Crestron Surround Sound Tuning Kit User manual

Crestron
Professional Surround Sound Tuning Kit
Operations Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
Manufactured under license from Audyssey Laboratories. U.S. and foreign patents pending.
MultEQ XT is a trademark of Audyssey Laboratories™.
All brand names, product names and trademarks are the property of their respective owners.
©2010 Crestron Electronics, Inc.

Crestron Professional Surround Sound Tuning Kit
Contents
Professional Surround Sound Tuning Kit: Quickstart iii
Introduction ..............................................................................................................................iii
1. Hardware Hookup ..................................................................................................iii
2. Room EQ Setup......................................................................................................iv
3. Measurement ..........................................................................................................iv
4. Target Sound Options..............................................................................................v
5. Save Results ............................................................................................................ v
6. Audyssey Settings ..................................................................................................vi
7. Calibration Complete..............................................................................................vi
8. Optional Adjustments.............................................................................................vi
Conclusion ................................................................................................................................vi
Professional Surround Sound Tuning Kit 1
Introduction ...............................................................................................................................1
Setup ..........................................................................................................................................2
Supplied Hardware ......................................................................................................2
Installation................................................................................................................... 2
Hardware Hookup ....................................................................................................... 2
Operation ...................................................................................................................................4
Initial Configuration .................................................................................................... 4
Room EQ setup ...........................................................................................................6
Measurement ...............................................................................................................8
Detection Results....................................................................................................... 11
Target Sound Options................................................................................................ 12
Save Results ..............................................................................................................13
Audyssey Settings .....................................................................................................17
Calibration Complete.................................................................................................17
Optional Adjustments................................................................................................ 18
Problem Solving ......................................................................................................................19
Troubleshooting......................................................................................................... 19
Reference Documents................................................................................................19
Further Inquiries ........................................................................................................ 20
Future Updates .......................................................................................................... 20
Software License Agreement................................................................................................... 21
Return and Warranty Policies ..................................................................................................23
Merchandise Returns / Repair Service ...................................................................... 23
CRESTRON Limited Warranty.................................................................................23
Operations Guide – DOC. 6565C Contents •i

Crestron Professional Surround Sound Tuning Kit
Professional Surround Sound
Tuning Kit: Quickstart
Introduction
The following steps are designed to guide you through the basic hookup and use of
your Professional Surround Sound Tuning Kit.
Follow this checklist to tune your system.
1. Hardware Hookup
 All components in the system should be powered off while making
connections.
NOTE: Crestron’s Professional Surround Sound Tuning Kit may be used with an
AMS, an AMS-AIP or a PSPHD. For simplicity within this guide, all three models
will hereinafter collectively be referred to as “the processor”.
 Remove the plastic cover from the front of the processor.
 Place the microphone stand upright.
 Attach the microphone holder to the stand.
 Insert the microphone in a vertical position in the holder.
NOTE: You must place the microphone in a vertical position with the capsule
facing the ceiling for all measurements.
 Connect the mini female XLR end of the female mini XLR to male XLR
cable to the microphone.
NOTE: Use care when attaching the mini XLR cable so as not to strain the
connector.
 For the AMS, connect the male XLR end of the cable to the XLR end of the
female XLR to stereo 3.5 mm cable. For the PSPHD, connect the male XLR
end of the cable to the XLR end of the female XLR to mini XLR cable.
Operations Guide – DOC. 6565C Quickstart •iii

