Creative Structures Hexadome L User manual

1 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Installation
Version 3.1

3 | 322 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
CS-0551
Sub frame
center
CS-0560
Foot connector
Left
1x
6x
6x
6x
18x
6x
6x
6x
6x
12x
6x
6x
3x36x 40x 140x 190x
6x
6x
12x
6x
12x
6x
12x
CS-0539
Sub frame beam
ø90 mm - 149 cm
CS-0561
Foot connector
Right
CS-0540
Upper main
prole ø125 mm - 157 cm
CS-0593
Anchor slide
CS-0541
Upper
X-connector
CS-0562
Anchor support
CS-0543
T- Connector Upper Left
Marked with “UL”
CS-0549
Tension cable
CS-0537
Upper (long)
sub prole ø90 mm - 233 cm
CS-0235
Positioning
cable
CS-9041
Rope 33 m.
CS-0536
Lower Main
prole ø125 mm - 277 cm
CS-0093
Locking pin (medium)
ø90 mm prole
CS-9039
Locking pin (large)
ø125 mm prole
CS-0542
Lower
X-connector
CS-0590
Ratchet plate
CS-9058
Turn buckle
CS-0544
T- Connector Lower Left
Marked with “LL”
CS-0547
Upper cable
CS-0546
T- Connector Lower Right
Marked with “LR”
CS-0548
Center cable
Hexadome Large
BOX CONTENTS
CS-0248
Securing ring
6x
6x
CS-0538
Lower (short)
sub prole ø90 mm - 130 cm
CS-0545
T- Connector Upper Right
Marked with “UR”
6x CS-0558
Sub frame
connector
6x CS-0559
Locking strip
6x CS-0594
Pull bar large
1x CS-0614
Transport
rack & 2x box
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏ ❏ ❏ ❏ ❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
L
24x
❏CS-9059
Carabiner

5 | 324 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Pre-assemble the lower sub proles (6x) Pre-assemble the upper sub proles (6x)
STEP 1 STEP 2
! Curvature has to point backwards
LL
LR
Lower (short) sub prole
CS-0538
T-Connector Lower Right
Marked with “LR”
CS-0546
T-Connector Lower Left
Marked with “LL”
CS-0544
Locking pin
Short version
CS-0093
2x
Securing ring
CS-0248
2x
Upper (long) sub prole
CS-0537
T-Connector Upper Right
Marked with “UR”
CS-0545
T-Connector Upper Left
Marked with “UL”
CS-0543
UL
UR
Locking pin
Short version
CS-0093
2x
Securing ring
CS-0248
2x
! Curvature has to point backwards

7 | 326 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Pre-assemble the sub frame Assemble the frame body
STEP 3 STEP 4
! Secure all parts with locking pins
(short version) and securing rings
Sub frame center
CS-0551
Sub frame beam
CS-0539
6x
Sub frame connector
CS-0558
6x
Upper main prole
CS-0540
4x
Upper X-connector
CS-0541
3x
Upper X-connector
CS-0541
3x
Upper main prole
CS-0540
2x
! Curvature has to point upwards ! Secure all parts with locking pins
(long version) and securing rings
! Hooks have to point inwards

9 | 328 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
! Secure all parts with locking pins
(long version) and securing rings Mount the sub frame at the frame body
STEP 5
Locking strip
CS-0559
6x
Securing ring
CS-0248
6x

11 | 3210 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
! Note: this lifting methode
requires more height for building
LIFTING
While building, the structure has to be lifted multiple times so that the assembly can easily be done on oor level.
The structure is designed for two lifting methods:
1. Lifting from below (for example with a traverse lift) by using the subframe. Requirements lifting device:
• minimum lifting height: 7,5 meter
• minimum save working load: 1200kg (without suspended loads)
2. Lifted from the top (for example with a crane ) by using lifting slings (2 meter, 1000 KG) and the hook
of the X-connectors
Assemble the remaining upper main proles and Lower X-connectors
STEP 6
Upper main prole
CS-0540
Lower X-connector
CS-0542
Upper main prole
CS-0540
!
!
Rotate prole clockwise to
create space for assembly
Do not secure yet

