UC-PHONE-S/UC-PHONE-T
Desk Phones for Skype®for Business & Microsoft Teams™Software
DO GUIDE
Attach the stand as shown below:
DO Assemble the Device
DO Check the Box
ITEM
Cable, Ethernet, CAT5e, 6.6' (2 m)
Cord, Handset
Handset
Phone
Stand
QTY
1
1
1
1
1
Make the necessary connections as called out in the following diagrams.
DO Connect the Device
45
40
NOTE: The USB port on the back of the display is not used.
ＰＣ Ｉｎｔｅｒｎｅｔ
ＤＣ５Ｖ
Handset cord
HandsetHeadset
To headset (sold separately)
Internet:
To 802.3af compliant
PoE injector or switch via
included Ethernet cable
PC (Optional):
To PC LAN port
DC5V
Not used To handset cord
After the device is connected to the network and supplied with
power, it automatically begins the initialization process. After
startup, the phone is ready for use. You can congure the
phone via the web user interface or phone user interface. For
details, refer to UC-PHONE Supplementary Guide (Doc. 8368)
at www.crestron.com/manuals.
DO Use the Device
DO Learn More
Visit the website for additional information and the latest
rmware updates. To learn more about this product, use a QR
reader application on your mobile device to scan the QR
images.
UC-PHONE-S UC-PHONE-T
antenna or transmitter.
To change network settings or move Kaptivo to another board:
Go to kaptivo.com/setup in any browser and follow the online
instructions
1.
2.
As of the date of manufacture, the product has been
tested and found to comply with specications for CE
marking.
This product is Listed to applicable UL®Standards and
requirements tested by TUV.
Ce produit est homologué selon les normes et les
exigences UL applicables par TUV.
Federal Communications Commission (FCC)
Compliance Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
CAUTION: Changes or modications not expressly
approved by the manufacturer responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Industry Canada (IC) Compliance Statement
CAN ICES-3 (B)/NMB-3(B)
The product warranty can be found at
www.crestron.com/warranty.
The specic patents that cover Crestron products are
listed at www.crestron.com/legal/patents.
Certain Crestron products contain open source software.
For specic information, please visit
www.crestron.com/opensource.
Crestron and the Crestron logo are either trademarks or
registered trademarks of Crestron Electronics, Inc. in the
United States and/or other countries. Skype and Microsoft
Teams are either trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other
countries. UL is either a trademark or registered trademark
of Underwriters Laboratories, Inc. in the United States
and/or other countrieOther trademarks, registered
trademarks, and trade names may be used in this
document to refer to either the entities claiming the marks
and names or their products. Crestron disclaims any
proprietary interest in the marks and names of others.
Crestron is not responsible for errors in typography or
photography.
This document was written by the Technical Publications
department at Crestron.
©2018 Crestron Electronics, Inc.
DOC. 8358A (2052469) 08.18
Crestron Electronics
15 Volvo Drive, Rockleigh, NJ 07647
888.CRESTRON | www.crestron.com