Professional Surround Sound Tuning Kit Crestron
 For the AMS, connect the stereo 3.5 mm plug to the microphone input on
the AMS. For the PSPHD, connect the mini XLR plug to the microphone
input on the PSPHD.
NOTE: Use care when attaching the microphone cable so as not to strain the
connector.
 Using the included USB cable, connect your PC to the USB port on the
front of the processor.
2. Room EQ Setup
NOTE: When Pro Sound Tools™ or PROCISE™ Tools is run for the first time, a
setup wizard will take your through the process. Thereafter, the Configure button
can be used to initiate the process.
 Insert the CD that came with the kit and click Add/Change Mic Setup File.
Select the file for the microphone that came with your kit.
 When a center speaker or subwoofer is not used, un-check the Front Center
Speaker and/or Subwoofer checkboxes.
 Any subwoofer low-pass filter should be defeated or set to its maximum
frequency. Any subwoofer gain settings should be set to their nominal or 12
o’clock position. Also, any sort of auto standby or sleep mode for the
subwoofer should be disabled.
 Click Room Equalization Setup… to begin the process. The “Job
Information” screen is used to record the name of the customer or job and
the name of the technician performing the job.
 Click the forward arrow to proceed to the “Options” screen. The” Options”
screen is where you select the microphone file to match the microphone you
are using.
 Select your microphone and click the forward arrow to proceed to the
“Measurement” screen.
3. Measurement
 Quiet the room as much as possible.
 Turn off phones, TVs, radios, air conditioners, etc. and close any open
windows.
 Refrain from talking and do not sit or stand directly between any of the
speakers and the microphone.
NOTE: Do not touch the microphone stand or cable during the measurement
process.
A. Position 1 Measurement
 Place the microphone at the primary listening location, at the ear height of a
listener seated at this location.
iv •Quickstart Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
NOTE: It is important to have the microphone in the primary listening position for
the first measurement.
 Press the Measure button. The Audyssey™ test signal will play a series of
10 “chirps” through each channel.
B. Additional Position Measurements
 Move the microphone to another listening position and press the Measure
button again. Repeat the process for all listening positions in the room.
 You will need to measure a minimum of three positions before you can
continue. The recommendation is to measure a minimum of eight positions
for typical rooms.
 Click the forward arrow to finish the measurement process and continue to
the “Detection Results” screen, which displays the results of the
measurements.
 Click the forward arrow to proceed to the “Target Sound Options” screen.
4. Target Sound Options
 Choose which of the Audyssey™ target curves you want to use by selecting
the radio button next to the curve:
 For small to medium rooms (up to 2500 cu. ft.), choose the High
Frequency Roll Off 1 curve.
 For medium to large rooms (up to 5000 cu. ft.), choose the High
Frequency Roll Off 2 curve.
 For rooms larger than 5000 cu. ft., choose the SMPTE 202M
curve.
 The Midrange Compensation option (selected by default) is used to adjust
the balance between on-axis and reflected sound in the crossover region. It
is recommended that you leave this box checked. You can return to this
screen later and change your setting if you prefer.
 Click the forward arrow to calculate your correction curves and proceed to
the “Save Results” screen.
5. Save Results
A. Transfer the MultEQ®XT Filters
 Click Transfer to Crestron to temporarily store the filters so you can listen
to them. This process may take several minutes.
B. MultEQ®Pro On/Off Demo
 You can now use the MultEQ On and Off buttons to demo the MultEQ®XT
filters.
Operations Guide – DOC. 6565C Quickstart •v

Professional Surround Sound Tuning Kit Crestron
This step is for PSPHD only.
For AMS, proceed to step D. C. Dynamic EQ & Dynamic Volume On/Off Demos
 When MultEQ is On, use the Dynamic EQ On and Off buttons to demo the
Dynamic EQ function. The Dynamic Volume presets can be auditioned as
well.
D. Save the MultEQ®XT Filters
 Click the Save Permanently to Crestron button to save the correction
curves. This process may take several minutes.
NOTE: It is important to use the Save Permanently to Crestron function before
leaving the program. Otherwise, all measurements will be lost and you will have to
start the process over from the beginning.
This step is for PSPHD only.
For AMS, proceed to step 7. 6. Audyssey Settings
 After saving the MultEQ®XT filters, the “Audyssey Settings” screen is
displayed. Use the sliders to adjust the amount of volume swing for each of
the preset values (Day, Evening, Midnight). After this is complete, click the
right arrow near the bottom of the screen.
7. Calibration Complete
 When the Calibration Complete message appears, click Close in the lower
right corner of the window to exit the application.
8. Optional Adjustments
Sometimes users want to change the level of the center channel (for example, to
boost dialog) or subwoofer. This is optional and is not required most of the time but
if it is desired, adjustments to these or any other channels can be made by going into
Pro Sound Tools or PROCISE Tools and clicking on Speaker Adjustments. This
allows each speaker’s level to be adjusted individually.
NOTE: After completion, you can demonstrate the improved performance of
Audyssey™ Room Tuning from the AMS or PSPHD front panel. On the AMS, go to
the Audyssey Configuration menu by selecting Theater, More, Tools and
Audyssey. On the PSPHD, press SETUP, then select Audyssey MultEQ. This will
allow an A/B comparison of the Audyssey and non-Audyssey configurations. On the
AMS, the system will automatically default to the Audyssey configuration when this
menu is entered or exited. On the PSPHD, the last setting will take priority.
Conclusion
This concludes the Quickstart section of the Professional Surround Sound Tuning Kit
Operations Guide. Continue reading for more information on installing and operating
the Professional Surround Sound Tuning Kit.
vi •Quickstart Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
Professional Surround Sound
Tuning Kit
Introduction
Creston’s Professional Surround Sound Tuning Kit for the Adagio®Media System
and the PROCISE™ High Definition Professional Surround Sound Processor allows
custom installers use the Audyssey MultEQ®Pro PC application to bring Audyssey
MultEQ®XT sound equalization technology to high quality listening rooms.
Audyssey MultEQ®XT creates an optimum listening experience for every seat in
your theater using an ingenious equalization solution that automatically corrects the
time, level and frequency response for each speaker within the space.
Every listening room or home theater room will add colorations to the direct sound
coming from the loudspeakers. These colorations occur at both bass and treble
frequencies. In the bass, they are caused by the natural resonances (also called
modes) every room has. In the treble, they come from wall, floor and ceiling
reflections of the sound from the loudspeakers. MultEQ®Pro measures the sound
information throughout the listening area. Based on these measurements, MultEQ®
Pro calculates an equalization solution that effectively removes sonic colorations
caused by the interaction of sound from the speakers with the room, allowing the
speakers to attain their best possible performance.
Professional Surround Sound Tuning Kit
Operations Guide – DOC. 6565C Professional Surround Sound Tuning Kit •1

