Creator CRT-350-N User manual

SPECIFICATION
Model No.
CRT-350-N
Date
2016/4/8
Motor-driven Card Reader
User Manual
Ver.
1.1
Page
1/17
Motor-driven Card Reader
Model:CRT-350-N
USER MANUAL
CREATOR(CHINA) TECH CO., LTD.

SPECIFICATIONS
CRT-350-NJ10 2/17
Version Profile
Version Completed Descriptions
1.1 2016-04-02 Product Outline Modification
1.0 2015-11-10 The First Release

SPECIFICATIONS
CRT-350-NJ10 3/17
CATALOG
1 Product Composition
................................................................................................ 错误！未定义书签。
2 Product Model .......................................................................................................... 错误！未定义书签。
3 Product Feature........................................................................................................ 错误！未定义书签。
4 Card Type Required.................................................................................................错误！未定义书签。
5 Universal Specs........................................................................................................ 错误！未定义书签。
6 Basic Function.......................................................................................................... 错误！未定义书签。
7 Adaptability ..............................................................................................................错误！未定义书签。
8 Lifetime..................................................................................................................... 错误！未定义书签。
9 Reliability.................................................................................................................. 错误！未定义书签。
10 Power Failure Protection........................................................................................ 错误！未定义书签。
11 Warped Card Adaptability....................................................................................... 错误！未定义书签。
12 Communication Interface....................................................................................... 错误！未定义书签。
13 Product Outline....................................................................................................... 错误！未定义书签。

SPECIFICATIONS
CRT-350-NJ10 4/17
1 Product Composition
CRT-350-N Basic composition as follows:
1－Electronic control shutter
2－Card reader main body
3－PSAM card slot
4－RS-232 communication interface
5－DC socket
Caution: Above of DC 30V is prohibited, which may damage the device.
4
5
3
2
1

SPECIFICATIONS
CRT-350-NJ10 5/17
2 Product Model
CRT-350-N
3 Product Principal Feature
The product is anATM-oriented card reader supporting magnetic stripe card & contact IC card.
1) R/W magnetic stripe card & IC card with 2 PSAM card slots.
2) Electronic control shutter, unlock shutter via mag-stripe card detected or switch.
3) Auto capture from front, eject card from front, retrieve card from rear, jittery card front insertion
4) Communication protocol complied with the requirement of banking self-service kiosk.
5) CE & RoHS approved.
6) Power down protection.
7) EMV 4.2 Level 1 & PBOC 3.0 Level 1 certified.
3.1 Card Transmission Function
Auto capture from front, eject card from front, retrieve card from rear, jittery card front insertion
Motor drive
Rubber-wheel friction drive
3.2 R/W Mag-stripe Card
Support R/W 3 tracks below:
ISO/IEC Track1
ISO/IEC Track2
ISO/IEC Track3
R/W mag-stripe card, support 300oe LOCO or Hi-Co mag-stripe card.
3.3 Communication Function
RS-232 Asynchronous half duplex communication
Interface：DB-9pin male socket
3.4 Electronic Control Shutter
Electronic control safety shutter is in close status (Default).
Unlock the shutter via command
3.5 Pre-detect the Magnetic Signal
Support ISO/IEC Track2 or ISO/IEC Track3 Unlock the shutter when magnetic signal detected.
Support ISO/IEC Track1 or ISO/IEC Track2 or ISO/IEC Track3 Unlock the shutter when
magnetic signal detected (Optional).

