CrimeStopper Super Rage CS-2012DPII-TW1 User manual

CS-2012DPII-TW1
Super Rage™
2-Way FM/FMPaging RemoteAlarm, KeylessEntrySystem &EngineStarting
System with1-WaySidekick RemoteControl
OPERATINGINSTRUCTIONS
CONGRATULATIONS onyourchoiceofaCS-2012DP-TW1Super Rage™Alarm&RemoteEngineStarter
byCrimestopper SecurityProductsInc. Thisbookletcontainstheinformation necessaryforoperatingyour
system. If anyquestionsarise, contactyourinstallation dealerorCrimestopper SecurityProductsInc.
*IMPORTANTINFORMATION:PrimaryandOptionalFeatures
-PRIMARY: Thesearefeaturesthatmustbe connectedinorder forthesystem tooperateproperlyi.e.Power,
Ground,FlashingLights,Siren,LED,etc.
-OPTIONAL: Optionalfeaturesare connectedonlyifdesired oragreed uponbythe installing dealer i.e.Door
Locks,HornHonk,Dome lightillumination,TrunkPop,etc.Thesefeaturesmayrequireadditionalpartsand
laborcharges. Consultwithyourinstaller about thesefeatures before installation.
CONTACTINFORMATION:
TECHNICAL SUPPORT(800)-998-6880
Monday- Friday8:00am- 4:30pmPacific
Website: www.crimestopper.com
E-mail: [e-mail]
CRIMESTOPPER
SECURITYPRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA.93063 REV. 06.30.2007
ThisdevicecomplieswithFCC Rulespart15.Operation issubject
tothe followingtwoconditions:1)Thisdevicemaynotcause
interference,and (2)thisdevicemustacceptanyinterferencethat
maybe received,including interferencethatmaycauseundesired
operation.The manufacturerisnotresponsibleforanyradioorTV
interferencecausedbyunauthorized modification tothis
equipment. Suchmodification couldvoidtheuser'sauthorityto
operatethe equipment.

2
TABLEOF CONTENTS
Operation Cautions&Warnings……..………..………………………………………………………….….………2
2-WayLEDPaging Remote………………………………………………………….………..….……….…..……..3
1-Way“SideKick”Non-PagingRemote……………….………..………………………………….……..…..……..4
PagingTones&LEDs……….………………………………………….………..…………………..….….…..…….5
.
Operating Instructions-Alarm……………………………………………………….………..……………..……..6-9
LEDDiagnostics………………..…………………………………………………………………….………..…..…...9
RemoteEngine Control………………………...…………………………………………………….………...…..9-13
OptionalTurboTimer Mode……………………...…………………………………………………………..…..….14
Anti-CarjackProtection...……………………………………….………….……..…………...…………..……...…15
TransmitterProgramming……………………………….……………………………………………..………….…16
PagerRemoteBatteryReplacement……………………………………………….………….……………...……17
Troubleshooting:“Beforeyou call section”………………………………………………..……………………..18-19
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from
the use of thisequipment. Thissystemisdesigned to be professionally installed intoacar or vehicle ingood running
order. Items, such as parking brake, door switches,and all engine safety features, must be inperfect working
condition.
DAMAGE resulting from misuse or negligence is NOT covered under warranty and will be subject to repairand/
or replacement charges.
IT IS ABSOLUTELY THEOWNER’S SOLE RESPONSIBILITY TO: A) Understand the operation of this systemand its
safety features. B) Check for proper operation of these safety features prior to acceptingdelivery of the vehicle from
the installation facility. C) Check and maintainthe condition of the vehicle and all itemsrelative to the proper operation
of thissystemand its safety features.
DO NOT remotestart thevehicle inaclosed garage. Make sure that the vehicle is outdoors,agaragedoor is
open, or there isadequate exhaust ventilation. Failure to observethisrule couldresult in injury or death from
poisonous Carbon Monoxidefumes. Thisis especially important when using the Timed Self-Start feature of the unit