13 | 3212 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
! Secure all parts with locking pins
(long version) and securing rings
Repeat this step for the other ve sides
! Rotate prole counter clockwise
and push the X-connector slowly
in the proles
Upper cable
CS-0547
12x
Mount the rst end of the upper cables
STEP 7
! Use the two inner eyes of the X-connector

15 | 3214 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Mount the rst end of the 12 center cables Mount the rst end of the center cables
STEP 8 STEP 9
Center cable
CS-0548
12x
Lower main prole
CS-0536
12x
! Secure all parts with locking pins
(long version) and securing rings

17 | 3216 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Mount the upper sub proles (6x) Mount the second end of the 12 upper cables
STEP 10 STEP 11
UL
UR
!
!
!
Curvature sub proles
has to point inwards
Secure all parts with locking pins
(long version) and securing rings
When crossing other cables, place the cable
above the rst crossing cable and below
the next crossing cable(s)

19 | 3218 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Mount the rst end of the 12 tensioning cables Mount the second level of main proles
STEP 12 STEP 13
Tensioning cable
CS-0549
12x
Lower main prole
CS-0536
12x
! Secure all parts with locking pins
(long version) and securing rings

21 | 3220 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Mount the lower sub proles (6x) Mount the second end of the center cables
STEP 14 STEP 15
LL
LR
! Secure all parts with locking pins
(long version) and securing rings
! Curvature sub proles
has to point inwards

23 | 3222 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Mount last level of main proles Mount the feet (6x)
STEP 16 STEP 17
Lower main prole
CS-0536
12x
! Secure all parts with locking pins
(long version) and securing rings
Foot connector Left
CS-0560
Foot connector Right
CS-0561
Anchor slide
CS-0593
Anchor support
CS-0562
! Secure the Foot connectors with locking
pins (long version) and securing rings
! Hooks have to point to
the inside of the structure
! Secure the Anchor slides with locking
pins (long version) and securing rings

25 | 3224 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Positioning cable
CS-0235
6x
Mount the positioning cables Anchor the structure
STEP 18 STEP 19
! The positioning cables are used to secure an acurate distance between the feet.
After mounting the positioning cables the structure can be placed on its feet
Pull the legs of the structure outwards to put the positioning cables under tension
Remove the positioning cables after anchoring
! For the dierent anchoring options
and instructions see the anchoring guide

27 | 3226 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Mount and tension the 12 tension cables Place the cover over the structure
Place the pull bars in the loops of the cover corners
STEP 20 STEP 21
STEP 22
By tensioning the tension cables all the cables in the structure get tensioned and the structure gets its rigidity The included rope can be used to pull the cover
over the structure
! Do not place the cover in
windy conditions or take decent
security measures
Pull bar
CS-0594
! Use the inner hooks

29 | 3228 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
Tension the cover at the corners Tension the contours of the cover with the turn buckles
STEP 23 STEP 24
Use the seams of the cover to align the cover with the structure
Ratchet plate
CS-0590
Turn tensioner
CS-9039
12x

31 | 3230 | 32
Hexadome L
Building instructions
www.creative-products.nl
Hexadome L
Building instructions
www.creative-products.nl
If necessary use the lashings to shape the corners Mount the side panels (if desired)
Mount the connection gutter (if desired)
STEP 25 STEP 26
STEP 27
Close the zippers from right to left, seen from the inside of the structure
Connection gutter
CS-0270
1. Hang the side panel under the cover openings using the 5 hooks on the upper contour
2. Close the zipper from right to left, seen from the inside of the structure. The 5 hooks now can be
demounted
3. Tension the side panel with the lashings at the bottom. Tension the outer lashings to the structure feet
and the inner lashings to the ground
Inside
Side panel
CS-0402
! For the dierent achoring options and
instructions see the anchoring guide
! The walls must be closed during
stormy weather
