Overview
The GLS-OIR-CSM-EX-BATT is a battery-powered, passive infrared occupancy sensor designed
for ceiling mount installation in small areas up to 500 sq ft (47 sq m). It communicates wirelessly
with a Crestron® control system via the infiNET EX® wireless network, allowing for quick
installation without running any wires.
As part of a complete Crestron system, the GLS-OIR-CSM-EX-BATT enables automation of
lighting, shading, HVAC, and AV equipment based on room occupancy or vacancy. It can also be
used to expand the capabilities of room scheduling, asset management, or energy monitoring
solutions through integration with the Crestron Fusion® Enterprise Management service.
This section provides the following information:
•Features

2 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Features
Key features include:
lWireless ceiling mount occupancy sensor
lPassive infrared motion detection
l360 degree, 500 sq ft (47 sq m) coverage
lHalf mask and perforated mask included
l10-year battery life using 9V lithium battery (included)
lControl system integration via infiNET EX® wireless network
lVacancy-only capability with grace occupancy
lDiscreet, low-profile appearance
Passive Infrared Occupancy Sensing
Passive infrared (PIR) technology employs a highly sensitive, specialized lens that divides the
field-of-view into sensor zones. The sensor detects motion when a person passes between zones,
achieving dependable motion detection with superior immunity to false triggering from
vibrations, inanimate objects, or movement in an adjacent corridor. The detection sensitivity is
adjustable for optimum performance. Timeout can be set anywhere from 30 seconds to 30
minutes to maintain occupied status during short periods of inactivity. A half mask and
perforated mask are included to customize the coverage area.
Vacancy Only Mode with Grace Occupancy
The GLS-OIR-CSM-EX-BATT can be configured via the control system program to sense vacancy
only. In this mode, lighting and other equipment is shut off automatically when a room becomes
vacant, but can only be turned on manually. If the lights turn off while someone is in the room,
they can be turned back on by simply waving a hand within the 15 second grace period.
infiNET EX® Wireless Technology
Ultra-reliable infiNET EX wireless technology provides steadfast two-way RF communications
throughout a residential or commercial structure without the need for physical control wiring.
The GLS-OIR-CSM-EX-BATT communicates with a Crestron control system via an infiNET EX
wireless gateway (CEN-GWEXER, sold separately), and functions as part of a complete network
of wireless sensors, lighting dimmers, motorized shades, thermostats, door locks, keypads,
handheld remotes, and other devices.
Crestron infiNET EX wireless technology employs a mesh network topology so each “EX” device
on the network acts as a routing node or “expander,” which relays the signals it receives on to
other EX devices within range. This effectively extends the total range of the network and
provides multiple redundant signal paths for extra reliability. A maximum of six “hops” across
routing nodes is allowed, although a maximum of three is recommended. Please note that the
GLS-OIR-CSM-EX-BATT and other battery-powered infiNET EX devices only operate as leaf
nodes and do not provide expander functionality. If needed, up to five dedicated infiNET EX
expanders (CLW-EXPEX, sold separately), may be deployed as supplemental routing nodes to fill

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 3
any gaps in coverage. Up to 100 infiNET EX devices are permitted per gateway, although best
practices suggest a limit of 50. For details, refer to the “Installation and Setup of Crestron RF
Products, Best Practices” guide.
Ceiling Surface Mount Installation
The GLS-OIR-CSM-EX-BATT includes hardware for mounting to a typical drywall or drop-tile
ceiling. When installed, it achieves a discreet appearance against a white ceiling, and the body
may be painted to blend with other surfaces.
NOTE: Painting over the lens may result in erroneous occupancy detection.

4 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Specifications
Product specifications for the GLS-OIR-CSM-EX-BATT.
Product Specifications
Sensing
Motion Detection
Technology
Passive infrared (PIR) motion detection
Coverage Area 500 sqft (47 sq m)
Coverage Pattern 360° (half mask and perforated mask included)
Major Motion Area 150 to 500 sq ft (14 to 47 sq m)
Minor Motion Area 0 to 150 sq ft (0 to 14 sq m)
LED Indicators
STATUS (1) Red and (1) green LEDs for test mode, setup, and battery condition
Controls
SENSITIVITY (1) Knob (behind cover), adjusts PIR sensitivity from low to high
TIMEOUT (1) Knob (behind cover), adjusts timeout from 30 seconds to 30 minutes
TEST (1) Pushbutton (behind cover) for test mode, setup, and battery condition
Wireless
RF Transceiver infiNET EX 2-way RF, 2.4 GHz ISM Channels 11-26 (2400 to 2483.5 MHz), default
channel 15;
IEEE 802.15.4 compliant
Range (typical) 50 ft (15 m) to gateway or nearest mesh network device(s), subject to site-
specific conditions and individual device capabilities, range between floors or
ceilings is limited to one level
Gateway Requires an infiNET EX gateway (sold separately)
Power Requirements
Battery (1) Ultralife® U9VL-J-P 9 Volt 1200 mAh lithium disposable battery (included)
Battery Life 10 years under normal operating conditions
Environmental
Temperature 32° to 104°F (0° to 40°C)
Humidity 10% to 90% RH (noncondensing)

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 5
For indoor use only
Construction
Housing Plastic, white finish, removable cover
Mounting Ceiling surface mount, 3in. (76mm) screw spacing
Dimensions
Height 1.19 in. (31 mm)
Diameter 4.38 in. (112 mm)
Weight
0.4lb (170g)
Compliance
Regulatory Model: GLS-OIR-CSM-EX-BATT
CE, IC, FCC Part 15 Class B digital device
To search for product certificates, refer to support.crestron.com/app/certificates.