3
2
-
WAYLEDPAGINGREMOTE
PAGER/ REMOTETRANSCEIVER:
The hand-heldremotetransceiverisused tosend and receiveinformation from
the vehicle. TheControlModuletransmitsconfirmation signalsfromthe vehicleto
yourpager.Yourrangewill varydependingon location,terrain,andlocalRF
noise/interference.Thissystemisnotguaranteed topage you ifyou arebehind
concretewalls,underground,inalarge structure,orinan area withhigh levelsof
electronicinterference.Handlethe pager/remotewithcare.Formoreon range,
see “RangeQuestions”onpage 18.
OPERATION:
Button Functions ButtonOptions Buttons Functions
ButtonOptions
Lock Doors&ArmSystemPress and Holdfor3
seconds
Activate“Panic”feature
Aux#3 Press Button #1 and #4 at the
sametime
Unlock Doors&Disarm
System Press twiceforsecond door unlock
Aux#4 Press Button #3 and #4 at the
sametime.
TrunkRelease(Aux#1) Press andReleaseforAux
#1
CarJack
(See page 14) Press andHoldButton#1 and #3 at the sametimefor2seconds.
Aux#2 Press andHoldButton #2
and #3 at the sametimefor
3seconds. (Aux#2)
Silent
Arm/Disarm Press Button #2 and #4 at the
sametime.
Start orStopengine Press and Holdfor3
seconds
SensorDisable
Valetmode Press within3secondsof armingtodisable
sensorinput
WhenDisarmed Press andHold for3
secondstogointoValetmode. Release,
press andholdagainfor3sec. toenter
Valet Park.
Press andholdfor5secondstoswitchtovehicle#2.
SideButton
2-caroperation (Side Button)
(Change fromCar1toCar
2)
Press andreleasetoshowthe previousstatus.
UNLOCK
LOCK
STARTTRUNK
#1 #2
#3 ENGINE
POP
VEHICLE
2nd
#5
#4

4
1-WAYSIDEKICK REMOTE
1-Waysidekickremoteaddsflexibilitytoyour
CS-2012DP-TW1.You can havetheconvenience
ofoperatingyoursystemwithoutneeding tocarry
the larger pager remote.The Sidekickremotehas
less rangeand offersall ofthesameoperation
featuresexceptforpage-backconfirmation.See
diagrambelowforSidekick1-Wayremote
operation.
QUICKCHART
Button ButtonFunctions ButtonOptions Buttons ButtonFunctions Buttonoptions
Lock Doors&ArmSystem
Press andHoldfor3seconds
Activate“Panic”feature
then
ActivatesAux#3 Press Button #5 then
Button #2
Unlock Doors&Disarm
System Press twiceforsecond door unlock
then
START
ActivatesAux#4 Press Button #5 then
Button #4
TrunkRelease(Aux#1) Pressand ReleaseforAux
#1
ActivatesCarJack
(See page 14) Press andholdButton #1 and #3 at the sametime
for2seconds.
then
ActivatesAux#2 Press button #5, then press &
holdbutton #1 for3Sec.
START
Start orStopengine Press andHoldfor3seconds
START
Silent Arm/Disarm Press Button #2 and #4
at the sametime.
2-caroperation (Center
Button)
(Change fromCar1toCar
2)orCar2toCar1.
2nd Function Button
Press andHoldfor2seconds
WhileinCar2mode you
have5secondstopressa
functionorremotewillreturn
toCar1.
START
LOCK UNLOCK
REMOTE
#4
#3
#2
#1
2ND VEHICLE
TRUNK
(AUX#3)
(AUX#2)
(AUX#4)
STARTER #5
CRIMESTOPPER
(2ND FUNCTION)

5
PAGINGTONES &LEDs
CS-2012TW1PAGINGLEDs
Orange/GreenLED:RedLED:
BlueLED:
YellowLED: DoorTrigger
Shock sensor,
Trunkpop RemoteStart,
Ignition Lock/Unlock,
Hood/Trunk
PAGE-BACK:
FEATURE BUTTON ACTION BEEPS LEDCOLOR&FLASH
LOCK #1 (Lock) Press &Release 1X, then 1X Orange-1X
UNLOCK #2 (Unlock) Press &Release 1X, then 2XGreen -2X
AUX#1 #3 (Trunk) Press &Release 1X, then 3fast Yellow–1X
AUX#2 #2&3Press &Hold 1X NO PAGEBACK
AUX#3 #1&4 Press &Release 1X NO PAGEBACK
AUX#4 #3&4 Press &Release 1X NO PAGEBACK
PANIC #1 (Lock) Press andHoldfor
at least3seconds 1X, 2X,12X Orange12X-Green1X
REMOTESTART
REQUEST #4 (Start) Press &Holdbutton for at least1second 1X, 3X Blue -3X
ENGINERUNNING
CONFIRMATION 6X Blue -6X
TURN OFFENGINE
(Fromremote) #4 (Start) Press &Release NoBeep NoPage Back
DOORVIOLATION 1Long/ 1short Red –Flashing
HOOD/TRUNK
VIOLATION 5Long Green -5X
SHOCKVIOLATION
1Long/ 2Short Yellow-Flashing
PRE-WARN 1X Yellow–1X
IGNITION
VIOLATION 1Long/ 3Short Blue -Flashing

