Crestron CLS User manual

CrestronCLS/CLSI-C6&CLS/CLSI-C6M
iLux®IntegratedLightingSystem
OperationsGuide
(FirmwareV2.01.01orlater)

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
Regulatory Compliance
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Industry Canada (IC) Compliance Statement
As of the date of manufacture, the CLS/CLSI-C6/C6M has been tested and found to comply with specifications
for CE marking and standards per EMC and Radiocommunications Compliance Labelling.
Crestron, the Crestron logo, Cameo, Cresnet, Crestron Green Light, Crestron RoomView, Crestron Toolbox, D3 Pro, iLux, Isys, SIMPL
Windows and SystemBuilder are trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and other
countries. Somfy is either a trademark or registered trademark of Somfy Systems, Inc. in the United States and/or other countries.
Windows is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
©2011 Crestron Electronics, Inc.

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
Contents
iLux®Integrated Lighting System: CLS/CLSI-C6/C6M 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Specifications ..............................................................................................................4
Physical Description....................................................................................................6
Setup........................................................................................................................................10
Identity Code.............................................................................................................10
Installation.................................................................................................................10
Configuring the CLS-C6..........................................................................................................11
Configuring With Front Panel Controls ....................................................................11
Configuring With iLux Designer...............................................................................23
Console Command Settings ......................................................................................25
Replacing the Function Button Label........................................................................26
Programming Software............................................................................................................28
Earliest Version Software Requirements for the PC .................................................28
Programming with Crestron SystemBuilder..............................................................28
Programming with D3 Pro.........................................................................................28
Programming with SIMPL Windows........................................................................29
Uploading and Upgrading........................................................................................................31
Establishing Communication.....................................................................................31
Programs and Firmware ............................................................................................32
Program Checks ........................................................................................................32
Operation.................................................................................................................................33
Button Types .............................................................................................................33
IR Receiver................................................................................................................35
Occupancy Sensing ...................................................................................................35
Override Mode ..........................................................................................................36
Load Shedding (Demand Response) .........................................................................36
Building Management System (BMS) Interface .......................................................37
Problem Solving ......................................................................................................................40
Troubleshooting.........................................................................................................40
Reference Documents................................................................................................40
Further Inquiries........................................................................................................41
Future Updates ..........................................................................................................41
Appendix A: Supported Devices .............................................................................................42
Keypads.....................................................................................................................42
Shade Controllers......................................................................................................44
Touch Panels .............................................................................................................44
Appendix B: Console Commands............................................................................................52
Appendix C: Factory Default Values.......................................................................................56
Appendix D: Button Functions................................................................................................58
Appendix E: Room Combining ...............................................................................................67
Appendix F: RC5 Code Expansion..........................................................................................70
Software License Agreement...................................................................................................71
Return and Warranty Policies..................................................................................................73
Operations Guide - DOC. 6347C Contents •i

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
Merchandise Returns / Repair Service.......................................................................73
CRESTRON Limited Warranty.................................................................................73
ii •Contents Operations Guide - DOC. 6347C

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
iLux®Integrated Lighting System:
CLS/CLSI-C6/C6M
iLux®Integrated Lighting System:
CLS/CLSI-C6/C6M
IntroductionIntroduction
Features and Functions
• Wall-mounted integrated lighting and shade control
• Six channels of dimming or switching
• Six groups of shade or drape control
• Linkable for up to 54 lighting channels and 54 shade groups
• Up to 16 user-settable scenes
• Seven configurable “rocker” buttons with customizable label strip
• Large ON and OFF buttons
• Flip-up front cover reveals setup controls and programming port
• Six bar graphs show lighting levels and shade positions
• Easy setup from front panel or iLux Designer software
• Built-in motion detector (CLS/CLSI-C6M)
• Optional IR remote
• Supports multipoint control using up to 16 keypads
• Supports touchpanel control using up to two touchpanels
• Supports external occupancy sensors
• Supports room combining of up to 36 partitions
• Supports integration with building management system
• Master air-gap relay | 230V AC version available
• Integrates with 2-Series control systems via Cresnet®
• Energy saving ASHRAE 90.1/LEEDS compliant
• Available in almond, black, or white
• Supports Daylight Harvesting
The CLS/CLSI-C6 and CLS/CLSI-C6M iLux®units are complete, integrated wall-
mounted lighting systems that can function as standalone devices and/or be part of a
Crestron®solution total control system network. The units are intended for
installation in boardrooms, auditoriums, home theaters, or anywhere versatile and
cost-effective control of lighting and shades is required. The CLS-C6 and CLS-C6M
are designed for 120 VAC installations; the CLSI-C6 and CLSI-C6M are designed
for 230 VAC installations. All units are functionally identical, except that the
CLS/CLSI-C6M units include a built-in motion sensor. For simplicity in this guide,
the term "CLS-C6" is used except where noted.
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •1

