Creative Structures Crossover L User manual

Crossover L
Installation
Version 3.1

CS-0049
Main prole
ø90 mm - 219 cm
CS-0050
X-connector
28x
4x
1x
4x
4x
4x
70x 30x 110x
1x
4x
4x
4x
4x
4x
4x
CS-0334
Sub frame
center
CS-0335
Sub frame
beam ø70 mm - 108 cm
CS-0055
Lower sub prole
ø70 mm - 101 cm
CS-0054
Upper sub prole
ø70 mm - 179 cm
CS-0093
Locking pin (medium)
ø90 mm prole
CS-0105
Locking pin (small)
ø70 mm prole
CS-0248
Securing ring
CS-0336
Sub frame
connector
CS-0337
Locking strip
CS-0052
T- Connector Lower Left
Marked with “LL”
CS-0051
T- Connector Upper Left
Marked with “UL”
CS-0057
T-Connector Lower Right
Marked with “LR”
CS-0056
T-Connector Upper Right
Marked with “UR”
Crossover L
BOX CONTENTS
CS-0233
Transportbox
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏ ❏ ❏ ❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏CS-0058
Foot connector Left
4x
4x
4x
4x
1x
1x
4x
8x
8x
4x
16x
CS-0108
Foot connector Right
CS-0099
Anchor slide
CS-0148
Anchor support
CS-0497
Pull bar
CS-9012
Big Bag
CS-9013
Rope 20 m.
CS-0236
Ratchet plate
CS-9009
Turn buckle
CS-0234
Tensioning
cable
CS-0235
Positioning
cable
CS-0086
Main
cable
4x
1x CS-9037
Strap 4 m.
L
3 | 322 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl

5 | 324 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
!
Assemble frame body Secure all parts with locking pins
(long version) and securing rings
Main prole
CS-0049
X-connector
CS-0050
X-connector
CS-0050
Hooks have to
point inwards
Main prole
CS-0049
Main prole
CS-0049
!
!
STEP 1
Upper main prole
CS-0049
X-connector
CS-0050
X-connector
CS-0050
Secure all parts with locking pins
(long version) and securing rings

7 | 326 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Locking strip
CS-0337
4x
Securing ring
CS-0248
4x
Mount sub frame at frame body
STEP 3
!
!
Pre-assemble the sub frame
Sub frame center
CS-0334
Secure all parts with locking pins
(short version) and securing rings
Joint has to point
downwards
Sub frame beam
CS-0335
4x
Sub frame connector
CS-0336
4x
STEP 2

9 | 328 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
While building, the structure has to be lifted multiple times so that the assembly can easily be done on oor
level. The structure is designed for two lifting methods:
1. Lifting from below (for example with a traverse lift) by using the subframe. Requirements lifting device:
• minimum lifting height: 6 meter
• minimum save working load: 300 kg
2. Lifting from above (for example with a crane) by using lifting slings (2 meter, 1000 KG) and the hooks of the
X-connectors
LIFTING
Note: this lifting methode
requires more height for building
!
Main cable
4x per X-connector
CS-0086
Mount the rst end of the 8 tension cables
STEP 4

11 | 3210 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Main prole
CS-0049
8x
Mount the rst level of main proles
STEP 5
Secure all parts with locking pins
(long version) and securing rings
! Pre-assemble the upper sub proles (4x)
STEP 6
Upper (long) sub prole
CS-0054
T-Connector Upper Right
Marked with “UR”
CS-0056
T- Connector Upper Left
Marked with “UL”
CS-0051
Curvature has to point
downwards/backwards
!
Locking pin
Short version
CS-0105
2x
Securing ring
CS-0248
2x
UL
UR

13 | 3212 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Mount the upper sub proles (4x) Mount the second end of the 8 inner main cables
STEP 7 STEP 8
Secure all parts with locking pins
(long version) and securing rings
!
Curvature sub proles
has to point inwards
!
UL
UR

15 | 3214 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Mount the rst end of the tensioning cables
STEP 9
Secure all parts with locking pins
(long version) and securing rings
!
Mount the second level of main proles
STEP 10
Main prole
CS-0049
8x
Tensioning cable
CS-0234
8x

17 | 3216 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Mount the lower sub proles (4x)
STEP 12
Secure all parts with locking pins
(long version) and securing rings
!
Pre-assemble the lower sub proles (4x)
STEP 11
Curvature sub proles
has to point inwards
!
Curvature sub proles
has to point inwards
!
LL
LR
Locking pin
Short version
CS-0105
2x
Securing ring
CS-0248
2x
Lower (short) sub prole
CS-0055
T-Connector Lower Right
Marked with “LR”
CS-0057
T-Connector Lower Left
Marked with “LL”
CS-0052
LL
LR

19 | 3218 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Mount the second end of the 8 remaining main cables
STEP 13 Mount the last level of main proles STEP 14
Secure all parts with locking pins
(long version) and securing rings
!
Main prole
CS-0049
8x

21 | 3220 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Positioning cable
CS-0235
4x
The positioning cables are used to secure an acurate distance between the feet.
After mounting the positioning cables the structure can be placed on its feet
Pull the legs of the structure outwards to put the positioning cables under tension
!
Mount the positioning cables
STEP 16
Foot connector Left
CS-0058
Foot connector Right
CS-0108
Anchor slide
CS-0099
Anchor support
CS-0148
Mount the feet (4x)
STEP 15
Secure all parts with locking pins
(long version) and securing rings
!
Hooks have to point to the
inside of the structure
!

23 | 3222 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Mount and tension the 8 tension cables
By tensioning the tension cables all the cables in the structure get tensioned
and the structure gets its rigidity
STEP 18
Anchor the structure
STEP 17
For the dierent anchoring options and
instructions see the anchoring guide
!
After anchoring, the positioning cables can be removed.
! Use the inner hooks of the feet !

25 | 3224 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Guide the cover on both sides
!
Place the cover over the structure
The included rope can be used to pull the cover over the structure.
Tie the rope to the lifting eye.
Place the pull bars in the loops of the cover corners
STEP 19
STEP 20
Do not place the cover in windy
conditions or take decent security measures
!
Pull bar
CS-0489

27 | 3226 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
Turn buckle
CS-9009
8x
Use the outer hooks of the feet
!
Tension the contours of the cover with the turn buckles
STEP 22
Ratchet plate
CS-0236
Tension the cover at the corners
Use the the seams of the cover to align the cover with the structure
STEP 21

29 | 3228 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
NOTES
1. Hang the side panel under the cover openings using the 5 hooks on the upper contour
2. Close the zipper from right to left, seen from the inside of the structure. The 5 hooks now can be demounted
3. Tension the side panel with the lashings at the bottom. Tension the outer lashings to the structure feet and
the inner lashings to the ground
Side panel
CS-0402
Inside
Connection gutter
CS-0270
For the dierent anchoring options and
instructions see the anchoring guide
!
Mount the side panels (if desired)
Mount the connection gutter (if desired)
Close the zippers from right to left, seen from the inside of the structure
STEP 23
STEP 24

31 | 3230 | 32
Crossover L
Building instructions
www.creative-products.nl
Crossover L
Building instructions
www.creative-products.nl
