Crestron Avia AMPI-8075 Dimensional drawing

DO GUIDE
Speaker Connections
The speaker outputs can be wired conventionally, or they can be bridged to deliver higher power to a speaker. Refer to the following diagrams when
connecting speakers.
WARNING: This amplier is capable of delivering high power to the loudspeakers. Please use caution and adequate ear protection if listening to content at
high volume levels, as continued exposure to high sound pressure levels can cause permanent hearing impairment or loss.
Conventional wiring Bridged wiring
Speakers are bridged with the Avia Audio tool, which can be downloaded from www.crestron.com/software. The possible bridging combinations are Output 1
& Output 2, Output 3 & Output 4, Output 5 & Output 6, and Output 7 & Output 8.
NOTE: Only 8 ohm speakers can be bridged.
Fuse Replacement
If the amplier does not power up when the power is turned on, the fuse may need to be replaced. The fuse holder is located on the rear panel, next to the
power switch. To replace the fuse, perform the following procedure:
1. Disconnect power to the amplier.
2. Use a at-head screwdriver to push in the fuse holder.
3. While pushing in the fuse holder, turn the screwdriver counterclockwise until the fuse holder pops out.
4. Remove the fuse from the fuse holder and insert a new fuse.
CAUTION: Use the specied type of fuse only. Failure to do so may cause damage to the amplier.
NOTE: One spare fuse is included.
5. Insert the fuse holder into the amplier.
6. Push in the fuse holder with a at head screwdriver. While pushing in the fuse holder, turn the screwdriver clockwise until the fuse holder sets into place.
7. Push in the fuse holder a little further and turn the screwdriver clockwise until the fuse holder locks in place.
8. Connect power to the amplier.
AMP(I)-8075/AMP(I)-8150
AviaTM 8-Channel Commercial Ampliers
The Avia™ AMP-8075, AMPI-8075, AMP-8150, and AMPI-8150 feature similar operation. For simplicity within this guide, the term “amplier” is used for all
models except where noted.
DO Install the Device
These devices occupy 1U of rack space. Using a #1 or #2 Phillips screwdriver, attach the included rack ears to the device, and then mount the device into the
rack using eight mounting screws (not included).
DO Connect the Device
Make the necessary connections as called out in the following diagrams. Connect power last.
CAUTION: When connecting a Windows®7 or Windows 8 computer to the COMPUTER port for the rst time, make sure the computer has a live connection
to the Internet. For more information, refer to Answer ID 5745 in the Online Help section of the Crestron website (support.crestron.com).
CAUTION: Keep the device unplugged until all of the input, network, and speaker wiring is complete.
CAUTION: Check the speaker wires for shorts and frayed wiring around the SPEAKER OUTPUTS connectors.
NOTE: Ensure the unit is properly grounded by connecting the chassis ground lug to an earth ground (building steel).
NOTE: To prevent overheating, do not operate this product in an area that exceeds the environmental temperature range listed in the table of specications
on the product web page.
Front Panel
Rear Panel
DO Check the Box
QUANTITY PRODUCT PART NUMBER
2Bracket, Rack Ear, 1U 2032122
2Bracket, Rear Mounting 2045677
1 Cable, USB 2.0, A - B, 6' (1.83 m) 2014966
8Connector, 2-Pin 2044402
8Connector, 3-Pin 2003575
AMP-8075 and AMP-8150 Only
1 Fuse, 10.0 A, Time Lag, 1.25" x 0.25", Ceramic Cartridge, 250 V 2017577
1 Power Cord, 6' 7" (2 m) 20 01134
AMPI-8075 and AMPI-8150 Only
1 Fuse, 6.3 A, Time Lag, 5 x 20 mm, Ceramic Cartridge, 250 V 2024846
1Power Cord Varies by country
Install front rack ears. Install rear rack ears.
1 2
1
MODELS REQUIRED FUSE TYPE
AMP-8075
AMP-8150
(US & Canada)
10.0 A, Time Lag, 1.25" x 0.25",
Ceramic Cartridge, 250 V
AMPI-8075
AMPI-8150
(International/220-240 VAC)
Fuse, 6.3 A, Time Lag, 5 x 20 mm,
Ceramic Cartridge, 250 V
COMPUTER:
Direct computer connection to device
8 ΩONLY
EVEN
BRIDGE CH
ODD
SPEAKER OUTPUTS:
To speakers
LAN:
10/100/1000BASE-T Ethernet to LAN
LINE INPUTS 1–8:
From DSP outputs
POWER:
From ac power outlet
Ground

DO GUIDE DOC. 7813D (2047094) 06.17
Specications subject to change without notice.
DO Operate the Device
Apply Power
To turn the amplier and audio outputs on, move the POWER switch to |. To turn the amplier and audio outputs off, move the POWER switch to O. This will
also reset the unit.
When power is applied to the device, the PWR LED on the front panel operates with the following behavior:
• Green - Normal operation
• Amber - Device is booting up
• Amber/Green (Cycling) - No network connection
Adjust the Signal Levels
Each input has its own signal level control that can be adjusted as necessary to balance the sound between inputs or to accommodate different audio
sources. To adjust an input’s level, turn the knob clockwise to increase the signal level or turn the knob counterclockwise to reduce the signal level.
Monitor Operation
Use the front panel’s status indicators and VU meters to monitor each speaker output.
LEDs in the STATUS section indicate the following for each output:
• Presence of a fault
• An overcurrent condition
• A DC offset condition
• Excessive operating temperature
• 70 volt operation (100 volt operation for AMPI-8075 and AMPI-8150)
LEDs in the VU section indicate each output’s signal level and whether a clipping condition is present.
Reset the Device
Press RESET on the front panel to restart the device.
As of the date of manufacture, these products have been tested and found to comply with specications for CE marking.
These products are Listed to applicable UL®Standards and requirements tested by Underwriters Laboratories Inc.
Ces produits sont énumérés aux normes applicables et les exigences UL par Underwriters Laboratories Inc.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
CAUTION:Changes or modications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)
Rack Mounting Safety Precautions
•Elevated Operating Ambient Temperature: If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient
temperature. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specied by the manufacturer.
•Reduced Airow: Installation of the equipment in a rack should be such that the amount of airow required for safe operation of the equipment is not compromised.
•Mechanical Loading: Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.
•Circuit Overloading: Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and
supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
•Reliable Earthing: Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit
(e.g., use of power strips).
Electrical Connection
“This product must be connected to an earthed mains socket-outlet.”
• Finland: “Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.”
• Norway: “Apparatet må tilkoples jordet stikkontakt.”
• Sweden: “Apparaten skall anslutas till jordat uttag.”
The specic patents that cover Crestron products are listed at http://www.crestron.com/legal/patents. The product warranty can be found at www.crestron.com/warranty
Certain Crestron products contain open source software. For specic information, please visit www.crestron.com/opensource.
Crestron, the Crestron logo, and Avia are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Windows is either a trademark or registered trademark of Microsoft Corporation in the United States and/or other countries. UL and the
UL logo are either trademarks or registered trademarks of Underwriters Laboratories, Inc. in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their
products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2017 Crestron Electronics, Inc.
DO Learn More
Visit the website for additional information and the latest rmware updates. To learn more about this product, use a
QR reader application on your mobile device to scan the QR images.
Crestron Electronics
15 Volvo Drive, Rockleigh, NJ 07647
888.CRESTRON | www.crestron.com
AMP-8075 AMP-8150
