Crestron HD(I)-XSPA How to use

Crestron HD(I)-XSPA
7.1 High-Definition Surround Sound AV
Receiver
Operations & Installation Guide

Important Safety Instructions
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•
Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
•Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
•Only use attachments/accessories specified by the
manufacturer.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED
TO DRIPPING OR SPLASHING. OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED
ON THE APPARATUS.
WARNING:
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. ONLY QUALIFIED SERVICE PERSONNEL
SHOULD PERFORM SERVICE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product's enclosure t hat may be of sufficient magnitude
to constitute a risk of electric shock to persons.
•Use only with the cart, stand, tripod, bracket or
table specified by the manufa
cturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
THIS IS AN APPARATUS WITH CLASS I
CONSTRUCTION. IT SHALL BE CONNECTED TO AN
ELECTRICAL OUTLET WITH AN EARTHING GROUND
TERMINAL.
IMPORTANT:
These devices can be used with Class 2 output wiring.
•Unplug this apparatus during lightning storms or when
unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•Disconnect power prior to connecting or disconnecting
equipment.
•Do not install in direct sunlight.
•
The apparatus must be installed in a way that the power cord
can be removed either from the wall outlet or from the
device itself in order to disconnect the mains power.
•
Prevent foreign objects from entering the device.

The specific patents that cover Crestron products are listed at patents.crestron.com.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other
U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are registered trademarks & DTS-HD
Master Audio is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.
Manufactured under license from Dolby Laboratories.
Crestron, the Crestron logo, AIR, Aspire, Cresnet, Crestron Studio, Crestron Toolbox, DigitalMedia, DigitalMedia 8G, DigitalMedia 8G+, DM, DM
8G+, Essence, Excite, QuickSwitch HD, Saros, and Sonnex are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United
States and/or other countries. Blu-ray Disc is either a trademark or registered trademark of the Blu-ray Disc Association in the United States and/or
other countries. Dolby, Dolby Digital, and the double-D symbol are either trademarks or registered trademarks of Dolby Laboratories in the United
States and/or other countries. DTS, DTS-HD Master Audio, and the DTS logo are either trademarks or registered trademarks of DTS, Inc. in the
United States and/or other countries. HDBaseT and the HDBaseT Alliance logo are either trademarks or registered trademarks of the HDBaseT
Alliance in the United States and/or other countries. HDMI and the HDMI Logo are either trademarks or registered trademarks of HDMI Licensing
LLC in the United States and/or other countries. Other trademarks, registered trademarks and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
Crestron is not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2014 Crestron Electronics, Inc.
Regulatory Compliance
As of the date of manufacture, the HD-XSPA and HDI-XSPA have been tested and found to comply with
specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A Contents •i
Contents
7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA 1
Introduction ............................................................................................................................... 1
Features and Functions ................................................................................................ 1
Applications................................................................................................................. 6
Internal Block Diagrams.............................................................................................. 7
Specifications ..............................................................................................................8
Physical Description.................................................................................................. 14
Setup ........................................................................................................................................ 20
Identity Code ............................................................................................................. 20
Installation ................................................................................................................. 21
Hardware Hookup ..................................................................................................... 23
Uploading and Upgrading........................................................................................................ 26
Establishing Communication..................................................................................... 26
Programs and Firmware ............................................................................................ 27
Program Checks ........................................................................................................ 27
Configuration........................................................................................................................... 29
“Installer” Menu ........................................................................................................ 29
Configure Inputs........................................................................................................ 30
Configure Outputs ..................................................................................................... 32
Configure Network.................................................................................................... 34
Configure Front Panel ............................................................................................... 39
Operation ................................................................................................................................. 42
Power......................................................................................................................... 42
Select a Source or Decoding Mode ........................................................................... 42
Volume Control and Mute (Theater Output Only) .................................................... 44
Additional Functions ................................................................................................. 44
Problem Solving ...................................................................................................................... 50
Troubleshooting......................................................................................................... 50
Check Network Wiring.............................................................................................. 50
Reference Documents................................................................................................ 51
Further Inquiries ........................................................................................................ 51
Future Updates .......................................................................................................... 51
Return and Warranty Policies .................................................................................................. 52
Merchandise Returns / Repair Service ...................................................................... 52
Crestron Limited Warranty........................................................................................ 52