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
Six Channel Dimming
The CLS-C6 features six channels of dimming for LED*, incandescent, magnetic
low-voltage, neon/cold cathode, and two-wire dimmable fluorescent loads. On/off
switching of many non-dimmable lighting loads is also possible. Each channel will
handle up to 800 watts individually, with a total rating of 1920 watts at 120 VAC for
CLS-C6/C6M (2300 watts at 230 VAC for CLSI-C6/C6M). Larger loads and
additional load types can also be supported using Crestron CLS-EXP series
expansion modules.
Six Group Shade Control
Using Crestron’s networked shade and drape controllers (sold separately), the
CLS-C6 enables versatile control of a roomful of motorized window treatments,
screens, and lifts in up to six shade groups. Each controller is connected to the
CLS-C6 via the four-wire Cresnet®bus.
Energy Management
Using Crestron Green Light®technology the iLux line of integrated lighting systems
allow for the management of demand response for load shedding and room
occupancy sensing for maximum energy efficiency and cost savings.
Versatile Operation
The deceptively clean front panel actually affords an extensive amount of control
and customization to suit each unique room application. Large ON and OFF buttons
provide instant access to the “On” and “All Off” scenes, while the six main buttons
can be set up to recall additional scene presets, adjust shades, or perform a host of
other functions. The buttons' “rocker” action enables intuitive control for adjusting
lighting levels and shade positions. An additional “up/down” button is configurable
for a variety of functions, including use as a master lighting or shade control, or as a
“shift” button to expand the capabilities of the six main buttons.
With each new scene selection, window shades reposition and lights fade elegantly
to their new settings. The selected scene is indicated by a white LED beside each
button, and the customizable label strip allows each button to be clearly labeled
using Crestron Engraver software or standard 3/8” tape labels. Dimming levels and
shade positions are displayed graphically on six green LED bar graphs accessible
behind the flip-up front cover. Additional controls and a numeric display hidden
beneath the cover enable setup without requiring a PC. Enhanced customization is
provided via the PC programming port using iLux Designer software.
Built-in Motion Detector (CLS/CLSI-C6M)
The CLS/CLSI-C6M model provides the addition of a built-in infrared motion
detector, enabling automated control based on room occupancy. Lights can be
programmed to turn on and shades open automatically when someone enters the
room, or turn off and close when the room is left empty. Remote motion detectors
are also available to expand the coverage of the CLS/CLSI-C6M, or add occupancy
sensing capability to the CLS/CLSI-C6M.
Daylight Harvesting
When used with an optional GLS-LOL photocell, the CLS-C6 is capable of reducing
energy usage by employing “daylight harvesting”. This technique allows the electric
light levels to be reduced based on the amount of natural light available in the space.
* For a list of compatible ballasts, visit www.crestron.com/lightingcompatibility.
2 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
The GLS-LOL may be connected to the CLS-C6 through either a GLS-SIM or the
available input on a Cameo®“Pro” keypad. For more information, refer the latest
version of the Crestron iLux Lighting Systems Installation Guide (Doc. 6394 for
CLS-C6/C6M; Doc. 6413 for CLSI-C6/C6M), which is available from the Crestron
Web site (www.crestron.com/manuals).
IR Remote Control
The CLS-C6 units are equipped with an onboard IR receiver to allow for wireless
remote control using Crestron’s optional infrared remote control (sold separately).
Multipoint Keypad Control
Up to 16 Crestron keypads may be connected to a single CLS-C6, providing versatile
multipoint control for rooms with multiple entrances or work areas. Individual
keypad buttons can be programmed to work through the master unit or can target
specific slave units for maximum control and room management.
Touchpanel Support
The CLS-C6 can support up to two touchpanels without the need of a centralized
processor. Using the iLux Designer software, add touchpanels to a standalone system
with hard and soft button programming including two way zone status feedback.
Multi-Unit Expansion
A single CLS-C6 master will support up to eight additional units, enabling systems
of up to 54 lighting zones and 54 shade groups. Scene recall, master dimming, and
occupancy status are shared between the units. Each individual unit can still support
a complete assortment of local devices including keypads, shade controllers,
touchpanels, and sensors.
Room Combining Support
When your application includes divisible rooms, the CLS-C6 has advanced
room-combining features capable of supporting even the most complex layouts.
When additional CLS-C6 slave units are linked to a master CLS-C6, advanced room
combining of up to nine rooms become possible. The iLux Lighting System supports
up to 36 room partitions, allowing for all possible room combinations. Room
combining status (combined or separate) can be controlled via external partition
sensors, via keypad or touchpanel buttons, or via an external command from a
Crestron control processor.
Building Management System Integration
Crestron CLS-C6 includes BMS integration capabilities for straightforward inclusion
of building management systems as a component of managing energy demands.
Control System Integration
The CLS-C6 actually features two separate Cresnetcontrol networks, one for local
devices and one for connection to a 2-Series control system.
Connecting the CLS-C6 to a control system allows its functions to be controlled
from touchpanels, RF wireless remotes, and even computers, supporting extensive
flexibility for remote control and integration with other devices and systems.
Additional functions such as on-the-fly room combining and activating operations
based on a real-time clock are also made possible by connecting the CLS-C6 to a
control system.
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •3

