CrimeStopper CS-2014.DPII.FM.TW2 User manual

CS-2014DPII-TW2.FM/FM SuperPage™
2-Way FM/FMLCD Paging Alarm&RemoteEngineStarting System
OPERATIONINSTRUCTIONS
INTRODUCTION
CONGRATULATIONS onyour choice oftheSuperPage V™by Crimestopper SecurityProductsInc. Thisbooklet
contains theinformationnecessary foroperating yoursystem. If anyquestions arise, contact your installationdealer or
Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These features must beconnectedinorder forthesystem tooperateproperlyi.e. Power, Ground, LED,
etc.
-OPTIONAL: Optionalfeatures areconnected onlyifdesired or agreed uponby theinstallingdealer i.e. HornHonk,
Dome lightillumination,Door Locks, Trunk Pop, etc. These features mayrequire additionalparts andlabor charges.
Consult withyour installer about these features BEFORE installation!
CONTACTINFORMATION:
TECHNICAL SUPPORT(800)-998-6880
Monday- Friday8:00am- 4:30pmPacific
Website: www.crimestopper.com
CRIMESTOPPER
SECURITYPRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA.93063 REV. 06.6.2006
ThisdevicecomplieswithFCC Rulespart15.Operation issubject
tothe followingtwoconditions:1)Thisdevicemaynotcause
interference,and (2)thisdevicemustacceptanyinterferencethat
maybe received,including interferencethatmaycauseundesired
operation.The manufacturerisnotresponsibleforanyradioorTV
interferencecausedbyunauthorized modification tothis
equipment. Suchmodification couldvoidtheuser'sauthorityto
operatethe equipment.

2
TABLEOF CONTENTS
OperationCautions&Warnings……..…………..……………………………………………………………………2
Transceiver/ Pager-Remote……….....…………..……………………………………………………………………3
1-WaySidekickRemoteControl………………………….…………………………………………………..…...…..4
OperatingInstructions-Alarm……………………………………………………….………..……………..……..5-8
RemoteEngineControl………………………...……………………………………………….…….………...….9-12
Anti-CarjackProtection...……………………………………….………….……..………………..………..………..13
LEDDiagnostics………………..……………………………………………………………………….………..….…14
Transceiver/ Remote Control Programming……………………………………………………..……………14-15
2VehicleOperation……...………………………….……………………………….………….…………….….……16
Troubleshooting/FAQ Section……………….…………………………………………………………..……..17-18
Low BatteryWarning –LCD Remote / SettingClock –LCD Remote……………………………….….……..19
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPERSECURITYPRODUCTS,INC. andits VENDORS shallnotbeliablefor anyaccident
resulting fromthe useofthisequipment. Thissystemisdesignedtobeprofessionallyinstalledintoacar or
vehicleingoodrunning order.Items,suchasparkingbrake,door switches,andallenginesafetyfeatures,
mustbeinperfectworkingcondition.
DAMAGEresulting frommisuseornegligenceisNOTcoveredunderwarranty and will be subjectto
repairand/ or replacementcharges.
ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO: A)Understandthe operationofthis
systemanditssafetyfeatures.B)Checkforproperoperationofthesesafetyfeaturespriortoaccepting
deliveryofthevehiclefromtheinstallation facility.C)Checkandmaintainthecondition ofthe vehicleandall
itemsrelativetotheproperoperationofthissystemanditssafetyfeatures.
DO NOTremotestartthevehicleinaclosedgarage. Makesurethat the vehicleisoutdoors, agarage door
isopen,orthereisadequateexhaustventilation.Failuretoobservethisrulecouldresultin injuryordeath
frompoisonousCarbon Monoxidefumes.Thisisespeciallyimportantwhen using theTimed Self-Startfeature
of theunit

