Creda Tumble Dryer User manual

You must read these instructions prior to using the
appliance and retain them for future reference.
Condensing
Tumble Dryer
Instruction Book

Getting to know your Dryer 3
Important Safety Points 4
Installation of your Dryer 5
Caring for your Wash 6
Sorting your laundry 7
Items requiring special attention 8
How to operate your Dryer 9
Electrical Requirements 13
Caring for your Dryer 14
Something Wrong? Inside Back Cover
Service – Creda Tumble Dryers Back Cover
Contents
2
This appliance conforms to the following EEC Directives:
Low Voltage Equipment
73/23/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC
93/68/EEC
EEC Standards
Retention of this Instruction Book
This Instruction Book should be kept at hand, as it contains important details on the safe
and correct use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind,
make sure this Book is also provided so the new owner can become familiar with the
appliance and safety aspects.

3
CONTROL PANEL
PUSH HERE TO
OPEN DOOR
AIR INTAKE GRILLE
PLINTH
(NOT ON ALL MODELS)
Features - Getting to Know Your Dryer
WATER CONTAINER
FLUFF
FILTER
SERIAL/MODEL No. (RECORD DETAILS ON SERVICE PAGE AT REAR.)
CONDENSER
REVERSIBLE
DOOR CATCH
Using your Dryer is easy. Nevertheless, for your own safety and to achieve the best
results, it is important to read through this handbook before using the appliance. Your
Condenser Dryer requires specific attention, more so than a vented dryer to maintain
optimum performance.
DOOR CATCH

Note: This Dryer is only suitable for Domestic use.
Never allow children to play with
the Dryer.
Never switch the machine off
leaving a hot load in the drum.
Never tumble dry without the
filter, condenser and water
container in position.
Never exceed maximum
recommended load capacity.
Never place dripping wet
items in the drum.
Never allow lint to collect around
the Dryer.
Never use liquid conditioner in the
Dryer.
Do not dry articles that have not been
washed, rinsed and spun.
Never attempt to stand on top of your
Dryer.
Never dry fabrics that have been
chemically cleaned or have become
contaminated with solvents.
Never obstruct or drape anything over
the dryer which may block the rear
vents.
Always switch off at the Wall,
remove plug and close the
Door when not in use.
Always comply with the
specified electrical
requirements.
Ensure that your Dryer is
installed correctly and has
adequate ventilation.
Ensure air intake grille is
never obstructed or blocked.
Always finish every programme with
the cool cycle.
Always clean the filter of fluff after use.
Always empty Water Container after
every programme.
Always buy genuine Manufacturer’s
Spares and accessories.
Important Safety Points
Never ...
Always ...
4
✘ ✘
✘
✘
✘
✘
✘
✘
✘
✘
✘
✔ ✔
✔
✔
✔
✔
✔
✔

5
Installation of your Dryer
There is no internal packing to be removed before use, but make
sure the drum is empty. Wipe the inside of the Drum before use to
remove any transit dust. Your Dryer does not blow moist air into
the room, avoiding the requirement of a vent hose.
Position the Dryer where air can freely circulate around it, a 15mm
gap each side is recommended.
The door of your Dryer is reversible and can easily be changed
before installation. Exchange diagonally the hinge brackets for
blanking plugs. Exchange door latch and catch with their
opposing blanking plates. See diagram above.
Support the weight of the door when removing hinges.
Dryers can be to permanently stack on top of Washing machines,
saving valuable floor space. The Dryer should not be
located next to a hob, cooker, heater or high level grill, as heat
from these appliances could cause damage. When ordering you
must state the product numbers of the Washing machine and
Tumble Dryer (Tel. No. 0541 530 530).
Note: Separate mains plugs and sockets must be used for each
appliance. Do not use 2-way adaptors or extension leads.
As the dryer is heavy assistance should be obtained when
stacking the dryer.
HINGE
HINGE
DOOR
LATCH
DOOR
CATCH
Location
Door Reversal
Instructions
Stacking Your
Appliance

The following wash-care labels should be observed.
The majority of fabrics today can be dried in a Dryer. There are however certain fabric
finishes which need to be dried away from direct heat.
Item can be used in Dryer.
Do not use in Dryer.
Dry at high heat setting.
Dry on low heat setting.
Caring for your Wash
Items not suitable for your Dryer ...
Fabric Conditioner
For really fresh and soft fabrics, we recommend you use a liquid fabric conditioner in the final
rinse of your wash. This helps to eliminate the build up of static.
6
Items containing Rubber or Plastic
film, e.g. pillows, cushions, PVC
rainwear.
Inflammable articles or items
containing inflammable
substances, e.g. towels
contaminated with hair lacquer.
Fibreglass, e.g. some types of
curtains.
Items which have been dry cleaned.
Woollen articles.
Large bulky items, e.g. pillows,
continental quilts, sleeping bags,
double blankets and large bedspreads.