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
Connecting to an Ethernet-networked control system provides a gateway to larger
applications such as integration with facility-wide lighting, HVAC, security, and
remote monitoring via Crestron RoomView®Help Desk software as well as third-
party SNMP software.
Specifications
The following table provides specifications for the CLS-C6.
CLS-C6 Specifications
SPECIFICATION DETAILS
Load Ratings
CLS-C6/C6M
Dimmer channels
Max load per channel
Min load per channel
Max load per unit:
CLSI-C6/C6M
Dimmer Channels
Max load per channel
Min load per channel
Max load per unit:
6
800 W/VA (6.7 Amps @ 120 VAC)
15 W/VA (0.125 Amps @ 120 VAC)
1920 W/VA (16 Amps @ 120 VAC)
6
800 W/VA (3.5 Amps @ 230 VAC)
25 W/VA (0.108 Amps @ 230 VAC)
2200 W/VA (10 Amps @ 220 VAC)
2300 W/VA (10 Amps @ 230 VAC)
2400 W/VA (10 Amps @ 240 VAC)
Load Types LED1, Incandescent, Magnetic Low-voltage,
Neon/Cold Cathode, 2-Wire Dimmable
Fluorescent, & Non-Dim Lighting (also:
Electronic Low-voltage, 3 and 4-Wire
Fluorescent, High-Inrush Switching, & 277V
via CLS-EXP Series expansion modules2)
Power Requirements CLS-C6/C6M Line Power, 100 –127 VAC, 50 /
60Hz
CLSI-C6/C6M Line Power, 220 – 240 VAC, 50
/ 60Hz
Default Net ID 1F
Control System Update Files3, 4
2-Series Control System Version 2.004.CUZ or later
IR Receiver
Reception Frequency 36 kHz
Requires CLS-IRHT8 IR remote
(sold separately).
Built-In Motion Detector
(CLS/CLSI-C6M only)
Type
Range
Infrared
20 to 30 feet at 4-foot elevation
(6 to 9 meters at 1.2 meter elevation)
Firmware V2.01.01 or later
(Continued on following page)
4 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
CLS-C6 Specifications (Continued)
SPECIFICATION DETAILS
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% RH (non-condensing)
Overall Dimensions:
Height
Width
Depth
4.48 in (114 mm)
8.89 in (226 mm)
2.47 in (63 mm) for CLS/CLSI-C6
2.60 in (66 mm) for CLS/CLSI-C6M
Weight 1.43 lbs (0.65 kg)
Available Models:
CLS/CLSI-C6A iLux Integrated Lighting System, Almond
CLS/CLSI-C6B iLux Integrated Lighting System, Black
CLS/CLSI-C6W iLux Integrated Lighting System, White
CLS/CLSI-C6MA iLux Integrated Lighting System with Motion
Detector, Almond
CLS/CLSI-C6MB iLux Integrated Lighting System with Motion
Detector, Black
CLS/CLSI-C6MW iLux Integrated Lighting System with Motion
Detector, White
Available Accessories
C2N-CBD-P/-CBF-P/-CBD-E Cameo®Keypad, Standard Mount/Flush Mount
C2N-CBD-TS/CBF-T Cameo®Keypad, Standard Mount/Flush Mount
C2N-DB Decorator Series Keypad
C2N-MNETGW infiNET Gateway
C2N-MNETRPT infiNET Repeater
C2N-SDC Shade and Drape Controller (120V AC)
C2N-SDC-DC Shade and Drape Controller (24V DC)
C2N-SSC-2 Somfy®Shade Controller
C2NI-CB International Keypad (230 VAC)
C2NX-B Designer Series Keypad
CLS-EXP-DIM iLux Dimmer Expansion Module
CLS-EXP-DIMFDB iLux 3-Wire Fluorescent Dimmer Expansion
Module
CLS-EXP-DIMFLV iLux 0-10V Fluorescent Dimmer Expansion Module
CLS-EXP-DIMU iLux Universal Dimmer Expansion Module
CLS-IRHT8 iLux IR Handheld Remote
CNPWS-75 Cresnet Power Supply
GLS-LOL Crestron Green Light™ Photocell , Open-Loop
GLS-SIM Sensor Integration Module
TPS-4L Touchpanel, Isys™3.6" Wall Mount
TPS-6L Touchpanel, Isys™5.7" Wall Mount
1. For a list of compatible ballasts, visit www.crestron.com/lightingcompatibility.
2. Larger loads and additional load types can also be supported using Crestron CLS-EXP Series expansion
modules (sold separately).
3. The latest versions can be obtained from the Crestron Web site. Refer to NOTE after last footnote.
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •5