3
TRANSCEIVER/ PAGER-REMOTE
PAGER/ REMOTETRANSCEIVER:
The hand-heldremotetransceiver isusedtosend and
receiveinformation fromthe vehicle.The ControlModule
transmitsHigh FrequencyFM/FMsignalsfromthe vehicle
toyouroverlongdistances.Yourrange will vary
depending on location,terrain,and localRF
noise/interference.Thissystemisnotguaranteed topage
youifyouarebehind concretewalls,underground,ina
largestructure,orinanareawithhighlevelsofelectronic
interference.Handlethepager/remotewithcare ifthe
LCD displayand/or the electronicsmaybedamagedif
subjectedtoabuse.The AAA Cell 1.5Valkaline battery
can easilybereplaced bysliding open the batteryaccess
dooronthebackofthe remote.Batterylifewill vary
depending on usage.TheLCDscreenwill displayalow
batteryicon when the batteryislow.For more see
“Range Questions”onpage17.
Button ButtonFunctions ButtonOptions Buttons ButtonFunctions
ButtonOptions
Lock Doors&ArmSystemPressand Holdfor3
seconds
Activate“Panic”feature
Aux#3 Press Button #1 and #4 at
the sametime
Unlock Doors&Disarm
System Press twiceforsecond door unlock
Aux#4 Press Button #3 and #4 at
the sametime
TrunkRelease(Aux#1) Press andReleaseforAux
#1
CarJack
(See page 14) Press Button #1 and #3 at the sametime
Aux#2 Press andHoldbutton #2 &
#3 for3sec.
SilentArm/Disarm Press Button #2 and #4 at
the sametime
Start orStopengine
Pressand Holdfor3 seconds
Press andreleasetolight up the LCD screen.
Press andreleasetwicetorecallthe lastmessage fromthe LCD screen.
2-caroperation (Side Button)
Press andHoldtwoseconds
tochange fromCar1toCar
2
Press 5timestochange the Timeand DisableorEnable Beep on the remote. See page 19 fordetails.
#2DISARM
UNLOCK
LCD
SCREEN
#4ENGINE
START/STOP
#1ARM
LOCK
#3TRUNK
#5RECALL
CAR I orII
FIXED
ANTENNA
AM

4
1-WAYSIDEKICK REMOTE
1-Waysidekickremoteaddsflexibilitytoyour
CS-2014DP-TW2FM/FM.You can havethe
convenienceofoperating yoursystemwithout
needingtocarrythelargerpagerremote.The
Sidekickremotehasless range andoffersall ofthe
sameoperationfeaturesexceptfor page-back
confirmation.SeediagrambelowforSidekick1-
Wayremoteoperation.
QUICKCHART
Button ButtonFunctions ButtonOptions Buttons ButtonFunctions Buttonoptions
Lock Doors&ArmSystem
Press andHoldfor3seconds
Activate“Panic”feature
then
ActivatesAux#3 Press Button #5 then
Button #2
Unlock Doors&Disarm
System Press twiceforsecond door unlock
then
START
ActivatesAux#4 Press Button #5 then
Button #4
TrunkRelease(Aux#1) Pressand ReleaseforAux
#1
ActivatesCarJack
(See page 14) Press Button #1 and #3 at the sametime.
then
ActivatesAux#2 Pressbutton #5, Then press
&holdbutton #1 for3Sec.
START
Start orStopengine Press andHoldfor3seconds
START
Silent Arm/Disarm Press Button #4 and #2
at the sametime.
2-caroperation (Center
Button)
(Change fromCar1toCar
2)orCar2toCar1.
2nd Function Button
Press andHoldfor2seconds
WhileinCar2mode you
have3secondstopressa
functionorremotewillreturn
toCar1.
START
LOCK UNLOCK
REMOTE
#4
#3
#2
#1
2NDVEHICLE
TRUNK
(AUX#3)
(AUX#2)
(AUX#4)
STARTER #5
CRIMESTOPPER
(2ND FUNCTION)