6
OPERATINGINSTRUCTIONS-ALARM
Active Arming/ Locking:
Press and releasebutton #1(Locksymbol)onthetransmitter.The systemwillarmand confirmwithonesiren
chirp, one lightflash,andtheLEDwill begintoflash. Powerlockswill lock(if equipped).Starterdisablecircuit
will turnon. Afterashortdelaytoallowthe vehicleandelectronicstosettle,thesystemiscompletelyarmed.
Disarming:/ Unlocking
Press andreleasebutton#2(Unlocksymbol)on thetransmitter.Systemwill disarmandconfirmwithtwo
siren chirps,twolightflashes,andtheLEDwill turnoff. Powerlockswill Unlockand Interior Domelightwill
turnon(ifinstalledwiththeseoptionalfeatures)
Disarming WhileTripped(Triggered):
DisarmingtheSystemwhileitistriggeringrequiresTWOpressesofthe#2UnlockButton.Thefirstpressof
Button#2Resetsthealarmcycleonly(systemstill armed) whileasecond presswilldisarm/unlockthesystem.
SilentArming/Disarming(Ondemand):
ToArmor Disarmthe systemwithoutsiren chirps,pressandreleasebothButtons#2(Unlock)and #4(Start)
atthesametime.Systemwill ArmorDisarmwithoutsirenchirpsthatone time.Flashing lightsandLEDwill
be theonlyindicatorsofArm/Disarmstatus.Ifthe systemwastrippedwhileyouwere away,4chirpswill be
heard tonotifyyouthatthesystemwastripped.
SilentArming/Disarming(ChirpDefeat):
Thissystemcanbeprogrammed tosilentarmanddisarmusingthenormallockand unlockbuttons.Flashing
lightsand LEDwillbetheonlyindicatorsofarmedordisarmstatus.Checkwithyourinstallerorfollow
programming optioninstructionsintheinstallationmanual.
RemotePanicProtection
Tosoundthealarminanemergencysituationortodrawattention toyourvehicle,pressand holdButton#1
(Lock)forat least 3secondsuntil the sirensounds. Press Button #2 (Unlock)toresetpanicmode.
Driver’sPriority/ SplitUnlock (Optional)
When usingtheoptionalseparatedriver’sandpassengerunlockfunction,pressandreleasebutton#2
(Unlocksymbol)onthetransmitter tounlockdriver’sdoor only,thenpressthe #2buttonagainwithin2-4
secondstounlockremaining doors.Thisfeatureisoptionaland requiresadditionalpartsand/orlabor.
Arming WithShockSensorBypass
Toarmthe alarmandbypassshocksensor protection,pressButton #1asnormalthen press andrelease
Button#1 and#2 together within2seconds.You will hear3extrasirenchirpsindicating shocksensor bypass
for thisarmingcycleonly.