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
4. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
NOTE: Crestron software and any files on the Web site are for Authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users may
be required to register to obtain access to certain areas of the site (including the FTP site).
Physical Description
All controls and indicators for the CLS-C6 are located on the front of the unit. The
front panel also contains a mini phone jack, under the flip-up cover, used for
programming functions, and an IR port for control via an IR remote device. All other
ports and connectors are located on the rear panel. Refer to the table “Connectors,
Controls, & Indicators” which starts on page 8 for details.
CLS-C6 (Cover Open)
6 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
CLS-C6 Overall Dimensions
8.89 in
(226 mm)
4.48 in
(114 mm)
1.88 in
(48 mm)
2.38 in
(60 mm)
0.59 in
(15 mm)
CLS-C6/
CLSI-C6
0.72 in
(18 mm)
CLS-C6M/
CLSI-C6M
CLS-C6 Front Panel
^
^
Scene 1 Scene 2 Scene 3 Scene 4 Scene 5 Scene 6
^
^
Min
Sec
Lights
Shades
Save
Cancel
123456
ON
OFF
1
2
3
4
6
8
5
9
10
11
13
14
15
7
12
CLS-C6 Rear Panel
16
17
18 19
16
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •7

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
Connectors, Controls, & Indicators
# CONNECTORS,
CONTROLS, &
INDICATORS
DESCRIPTION
1 Bar In Standard mode and Lights mode, the bar
graphs, each a series of seven LEDs, indicate
the current light intensity for the six lighting
loads. When under photocell control, the top
bar graph LED for a controlled load will blink.
In Shades mode, they indicate the shade
position for each of the shade groups. The bar
graphs have other functions in Setup mode.
2 Label Strip Customizable label for the six scenes.
3 Function Buttons and
LEDs In Standard mode, these buttons are typically used to select/recall scenes. In Lights mode,
they are used to make temporary adjustments
to the six lighting loads. In Shades mode they
are used to make temporary adjustments to
the shade groups. They can also be
programmed to perform other functions.
4 IR Detector The IR detector responds to commands from
the optional Crestron remote control. The
remote control can be used to recall Scenes 1
– 4, the On and Off scenes, and perform
master raise and lower of the lighting loads.
5 Motion Detector
(CLS/CLSI-C6M only) The built-in motion detector can be used to activate a particular scene when there is
activity in the room, and/or to activate a
particular scene (typically Off) when there is
no activity for a specified period. A limited
number of actions are available when
programmed locally; more are available using
the iLux Designer software program.
6 Mini Phone Jack Use this 3.5mm TRS mini-phone jack, located
on the front panel, as an RS-232
programming port, to communicate with the
iLux Designer and Crestron Toolbox™to
configure the unit, and to upgrade the unit’s
firmware.
7 Two-Digit Display In Standard mode, the display is normally
blank, except when showing scene fade time.
The Min and Sec LEDs illuminate when the
display is indicating time in minutes or in
seconds, respectively. In Setup mode, the
display uses a two-character mnemonic to
indicate which specific aspect of the CLS-C6
you are changing. As these are being
adjusted, the display may indicate values.
(Refer to “Setup Mode” on page 12 for
details.)
(Continued on following page)
8 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D
Graphs