Professional Surround Sound Tuning Kit Crestron
Setup
Supplied Hardware
The hardware supplied with the Professional Surround Sound Tuning Kit is listed in
the following table.
Supplied Hardware for the Professional Surround Sound Tuning Kit
DESCRIPTION PART NUMBER QUANTITY
APM1 Microphone & CD with Calibration
File
4504520 1
Cable Assembly, XLR to Stereo 3.5 mm, 5’ 2017722 1
Cable Assembly, Female XLR to Male Mini
XLR, 6’
2026344 1
Cable Assembly, USB 2.0, Series “A” to “B”
Plugs, 6’
2014966 1
Cable Assembly, Female Mini XLR to Male
XLR, 6’
2018284 1
OEM Cable, XLR, 18’ 2017745 3
OEM Boom Stand, Ultra Light 2017744 1
Installation
NOTE: The CD that comes with the Professional Surround Sound Tuning Kit
contains a file specially configured for the individual microphone that also comes
with the kit. Crestron suggests you keep the CD and the microphone together and
also that you make a backup copy of the CD and store it in a safe place.
The Professional Surround Sound Tuning Kit requires that you have at least one of
the following software applications installed on your PC:
• Pro Sound Tools™ (version 1.00.19 or later) for the AMS
• PROCISE™ Tools (version 1.00.19 or later) for the PSPHD
• Crestron Toolbox™ (version 1.06.10 or later)
Hardware Hookup
While making connections, all components in the system should be powered off.
Place the microphone stand upright. Attach the microphone holder to the stand.
Insert the microphone in a vertical position in the holder.
NOTE: You must place the microphone in a vertical position with the capsule
facing the ceiling for all measurements. Refer to illustration on the following page.
2 •Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
Microphone Stand and Microphone in Measuring Position
Connect the mini female XLR end of the female mini XLR to male XLR cable to the
microphone.
NOTE: Crestron’s Professional Surround Sound Tuning Kit may be used with an
AMS, an AMS-AIP or a PSPHD. For simplicity within this guide, all three models
will hereinafter collectively be referred to as “the processor”.
For the AMS, connect the male XLR end of the cable to the XLR end of the female
XLR to stereo 3.5 mm cable. For the PSPHD, connect the male XLR end of the cable
to the XLR end of the female XLR to mini XLR cable.
For the AMS, connect the stereo 3.5 mm plug to the microphone input on the AMS.
For the PSPHD, connect the mini XLR plug to the microphone input on the PSPHD.
For details on the AMS, refer to the latest version of the Adagio Media System
Operations Guide (Doc. 6509). For details on the AMS-AIP, refer to the latest
version of the Adagio Media System Operations Guide (Doc. 6516). For details on
the PSPHD, refer to the latest version of the PROCISE High Definition Surround
Sound Processor Operations Guide (Doc. 6837). All are available from the Crestron
website (www.crestron.com/manuals).
NOTE: The Professional Surround Sound Tuning Kit provides 3 18’ XLR cables. If
more cable length is required to reach the processor, you can add these as needed in
between the male XLR end of the microphone cable and the XLR end of the XLR to
stereo 3.5 mm cable (for the AMS) or the XLR end of the XLR to mini XLR cable
(for the PSPHD). You can chain multiple cables for a longer length if required. If
additional XLR cables are needed, you may supply your own.
Using the USB cable included with the Professional Surround Sound Tuning Kit,
connect your PC to the USB port on the front of the AMS.
NOTE: The USB connection is required for Audyssey MultEQ® Pro to function.
Operations Guide – DOC. 6565C Professional Surround Sound Tuning Kit •3