5
ARM-LOCK
OPERATINGINSTRUCTIONS-ALARM
Active Arming/ Locking:
Press button#1 (Lock symbol)onthetransceiver. TheSystem will arm emitonesirenchirp,
onelightflash,andtheLED willbegintoflash.Power locks willlock (ifequipped). Starter
disable circuit willturn on.LCDPagerwill beep once while displaying a Locking symbol. After
ashort delay to allow thevehicleandelectronics to settle, thesystem willbe completely
armed.
Disarming:/ Unlocking
Press button#2 (Unlock symbol)onthetransceiver. System willdisarm andconfirm withtwo
sirenchirps, two lightflashes, andtheLEDwillturnoff. Power locks willunlock andInterior
Dome lightwill turnon(ifinstalled withthese optionalfeatures). LCD Pager will beep twice
while displaying anUnlock symbol.
Alarm Triggers:
If thereisanintrusioninto thevehicle, ahard impact to thebody or theignitionisturnedon,
thealarm willsoundandflash thelights for 1minute. After 1minute,thetrigger cyclewill
automaticallystop andalarm willremainarmed to continueprotectingthevehicle. If adoor is
left openafter anintrusionthentheunitwillcycleamaximumof 2minutes andcontinue to
protect the other un-tampered or unopened zones.
LCD Remote Paging/ ZoneViolations:
Whenthe system is triggered, the alarm sends a paging signalto the remote. If you are within
range, youwillreceive a violationpagingsignalthat consists of a vibrationfollowed by 5
audible beepstonotify youthe vehicle has beentampered with.
SHOCK SE
NSOR
DOORTRIGGER
IGNITIONTRIGGER
HOOD/TRUNK
TRIGGER
DISARM
-
UNLOCK

6
SILENTARM
SILENTDISARM
PANICMODE
All IconsFlash
OPERATINGINSTRUCTIONS-ALARM
Disarming WhileTripped(Triggered):
DisarmingtheSystemwhileitistriggeringrequiresTWOpressesofthe#2UnlockButton.Thefirstpressof
Button#2Resetsthealarmcycleonly(systemstill armed) whileasecond presswilldisarm/unlockthesystem.
Selective SilentArming/Disarming:
ToArmor Disarmthe systemwithoutsiren chirps,press and
releasebothButtons#2(Unlock)and #4 (Start)atthesametime.
Systemwill Armor Disarmwithoutsirenchirps.Flashinglightsand
LEDwill bethe onlyindicatorsofArm/Disarmstatus.The LCD will
Displayamusicalnotewithan“X”whenthesystemisarmedor
disarmedwithoutachirp
PriorintrusionAlert
Thissystemwill notifyyou ifthealarm wastriggeredwhileyou
whereaway.Upon disarming,therewill befour additionalsirenchirpsafterthe twonormaldisarmchirps.
Checkyourvehicleforanysignsofabreakinortampering.Also,seeLEDDiagnosticsSectiontodetermine
the causeof the trigger.
RemotePanicProtection
Tosoundthe alarminan emergencysituation or todrawattentiontoyour vehicle,press
and holdButton #1 (Lock)foratleast3secondsuntil thesiren sounds.Press Button#2
(Unlock)toresetpanicmode. TheLCDdisplaywillflashall theiconsand emit10beeps
whenthepanicmodeistriggered.
Selective Shock SensorDisable
Toarmthealarmandbypassshocksensorprotection,press Button#1 asnormalthen
pressandreleaseButton#1and#2togetherwithin2seconds.Youwill hear 3extra
siren chirpsindicating shocksensor bypass for thisarming cycleonly.Thisfeature useful
whenparkingnearrailroadtracks,airports,orareawithexcessiveloudmachineryor
noisetoprevent thenuisanceof unnecessaryfalsealarms.
OpenDoorAlert/ Bypass
Upon arming,thissystemwill warnyouifadoorisleft open.The LCD pager will vibrateand beep (15X’s)
alongwithdisplayingtheopenzoneon yourLCD screen.Thiszonewill automaticallybebypassed until
closed; otherwise, the alarmwillcontinue toprotectall other zones.