SPECIFICATIONS
CRT-350-NJ10 6/17
3.6 R/W Contact IC Card
Support R/W asynchronous or synchronous card
1). CPU Card (Asynchronous)
ISO/IEC 7816 -1,-2,-3 criteria
Table 1：CPU & IC Card Interface Specifications
IC Card
Definition Specifications Descriptions
Vcc DC+5V±0.25V (Max 50mA)
DC+3V±0.25V (Max 20mA) IC card power
Vpp Open circuit
Clk 3.58MHz(Default)
7.16MHz(Automatic Upgrade firmware)
Working clock is controlled by the
firmware
Baud Rate 9600~115200bps
Baud rat
e is controlled by FD
parameter.
Card Type T=0; T=1 Support T=0/T=1
PPS Support
2). Asynchronous IC Card：ISO/IEC 7816 -1,-2,-10 Criterion
Operating power：5V/3V
Support SL4442/SLE4428 R/W CPU IC card
AT24C01/24C02/24C04/24C08/24C16/24C32/24C64 R/W Memory card
AT88SC102 R/W CPU card

SPECIFICATIONS
CRT-350-NJ10 7/17
3.7 R/W SAM
Support to operate SAM,2 SAM slots integrated（SAM1,SAM2）
Support to detect SAM status
Table 2: SAM card, IC card interface specs.
IC Card
Definition Specs. Descriptions
Vcc DC+5V±0.25V (Max 50mA)
DC+3V±0.25V (Max 20mA) IC card power
Vpp Open circuit
Clk 3.58MHz(default)
7.16MHz(Automatic upgrade firmware)
Working clock is controlled by
firmware.
Baud Rate 9600~115200bps
Baud rate is controlled by FD
parameter.
Card Type T=0; T=1 Support T=0/T=1
PPS Support
SAM Card Interface Definition
PSAM Card Definition Descriptions
1 C1 VCC
2 C2 RST
3 C3 CLK
4 C5 GND
5 C6 VPP(open)
6 C7 I/O
3.8 Card Retrieve
Support retrieve card from rear.
Retrieve card with counter to read/write counting value.
3.9 Criterion
Comply with:
ISO/IEC 7811 for mag-stripe card
ISO/IEC 7816 for IC card
EMV2000 Ver 4.0 L1
PBOC 3.0 L1
3.10 Encryption
1) Support China commercial encryption algorithm (hardware integrated encrypted chip) to
provide the sensitive data transmission with encrypted protection.
2) Support DES, 3DES, AES prevailing encryption algorithm to provide the sensitive data
transmission with encrypted protection.

SPECIFICATIONS
CRT-350-NJ10 8/17
4 Card Type Requested
Length：85.47～85.90 mm
Width: 53.92～54.18 mm
Thickness: 0.76
±0.1 mm
4.1 Mag-stripe Card
1) Mag-stripe card type ISO/IEC 7810/ID-1, 7811-1/2/6 approved.
2) Magnetic force Support Lico / Hico
3) Read mag-stripe card
4) Write mag-stripe card
5) Mag-stripe card recording specs.
ISO Track1 ISO Track2 ISO Track3
Record Density 210 bpi 75 bpi 210 bpi
Data Max. Capacity 76 37 104
Record Length variable variable variable
Data Code 7 bit 5 bit 5 bit
4.2 IC Card
1) IC card criteria Comply with ISO/IEC 7816-1/2/3,
EMV 4.2 , PBOC 3.0
2) IC card type CPUcard T=0 ,T=1
SL4442,SLE4428
AT24C01,AT24C02....24C64
AT88SC102
4.3 SAM Card
1) SAM Card Criteria Comply with ISO/IEC 7810/ID000
ISO/IEC 7816-1/2/6,
2) IC Card Type SAM card T=0 ,T=1
4.4 Clean Card
Clean card forATM or card reader is suggested to be used.

SPECIFICATIONS
CRT-350-NJ10 9/17
5 Universal Specifications
5.1 Product Outline
Please refer toAppendix enclosed herein for the size & outline photo of the product.
5.2 Product Weight
Around1.3kg (Excluding accessories & package)
5.3 Power Specs.
1) Working Voltage：DC 24V ±10%
2) Power Ripple：<200mV
3) Working Current (Excluding magnetic current)：
Idle Current: < 250mA
Peak Current: <3000mA（Duration:50ms）
Card-driving current only: <1200mA
4) Electromagnetic working current:
Shutter electromagnetic current: <800mA
IC card electromagnetic current: <600mA
5.4 Communication Method
RS-232
6 Basic Function
Type Index Descriptions
Transmission
Speed Standard speed 190mm/s
±5% Transmission speed when R/W card.
Max. speed 300mm/s
Transmission
Time Around 1.5s From card-holding position to card corridor
Front card-out
length 24mm
±1mm Card-out length from front card-holding
position
Pressure Rate DC200V ,1min Between PCBA GND & metal body
Insulating
Resistor DC200V ＞10MΩBetween PCBA GND & metal body