Professional Surround Sound Tuning Kit Crestron
Operation
Unless otherwise noted, the steps on the following pages are for both Adagio (AMS
or AMS-AIP) and PROCISE (PSPHD).
ONLY
Steps that are specific to Adagio will have an icon in the left margin, like the one
shown to the left.
ONLY
Steps that are specific to PROCISE will have an icon in the left margin, like the one
shown to the left.
Initial Configuration
For the AMS, the Audyssey MultEQ®Pro application can be accessed directly
through Pro Sound Tools or through Pro Sound Tools via Crestron Toolbox. For the
PSPHD, the Audyssey MultEQ®Pro application can be accessed directly through
PROCISE Tools or through PROCISE Tools via Crestron Toolbox.
ONLY
NOTE: When Pro Sound Tools is run for the first time, a setup wizard will run to
take you through the necessary steps for your system. Thereafter, the Configure
button can be used to initiate the process.
“Pro Sound Tools” Window
Click Configure at the top of the window to open the “System Configuration”
window.
4 •Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
Pro Sound Tools “System Configuration” Window
If you have not already installed the special file for the microphone that came with
your Professional Surround Sound Tuning Kit, insert the CD that came with your kit
and click Add/Change Mic Setup File. The application will present a standard
“Browse” window where you can navigate to your CD drive and select the special
file for the microphone that came with your Professional Surround Sound Tuning
Kit. This should be “Audyssey Mic #####.apm” (where ##### represents the
microphone serial number).
ONLY
NOTE: When PROCISE Tools is run for the first time, a setup wizard will run to
take you through the necessary steps for your system. Thereafter, the Configure
button can be used to initiate the process.
“PROCISE Tools” Window
Click Configure at the top of the window to open the “System Configuration”
window.
Operations Guide – DOC. 6565C Professional Surround Sound Tuning Kit •5

Professional Surround Sound Tuning Kit Crestron
PROCISE Tools “System Configuration” Window
If you have not already installed the special file for the microphone that came with
your Professional Surround Sound Tuning Kit, insert the CD that came with your kit
and click Add/Change Mic Setup File. The application will present a standard
“Browse” window where you can navigate to your CD drive and select the special
file for the microphone that came with your Professional Surround Sound Tuning
Kit. This should be “Audyssey Mic #####.apm” (where ##### represents the
microphone serial number).
Room EQ setup
When the Pro Sound Tools or PROCISE Tools application is launched, it will
provide a window for selecting the current system configuration (for example, 5.1,
6.1, 7.1 plus additional rooms, etc.). When a center speaker or subwoofer is not used,
un-check the Front Center Speaker and/or Subwoofer checkboxes as appropriate, in
order to enable “phantom” center and “phantom” subwoofer. The phantom setting
will route center and/or subwoofer information to the main speakers.
Any subwoofer low-pass filter should be defeated or set to the THX setting
(sometimes called “LFE input”). If the subwoofer low-pass filter cannot be defeated,
set it to its maximum frequency. Any subwoofer gain settings should be set to their
nominal position or at 12 o’clock on a conventional level control. Also, if the
subwoofer has any sort of auto standby or sleep mode that turns the power to the
subwoofer off after it does not receive any signal for some period of time, please
disable this mode. This will ensure that the subwoofer is always on, which is
important when taking measurements. The subwoofer may be set back to auto after
measuring is complete.
Click Room Equalization Setup… to begin the process.
NOTE: If you have not already done so, the application will prompt you to install
the special file for the microphone that came with your Professional Surround Sound
Tuning Kit.
NOTE: The Master Volume control and Active Input Source drop down list will
function until the process gets to the “Job Information” screen, at which point the use
of these is disabled until the filters are transferred (refer to “Save Results” which
starts on page 13).
6 •Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
NOTE: The screen illustration that follows shows a black border around the
Audyssey section of the window. This is the view in PROCISE Tools. The view in
Pro Sound Tools will have a gray border around the Audyssey section of the
window. In addition, in the list at the left side of the Audyssey section of the
window, Audyssey Settings appears only in PROCISE Tools.
“Job Information” Screen
The “Job Information” screen is used to record the name of the customer or job and
the name of the technician performing the job.
Click the forward arrow to proceed to the “Options” screen.
“Options” Screen
The “Options” screen is where you select the microphone file to match the
microphone you are using. If you have more than one Professional Surround Sound
Operations Guide – DOC. 6565C Professional Surround Sound Tuning Kit •7

