Media Presentation Audio
Amplifier: MP-AMP30
Introduction
The Crestron®MP-AMP30 provides a convenient, low-cost audio amplifier solution
for a variety of applications. A perfect complement to the entire Media Presentation
line from Crestron, it features a compact surface-mountable design that installs
virtually anywhere without requiring an equipment rack. High-efficiency Class D
circuitry delivers 15 Watts per channel to drive one or two pairs of 8-Ohm speakers,
or a single pair of 4-Ohm speakers, making it ideal to support stereo speakers at the
front of a room or mono speakers in the ceiling. Mono-summed operation is enabled
by changing two jumpers on the front panel.
Refined, reliable operation is ensured thanks to pop-free turn-on circuitry and
electronic short-circuit and overload protection. An energy-saving design achieves
optimum efficiency under load, and powers down automatically when no input
signal is detected for more than five minutes, reducing overall power consumption
and heat as part of a green system design. Its extruded aluminum housing is both
attractive and effective at dissipating heat, affording a silent running design without
cooling fans.
Features and Functions
• Compact surface mount power amplifier
• 15 Watts per channel into 8 or 4 Ohms
• Stereo or mono-summed operation
• High-efficiency Class D topology
• Energy saving design reduces power consumption when idle
• Convection cooled for noiseless operation
• Simple volume, bass, and treble adjustments
• Built-in loudness contour circuit
• Electronic short-circuit and overload protection
• Detachable terminal block speaker connections
• Unbalanced RCA line inputs, 3-foot (~0.9 meter) cable included
Operations & Installation Guide – DOC. 6917B Media Presentation Audio Amplifier: MP-AMP30 •1

Media Presentation Audio Amplifier Crestron MP-AMP30
Installation and setup of the MP-AMP30 is simple. Detachable output connectors
facilitate the termination of speaker wiring up to 16 gauge. RCA inputs connect
directly to the line output of a video projector or display, audio processor, mixer, or
AV switcher. Rotary controls provide for adjusting the overall speaker volume, as
well as bass and treble. For quiet environments, loudness compensation is employed
by setting the volume control below the center detent position.
Applications
The following diagram shows an MP-AMP30 in a typical application.
Specifications
Specifications for the MP-AMP30 are listed in the following table.
MP-AMP30 Specifications
SPECIFICATION DETAILS
Audio
Input Volume Range
Loudness
Bass Gain Range
Treble Gain Range
Frequency Response
S/N Ratio
THD+N:
Output Power
-55dB to +20dB
Active at volume settings below center detent
±15dB @ 100Hz
±15dB @ 10kHz
20Hz to 20kHz ±0.5dB
75dB 20Hz to 20kHz A-weighted
0.7% 20Hz to 20kHz
15 Watts per channel at 8 or 4 Ohms
Power Requirements
Power Consumption
48 Watts (2.0 Amps @ 24 Volts DC) Power supply
included
(Continued on following page)
2 •Media Presentation Audio Amplifier: MP-AMP30 Operations & Installation Guide – DOC. 6917B

Crestron MP-AMP30 Media Presentation Audio Amplifier
MP-AMP30 Specifications (Continued)
SPECIFICATION DETAILS
Environmental
Temperature
Humidity
Heat Dissipation
41º to 104º F (5º to 40º C)
10% to 90% RH (non-condensing)
21 BTU/Hr
Enclosure
Chassis
Mounting
Aluminum w/polycarbonate label overlay and four
integral mounting flanges
Freestanding or surface mount
Dimensions
Height
Width
Depth
5.85 in (149 mm)
3.91 in (100 mm)
1.43 in (37 mm)
Weight 11.8 oz (335 g)
Physical Description
This section provides information on the connections, controls and indicators
available on your MP-AMP30.
MP-AMP30 Front View
Operations & Installation Guide – DOC. 6917B Media Presentation Audio Amplifier: MP-AMP30 •3

Media Presentation Audio Amplifier Crestron MP-AMP30
MP-AMP30 Overall Dimensions
4 •Media Presentation Audio Amplifier: MP-AMP30 Operations & Installation Guide – DOC. 6917B

Crestron MP-AMP30 Media Presentation Audio Amplifier
Connectors, Controls & Indicators
# CONNECTORS*,
CONTROLS &
INDICATORS
DESCRIPTION
1 BASS Control
Rotary low frequency boost/cut adjustment,
flat at center detent
2 TREBLE Control Rotary high frequency boost/cut adjustment,
flat at center detent
3 VOL Control Rotary input level adjustment
4 AUDIO OUT 8Ω, R, L
+ - + -
R L
(2) 2-pin 3.5 mm detachable terminal blocks;
Left & right channel speaker-level audio
outputs
Wire Size: Connector accepts 16 AWG
maximum
Output Power: 15 Watts per channel at 8 or 4
Ohms
5, 6 AUDIO IN
L R
(2) RCA female
Unbalanced stereo line-level audio input
Maximum Input Level: 2 Vrms
Input Impedance: 18k Ohms
3 ft (0.9 m) stereo RCA-RCA cable included
7
ST
MO
Mode selection jumpers, select stereo or
mono-summed operation
8 PWR
O
(1) green LED, indicates operating power
supplied from external power supply
9
(1) 2.1 mm barrel DC power jack, 24 Volt DC
power input;
(Power supply included)
* Interface connectors for AUDIO OUT ports are provided with the unit.
Operations & Installation Guide – DOC. 6917B Media Presentation Audio Amplifier: MP-AMP30 •5

Media Presentation Audio Amplifier Crestron MP-AMP30
Setup
Installation
Mount the MP-AMP30 to a flat surface near the audio source equipment, using four
screws (not supplied).
Hardware Hookup
Hardware Connections for the MP-AMP30
Before applying power, do the following:
1. Make sure the shunt jumpers are properly positioned for stereo (ST) or
mono (MO) audio. (Refer to diagram on unit.)
2. Connect all input and output cables (refer to the above illustration).
3. Set the BASS and TREBLE controls to their default center detent
positions, and set the VOL control to a low (counterclockwise) position.
Apply power and verify operation as follows:
1. With the 24VDC power source connected, the green LED should be
illuminated.
2. Slowly turn the VOL control clockwise until the audio is at a comfortable
level.
3. Adjust the TREBLE and BASS controls to suit personal preference.
6 •Media Presentation Audio Amplifier: MP-AMP30 Operations & Installation Guide – DOC. 6917B