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •1
•True 7.1 surround sound processing for any room of the house
•DTS-HD Master Audio™, Dolby®TrueHD, and Dolby Digital®Plus
decoding
•Built-in high-efficiency, high-performance 8-channel power amplifier
•140 watts per channel at 8 Ω, 240 watts per channel at 4 Ω
•Support for both active powered subwoofers and passive in-wall
subwoofers
•Eleven inputs—four HDMI®, one S/PDIF optical, two S/PDIF coaxial,
two unbalanced stereo, one balanced stereo, and one DM 8G+™
•DM 8G+ input enables seamless whole-house AV system integration
via Crestron DigitalMedia™
•Enables direct connection to an HDBaseT®source via the DM 8G+
input
7.1 High-Definition Surround
Sound AV Receiver: HD(I)-XSPA
Introduction
The Crestron®HD-XSPA and HDI-XSPA make it easy and affordable to put great
surround sound in any room of the house as part of a complete home automation and
entertainment system. Engineered with integration in mind, the HD-XSPA and
HDI-XSPA deliver pure, impactful power and performance in less space than other
alternatives, and include advanced features for sharing sources between rooms and
controlling everything with a choice of touch screens, handheld remotes, and mobile
devices. In one compact, 2-space rack-mountable package, the HD-XSPA and
HDI-XSPA pack a professional-grade 7.1 surround sound processor, high-efficiency
8-channel power amplifier, 4K Ultra HD video switcher, DigitalMedia™ receiver,
and Crestron control interface.*
The HD-XSPA and HDI-XSPA are functionally identical. For simplicity within this
guide, the term “HD-XSPA” is used except where noted.
Features and Functions
(Continued on following page)
* Full functionality requires a Crestron control system with professional programming performed by an
authorized Crestron system programmer.

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
2•7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
•HDMI output supports Full HD 1080p, 3D, and 4K Ultra HD video
displays
•Advanced HDCP management for trouble-free handling of copy-
protected digital content
•QuickSwitch HD®technology for fast, reliable switching
•Unbalanced stereo downmix output for second zone or audio return
•Amplified stereo downmix output available in lieu of back speakers
•RS-232, IR, Ethernet, relay, and contact sensing ports for control of
local devices*
•CEC pass-through from a control system for device control via HDMI*
•USB HID mouse/keyboard extension and routing via DigitalMedia
•Native Crestron control system integration via 10/100 Ethernet
•Color LCD front panel for basic setup and operation
•Front panel USB port for installer setup
•Simplified setup via front panel or software
•Built-in noise generator for audio setup
•DSP with 9-band graphic or parametric EQ, delay, crossover, and
compression
•Source input compensation and 80 ms lip sync adjustment per input
•Allows any SPDIF or analog audio input to be used with any HDMI
video input
•Easy speaker wire termination via heavy-duty detachable terminal
blocks
•Intelligent amplifier protection and remote fault monitoring
•70/100 volt “constant-voltage” output options available
•Low power consumption, cool-running operation
•Compact 2-space rack-mountable design
Features and Functions
(Continued)
High-Definition Professional Surround Sound Processor
Great surround sound starts with a great processor, and the HD-XSPA employs
professional grade decoding and signal processing to support the latest 7.1 digital
formats including Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio.
Onboard DSP provides the sonic tools needed to maximize the sound quality of each
speaker within the room, including a choice of 9-band graphic or parametric EQ,
plus trim, delay, and crossover adjustments. Additional controls are provided for
main volume, bass, treble, loudness, compression, and LFE. Advanced HDCP
management ensures trouble-free handling of copy-protected digital HD content.
High-Powered 7.1 Surround Sound Amplifier
Despite its compact size, the HD-XSPA delivers a generous amount of power from
its onboard multichannel power amplifier. Each amp channel is capable of producing
a gratifying 140 watts at 8 Ω, and 240 watts at 4 Ω. Instead of the customary seven
amp channels, the HD-XSPA features eight full channels of robust amplification to
drive a complete 7.1 speaker system including a passive in-wall subwoofer,
minimizing both rack space and floor space requirements. A line-level sub output is
also included to support an active powered subwoofer.
* Full functionality requires a Crestron control system with professional programming performed by an
authorized Crestron system programmer.

