Creative Structures CROSSOVER M User manual

CROSSOVER M | PRODUCTSHEET | 2021 | EN | 1
CROSSOVER M
38 m2
Installation Structure and cover
2 0:45 h
Length
622 cm
Heigth
375 cm
Width
622 cm
Heigth
opening
215 cm
Dimensions Outside
Dimensions Inside
Materials Structure
Sidewalls
Materials Cover
Tubes Ø90 mm/Ø70 mm
6082T6 Alloy
Connectors Galvanized steel
Cabels Stainless steel 316
Fabric Airtex white®
Weight fabric 350 grams/m2
Reinforcements PVC
Certiication California T19 M2/B1
Sidewall with door
Sidewall Door opening
in the sidewall
Sidewall with windows Sidewall with door
and windows
Fabric Stam 6002®
Weight fabric 630 grams/m2
Reinforcements Stam 6002®
Certiication California T19 M2/B1
-20 C
-30 C
+70 C
+70 C
Gutter M
Connect Crossover M (COM)
with Crossover M (COM)
Connect Crossover M (COM)
with Hexadome M (HDM)
Connect Crossover M (COM)
with Crossover L (COL)
Connect Crossover M (COM)
with Hexadome L (HDL)
Gutter M to L
Gutters
Fabric Transparant
Weight fabric 660 grams/m2
Reinforcements PVC
Certiication California T19 M2/B1
-20 C +70 C
570 cm
280 cm
210 cm 200 cm
Dimensions (WxH) Dimensions (WxH)
1.07
3.24
26°
2 m
1 m
3 m
1 m
1 m
4 m3 m2 m1 m
+7.11
3.61 3.46 3.10 2.28
8.11
8.44

CROSSOVER M | PRODUCTSHEET | 2021 | EN | 2
Transport packaging Structure
Transport packaging Cover Mounting 2 options
315 kg 315 kg
OPTION 1  Standard 1 box (vertical)
Dimensions (LxWxH) Total weight (excl. cover)
OPTION 2  Alternative 1 box (horizontal)
Dimensions (LxWxH) Total weight (excl. cover)
1x: 120x80x247 cm 1x: 243x80x130 cm
Lights Speakers TV’s Heaters
Airtex white®
Cover 70x80x40 cm 27 kg
Sidewall 60x40x10 cm 6 kg
Sidewall with window 60x40x10 cm 6 kg
Sidewall with door 60x60x10 cm 6 kg
Sidewall with window
and door 60x60x10 cm 7 kg
Gutter M 85x48x4 cm 3 kg
Gutter M to L 68x45x6 cm 4 kg
Stam 6002®
Cover 70x80x40 cm 42 kg
Sidewall 60x40x10 cm 8 kg
Sidewall with window 60x40x10 cm 8 kg
Sidewall with door 60x60x10 cm 8 kg
Sidewall with window
and door 60x60x10 cm 9 kg
Gutter M 85x48x4 cm 3 kg
Gutter M to L 68x45x6 cm 7 kg
Mount up to 100 kg per hook
by using the hooks at the
Upper X-connector (1).
Mount up to 25 kg per insert by
using the M10 screws insert at
the Lower sub proile (2).
OPTION 1  Hooks
OPTION 2  M10 screw insert
4x
4x
2
1
TV

CROSSOVER M | PRODUCTSHEET | 2021 | EN | 3
Anchoring and ballast 4 options
OPTION 1  Anchoring Ground pens (set of 8) OPTION 2  Anchoring M12 concrete screws (set of 16)
7,6 kg (per piece) 0,1 kg (per piece)
Ø3,5x100 cm Ø1,2x9 cm
INSTRUCTIONS  Placing anchoring Ground pens INSTRUCTIONS  Placing anchoring M12 concrete screws
Used on soft surfaces
(e.g. grass, sand and gravel)
Used on hard surfaces
(e.g. concrete, asphalt and pavement)
8x 16x
28 cm 28 cm
14 cm 18 cm 5 cm
811 cm 811 cm
867 cm 867 cm
28 cm 28 cm
18 cm 18 cm 5 cm

CROSSOVER M | PRODUCTSHEET | 2021 | EN | 4
Anchoring and ballast 4 options
OPTION 3  Ballast TÜV
Ballast TÜV Straight with concrete tilesBallast TÜV Straight (set of 6)
Ballast TÜV Multiple
4x60 kg (per piece)
60 kg (per piece)
You can place 50x50x4 cm concrete tiles
on both ballast frames and secure them with
straps.
Ballast TÜV Straight is a ballast
anchoring for a singel Crossover
or Hexadome feet.
Topview connected Crossovers with
Crossovers (Village).
Ballast TÜV Straight is used as ballast
anchoring for one Crossover foot.
Ballast TÜV Multiple is used as ballast
anchoring for connecting multiple feet.
Ballast TÜV Straight
Ballast TÜV Multiple
EXAMPLE  Ballast TÜV
S
Ballast TÜV Straight can be used if the
surface is not suitable for anchoring. The
Ballast TÜV Straight contains 1 interface (1)
(Crossover ML and Hexadome M) and
2 ballast frames (2) (suitable for
Crossover ML and Hexadome ML)
The numbers and weight per foot below are
based on:
• Peak wind velocity
• Measured on the highest point of the structure
• All side panels closed
• Ballast system used
Km/h m/s Knots
78,8 km/h 21,9 kg 42,5 knots
Max. peak velocity according to European standards:
Required ballast according to European standards:
Ballast Per peak wind velocity
Ballast Requirements per peak wind velocity
S
M
S
S
SS
S
S
M
M
M
M M
M M
M
Ballast TÜV Multiple can be used if the
surface is not suitable for anchoring. The
Ballast TÜV Multiple contains 1 interface (1)
and 4 ballast frames (2).
Ballast TÜV Multiple is a ballast
anchoring for multiple feet (Village).
Wind peak Balast (per foot)
40 km/h 73 kg
50 km/h 115 kg
60 km/h 165 kg
70 km/h 255 kg
80 km/h 294 kg
90 km/h - kg
100 km/h - kg
Ballast (per foot)
285 kg
1
2
190 cm
95 cm
6 cm
98 cm
50 cm
1
2
6 cm
98 cm
94 cm

CROSSOVER M | PRODUCTSHEET | 2021 | EN | 5
BALLAST
INSIDE
CREATIVE
DECKING
CONNECT
STRUCTURE
TO DECKING
Anchoring and ballast 4 options
OPTION 4  Creative Decking
Creative Decking provides ballast with the integrated steel ballast
plates. The main part of the weight of the decking will be counted as
ballast. Therefor you will need less additional ballast. When building on
soft surfaces (e.g. grass, sand and gravel) you can also choose to use
our groundpens instead of the ballast plates.
We advise to close the Creative Structure with sidewalls in the event of
heavy winds.
8 kg (per proile)
28 kg (per plate)
88x11x6 cm (per proile)
118x58x1 cm (per plate)
8x
4x
12x
SET  Ballast Plate Set for Crossover M (4 sets of 3 plates)
Ballast proile
Ballast plate Square
399 kg
Total weight