7
OPERATINGINSTRUCTIONS-ALARM
Alarm Triggering
Anintrusionintothevehicleorhardimpacttothebodywill soundthealarm andflashthelightsfor20Sec.
After 20 Sec.the triggercyclewill automaticallystopand alarmwillremainarmed tocontinueprotecting the
vehicle.Ifadoorisleftopenafteranintrusionthentheunit will cycleamaximumof2minutesandcontinueto
protecttheotherun-tamperedorunopenedzones.
PriorintrusionAlert
Thissystemwill notifyyouifthealarmwastrippedwhileyou whereaway.Upondisarming,thetwonormal
disarmchirpswill beheardthenthesystemwill emit4additionalsirenchirps.Checkyourvehicleforany
signsofabreakinortampering.Alsosee LEDDiagnosticsSection todetermine the causeof the trigger.
OpenZoneAlert/ Bypass
Upon arming,thissystemwill warn youifadoorisleft open.After a60 second setupdelay(for extended
domelights)haselapsed,ifthe system detectsafaultoradoor left open,the sirenwill chirp5timesalong
with5light flashes. Thiszone will beautomaticallybypassedandthealarmwill protectall other zones.
Pre-WarningShock Protection
The Pre-warning(warn-away)featurewill activatewhen alow-levelshock or vibration detectedbythe
system’sshocksensor.The alarmwill chirp the siren 5timesandflashthelightsoncetohelpdeterany
furthertampering withthevehicle.
Passive ArmingMode:(Programmable)
Passive(automatic)arming occurs30 secondsafter the ignition isturnedoff and the lastdoor isclosed.Upon
closingthe lastdoor,theunitwill flashthe lightstwiceand LEDwill be flashing rapidlytoconfirmpassive
countdown.If adoor isreopenedwithinthe30secondperiod,the countdownstop andbeginagainwhenthe
doorisclosed. Passivearming providesfailsafeprotectionincaseyouforgettoarmthesystem.
Passive Locking:(Programmable)
The CS-2012DP-TW1systemcanbe programmedtopassivelylockthedoorswhenthesystempassively
arms. Thedefault setting isOFF becausepassivelocking increasestheriskof lockingthekeysinthevehicle.
Trunk/HatchPop(Optional, Remote AUX.Output1)
Thisfeatureisdesigned tointerfacewithexisting Factorypower trunkor power hatchreleasesystemsand
mayrequire additionalpartsand/or labor charges. Press andreleaseButton #3 (Trunk)on thetransmitter to
pop/open thetrunk/hatch. Ifthesystem isarmed, itwill alsodisarmwhen the button#3ispressed.

8
OPERATINGINSTRUCTIONS-ALARM
Remote AUX. Output 2 (Optional)
Thissystem containsasecondauxiliary output to activate other accessories or devices. To activate Output2,press
andholdButton2&3. Thisisamomentary outputthat will stay active as longastheremote buttonishelddown.
Remote output#2 requires programmingbefore operation.Check withyourinstaller or follow programmingoption
instructions inthe installationmanual.
Remote AUX. Output 3 and 4 (Optional)
Thissystem containsa3rd &4th auxiliary outputto activate other acc or devices. To activate Output3press button1&4
andrelease for Output 4 press andrelease button3&4. These outputscanbe program for Momentary, Latchor Timed.
Check withyour installer or follow programming optioninstructions intheinstallationmanual.
DomeLight Illumination (Optional)
Thisfeature willturnonthevehicle’s domelightupondisarmingfor 30 seconds or until thekey isinserted andturned
on. This willprovide illuminated entry to your vehicleindimly lit areas for safety andsecurity.
EmergencyOverride (Disarm)
If youhave lost thetransmitter or itstops workingfor anyreasonandtheAlarm isarmed, youwillhave to disarm the
system manually. Openthe door withthekey [alarm willsound], turntheignitionon,and press the override/program
buttonfor about 5seconds. TheAlarm willdisarm andallow youto use the vehicleuntil youcanrepair/replace the
remote. Note youhave to putthe system into valet mode to prevent passive arming.
Valet Mode (Enter manuallyor using the remote)
To disableAlarm andRemote EngineStartingfor vehicleservicingor otherwise, turntheignitiononand press the
override/program button[about 5-7 seconds] until youhear (3) sirenchirps andthe LED turnsonsolid. Repeat the
process toexit VALET mode. To enter/ exit valet via theremote,press andhold both buttons#1 (Lock) andButton #2
(unlock) together forabout3seconds until3chirps are heard. Repeatthisstep toexitviatheremote transmitter.
Lock/Unlock andAUXfeatures willstilloperate wheninVALET mode howeverremote start andalarm functionsare
inhibited.
Valet Park Mode (Using the remote transmitter only)
Note: Valet Park mode is only accessiblewhenusing the remote transmitter. Valet park mode allows youto turnover
the vehicle to a valet allowing access to drive/lock/unlock your vehicle, but alarm willtrigger if the trunk is opened. To
activate Valet Park, press and hold bothbuttons #1 (Lock) and Button#2 (unlock) together for about3 seconds. 3
chirps willbe heard first whenunit goes into regular Valet. Release, press andhold bothbuttons againyouwillhear 2
more chirps. LED willflashslowly whenin Valet Park. Repeat step to exit Valet Park mode.