The same care should be taken for Drying fabrics as when
Washing, e.g. split fabric groups, close all zips and hooks, belts
and strings should be tied in loose bow.
It is important to extract as much water as possible from each item
before drying. This reduces the drying time, energy consumption
and the running cost.
Cotton fabrics max. 6 Kg (13.2 lb)
Synthetics, eg Polyester, polycotton max. 3 Kg (6.6 lb)
Acrylics max. 2 Kg (4.4 lb)
Note: Man-made fibres require more space to dry without creasing.
If cotton/terry towelling items are grouped with synthetic fabrics
they could remain damp at the end of the drying cycle. If this
occurs, simply replace cottons for a short period of drying to
finish off.
The table below shows the approximate weight of everyday items.
Sorting your laundry
7
Maximum Dry
Load Size
Typical Load
Clothing articles
Household items
Blouse Cotton
Other 150g 100g 5oz 4oz
Dress Cotton
Other
Cotton
Other
500g
350g 1 lb 2oz 12oz
Jeans 700g 1 lb 6oz
10 Nappies 1000g 2 lb 3oz
T-shirt
(Note: 1 Kg = 1000g)
150g 5oz
Shirt 300g
200g 10.5oz 7oz
Duvet cover
(Double) Cotton Other 1500g 1000g 3 lb 5oz 2 lb 4oz
Tablecloth Large
Small
Double
Single
700g
250g 1 lb 6oz 9oz
Tea Towel 100g 4oz
Bath Towel 700g 1 lb 8oz
Sheets 500g
350g 1 lb 2oz 12oz
Hand Towel 350g 12oz
Note: When drying
sheets, part way
through the cycle,
remove and open them
out to ensure full and
even drying.
To continue the
programme press the
start button.

Items requiring special attention
8
Drying requirements of blankets and bedspreads vary according to size,
weight and fabric.
If you have difficulty getting them into the Dryer, the machine will have
difficulty drying them properly as they expand when drying and prevent
air flow through the Dryer. This can cause the appliance to overheat.
Blankets (e.g. Acrilan, Courtelle, Dralon and Orlon) must never be over
dried. Such acrylic fabrics should be dried with care on low heat.
Always refer to manufacturers drying instructions.
Always dry starched articles separately from your normal garments.
Ensure as much of the solution is removed from the garments as possible
before placing in the Dryer.
Use a slightly heavier starch solution than you would when drying items
on the washing line.
If garments are over dried the starch will powder, leaving the fabric
limp.
Blankets and
Bedspreads
Permanently
pleated or creased
garments
Starched articles

How to operate your Dryer
9
1. Ensure hands are dry. Plug the appliance in. Switch on at the
wall socket.
2. Open the Door by pressing the Front panel as shown.
3. Place the selected fabrics into the Dryer. Ensure the fabrics
are pushed towards the back of the Drum and away from the
Door seal.
4. Always check the following:
5. Close the Door.
6. Select the required heat setting.
Press switch in at Top
Low Heat Acrylics and Synthetics
Press switch in at Bottom
High Heat Cottons
PUSH HERE &
RELEASE TO
OPEN DOOR
FLUFF FILTER
is clean and in place
WATER CONTAINER
is empty and in place
CONDENSER
is in place
Press here for Low
Press here for High

The timer control gives you the choice of either Eco/
Economy or timed drying.
To select the Eco/Economy programme turn the
timer control clockwise to the Eposition. The
ecosense/economy light will switch on. When the
load is dry this programme automatically advances
into the cool cycle, at which point the ecosense/
economy light will switch off.
Select the required Drying time by rotating the Timer
control clockwise (up to 120 minutes) just past the
required time, then anti-clockwise to the desired time.
Refer to the Drying guide.
10
TIMER
CONTROL
How to operate your Dryer
The Timer control can be set manually to any time (up to 100 minutes). This is particularly
useful for damp dry results.
The Eco/Economy option optimises the energy efficiency, saving time and money for the
user.
7. Rotate the Timer control to select the appropriate required drying
time. All of our Dryers have an energy saving feature which
reduces the heat input when the temperature in the drum reaches
a predetermined level.
Timed Dryers:
Automatic Eco/Economy
Dryer:
NOTE: Never force the Timer control beyond the
stop positions.
NOTE: Only turn the Timer control clockwise.
START
BUTTON
FILTER CARE
(NOT ALL
MODELS)
EMPTY WATER
LIGHT
HEAT
SWITCH
CONTROL
PANEL
START
BUTTON
ECOSENSE/
ECONOMY
LIGHT
EMPTY WATER
LIGHT
HEAT
SWITCH
CONTROL
PANEL
TIMER
CONTROL
ECO/
ECONOMY
PROGRAMME
0
10
20
30
40
50
60
70
80
90
100
110
120
cool
0
E
0
80
cool
100
90
70
50
40
30
60
20
10
cool
a
u
t
o
m
a
t
i
c
t
i
m
e
d
d
r
y
i
n
g
