Creality BLTouch Manual

Scan QR code to view detailed instruction
Website Facebook
This guidebook is for Creality V1 mainboard.It include but not
limited to the following 3d printer:
CR-10/Ender-3
File download: https://www.creality3d.cn/download/
12/F, Block 3, JinChengYuan, Huafan Road, Tongsheng Community,
Dalang, Longhua District, Shenzhen, China, 518109
Official Website: www.creality3d.cn
Tel: [phone]
E-mail: [email protected] [email protected]
SHENZHEN CREALITY 3D TECHNOLOGY CO., LTD.
AUTO BED LEVELING SENSOR FOR 3D PRINTER
BLTouch Guidebook
for Creality V1 Mainboard
BLTouch M3X6 2PCSM3X8 2PCS
Rack Pinboard A
ISP Pinboard Burner
Connectors Tie
Packing List
①Circuit Principle ②
Update Firmware
③
Creality V1
Mainboard
EXP1
Z Stop
Screen
BLTouch
VCC
GND
SIG
BurnerISP Pinboard
Pinboard A
Connectors
2Pin 3Pin
5Pin
PC
Mianboard
ISP Pinboard
Burner
PC
1
2
1、Connect ISP Pinboard and Burner.
2、Open the control box and find out the mainboard
3、Insert ISP pinboard into the mainboard 2X3 pins as
the sign shows.
4、Insert the burner into computer USB port.
4
3
5
MISO
SCK
RST
VCC
MOSI
GND
MISO
SCK
RST
VCC
MOSI
GND
ATmega1284P
1、Open progisp.exe
2、Select Chip ATmega1284p.
3、Click ... → Set Low Value=DC, HighValue=D6, ExtValue=FD→Click Write
and close the window.
4、load Flash→Select .hex file.
5、Click Auto to update firmware，wait until it finishs, then close.
6、Unplug the ISP Pinboard from mainboard.

Circuit Wiring
⑤
Platform Adjustment
⑥
Install BLTouch
④
Software Settings
⑦
1、Insert connectors into 5 Pin
Port.
2、Install BLTocuh on the rack with
2 M3X6 screws
3、Rotate the knob until the distance between them is about 0.2mm（as a sheet of A4 paper），write down the value of A（For example, figure 3）
.
１、Ｏpen Cura
２、Settings→ Printer-Ｍanage
Printers
３、Machine Settings ４、Change "G28" to "G28 X0 Y0 G29 Z0"
4、Control→Motion→Z Offset→write down the value of B，then rotate the knob until it comes out as: C=B+A. Return Control and Select Store
settings.
3、Loosen all fan cover screws,
Install the farme on the
corresponding position with 2
M3X8 screws
4、Secure the cable to the guide tube
and cable with a cable tie and bypass
the rear side of the gantry.
0.2mm
A4 paper
12
34
1、Unplug the screen cable, connect
the pinboard A to the screen port
(EXP1).
2、Insert the screen cable into 10
pins port.
3、insert the connectors to the 3
pins port as the sign shows.
4、Unplug the Z limit switch(Z-stop
port),and insert the connectors.
1、Prepare→Auto home，and wait until it stops.
2、Prepare→Move axis→Move Z→Move 0.1mm→Rotate the knob until the distance between them is about 0.2mm（as a sheet of A4 paper），write
down the value of A.
BC
A
figure 3
Screen
