CCrreessttrroonnDDMMCC--VVIIDD--RRCCAA--AA
The DMC-VID-RCA-A is an input card for a Crestron DigitalMedia™Switcher,
providing one analog video input and one stereo analog audio input. The
DMC-VID-RCA-A accepts component HDTV signals up to 1080p, as well as
standard definition NTSC/PAL composite and S-Video. An HDMI pass-thru
output connection is also provided, which passes the audio and video input
signals through digitally to feed a local device, or to feed a second DM switcher
for output expansion purposes.
SPECIFICATIONS
Video
SSiiggnnaallTTyyppeess: Component (YPBPR), S-Video (Y/C), or composite input;
HDMI converted pass-thru
IInnppuuttFFoorrmmaattss::NTSC or PAL
IInnppuuttRReessoolluuttiioonnss::480i/p, 576i/p, 720p, 1080i/p
OOuuttppuuttFFoorrmmaattss//RReessoolluuttiioonnss::Matched to input
AAnnaalloogg--TToo--DDiiggiittaallCCoonnvveerrssiioonn::
10-bit 170 MHz
Audio
SSiiggnnaallTTyyppeess::Analog stereo input, HDMI converted pass-thru
AAnnaalloogg--TToo--DDiiggiittaallCCoonnvveerrssiioonn::24-bit 48 kHz
PPeerrffoorrmmaannccee((aannaalloogg))::Frequency Response: 20Hz to 20kHz ±0.75dB;
S/N Ratio: >95dB, 20Hz to 20kHz A-weighted;
THD+N: <0.005% @ 1kHz;
Stereo Separation: >90dB
Connectors
HHDDMMIIOOUUTT::(1) 19-pin Type A HDMI female;
HDMI digital video/audio output;
Provides pass-thru signal from IN connections for system expansion
IINN--YY,,PPbb//YY,,PPrr//CC//CCOOMMPP::(3) RCA female comprising (1) auto-sensing multi-format
analog video input;
Signal Types: Component (YPBPR), S-Video (Y/C), or composite input;
Input Level: 1 VP-P nominal;
Input Impedance: 75 ohms nominal
IINN--AAUUDDIIOO::(2) RCA female;
Unbalanced stereo line-level audio input;
Maximum Input: 2 VRMS;
Input Impedance: 15k ohms
Construction
Plug-in card, occupies (1) DM Switcher input card slot, includes steel faceplate w/black
matte powder coat finish w/black matte powder coat finish
Weight
7.0 oz (199 g)