Professional Surround Sound Tuning Kit Crestron
Tuning Kit and therefore more than one microphone, it is important that you choose
the correct serial number for the microphone you are using during the installation.
The serial number on the microphone setup file should match the one printed on the
microphone.
Click the forward arrow to proceed to the “Measurement” screen.
Measurement
“Measurement” Screen
The microphone should be positioned as far out from the stand as possible to
minimize the effect of stand reflections.
NOTE: You must place the microphone in a vertical position with the capsule
facing the ceiling for all measurements. Refer to illustration on page 3.
Quiet the room as much as possible. Background noise can disrupt the room
measurements. Turn off cell phones, televisions, radios, air conditioners, fluorescent
lights and other devices or home appliances. Close any open windows.
Refrain from talking and do not sit or stand directly between any of the speakers and
the microphone during the room measurements. Each speaker will emit a series of
test signals during the measurements and your body and background noise can
disrupt the microphone’s ability to properly record the room response to the test
signal.
Position 1 Measurement
For the Position 1 measurement, place the microphone at the primary or most central
listening location. The height should be the ear height of a listener seated at this
position.
NOTE: It is important to have the microphone in the primary listening position for
the first measurement. Every position measurement will record the room’s frequency
and time response but Position 1 also detects the absolute polarity of each speaker,
calculates the exact distance (within a half inch) for setting delays and determines
levels (within half a dB) for each speaker. The speaker type, distance, level, filter
8 •Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
characteristics and crossover frequency from the Position 1 measurement are
displayed later on the “Detection Results” screen (refer to “Detection Results” which
starts on page 11).
Press the Measure button. The Audyssey test signal will play a series of 10 “chirps”
through each channel. The name of the speaker being measured will be indicated
under the status bar while the test signal plays.
“Measurement Screen” (Showing Position 1 Progress)
After the application is finished playing the 10 chirps through each channel, the
application will transfer each channel’s measurement (this takes several seconds).
Click Undo Last if you want to erase your previous measurement.
Click Clear All at any time to erase all your position measurements and go back to
Position 1.
The Load Measurements and Save Measurements buttons allow you to start the
measurement procedure and return to it at a later time to continue, without losing any
measurements already taken. Press Save Measurements to save the current
measurements. Press Load Measurements to retrieve measurements already taken.
NOTE: When loading previously taken measurements, ensure the configuration
matches the current one. For example, loading a 5.1 channel measurement file into a
7.1 channel setup will result in two of the channels being undetected. Loading a 7.1
channel measurement into a 5.1 setup will result in the last two channels being
ignored.
Additional Position Measurements
Move the microphone to another listening position and press the Measure button
again. Repeat the process for all listening positions in the room. You will need to
measure a minimum of three positions before you can continue. The
recommendation is to measure a minimum of eight positions for typical rooms.
Stagger the height of the microphone by a few inches from location to location to
account for different listener heights.
Operations Guide – DOC. 6565C Professional Surround Sound Tuning Kit •9