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
Connectors, Controls, & Indicators (Continued)
# CONNECTORS,
CONTROLS, &
INDICATORS
DESCRIPTION
8 Lights Button and LED Use this switch to select the Lights mode. The
LED illuminates when the mode is selected.
Refer to “Lights Mode” on page 38 for details.
9 Shades Button and
LED Use this switch to select the Shades mode. The LED illuminates when the mode is selected.
Refer to “Shades Mode” on page 38 for details.
10 ^, v, Save, and Cancel
Buttons Use these push buttons to navigate and execute
setup functions. The Save and Cancel LEDs
indicate when these functions are active. Refer
to “Setup Mode” on page 12 for details.
11 Reset Button If the unit stops functioning and does not
respond to button pushes, use a thin object
such as a paperclip to activate this switch. The
unit reboots (all lighting loads go off, the two-
digit display shows “– –,” and all lighting loads
go to their previous state).
12 Shift LEDs These LEDs are covered by the label strip, but
are easily visible through the strip when they are
illuminated. When the Shift mode is enabled via
programming, there can be two functions
defined for each of the six function buttons. The
unit will always be in “upper” or “lower” Shift
mode as indicated by the state of the LEDs.
13 Up/Down Push button This three position “rocker” switch is
programmable for master lights control (all lights
or last scene), master shade control, or as a
“shift” button to allow a second set of functions
for the six function buttons.
14 ON Button The ON button always acts as a recall scene
button for the “On” scene. Refer to “Standard
Mode” on page 33 for details.
15 OFF Button The OFF button always acts as a recall scene
button for the Off scene, which will always turn
all lighting loads off and open the air-gap relay.
Refer to "Standard Mode” on page 33 for
details.
16 LOAD1 – LOAD6 Use these terminals to connect the CLS-C6
dimmer channel outputs to the appropriate
lighting loads.
17 HOT, NEUTRAL,
(Ground) Use these terminals to connect the unit to the 120V (CLS-C6/M) or 230V (CLSI-C6/M) AC
power source.
18 CONTROL SYSTEM
G Z Y 24 Use this 4-pin terminal block to connect the CLS-C6, using standard Cresnet wiring, to a
2-Series control system network. In this
configuration, the CLS-C6 acts as a standard
Cresnet slave device. (The CLS-C6 does not
draw power from Cresnet.).
19 LOCAL DEVICES
G Z Y 24 Use this 4-pin terminal block to connect the CLS-C6, using standard Cresnet wiring, to local
devices. In this configuration, the CLS-C6 acts
as the Cresnet Master.
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •9

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
Setup
Identity Code
The Net ID of the CLS-C6 has been factory set to 1F. The Net IDs of multiple
CLS-C6 devices in the same system must be unique. Net IDs are changed from a
personal computer (PC) via the Crestron Toolbox™ or iLux Designer software
programs. (Refer to “Establishing Communication” on page 31.)
When setting the Net ID, consider the following:
®/SystemBuilder™program.
For more details, refer to the Crestron Toolbox or iLux Designer help files.
Installation
Detailed installation procedures are provided in the latest version of the Crestron
iLux Lighting Systems Installation Guide (Doc. 6394 for CLS-C6/C6M;
Doc. 6413 for CLSI-C6/C6M).
10 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D
• The Net ID of each unit must match an ID code specified in the SIMPL™
Windows or D3 Pro
• Each network device on the same gateway must have a unique Net ID.

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
Configuring the CLS-C6
The overall configuration of the CLS-C6 can be accomplished in two ways: using the
front panel controls, or using the supplied iLux Designer application software, which
can be downloaded from the Crestron Web site.
Configuring via the front panel controls is not as extensive as what can be done using
the iLux Designer, but permits basic functional setup without having to use a PC.
In addition, some aspects of the CLS-C6’s operation can be modified only via certain
Crestron Toolbox console commands. (Refer to “Console Command Settings” on
page 25 for details. Refer also to “Appendix B: Console Commands” on page 52 for
details on all applicable console commands.)
NOTE: Toolbox does not distinguish between the CLS-C6/C6M and CLSI-C6/C6M
devices. All report as CLS units.
Configuring With Front Panel Controls
You can make temporary changes to accommodate a particular circumstance, or
change scene presets and replace the originals, as described below. To make more
extensive changes in the configuration of the CLS-C6 without using the iLux
Designer software, use the "Setup Mode", as described beginning on page 12.
Temporary Changes/Adjustments
Temporary changes/adjustments to the lighting levels or shade presets can be
accomplished as discussed in “Lights Mode” on page 38 and “Shades Mode” on
page 38.
Changing Scene Presets
Scene Presets With Daylight
Harvesting
If a photocell is present, Scenes 1
through 8 (plus the ON scene) will
automatically utilize Daylight
Harvesting. When this automatic
behavior is enabled, the top bar
graph LED for that load will blink.
NOTE: When editing scenes with
p
hotocell-controlled loads, photocell
output will be temporarily disabled.
When the scene is recalled,
p
hotocell control will resume and
light levels may change. To reduce
the possibility of unintended scene
behavior caused by photocell
reaction to sunlight, edit scenes at
night.
The CLS-C6 scene settings can be modified via the front panel controls without
having to use a PC. Changes to the lighting load levels and shade presets for one or
more scenes can be accomplished as follows:
NOTE: The iLux Designer or SIMPL Windows programs can lock a scene to
prevent it from being changed using the front panel controls. If the selected scene is
“locked” in the configuration, when you try to make any adjustment, “Er” will
display for three seconds, and the scene will remain in its existing state.
1. In Standard mode, press the function button of the scene you wish to
modify and hold it for five seconds. (Make sure you press the center of the
button so both sides make contact.)
2. The two-digit display will first count down as the lighting loads fade to their
preset levels for that scene; it will then begin flashing between Sc. and the
scene number; the Lights LED will be lit, and the Save and Cancel LEDs
will flash.
3. Use the six function buttons to adjust the levels of the lighting loads for that
scene. Press the left side of the buttons to lower the lighting loads; press the
right side of the buttons to raise the lighting loads.
4. If you would like a certain lighting load to be unaffected by that scene
recall, press and hold the center of the button (so both sides make contact)
for three seconds. The top two and the bottom two LEDs of the associated
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •11