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •3
The HD-XSPA can be set up to support a wide variety of speaker configurations up
to 7.1. When configured for use with a 5.1 or smaller speaker system, two of its amp
channels can be reallocated to drive a second stereo zone (refer to the discussion of a
downmix output on the following page for more information).
Complete Connectivity
The HD-XSPA includes full input connectivity for all types of digital and analog
sources including Blu-ray Disc®players, HDTV receivers, game consoles,
computers, media servers, and mobile devices. Additionally, a DigitalMedia input
and stereo downmix output are included to facilitate integration as part of a whole
house AV system:
•HDMI inputs provide the essential interface for handling high-definition 7.1
digital surround sound and 4K Ultra HD video sources. The HD-XSPA
includes four HDMI inputs, which can be expanded using a Crestron
HD-MD8X1 or HD-MD8X2 switcher.1The HD-XSPA also allows for
control of the connected sources through their HDMI connections using
CEC (Consumer Electronics Control) signals sent from a Crestron control
system.2
•S/PDIF inputs are provided in the form of one optical and two coaxial type
inputs, providing connectivity for S/PDIF digital audio sources. Audio
signals can also be received from a Sonnex®Multiroom Audio System via
an AUD-EXT Audio Extender.1
•Stereo analog inputs (2 unbalanced, 1 balanced) are included to handle
analog signals from line-level sources. Audio signals can also be received
from a Sonnex Multiroom Audio System via an AUD-EXT Audio
Extender.1
•A DigitalMedia 8G+™ input provides a 1-wire connection to a
DigitalMedia switcher. The switcher can be located in a central equipment
cabinet along with all the shared video sources for the house, allowing any
of those sources to be distributed to any room in the house, including rooms
equipped with an HD-XSPA. The DM 8G+ input can also be used to
connect laptop computers and other portable devices from anywhere in the
house using a DM 8G+ transmitter or HDBaseT transmitter.1The
transmitter can either be routed through the central DigitalMedia switcher
or wired directly to the DM 8G+ input on the HD-XSPA. DM 8G+
technology requires just one CAT5e wire for hookup, supporting Full HD
1080p video and 7.1 audio over wire lengths up to 330 ft (100 m), and 4K
Ultra HD video over shorter distances.3
1. Item(s) sold separately. Please refer to each product’s spec sheet for complete specifications,
capabilities, and limitations.
2. Full functionality requires a Crestron control system with professional programming performed by an
authorized Crestron system programmer.
3. The maximum cable length for DigitalMedia 8G+ or HDBaseT is 330 ft (100 m) for resolutions up to
1600 x 1200 and 1920 x 1200 (including 1080p60 and 2K) using DM-CBL-8G DigitalMedia 8G™
cable, DM-CBL DigitalMedia Cable, DM-CBL-D DigitalMedia D Cable, or third-party CAT5e (or
better) UTP or STP. For higher resolutions (including 4K), the maximum wire length is 230 ft (70 m)
using DM-CBL-8G, or 165 ft (50 m) using DM-CBL, DM-CBL-D, or CAT5e. Shielded cable and
connectors are recommended to safeguard against unpredictable environmental electrical noise which
may impact performance at resolutions above 1080p. Refer to the Crestron DigitalMedia Design
Guide (Doc. 4546) at www.creston.com/dmresources for complete system design guidelines. DM
8G+ is compatible with HDBaseT Alliance specifications for connecting to HDBaseT compliant
equipment. All wire and cables sold separately.