9
OPERATINGINSTRUCTIONS-ALARM
Optional M.A.P.(MobileAccessoriesProtection)
Thissystemcan beprogrammed toprovideCrimestopper’sunique M.A.P.(MobileAccessoriesProtection)
featurethatallowsyoutopreventunauthorizedaccess ofyour vehiclesAudio,Cellular,Navigation,or
Entertainmentsystems.ThisfeatureisOPTIONALandwill requiresextrapartsand labor for installation.
Consultyour installationdealeraboutMAP before or during installation.The CS2012TW1mustbe
programmed for MAP operation.When the systemisputintoValetParkmode,M.A.P.will preventstereo,
entertainment, navigation,or cellularsystemfrombeing used.BasicM.A.P.wiring information isprovided in
the installationmanual.
LEDDIAGNOSTICS
The CS-2012DP-TW1systemincludesdisarmdiagnostics,throughtheREDLEDlight,thatwill helpin
determiningwhatcausedthe lasttrigger ofthe alarmsystem.Thisisavaluabletoolindetermininghowthe
vehiclewastampered withor ifthereisafalsealarmprobleminwhichcaseyou can makethe necessary
adjustmentstocorrecttheproblem.Whenthesystemisdisarmedwiththeremoteyou will hearthenormal2
chirps,then 4quickchirpsthatindicatethe alarmwastriggeredwhileyouwereaway.Checkthe LEDlightfor
asequenceofflashes:
ShockSensor =1Flash Door=2FlashesHood/Trunk=3Flashes Ignition =4Flashes
Diagnosticswill resetwhen theIgnitionisturnedonorwhenthesystemisre-armed.
REMOTEENGINECONTROL
REMOTEENGINESTARTING -SUCCESSFULSTART
1)Press and releasethe remotestartbuttonforatleast1second.Systemwill chirp 3timesforaudible
confirmation. (Chirpscanbeprogrammed onoroff-SeeOptionprogrammingintheinstallationmanual.)
2)Parking lightsflashonce,then turnonsolid,Ignition/Accessorycircuitsturnon.
3)After 6secondsStarterMotorengages,Parking lightsandAccessorycircuitsturnoff whilecranking.
4)EngineStartsandRuns. Parking LightsandAccessoryturnbackon, DoorsLock.
5)Enginewill remainrunningfor programmed run timeuntil resetwithBrakepedal.Ifneeded,theenginecan
be turnedoffwithremotetransmitter.

10
REMOTEENGINECONTROL
REMOTEENGINESTARTING -SUCCESSFULSTARTDIAGRAM:
REMOTEENGINESTARTING -UNSUCCESSFULSTART
Inthe eventthatthe enginedoesnotstartonthe firstattempt, thesystemshutsdownforafewseconds,then
attemptstorestarttheenginea2nd and3rd time.For hard starting engines,the unitwill allowastarter crank
timeofup to10secondsmaximum.Thisshouldprovide amplecranking timefor difficultstarts,butislimited to
10 secondstohelppreventdamagetothe starterfromover cranking.
1)Ifenginestartson2nd or 3rd attempt, seesteps4&5(last page) of "SuccessfulStart".
2)IfThirdattemptfailstostartengine,thesystemwill turnoff and doorswill remainlocked.NOFURTHER
ATTEMPTSWILLBE MADEAUTOMATICALLYUNLESS YOUPRESS THESTARTBUTTONAGAIN.
TURNING OFFAREMOTESTARTEDENGINE:
1)EngineisrunninginRemoteStart(Parking lightsON).
2)Press andreleasetheStart button forat least 1second.
3)Engine&parking lightsturn OFF,Doorsremainlockedorwill re-lockif applicable.
TURNING OFFAREMOTESTARTEDENGINEDIAGRAM:
ENGINE&LIGHTSOFF
START
AFTER
IGN
3
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.
START