SPECIFICATIONS
CRT-350-NJ10 10/17
7 Adaptability
7.1 Working Temperature & Humidity
5~50°, 20% ~ 80%RH
7.2 Storage Temperature & humidity
-20°~ +70°, 20% ~ 80%RH
Remarks:
Under storage status, card reader doesn’t works.
-20° Storage time <24hours
60° storage time <96hours
7.3 Vibration
Frequency scope:5～50Hz；
Acceleration:2m/s2（0.2G）；
Vibration direction & time: X,Y,Z in 3 directions,15minutes/direction.
Amplitude:2mm；
All functions won’t be effected after vibration.
7.4 Shock
Acceleration：294m/s2（30G），11ms，
X,Y,Z in three directions,1time/direction.
All functions won’t be effected after vibration.(No package condition tested.)

SPECIFICATIONS
CRT-350-NJ10 11/17
8 Lifetime
8.1 Card Reader Lifetime
Card transmission:1,000,000 times
（One time means card shuttle runs in the corridor of card reader.）
Principal Parts: R/W Magnetic Head1,000,000 times
Pre-detecting magnetic head: 1,000,000 times
Drive motor: 1,500,000 times
Synchronous rubber belt: 1,000,000 times
Drive rubber wheel: 1,000,000 times
IC card contact: 300,000 times
9 Reliability
9.1 R/W Mag-stripe card Error Rate
Error Rate：< 1/1000
Test Condition：Standard mag-stripe card tested under normal temperature(15～25℃,35～60%RH)
Test Period: 1 working stroke/10s
Remarks:Working stroke represents R/W magnetic once. New card will be replaced when 2000 times
conducted during non-stop test.
Max. mag-stripe card reading performance: support TC-JI 15% BB 30%SI Q card & TC-A 30%SI Q
card.
9.2 R/W IC Card Error Rate
Error Rate：<1/1000
Test Condition：Suitable IC card under normal temperature (15～25℃,35～60%RH)
Test Period：1 working period/10s
Remarks:
Working period means card will be fully driven to IC contact position and activated during power up.
Plus, new card will be replaced when it runs over 2000times during non-stop test.
9.3 MTBF
>200,000hours (Electronics only)
9.4 Self-diagnosis
1) Safety self-diagnosis
Self-diagnosis executed when power up or sending command or during working.
2) Sensor self-diagnosis

SPECIFICATIONS
CRT-350-NJ10 12/17
9.5 Maintenance Requirements
1) Optical sensor maintenance
2) Drive mechanism maintenance

SPECIFICATIONS
CRT-350-NJ10 13/17
10 Power Failure Protection
The card will be back to users when backup capacitor connected during main power down.
10.1 Power Failure Definition
1) Power failure value:<20V
2) Power failure lasting time:>15ms
10.2 Power Failure Troubleshooting Process:
When power failure occurred during card reader’s operation,the card inside will be driven to the front by
resetting initialization command Pd Wv and the stored power of backup capacitor.
Remarks: During power failure, the card reader won’t respond RS232 communication and DSR_PIN
displays OFF status.
More specifications on Pd,Wv,pls refers to the communication protocol of CRT-350-NJ10.
10.3 Power Failure Recovery:
The card reader will start communication and DSR_PIN will move to ON status once the main power
reaches 20V above.
10.4 Backup Capacitor Specs.:
1) Capacitor level: >0.33F(Withstand voltage >50V)
2) Capacitor output：18~25V Constant 2Aoutput ≥2s
11 Warped Card Adaptability
2mm Average warped card height <2mm
1) Warped Height <1.0mm free card move
2) Warped Height <2.5mm R/W mag-stripe card to be effected
3) Warped Height >4.0mm Card drive stuck