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
4•7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
•A downmix output provides a stereo or mono downmix of the surround
sound signal to feed a second listening zone or headphone amp. It can also
be used to provide an audio return channel to a Sonnex Multiroom Audio
System, allowing the local audio to be distributed to multiple stereo zones
throughout the house. The downmix signal is provided through an
unbalanced line-level output, which can be extended up to 2000 ft (610 m)
over a single CAT5 wire using an AUD-EXT Audio Extender. 1 The
downmix output can also be configured as an amplified output to directly
drive a pair of speakers. (When the amplified downmix option is enabled,
the surround sound speaker system is limited to 5.1.) The downmix output
includes dedicated controls for volume, bass, treble, loudness, and balance,
which can be made accessible from any touch screen, keypad, or remote in
the house.2
•A subwoofer line output provides a line-level output to feed a powered
subwoofer or external amplifier.
•The HDMI output normally connects to the local video display or projector.
The HDMI output passes Full HD 1080p60 and 4K Ultra HD video with
HDCP, Deep Color, and 3D from any of the four HDMI inputs. It also
passes audio, with the ability to select either a straight pass-through from
the selected HDMI, SPDIF, or analog audio source, or a stereo downmix of
the decoded surround sound signal. It can even pass CEC signals from a
control system to control the display device. As an option, the HDMI output
can be connected to a DM-TX-201-C DM 8G+ Transmitter1to provide an
AV return channel to a centralized DigitalMedia system, allowing local
sources to be shared with other rooms in the house.
Each input on the HD-XSPA includes an input compensation adjustment to match
the average level between sources, and up to 80 ms of lip-sync delay.
Ultimate Integration
By design, the HD-XSPA works seamlessly as part of a complete Crestron whole
house AV distribution and automation system:
•Audio signals can be routed to and from the HD-XSPA using Crestron
AUD-EXT Audio Extenders,1allowing for integration with a Sonnex
Multiroom Audio System.
•DigitalMedia connectivity affords sharing of multichannel audio along with
HD video as part of a complete DigitalMedia network.
•Via DigitalMedia or Ethernet, the HD-XSPA can communicate with a
Crestron control system, allowing user-friendly operation via a choice of
touch screens, handheld remotes, smartphones, and tablet computers.
•Using the hardware provided, the HD-XSPA can be installed in an
equipment rack or placed on a shelf.
Keyboard and Mouse Extender
When connected to a DigitalMedia switcher or transmitter, the HD-XSPA can
function as a keyboard and mouse extender. Via its rear panel USB port, a USB
HID-compliant keyboard and mouse can be connected and used to control a
computer or media server in the central equipment cabinet (or any other location).
1. Item(s) sold separately. Please refer to each product’s spec sheet for complete specifications,
capabilities, and limitations.
2. Full functionality requires a Crestron control system with professional programming performed by an
authorized Crestron system programmer.

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •5
Other types of USB devices, including mobile phones, media players, Web cameras,
flash drives, and game controllers, can be supported by adding a
USB-EXT-DM-REMOTE extender module.1Also, a local host computer, media
server, or game console can be controlled from a remote location by adding a
USB-EXT-DM-LOCAL extender module.1
Amplifier Monitoring and Protection
For systems utilizing in-wall or in-ceiling speakers, it is critical that the amplifier
driving those speakers possesses the intelligence to protect itself in the event of a
shorted or damaged speaker line. The HD-XSPA includes sophisticated protection
from all types of faults on a per channel basis. In the event of a fault, the front panel
LCD provides clear fault indication to speed the troubleshooting of damaged or
incorrect wiring, poor rack ventilation, and other unforeseen issues. Fault alerts may
also be broadcast to a touch screen or mobile device, and integrators can even
monitor and track the data remotely to ensure a rapid service response.
70/100 V Option
For ultimate versatility, the HD-XSPA can be equipped for use with 70 or 100 volt
speakers. A 70/100 V (constant-voltage) speaker system allows for the connection of
numerous speakers per circuit and long wire runs using small-gauge wire. Typical
applications include outdoor speaker zones and commercial environments. Any of
the HD-XSPA’s amplifier outputs can be converted to 70 or 100 volts using Sonnex
Output Transformers (SAT-70V/100V-2 or SAT-70V/100V-41).
Device Control Ports
The HD-XSPA includes an assortment of built-in control ports to allow for
programmable control of the local AV components and other room devices without
the need for extra control modules or wiring. Each control port is addressable from a
Crestron control system, whether that control system is installed locally or in another
room. Ethernet, RS-232, IR, and low-voltage relay ports provide for control of the
display device and AV sources, and may also be used to control a motorized screen
or lift, window treatments, lighting, and other equipment in the room. Many AV
devices can also be controlled directly via the HDMI ports. Four SENS inputs are
also included to accommodate power sensors, motion detectors, and other contact
closure devices.2
1. Item(s) sold separately. Please refer to each product’s spec sheet for complete specifications,
capabilities, and limitations.
2. Full functionality requires a Crestron control system with professional programming performed by
an authorized Crestron system programmer.