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
bar graph will be lit (and the display will show - -) to indicate that the level
of the lighting load will not change when that scene is recalled.
5. To change the shade presets for that scene press the Shades button; the
Shades LED will be lit.
6. Use the six function buttons to adjust the levels of the shade groups for that
scene. Press the right side to raise the shades; press the left side to lower
them. While the shades are moving, press any part of the button to stop.
Note that for shades that are not “presettable,” only full open or full closed
positions can be recalled as part of a scene.
7. If you would like a certain shade group to be unaffected by that scene recall,
press and hold the center of the button (so both side make contact) for three
seconds. The top two and the bottom two LEDs of the associated bar graph
will be lit (and the display will show - - ) to indicate that the level of that
shade group will not change when that scene is recalled.
8. To adjust the fade time, press the ^and vbuttons. When going up, the value
will go from 0 seconds to 59 seconds, and then 1 minute to 99 minutes.
When going down, the value will go from 99 minutes to 1 minute, and then
59 seconds to 0 seconds. The Min and Sec LEDs light as appropriate.
Adjustment to fade time can be made when either Lights mode or Shades
mode is active.
9. When all the lighting loads are at the desired level and shades are at the
desired position, press Save to save these settings as the new preset for that
scene. If you make a mistake while changing a setting, press Cancel to
discard changes and return to Standard mode before pressing Save.
10. Repeat the above procedures for all scenes that require changes.
Setup Mode
The Setup mode is used to change internal settings on the CLS-C6, including the
scene presets as discussed in the previous paragraph.
• To enter Setup mode, press and hold the Save and Cancel buttons for five
seconds. The Cancel button LED will blink, and the first setup option (Sc) will
be displayed, to indicate that the unit is now in Setup mode.
Note that while scrolling through the list of setup options, before an option is
“locked”, the Save button is not functional and its LED is off. However, the
Cancel button LED will blink - since the button can be pressed to return the unit
to Standard mode.
• If the unit is connected to a Cresnet control system and you are in the process of
adjusting scene settings, you cannot enter Setup mode. If you try, the two-digit
display will indicate “Er” (error).
• When the unit is in Setup mode, the two-digit display uses a two-character
mnemonic to indicate which specific aspect of the CLS-C6 you are changing. As
these are being adjusted, the display may indicate values. The following is a list
of the different Setup modes, and the corresponding mnemonic codes.
12 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
Setup Mode Mnemonics
TWO-DIGIT
DISPLAY DESCRIPTION
Sc Scene Programming
Ld Setup lighting load Loadtypes
LE Setup lighting load Low-End limits
HE Setup lighting load High-End limits
Lo Setup Lockout mode
bF button Functions (i.e. recall scene, toggle scene, shades
control, etc.)
ud Set function of up/down button
oc Setup occupancy sensing
Ad Run Auto-discovery
AS Assign Shade groups
id Set the Cresnet id of this unit
Ph Photocell test
Pc Photocell Calibration
PL Setup Photocell lower Limit
Pr Setup Photocell response time
Fd Restore Factory default
Er Error
• Press the ^or vbuttons to scroll through this list of available setup options.
Once the desired setup option appears in the display, use the various buttons on
the CLS-C6 to make adjustments, as described on the following pages.
• Once any adjustment is made, Setup mode is now “locked” into that particular
option (this is indicated by lighting the period at the end of the mnemonic).
Once locked in an option, the ^and vbuttons will no longer scroll through the
options; you must exit setup before you can choose another option.
When the adjustments are complete, press Save to store the changes permanently,
and exit Setup mode, or press Cancel to exit Setup mode without saving the changes.
The unit reverts to Standard mode.
Scene Programming (Sc)
Scene Presets With Daylight
Harvesting
If a photocell is present, Scenes 1
through 8 (plus the ON scene) will
automatically utilize Daylight
Harvesting. When this automatic
behavior is enabled, the top bar
graph LED for that load will blink.
NOTE: When editing scenes with
p
hotocell-controlled loads, photocell
output will be temporarily disabled.
When the scene is recalled,
p
hotocell control will resume and
light levels may change. To reduce
the possibility of unintended scene
behavior caused by photocell
reaction to sunlight, edit scenes at
night.
This setup option allows the user to adjust the scene parameters. This is another way
to accomplish scene changes as discussed in “Changing Scene Presets” on page 11.
This method also allows you to change the settings for scenes greater than scene 6.
Note that scenes can be turned off in addition to being recalled. When a scene is
turned off, only the lighting loads are turned off. If the scene contains any shades,
they are not affected. The fade time for turning the scene lights off is the same as for
recalling the scene. Therefore, no additional parameters need to be set to define the
off behavior.
Select the scene to be changed using the Up/Down button. As you cycle through the
list of scenes, the lights and shades will not change, and the bar graphs will be off.
Set the lighting loads and shade positions for the scenes as discussed in “Changing
Scene Presets” on page 11. As you set the scenes, note the following:
• When a lighting load reaches the HE (high end) limit, the lights will stop. The
two-digit display will continue to rise. If lights reach the LE (low end) limit, the
two-digit display will continue to go down, but lights will stay at the LE limit
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •13

