and
use the anchors provided. For pre-wired installations
(as in new home construction), it may be mounted to a
single gang box (Figure 2).
1.Strip 7/16" (11 mm) of insulation from one end of bell
wire and connect to the two screw terminals on back of
control console by color: white wire to 2 and white/red
wire to the 1.
2. Remove cover by gently prying at slot in top of the
cover with a small flat head screwdriver. Fasten with
6ABx1-1/4" self-tapping screws (drywall installation) or
6-32x1" machine screws (into gang box) as follows:
• Install bottom screw, allowing 1/8" (3 mm) to protrude
above wall surface.
• Position bottom of control console on screw head
and slide down to secure. Adjust screw for snug fit.
• Drill and install top screw with care to avoid cracking
plastic housing. Do not overtighten.
• Insert top tabs and snap on cover.
3. (For standard installation only) Run bell wire up wall
and across ceiling to motor unit. Use insulated staples
to secure wire in several places. Do not pierce wire
with a staple, creating a short or open circuit.
4. Strip 7/16" (11 mm) of insulation from end of bell wire.
Connect bell wire to the quick-connect terminals as
follows: white to white and white/red to red.
5. Position the antenna wire as shown.
6. Use tacks or staples to permanently attach entrapment
warning label to wall near control console, and manual
release/safety reverse test label in a prominent
location on inside of garage door.
NOTE: DO NOT connect power and operate opener at
this time. The trolley will travel to the full open position
but will not return to the close position until the sensor
beam is connected and properly aligned.
_Top
(_ I+ -- +11*')Mounting
Bell II I :1 Hole
Wire II 14 '
_. _JA-_--Terminal
II il Screws
I_,_-L-.__N'-m£ii Bottom
' Mounting
(BACK VIEW) Hole
To prevent possible SERIOUSINJURYor DEATHfrom
electrocution:
• DisconnectALL electric and battery power BEFORE
performing ANYservice or maintenance.
• ConnectONLYto 24 VOLTlow voltage wires.
To prevent possible SERIOUSINJURYor DEATHfrom a
closing garagedoor:
• Install control console within sight of garage door, out of
reachof children at a minimum height of 5 feet (1.5 m), and
awayfrom ALL moving parts of door.
• NEVERpermit children to operateor playwith control
console push buttons or remote controls.
• Activate door ONLYwhen it can be seenclearly,is properly
adjusted,and there are no obstructions to door travel.
• ALWAYSkeepgarage door in sight until completely closed.
NEVERpermit anyoneto cross path of closing garage door.
Outside Keylock Accessory Connections
To opener quick-connect terminals: white to white;
white/red to red.
HARDWARE SHOWN ACTUAL SIZE
Control Panel (std installation)
Control Panel (pre-wired)
Insulated
Staples
DrywallAnchors
Figure 1
REMOVE & REPLACE COVER
To Replace
Ta__lnsertTop
Push Bar Cover
Figure 2
PRE-WIRED INSTALLATION
24 Volt Bell Wire
Control Console Connections
Strip wire 7/16" (11 mm)
To release wire, push in
tab with screwdriver tip
Red White Grey
17

INSTALLATION STEP 7
Install the Battery
•Make sure motor unit is unplugged.
• Using a Phillips head screwdriver, remove the battery
cover on the motor unit.
• Partially insert battery into motor unit with terminals
facing out.
• Connect the red (+) and black (-) wires from motor unit
to corresponding terminals on battery.
• Replace battery cover.
Battery
INSTALLATION STEP 8
Install the Lights
• Press the release tabs on both sides of lens. Gently
rotate lens back and downward until the lens hinge is
in the fully open position. Do not remove the lens.
• Install up to a 100 watt maximum light bulb in each
socket. The lights will turn ON and remain lit for
approximately 4-1/2 minutes when power is
connected. Then the lights will turn OFF.
• Reverse the procedure to close the lens.
• If the bulbs burn out prematurely due to vibration,
replace with a Garage Door Opener bulb.
NOTE: Use only standard light bulbs. The use of short
neck or speciafity light bulbs may overheat the endpanel
or light socket.
INSTALLATION STEP 9
Attach the Emergency Release Rope
and Handle
• Thread one end of the rope through the hole in the top
of the red handle so "NOTICE" reads right side up
as shown. Secure with an overhand knot at least
1" (2.5 cm) from the end of the rope to prevent
slipping.
• Thread the other end of the rope through the hole in
the release arm of the outer trolley.
• Adjust rope length so the handle is 6 feet (1.83 m)
above the floor. Ensure that the rope and handle clear
the tops of all vehicles to avoid entanglement. Secure
with an overhand knot.
NOTE: If it is necessary to cut the rope, heat seal the cut
end with a match or lighter to prevent unraveling.
To prevent possible OVERHEATINGof the endpanel or light
socket:
•DONOTuse short neck or specialty light bulbs.
•DONOTuse halogen bulbs. UseONLYincandescent.
Release Tab
100 Watt (Max) _ )
Standard Light Bulb /
/
'i /
100 Watt (Max) _ Lens
Standard Hinge
©
Light Bulb --
Toprevent possible SERIOUSINJURYor DEATHfrom a
falling garage door:
• If possible, useemergencyreleasehandleto disengage
trolley ONLYwhengarage door is CLOSED.Weakor
broken springs or unbalanceddoor could result in an open
door falling rapidly and/or unexpectedly.
• NEVERuseemergency releasehandle unless garage
doorway is clear of persons and obstructions.
• NEVERusehandleto pull door open or closed. If rope knot
becomes untied,you could fall.
Trolley
Trolley
Release arm
Emer,
Release Handle
Overhand
Knot
18