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
6•7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
Applications
The following diagram shows an HD-XSPA in a residential application.
HD-XSPA in a Residential Application
HD-XSPA
8
DM
USB
1
ELE C T R O N I C S IN C ., R O CKL E I G H , NJ 07647 U S A
HD M I
2
7
6
910
11
IN
3
L
SUB
R
L
R
IN
4
IN
5
IN OUT
SUB
8 Ω 140 W 4 Ω 240 W
CLASS2 WIRING
CENTER
FRONT SURROUND BACK/DOWNMIX
AUD IO IN
DIGI TAL ANALOG
DOWNMIX
BALANCED
LR
+-G + -
PREAM P OUT SPEA KER OUTPUTS
1 2 3 4 1 2
S G S G S G S G
IR REL AY SENS
COM
1 2 3 4 G
G
120V~
50/60HZ
MAX 6A
GRD
TX
RX
RTS
CTS
HD-XSPA
8
DM
USB
1
ELECT RONICSINC., ROCKL EIGH,NJ 07647 USA
HD MI
2
7
6
910
11
IN
3
L
SUB
R
L
R
IN
4
IN
5
IN OUT
SUB
8 Ω 140 W 4 Ω 240 W
CLASS2 WIRING
CENTER
FRONT SURROUND BACK/DOWNMIX
AUD IO IN
DIGI TAL ANALOG
DOWNMIX
BALANCED
L R
+ - G + -
PREAM POUT SPEAK ER OUTPUTS
1 2 3 4 1 2
S G S G S G S G
IR REL AYSENS
COM
1 2 3 4 G
G
120V~
50/60HZ
MAX 6A
GRD
TX
RX
RTS
CTS
CAUTION
A
VIS:RISQUEDE CHOC ELECTRIQUENE
PASOUVRIR
LEFT BRIDGE RIGHT
+ - + -
8OHMS ONLY
+ -
LEFT RIGH T LEFT RI GH T LEFT RIG H T LEFT RI GH T LEFT RIGH T LEFT RIGH T LEFT RI G H T LEFT RI GH T
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
12345678
SPEAKEROUTPUTS
8Ω 120 W 4Ω 240 W
CLASS2WIRING
ELECTRONICSINC. ROCKLEIGH,N.J.07647 USA
ANALOGSOURCES
BALANCED
+ - G + -
BALANCED
+ - G + -
BALANCED
+ - G + -
BALANCED
+ - G + -
SPDIFOU T
LOOPTHRU
24 YZ G 24 YZG SETUP
SPDIFSOURCES
DIGITALOUT
L
R
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4
5 6 7 8
17 18 19 20
21 22 23 24
13 14 15 16
10
9
LAN
G
SWAMP-24x8
DM
SOURCE
CEN-N SP-1
PWR NET RESET SET UP ACTIVE
STREAM
CEN-NSP-1
TOUCH
SCREEN
CONTROL
SYSTEM
LAN
LAN
7.1
SURROUND
SOUND
SYSTEM
DISPLAY
SET TOP
BOX
GAME
CONSOLE
BLU-RAY
Living room
Kitchen
Dining room
Den
SPEAKERS
SPEAKERS
SPEAKERS
SPEAKERS
DM
HDMI
HDMI
HDMI
HDMI
Control
Control
LAN
Audio
Audio
Speaker
Speaker
L
A
N
Color Key
Speaker
Control
DM
HDMI
Audio
LAN
USB