6 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Dimension Drawings

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 7
Installation
This section provides the following information:
•Determine the Mounting Location
•Mounting

8 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Determine the Mounting Location
Use the following information to help determine the ideal mounting location.
NOTE: When determining the mounting location:
lAvoid areas where false tripping may occur due to outside motion such as an open
door.
lIdentify and avoid areas of possible vibrations and air currents (for example,
projectors, fans, vents) and mount the sensor at least 5 feet (2 meters) away from
these items.
PIR Masking
Use the included masks to block part of the PIR sensor to prevent it from detecting motion in
that area. Insert the half mask into the dome of the occupancy sensor to block 180° of the
detection area or remove any of the twelve 30º perforations from the full mask for a custom
detection area.
The following images provide typical illustration examples.
Occupancy Sensor Mounted in a Corner

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 9
Occupancy Sensor Mounted inCenter of Room, Perforated Mask Used to Block Doorways

10 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Motion Detection Range
The detection pattern for the sensitivity settings are shown in the illustrations that follow.
Top View - 8ft (~2.5m)

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 11
Side View - 8 - 12ft (~2.5 - 3.5 m)

12 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Mounting
Install in a drop ceiling or drywall, or into an octagon electrical box. The following items are
included with the GLS-OIR-CSM-EX-BATT for installation.
In the Box
Qty. Description
2 Plastic WallAnchors
2 Phillips Head Screws
1 1/2 Solid PIR Mask
1 360 degree 12 section perforated PIRmask
1 Ultralife 9 volt lithium battery
The following items are required for installation:
lPhillips head screwdriver
lPencil
lCutting Tools
NOTE: Ensure that the cover faces in the correct direction when it is installed.
Installing The Sensor
NOTE: To determine the mounting location, refer to Determine the Mounting Location on
page 8
1. Mark two holes on the mounting surface 3in.(76mm) apart for the plastic wall anchors.
2. Install the plastic wall anchors.

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 13
3. Twist the sensor cover counterclockwise to separate it from the sensor base.
4. Connect the battery to the two terminals in the sensor and secure the battery into the
housing.

14 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
5. Using the Phillips head screws and screwdriver, mount the base of the sensor to the plastic
wall anchors.

Product Manual — Doc. 9239A GLS-OIR-CSM-EX-BATT • 15
6. Align the arrows on the sensor cover with the arrows on the sensor base and then place
the sensor cover on the sensor base. Twist clockwise until the sensor cover clicks into place.

16 • GLS-OIR-CSM-EX-BATT Product Manual — Doc. 9239A
Configuration
Prior to configuration, ensure the device is running the latest firmware. To update the firmware,
refer to Firmware Upgrade on page 22.
The GLS-OIR-CSM-EX-BATT detects motion in a room to determine if the room is occupied or
vacant and then relays the occupancy or vacancy state to the connected control system. If the
sensor no longer detects motion, the timeout triggers. The length of the timeout is set using the
TIMEOUT knob under the cover.
NOTES:
lThe sensor requires a complete cycle of occupancy, vacancy, and the vacancy timeout
for proper operation. If occupancy is detected and the sensor turns on the lights, and
then the occupant quickly exits the room and turns the lights off using a local switch,
the sensor will not turn the lights on again until it can complete the vacancy timeout.
To avoid this, set the TIMEOUT knob on the sensor to 30s and program the timeout via
the control system.
lThe red LED will flash to indicate that the battery needs to be replaced. To replace the
battery, refer to Replace the Battery on page 20.
Timeout Settings
The time that the sensor takes to declare the room vacant after motion is no longer detected is
determined by the TIMEOUT knob setting inside the sensor. The TIMEOUT knob does not scale
linearly; it ranges from 30 seconds to 30 minutes with the midpoint of the knob corresponding to
5 minutes. Markings of 30s, 2m, 5m, 15m, and 30m are on the label to identify the settings.
Timeout settings can be changed by the control system based on the time of day or occupancy
status. The timeout settings revert back to the settings on the GLS-OIR-CSM-EX-BATT when no
control system overrides exist.
Sensitivity Settings
The sensor sensitivity can be adjusted so that small, medium, or large motion is required to
trigger an action within a 500 sqft (47sqm) detection area. The sensitivity scales linearly. The
top of the knob (High) represents high sensitivity (small motions such as finger and head
movement are needed to trip the device), the mid-point (Med) represents medium sensitivity
(medium motions such as moving arms and legs are needed to trip the device), and the bottom
of the knob (Low) represents low sensitivity (large motions such as entering or exiting a room
are needed to trip the device).