Professional Surround Sound Tuning Kit Crestron
NOTE: A minimum of three measurements is required. You will not be able to
continue to the next screen in the application until the third measurement is
complete.
The larger the room, the more positions you should measure (the maximum is 32
positions). Make sure you measure only in positions where people will be located
while listening to the system (i.e. measuring in a far off corner where nobody would
ever listen will not be beneficial and may detract from the overall benefit within the
main listening area).
Audyssey MultEQ®Pro measures the absolute polarity of each individual
loudspeaker. If any of your speakers are wired out of polarity (i.e. +and –reversed),
the application will show you an error window that explains which loudspeaker(s) to
check. You may then check the polarity problem before continuing with the
application. It is recommended that you check for polarity problems by examining
the wire connections at the amplifier, speakers and any splices in the speaker cables.
NOTE: In some situations, such as when the rear speakers are dipolar radiators, the
program may show a polarity error even if the speakers are correctly wired. Correct
wiring should be verified by checking the connections at the amplifier, speakers and
any splices in the speaker cables.
Polarity Error Window
NOTE: After measurements are complete, Crestron recommends saving these (by
pressing the Save Measurements button) before proceeding to the “Detection
Results” screen. The program will show a standard window asking you to select a
location to save the new .amd file.
Click the forward arrow to finish the measurement process and continue to the
“Detection Results” screen.
NOTE: You can always return to the “Measurement” screen and measure more
positions by clicking the back arrow (the application will remember the last
measured position).
10 •Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C

Crestron Professional Surround Sound Tuning Kit
Detection Results
“Detection Results” Screen
The “Detection Results” screen displays the Speaker Type, Distance, Trim,
Cutoff/slope and Crossover results derived from your Position 1 measurement (refer
to “Position 1 Measurement” which starts on page 8) and the recommended
Crossover derived from all of your position measurements.
• Speaker Type detects if the speaker connected to that channel is a satellite or
a subwoofer.
• Dist (feet) will automatically set the distance (delay) in the processor.
NOTE: Clicking on the heading for this column will change the display to
Dist (m) showing the distance in meters. Clicking the heading again will
change the display to show Delay (ms) showing the delay in milliseconds. A
third click will return the display to Dist (feet).
• Trim is displayed in dB. This number is not a dB SPL (absolute loudness)
number. It is an absolute trim and must be used as shown. When applied,
absolute trim gives reference level at the primary seat for volume set to
0dB. The Trim information will be automatically set in the processor.
• Cutoff/slope displays the filter characteristics applied to each speaker.
• Crossover is displayed in Hz. The Crossover information will be
automatically set in the processor. You can use the drop-down menus to
override the crossover settings that will be sent to the processor.
The Audyssey filter calculation is optimized based on your selected crossover
frequency setting in the Crossover drop-down menus. Crossover choices are listed in
descending order of preference to optimize satellite-subwoofer blending.
Only rarely should you ever choose the Large setting for the crossover. This setting
means the bass for that channel will not be sent to the subwoofer. Only in the
following situations, should you consider choosing the Large setting:
1. Your system does not have a subwoofer.
Operations Guide – DOC. 6565C Professional Surround Sound Tuning Kit •11

Professional Surround Sound Tuning Kit Crestron
2. Your satellite speakers extend as low or lower in frequency than your
subwoofer. Even in this case, however, you may not want to use Large
because your subwoofer probably has better power handling for the bass.
NOTE: Even if the Distance shown for the subwoofer is longer than the physical
distance, it is probably correct since subwoofers often have digital amps that delay
the signal.
Click the forward arrow to proceed to the “Target Sound Options” screen.
Target Sound Options
“Target Sound Options” Screen
On the “Target Sound Options” screen, choose which of the Audyssey target curves
you want to use by selecting the radio button next to the curve.
NOTE: To cover a wide range of room types, MultEQ®Pro currently provides a
selection of three target curves.
1. The High Frequency Roll Off 1 curve introduces a slight roll off at high
frequencies that accounts for the balance between direct and reflected sound
for a small to medium size rooms (room volume less than 2500 cu. ft.).
2. The High Frequency Roll Off2 curve introduces a slightly greater roll off at
high frequencies that restores the balance between direct and reflected
sound for medium to large size rooms (room volume between 2500 and
5000 cu. ft.).
3. The SMPTE 202M curve is an international standard for the high frequency
roll off applied in a typical 500-seat movie theater. It is appropriate for
professional mixing spaces and dubbing stages that must be calibrated for
film sound post-production. It can also be used in extremely large playback
spaces (room volume greater than 5000 cu. ft.).
12 •Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C