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •7
Internal Block Diagrams
The following diagrams represent the switching and DSP abilities of the HD-XSPA.
Internal Block Diagram of the HD-XSPA
CPU
CEC Display Control
Audio DSPD/AConv Amplifier
HDMI
5 x 1 HDMI
Switcher
DM/HDMI 1
HDMI 2
HDMI 3
HDMI 4
HDMI 5
S/PDIF
Optical
S/PDIF 2
S/PDIF 3
Digital Audio
Switch
Analog Audio
Switch
Unbalanced 1
Unbalanced 2
Balanced
A/D
LFE/Sub
Center
Right
Left
Surround Right
Surround Left
Back/Downmix Right
Back/Downmix Left
SPEAKERS
LFE/Sub
Downmix Right
Downmix Left
PRE-AMP

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
8•7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
HD-XSPA DSP Detail
4 x 2
Switch
Decoding
(7.1 and Mixdown)
Bass
Management
Volume/Tone/
Loudness
2 Channel
Downmix
2 Channel
Downmix
Back/Downmix L/R
Front L/R, Center, Surround L/R
Back L/R
Volume
Trim
Delay
(Up To 100 ms Per
EQ
Specifications
Specifications for the HD-XSPA are listed in the following table.
HD-XSPA Specifications
SPECIFICATION DETAILS
Audio – General
Features 11 selectable source inputs plus built-in
noise generator, 7.1 Dolby Digital/DTS™
surround sound decoder, 7.1 multichannel
signal processing and steering, 9-band
graphic or parametric EQ, 80 ms lip-sync
delay, 20 ms speaker delay, unprocessed
Direct mode, stereo or mono downmix
output, embedding of SPDIF or analog
audio to HDMI output, HDCP management,
Crestron QuickSwitch HD
(Continued on following page)

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •9
HD-XSPA Specifications (Continued)
SPECIFICATION DETAILS
Audio – General (Continued)
Input Signal Types DigitalMedia 8G+, HDBaseT, HDMI,
DisplayPort Multimode*, S/PDIF (coaxial
and optical), analog 2-channel (unbalanced
and balanced)
Output Signal Types Amplified 7.1 channel, line-level 2-channel
downmix and subwoofer, HDMI pass-
through or 2-channel downmix
Analog-To-Digital Conversion 24-bit 96 kHz
Digital-To-Analog Conversion 24-bit 96 kHz (192 kHz in Direct mode)
Audio – Amplified Surround
Sound and Downmix Outputs
Output Power 140 watts per channel at 8 Ω
240 watts per channel at 4 Ω
Damping Factor >200 @ 20 Hz
Amplifier Monitoring Over Current, Over/Under Voltage, Over
Temperature, DC Offset, Clipping
Frequency Response 20 Hz to 20 kHz ±0.5 dB
Total Harmonic Distortion +
Noise (THD + N) at 8 Ω
< 0.008% digital in, < 0.01% balanced in,
< 0.02% unbalanced in (at 1 kHz)
Total Harmonic Distortion +
Noise (THD + N) at 4 Ω
< 0.02% any input (at 1 kHz)
Signal-to-Noise (S/N) Ratio > 102 dB digital in, > 100 dB analog in
(A-Weighted at full output)
Decoding Modes None, Stereo, Dolby Pro Logic IIx Movie,
Dolby Pro Logic IIx Music, DTS Neo:6
Cinema, DTS Neo:6 Music, Two Channel
Steering – Surround, Two Channel
Steering – Rear, Multichannel Stereo
(Party), Dolby Digital, Dolby Digital EX,
Dolby Digital Plus, Dolby TrueHD, DTS,
DTS-ES Matrix, DTS-ES Discrete, DTS
96/24, DTS-HD Master Audio, PCM
Multichannel
Speaker Trims ±12 dB per output (Front L/R, Surround
L/R, Back L/R, Center, Sub)
Speaker Delay 0 to 20 ms per output
Crossover Frequency Large (full range), 40, 50, 60, 70, 80, 90,
100, 120, 150, or 200 Hz per output
(excluding sub)
Low Frequency Effects (LFE) -10.0 to 0.0 dB
Main Volume Level -80 to +20 dB, adjustable from 0% to 100%,
plus mute
Bass Control ±12.0 dB
Treble Control ±12.0 dB
EQ Modes 9-band graphic (per output) or 9-band
parametric (per output)
GEQ Center Frequencies 63, 125, 250, 500, 1k, 2k, 4k, 8k, 16k Hz
GEQ Gain ±12.0 dB per band
(Continued on following page)