7
PRE-WARN
TRUNK POP
OPERATINGINSTRUCTIONS-ALARM
Pre-WarningShock Protection
The Pre-warning(warn-away)featurewill activatewhen alow-levelshockorvibration
detectedbythesystem’sshocksensor.Thealarmwillchirp thesiren5timesandflash
the lightsoncetohelpdeteranyfurther tamperingwiththevehicle.Thepager/remote
will vibrateandbeep(1).
Passive ArmingMode:(Programmable)
Passive(automatic)armingoccurs30 secondsaftertheignition isturned off and the last
doorisclosed.Upon closingthe lastdoor,theunitwillflashthe lightstwiceand LEDwill
be flashingrapidlytoconfirmpassivecountdown.Ifadoor isreopenedwithinthe30-
second period,the countdownstopsand beginsagainwhenthedoorisclosed.Passive
arming providesfailsafeprotection incaseyouforget toarmthesystem.
Passive Locking:(Programmable)
The CS2014DP-FM/FMsystemcanbeprogrammed topassivelylockthedoorswhenthesystempassively
arms.The defaultsettingisOFF becausepassivelocking increasestheriskoflocking the keysinthe vehicle.
When the systemarms/lockspassively,withoutyoupressingthe remote.
Trunk/HatchPop(Optional, Remote AUX.Output1)
Thisfeature isdesignedtointerfacewithexisting Factorypowertrunkor power hatch
releasesystemsandmayrequire additionalpartsand/or labor charges.Press and
releaseButton#3 (Trunk)on thetransmitter topop/openthetrunk/hatch.If thesystemis
armed, itwill alsodisarmwhen button#3ispressed(programmable).
RemoteAUX.Output2(Optional, Requires specialprogramming)
Thissystemcontainsasecond auxiliaryoutputtoactivateotheraccessoriesor devices.
ToactivatethesecondAuxiliaryOutput:Press button #2and #3on the transmitter for
more than 2seconds.Thismomentaryoutputwill stayactiveaslong asthe remote
button ishelddown. Thereisno LCD/pager confirmation forAux.2output.
DomeLightIllumination (Optional)
Thisfeaturewill turnonthe vehicle’sdomelightupondisarmingfor30secondsoruntil the keyisinsertedand
turnedon. Thiswill provide illuminated entrytoyour vehicleindimlylitareasforsafetyandsecurity.

8
VALETMODE
VALETPARK
OPERATINGINSTRUCTIONS-ALARM
EmergencyOverride(Disarm)
Ifyou havelostthetransmitter or itstopsworking for anyreason andtheAlarmisarmed,youwill haveto
disarmthe systemmanually.Open thedoorwiththekey[alarmwill sound], turn the ignitionon,and press the
override/programbutton for about5seconds.TheAlarmwill disarmand allowyoutousethe vehicleuntil you
can repair/replacethe remote. ValetmodealsopreventsPassiveArming.
ValetMode(Entermanuallyorusing theremote)
TodisableAlarmand RemoteEngine Starting for vehicleservicing or otherwise,turntheignitiononand press
the override/programbutton [about5-7seconds]until youhear (3) sirenchirpsand the LEDturnsonsolid.
Repeattheprocess toexitVALETmode.Toenter/exitvaletviatheremote,pressandholdbothbuttons#1
(Lock)and Button#2(unlock)together for about3secondsuntil 3chirpsare heard.Repeatthisstep toexit
viatheremotetransmitter.Lock/Unlock and AUXfeatureswillstill operateinwheninVALETmode however,
remotestartandalarmfunctionsareinhibited.
ValetParkMode(Using theremotetransmitteronly)
Note:Valet Parkmode isonlyaccessiblewhen usingthe remote
transmitter.Valetparkmode allowsyoutoturnover the vehicle
toavaletallowing access todrive/lock/unlockyourvehicle,but
alarmwill trigger ifthetrunkisopened.ToactivateValetPark,
pressandholdbothbuttons#1(Lock)and Button #2(unlock)
together for about3seconds.3chirpswill be heardfirstwhen
unitgoesintoregular Valet. Release,press andholdboth
buttonsagain,youwill hear2more chirps.LEDwill alwaysflash
slowlywheninValetParkeven whenthe Ignition isturned on
(or drivingvehicle). Repeatstepabovetoexit Valet Parkmode.
Optional M.A.P.(MobileAccessoriesProtection)
Thissystem canbe programmed to provide Crimestopper’s uniqueM.A.P. (MobileAccessories Protection)featurethat
allows youto preventunauthorized access of yourvehiclesAudio, Cellular, Navigation,or Entertainment systems. This
featureisOPTIONALandrequires extraparts andlabor for installation.Consultyourinstallationdealer about MAP
before or during installation.The CS2014DPTW2-FM/FM must beprogrammed for MAP operation.When thesystem
is put into Valet Park mode, M.A.P. willprevent stereo, entertainment, navigation, or cellular system from beingused.