INSTALLATION STEP 10
Electrical Requirements
To avoid installation difficulties, do not run the
opener at this time.
To reduce the risk of electric shock, your garage door
opener has a grounding type plug with a third grounding
pin. This plug will only fit into a grounding type outlet. If
the plug doesn't fit into the outlet you have, contact a
qualified electrician to install the proper outlet.
To prevent possible SERIOUSINJURYor DEATHfrom
electrocution or fire:
• DisconnectALL electric and battery power BEFORE
performing ANY serviceor maintenance.
• Garagedoor installation and wiring MUSTbe in compliance
with ALL localelectrical and building codes.
• NEVERusean extensioncord, 2-wire adapter,or change
plug in anyway to makeit fit outlet. Besure the opener
is grounded.
RIGHO
If permanent wiring is required by your local code,
refer to the following procedure.
To make a permanent connection through the 7/8" (2 cm)
hole in the top of the motor unit:
• Remove the motor unit cover screws and set the cover
aside.
• Remove the attached 3-prong cord.
• Connect the black (line) wire to the screw on the brass
terminal; the white (neutral) wire to the screw on the
silver terminal; and the ground wire to the green
ground screw. The opener must be grounded.
• Reinstall the cover.
To avoid installation difficulties, do not run the
opener at this time.
PERMANENT WIRING
CONNECTION
Ground Tab
Green
Ground Screw
Black
Ground Wire Wire
White Wire Black Wire
19

INSTALLATION STEP 11
Install The Protector System ®
(Safety Sensors)
The safety reversing sensor must be connected and
aligned correctly before the garage door opener will
move in the down direction.
IMPORTANT INFORMATION ABOUTTHE SAFETY
REVERSING SENSOR
When properly connected and aligned, the sensor will
detect an obstacle in the path of its electronic beam. The
sending eye (with an amber indicator light) transmits an
invisible light beam to the receiving eye (with a green
indicator light). If an obstruction breaks the light beam
while the door is closing, the door will stop and reverse
to full open position, and the opener lights will flash
10 times.
The units must be installed inside the garage so that the
sending and receiving eyes face each other across the
door, no more than 6" (15 cm) above the floor. Either can
be installed on the left or right of the door as long as the
sun never shines directly into the receiving eye lens.
The mounting brackets are designed to clip onto the
track of sectional garage doors without additional
hardware.
Be sure power is NOTconnectedto the garagedoor opener
BEFOREinstalling the safety reversingsensor.
To prevent SERIOUSINJURYor DEATHfrom a closing
garage door:
• Correctly connect and align the safety reversing sensor.
This required safety device MUSTNOTbe disabled.
• Install the safety reversing sensor so beam is NOHIGHER
than 6" (15 cm) abovegarage floor.
If it is necessary to mount the units on the wall, the
brackets must be securely fastened to a solid surface
such as the wall framing. Extension brackets (see
accessories) are available if needed, If installing in
masonry construction, add a piece of wood at each
location to avoid drilling extra holes in masonry if
repositioning is necessary.
The invisible light beam path must be unobstructed, No
part of the garage door (or door tracks, springs, hinges,
rollers or other hardware) may interrupt the beam while
the door is closing.
above floor
I
E
Safety Reversing Sensor
Protection Area 6" (15 cm) max.
above floor
Facing the door from inside the garage
20