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
10 •7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
HD-XSPA Specifications (Continued)
SPECIFICATION DETAILS
Audio – Amplified Surround
Sound and Downmix Outputs
(Continued)
PEQ Center Frequency 10 to 20,000 Hz per band
PEQ Gain ±12.0 dB per band
PEQ Bandwidth 0.1 to 3.5 octaves per band
Loudness Compensation On/off
Compression None, Crestron DRC (Heavy, Medium,
Light), Dolby/DTS DRC (Heavy, Medium,
Light), Dolby TrueHD Auto
DTS Neo:6 Music Settings Center Gain 0.0 to 1.0, Standard or Wide
mode
Dolby Pro Logic IIx Music
Settings
Dimension ±7, Center Width 0 to 7,
Standard or Panorama
Audio – Preamp Downmix Output
Frequency Response 20 Hz to 20 kHz ±0.5 dB
Total Harmonic Distortion +
Noise (THD + N)
< 0.003% digital in, < 0.005% analog in
(at 1 kHz)
Signal-to-Noise (S/N) Ratio > 106 dB digital in, > 102 dB analog in
(A-Weighted at full output)
Downmix Volume Level -80 dB to +20 dB, adjustable from 0% to
100%, plus mute
Bass Control ±12.0 dB
Treble Control ±12.0 dB
Loudness Compensation On/off
Balance ±50%
Summing Stereo or mono selectable
Audio – Inputs
Input Compensation ±10.0 dB per input
Lip-Sync Delay 0.0 to 80.0 ms per input
Video
Features HDCP management, resolution
management, Crestron QuickSwitch HD
Input Signal Types HDMI, DisplayPort Multimode*, HDBaseT,
DM 8G+
Output Signal Type HDMI
Formats HDMI, DM
®
, and HDBaseT with Deep
Color, 3D, and 4K; HDCP content
protection support
(Continued on following page)

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •11
HD-XSPA Specifications (Continued)
SPECIFICATION DETAILS
Video (Continued)
Input Resolutions,
Progressive
640 x 480 @ 60 Hz
720 x 480 @ 60 Hz (480p)
720 x 576 @ 50 Hz (576p)
800 x 600 @ 60 Hz
848 x 480 @ 60 Hz
852 x 480 @ 60 Hz
854 x 480 @ 60 Hz
1024 x 768 @ 60 Hz
1024 x 852 @ 60 Hz
1024 x 1024 @ 60 Hz
1280 x 720 @ 50 Hz (720p50)
1280 x 720 @ 60 Hz (720p60)
1280 x 768 @ 60 Hz
1280 x 800 @ 60 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 Hz
1360 x 768 @ 60 Hz
1365 x 1024 @ 60 Hz
1366 x 768 @ 60 Hz
1400 x 1050 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 900 @ 60 Hz
1600 x 1200 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 24 Hz (1080p24)
1920 x 1080 @ 25 Hz (1080p25)
1920 x 1080 @ 50 Hz (1080p50)
1920 x 1080 @ 60 Hz (1080p60)
1920 x 1200 @ 60 Hz
2048 x 1080 @ 24 Hz
2048 x 1152 @ 60 Hz
2560 x 1440 @ 60 Hz
2560 x 1600 @ 60 Hz
3840 x 2160 @ 24 Hz
3840 x 2160 @ 30 Hz
4096 x 2160 @ 24 Hz
Plus any other resolution allowed by HDMI
up to 300 MHz pixel clock
Input Resolutions, Interlaced 720 x 480 @ 30 Hz (480i)
720 x 576 @ 25 Hz (576i)
1920 x 1080 @ 25 Hz (1080i25)
1920 x 1080 @ 30 Hz (1080i30)
Plus any other resolution allowed by HDMI
up to 300 MHz pixel clock
Output Resolutions Matched to inputs
Communications
Ethernet For control and setup; 10/100 Mbps,
auto-switching, auto-negotiating,
auto-discovery, full/half duplex, DHCP
USB USB client for setup via front panel
COMPUTER port;
Supports extension of USB HID class
devices over DM via rear panel USB host
port
(Continued on following page)