9
REMO REMOTEENGINECONTROLTEENGINECONTROL
REMOTEENGINESTARTING -SUCCESSFULSTART
1)Press remotestartbuttonontheremotetransmitter.Systemwill chirp 3timesfor audibleconfirmation.
(Chirpscan be programmed on or off-See installationmanual.)
2)Parking lightsflashonce,then turnonsolid,Ignition/Accessorycircuitsturnon.
3)After afewseconds,StarterMotor engages, Parking lightsandAccessorycircuitsturnoffwhilecranking.
4)EngineStartsandRuns. Parking LightsandAccessoryturnbackon, DoorsLock.
5)Enginewill remainrunningfor programmed run timeuntil resetwithBrakepedal.Ifneeded,theenginecan
be turnedoffwithremotetransmitter.
6)
REMOTEENGINESTARTING -SUCCESSFULSTARTDIAGRAM:
REMOTEENGINESTARTING –LCDPAGER-REMOTE:
When requestingaremotestart the LCDpagerremotewill confirm
withanIgnition Iconalongwith3beeps. Oncethevehiclehas
successfullystartedtheremotewillconfirmbackwith1vibration,a
moving vehicleIcon,and6beeps.
REMOTESTART
(Keyflashes)
START
AFTER
IGN
3
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.

10
REMOTEENGINECONTROL
UNSUCCESSFULREMOTESTART
Inthe eventthatthe enginedoesnotstartonthe firstattempt, thesystemshutsdownforafewseconds,then
attemptstorestarttheenginea2nd and3rd time.For hard starting engines,the unitwill allowastarter crank
timeofup to13secondsmaximum.Thisshouldprovide amplecranking timefor difficultstarts,butislimited to
13 secondstohelppreventdamagetothe starterfromover cranking.
1)Ifenginestartson2nd or 3rd attempt, seesteps4&5(onlastpage) under"SuccessfulStart".
2)IfThirdattemptfailstostartengine,thesystemwill turnoff and doorswill remainlocked.NOFURTHER
ATTEMPTSWILL BE MADEAUTOMATICALLYUNLESS YOUPRESS THEREMOTESTARTBUTTON
AGAIN.
TURNING OFFYOUR REMOTESTARTEDENGINE(VIAREMOTECONTROL):
1)EngineisrunninginRemoteStart(Parking lightsON).
2)Press RemoteStartbutton onremotetransmitter.
3)Engine&parking lightsturn OFF,Doorsremainlockedorwill re-lockif applicable.
ENGINE& LIGHTSOFF
START
ENTERINGYOUR REMOTESTARTEDVEHICLE:
1)Withengine running, RemoteUnlock/Disarmsystem(If armed)oropendoorwithkey.
2)Entervehicleandbecarefulnottostep on brakepedal!(RemoteStart Reset)
3)Turn Ignition toON/RUNposition, thenpressbrakepedaltoresettheRemoteStarter &Shift outofpark.
4)Remotestarter will resetinstantlywhenthe brakeispressed.Parking lightswill turn off and theignition key
isnowcontrollingyour vehicle.