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
until they reach Off—at which point they will turn off. If you save the scene
setting while the display is at a level below the LE limit, or above the HE limit,
the displayed value will be saved, but the light level will be limited to the
programmed limits.
• If a lighting load is defined as an “unused” load type, the bar graph for that
lighting load will have all LEDs off. If you try to adjust that lighting load, the
two-digit display will show “Er”.
• To mark a lighting load as "not affected" (i.e., the lighting load’s current state
will not be changed by recalling the scene), press and hold the center of the
corresponding button for three seconds. Adjustments made to such lighting
loads will cancel the “not affected” condition, and start adjusting from the
current light level.
• While adjustments are being made to the lights or shades, the two-digit display
will show the level, just like in Manual mode. The level for loads that are not
affected will be shown as “—.” In Manual mode, the display goes blank after
three seconds; in this mode, it returns to the “Sc. ##” display.
• For SDC (or SDC-DC) shades, when you press the left or right side of the
button, the two-digit display will immediately show full open or full closed as
soon as the shade starts moving, and the preset will be set to this full open or
closed position even if the shade is stopped before reaching the full open or full
close position.
• The iLux Designer or SIMPL programs can lock a scene to prevent it from being
changed using the front panel controls. If the selected scene is “locked” in the
configuration, when you try to make any adjustment, “Er” will display for three
seconds, and the scene will remain in its existing state.
• To adjust the fade time, while “Sc. ##” is displayed, press the ^and vbuttons to
adjust the time. The first time a button is pressed, current fade time will be
shown, but not changed. Subsequent presses will change the displayed value.
Adjustment to fade time can be made when either Lights mode or Shades mode
is active. When going up, the value will go from 0 seconds to 59 seconds, and
then one minute to 99 minutes. When going down, the value will go from 99
minutes to one minute, and then 59 seconds to 0 seconds.
• To save/cancel levels, press the Save button to save the new values and return to
Standard mode. Press the Cancel button to return to Standard mode without
saving – old scene parameters will be remembered.
Setup Lighting Load Types (Ld)
To set the load types for each lighting load, first enter Setup mode and scroll to the
“Ld” option. The bar graphs immediately indicate the currently selected load type for
each lighting load. Use the function buttons to change the load type, each load type
indicated by a pattern of bar graph segments and a number on the two-digit display,
as shown in the following table. Press the right and left side of the buttons to cycle
through the available load types.
14 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D