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
12 •7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
HD-XSPA Specifications (Continued)
SPECIFICATION DETAILS
Communications (Continued)
DigitalMedia DM 8G+, HDCP management, EDID format
management, CEC, PoDM, HDBaseT
compliant
HDMI Passes CEC and EDID, enables CEC
pass-through from control system to HDMI
inputs and output, supports HDCP,
provides HDCP key management
Power Requirements
Main Power
HD-XSPA 6 amps @ 120 Vac, 50/60 Hz
HDI-XSPA 3 amps @ 220-240 Vac, 50/60 Hz
Environmental
Temperature 41º to 104º F (5º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 300 Btu/h (140 watts @ 8 Ω)
425 Btu/h (240 watts @ 4 Ω)
Enclosure
Chassis Metal with black finish, vented sides, ultra-
quiet variable-speed fan cooled
Front Panel Metal with black finish and polycarbonate
label overlay
Mounting Freestanding or 2 U 19-inch rack-
mountable (includes removable feet and
rack ears)
Dimensions
Height 4.07 in (104 mm) with feet
3.47 in (89 mm) without feet
Width 19 in (483 mm) with rack ears
17.28 in (439 mm) without rack ears
Depth 15.78 in (401 mm)
Weight 32 lb (15 kg)
Available Models
HD-XSPA 7.1 High-Definition Surround Sound AV
Receiver
HDI-XSPA 7.1 High-Definition Surround Sound AV
Receiver, International Version, 220-240 V
Available Accessories
AIR
®
Series Surface Mount and Landscape Speakers
Aspire
®
Series In-Ceiling and In-Wall Speakers
AUD-EXT Audio Extenders
CBL SERIES Crestron Certified Interface Cables
CNSP-XX Custom Serial Interface Cable
DM-8G-CONN DigitalMedia 8G Cable Connector
Continued on following page)

Crestron HD(I)-XSPA 7.1 High-Definition Surround Sound AV Receiver
Operations & Installation Guide – DOC. 7448A 7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA •13
HD-XSPA Specifications (Continued)
SPECIFICATION DETAILS
Available Accessories
(Continued)
DM-8G-CONN-WG DigitalMedia 8G Cable Connector with Wire
Guide
DM-8G-CRIMP Crimping Tool for DM-8G-CONN
DM-8G-CRIMP-WG Crimping Tool for DM-8G-CONN-WG
DM-CBL-8G DigitalMedia 8G Cable
DM-TX-200-C-2G Wall Plate DigitalMedia 8G+ Transmitter
200
DM-TX-201-C DigitalMedia 8G+ Transmitter 201
DM-TX-401-C DigitalMedia 8G+ Transmitter 401
Essence
®
Series In-Ceiling and In-Wall Speakers
Excite
®
Series In-Ceiling and In-Wall Speakers
HD-EXT3-C HDMI over HDBaseT Transmitter with IR
and RS-232
HD-MD8X1 Quickswitch HD 8x1 HDMI Switcher
HD-MD8x2 Quickswitch HD 8x2 HDMI Switcher
HD-SCALER High Definition Video Scaler
HD-TX3-C HDMI over HDBaseT Transmitter
IRP2 IR Emitter Probe
Saros
®
Series Commercial Speakers
SAT-70V/100V Sonnex Output Transformer
USB-EXT-DM-LOCAL USB Extender Module for Host
USB-EXT-DM-REMOTE USB Extender Module for Devices
* HDMI requires an appropriate adapter or interface cable to accommodate a DisplayPort Multimode
signal.

7.1 High-Definition Surround Sound AV Receiver Crestron HD(I)-XSPA
14 •7.1 High-Definition Surround Sound AV Receiver: HD(I)-XSPA Operations & Installation Guide – DOC. 7448A
Physical Description
This section provides information on the connections, controls, and indicators
available on the HD-XSPA.
HD-XSPA Physical View, Front and Rear