SPECIFICATIONS
CRT-350-NJ10 14/17
12 Electronic Interface
RS-232 Interface & Power Socket
12.1 RS-232Communication Interface
1) Card Reader’s DB-9PIN Definition
Pin Signal Input/Output Functions
1 NC --
2 RXD I Data receive
3 TXD O Data send
4 DTR O Data ready
5 SGN Signal Ground
6 DSR I Data prepare
7 RTS O Request send
8 CTS I Clear send
9 NC --
2) RS-232 Data cable wiring diagram

SPECIFICATIONS
CRT-350-NJ10 15/17
12.2 Power Socket
Pin Signal Function
1 +24V 24V main power input
2 PGND Power Ground
3 PGND Power Ground
4 +24VB Backup power input
1) Single power wiring
PIN1, PIN4 connect DC 24V positive,PIN2,PIN4 connect DC 24V Ground
2) Backup capacitor wiring （Backup capacitor specs refers to 10.4）
PIN1 connects DC 24V positive,PIN2 connect DC 24V Ground
PIN4 connect backup capacitor positive,PIN3 connect backup capacitor negative

SPECIFICATIONS
CRT-350-NJ10 16/17
13 Product Outline
350N总装图
?
3.6
10
8.15
36.95
5.73 95.77 84.53
95.77
5.73
88.57
43.5
35.35
3
CRT-350N
无特殊说明尺寸公差执行方法:
1.一般线性公差、孔径、轴的
尺寸按1级公差带执行。
2.圆角、倒角按２级公差带执
行。 3.角度尺寸公差按３级公差带
执行。
文件编号
1:1
一般公差
3 级2 级1 级
范围
±2.00 ±0.50±0.25
>250~500
±0.25
±0.10
±0.04
≤3
±1.00
±0.74 ±0.62
±0.52
±0.35
±0.40
±0.30 ±0.25
±0.18 ±0.15
±0.21
±0.15 ±0.10
±0.07>6～18
签 字 日 期
处 数 更改说明
标 记
±0.05
>3～6
>18~50
QR - 066/A.2
电 话
传 真
材 料
0755-26710105
0755-26710345
零件名称
比 例
>50~120
A.0
>120~250
版 本
产品名称
工 艺
零件代码
日 期 数 量
图样标记
mm
单 位
共 2 页 , 第 1 页
设 计 审 核
校 对
CREATOR (CHINA) TECH CO., LTD
深 圳 市 创 自 技 术 有 限 公 司

SPECIFICATIONS
CRT-350-NJ10 17/17
101.2
55.5
3
17
35
35
卡片中心线
100.9
215.4
36
3.2
177.7
350N总装图
CRT-350N
无特殊说明尺寸公差执行方法:
1.一般线性公差、孔径、轴的
尺寸按1级公差带执行。
2.圆角、倒角按２级公差带执 行。 3.角度尺寸公差按３级公差带
执行。
文件编号
1:1
一般公差
3 级2 级1 级范围
±2.00 ±0.50±0.25
>250~500
±0.25
±0.10
±0.04
≤3
±1.00
±0.74 ±0.62
±0.52
±0.35
±0.40
±0.30 ±0.25
±0.18
±0.15
±0.21
±0.15 ±0.10
±0.07>6～18
签 字 日 期
处 数 更改说明
标 记
±0.05
>3～6
>18~50
QR - 066/A.2
电 话
传 真
材 料
0755-26710105
0755-26710345
零件名称
比 例
>50~120
A.0
>120~250
版 本
产品名称
工 艺
零件代码
日 期 数 量
图样标记
mm
单 位
共 2 页 , 第 1 页
设 计 审 核
校 对
CREATOR (CHINA) TECH CO., LTD
深 圳 市 创 自 技 术 有 限 公 司