Crestron CLS/CLSI-C6/C6M iLux®Integrated Lighting System
Load Type Number LEDs Default LowEnd
/ HighEnd
Unused 0 all off 0 / 100
Incandescent – default 1 top 1 on 0 / 100
MLV 2 top 2 on 0 / 100
NCC 3 top 3 on 0 / 100
Fluorescent (2-wire) 4 top 4 on 10 / 100
Non-dim (On at start/Off at start)¹ 5 top 5 on 0 / 100
Non-dim (On at end/Off at start)² 6 top 6 on 0 / 100
1. Whether going on or off, this load type will switch at the start of the fade.
2. If going off, this load type will switch at the start of the fade; if going on, it will switch at the end.
• When changing the load type using the rocker buttons, the two-digit display will
change to reflect the current load type. It will show “L#.” where # is the number
from the table above. Whenever the two-digit display is showing a load type, the
corresponding front panel LED is lit.
• During adjustment of this value, the lights will not change. If setup is exited
without pressing the Save button, the original values will be retained. When the
Save button is pressed, Setup mode will be exited, the new values will be saved,
and the lights will be updated to reflect the new curve type.
If the load type was changed, the LE and HE limits are automatically changed to the
default value for the new load type, listed in the above table.
Setup Low-End Levels (LE)
Some lights can flicker at very low levels. To avoid this, you can specify the low-end
limit accordingly. Whenever you try to adjust lights to a level below this value, they
will stay at the low-end limit until they are turned off. To set the low-end levels for
the six lighting loads:
• First enter Setup mode and scroll to the “LE” option (using the ^and vbuttons).
At this point the lights will not change, but the bar graphs should immediately
indicate the low-end levels for each lighting load. (In most cases this will be 0%,
which is indicated by all bar graph segments being off.) To set the low-end
level, use the rocker button corresponding to that lighting load to adjust the level
up or down. When the first adjustment is made, the light being adjusted will
jump to the current low-end level, and start adjusting from there.
• The low-end level cannot be adjusted above 33%.
• Note that for non-dim and “unused” lighting loads, the low-end level cannot be
adjusted (always at 0%). If you try to adjust this, the light and bar graph will not
change, and the two-digit display will show “Er.” to indicate an error.
If setup is exited without pressing the Save button, the original values will be
retained. For lighting loads where adjustment has been made, lights will jump to the
original low-end level. Light levels will not change on lighting loads where no
adjustment was made. When the Save button is pressed, Setup mode will be exited,
the new values will be saved, and the lights will not change.
Setup High-End Levels (HE)
This option allows you to set the “full on” level of the lighting loads below their
maximum brightness. To set the high-end levels for the six lighting loads:
• Enter Setup mode and scroll to the “HE” option (using the ^and vbuttons). At
this point the lights will not change, but the bar graphs immediately indicate the
Operations Guide - DOC. 6347D iLux®Integrated Lighting System: CLS/CLSI-C6/C6M •15

iLux®Integrated Lighting System Crestron CLS/CLSI-C6/C6M
high-end levels for each lighting load. (In most cases this will be 100%, which is
indicated by all bar graph segments being on.)
• To set the high-end level, use the rocker button corresponding to that lighting
load to adjust it up or down. When the first adjustment is made, the light being
adjusted will jump to the current high-end level, and start adjusting from there.
As adjustments are made, the current light level for the lighting load being
adjusted should appear in the bar graph and the two-digit display.
• The high-end level cannot be adjusted below 67%.
• Note that for non-dim and “unused” lighting loads, the high-end level cannot be
adjusted (always at 100%). If you try to adjust this, the light and bar graph will
not change, and the two-digit display will show “Er” to indicate an error.
If setup is exited without pressing the Save button, the original values will be
retained. For lighting loads where adjustment has been made, lights will jump to the
original high-end level. Light levels will not change on lighting loads where no
adjustment was made. When the Save button is pressed, Setup mode will be exited,
the new values will be saved, and the lights will not change.
Setup Lockout Mode (Lo)
This Setup mode is used to lockout all of the local controls in the CLS-C6 unit.
To toggle Lockout mode on or off:
• Enter Setup mode and scroll to the “Lo” option (using the ^and vbuttons).
Press and hold either the top or bottom portion of the raise/lower button for five
seconds to toggle the state on or off.
• Depending on the current state, the controls on the unit will either lock or
unlock. When Lockout mode is active, the 2-digit display will display “Lo”
when any local button is pressed.
NOTE: Lockout mode will not affect the lockout status of slaves.
NOTE: Lockout mode will not disable keypads.
Setup Button Functions (bF)
This Setup mode is used to define the behavior of the buttons on the CLS-C6 unit
itself, and on remote keypads if you want behavior other than the default. (Remote
keypads must be ID’d, using auto-discovery, prior to this, which will set them to
their default functions.) To enter this mode:
• First enter Setup mode and scroll to the “bF” option (using the ^and vbuttons).
Then use the Up/Down button to scroll through the available button functions
and values. This will scroll through all values for each function before
proceeding to the next function.
• If you press and hold the button, it will auto repeat. During auto-repeating, when
it reaches the minimum or maximum value for that function, it will stop. The
next button push will then increment/decrement to the next function.
Available functions and values are as shown in the table on the following page.
(Other functions require a PC with iLux Designer software to configure them.)
16 •iLux®Integrated Lighting System: CLS/CLSI-C6/C6M Operations Guide - DOC. 6347D