11
REMOTEENGINECONTROL
ENTERINGYOUR REMOTESTARTEDVEHICLE:
1)Withengine running, RemoteUnlock/Disarmsystem(If armed)oropendoorwithkey.
2)Entervehicleandbecarefulnottostep on brakepedal!(RemoteStart Reset)
3)Turn Ignition toON/RUNposition, thenpressbrakepedaltoresettheRemoteStarter &Shift outofpark.
4)Remotestarter will resetinstantlywhenthe brakeispressed.Parking lightswill turn off and theignition key
isnowcontrollingyour vehicle.
IDLEDOWNMODE(TAKE-OVEROPERATION)
Thismode allowsthe unittotakeover operationofyour idling,parked vehiclewhiletheignition keyis
removedandyouexitthe vehicle. Thevehicleisputintoaremoterunningconditionbeforeyouexitanditwill
remainrunningfor the programmed run time,until you return,or until theremotestartbutton ispressed.
Examples:
You pull up toaconveniencestoreforacoffee,"IdleDown" mode keepsengine running when you exitthe vehicle,(withkeys in
hand)remotelock/arm alarm.Whenyou return, unlock/disarm alarm, turnignition ONand driveaway.
IDLEDOWNMODE-EXITINGTHEVEHICLE:
1)Withengine running,press andreleasethe Start button.Sirenwill chirp3timesforconfirmation.
2)Parking Lightswill turnON.
3)Doorswill unlock, orifbrakepedalisbeing depressedthendoorswill unlockwhenit isreleased.
4)Turn OFFIgnition andremovekey.Engine shouldremainrunning.
5)Exitvehiclethenremotelockdoorsif desired.
6)Enginewill remainrunning forprogrammed run time, until youreturn, orpressthe remotestartbutton.
IGN
SOLID
OFF
UNLOCK
START
ENTERING AVEHICLEDURING “IDLE-DOWN”or“INFINITYRUN”MODES:
See “ENTERINGYOURREMOTESTARTEDVEHICLE”section above.

12
REMOTEENGINECONTROL
INFINITYRUNMODE
Thismode allowsthevehicle’sengine toremainrunning INDEFINITELY. Thismode canbebeneficialtolaw
enforcementvehiclesor commercialvehiclesthat needtoremainrunningunattendedforlong periodsoftime.
INFINITYRUNMODE–EXITINGTHEVEHICLE:
1)Followstepson thelastpage for“IDLEDOWNMODE-EXITINGTHEVEHICLE”,exceptpress the remote
startbuttonTWO timesat STEP #1.
2)Parking Lightswill startflashinginsteadof coming on solid, and doorswillunlock.
3)Turn Ignition switchOFF,removekeyand exit the vehicle. Engineshouldremainrunning.
4)The vehicle’sparkinglightswillflashforthe programmed runtime of12,24,or36,or48minutesand then
switchtosolidwhilemotorrunsindefinitelyoruntil fuelsupplyrunsout.
IGN
OFF
2X
FLASHFORPROGRAMMED
RUN TIME,THENSOLID
START
ENTERING AVEHICLEDURING “IDLE-DOWN”or“INFINITYRUN”MODES:
See “ENTERINGYOURREMOTESTARTEDVEHICLE”section at top ofpage 11.

13
REMOTEENGINECONTROL
TIMEDSELFSTARTMODE
Thismodeallowsthevehicletobeprogrammed toself-startevery4hoursandrun forthe programmedrun
time.Thiscan behelpfulduringextremelycoldconditionswhereenginefluidfreeze-up isaconcern.THE
VEHICLEMUSTBE OUTDOORSORINAWELL VENILATEDAREA.
TIMEDSELF-STARTMODE–EXITING THEVEHICLE:
1)Haveenginerunning withtheKey,thenpress andreleasethe Startbutton.
2)Withinthenext 10secondspress thevalet/programbuttononce.
3)Parking Lightswill turnOFFforabout 5seconds, and doorswill unlock.
4)Turn Ignition switchOFF,removekeyand exit the vehicle. Engineshouldremainrunning.
5)Toturn offtheengine,pressthe remotestartbutton.Theparkinglightswill flash4TIMES asa
confirmationthattheunit isinTimed Self-StartMode.
6)The Vehiclewill Start byitselfevery4hoursuntil drivenwithkeyorstarted viaremotecontrol.
IGN
SOLID
OFF
UNLOCK
PRESS 1X
WITHIN10SEC.
LIGHTSOFF5SEC.
FLASH 4X
LOCK
START
START
RESETTINGTIMEDSELFSTARTMODE
Toreset the timed self-start mode,startthe vehicleusingthe keyor the remotecontrol

14
OPTIONAL TURBOTIMERMODE
OPTIONALTURBOTIMERMODE:
IMPORTANTNOTE:Thismoderequires theuse ofanextrapartcalledamomentaryswitchorbutton
thatisnotincludedwiththekit.Check withyourinstalleraboutaddingthisfeature.Theoptional
Turbo Timermodeallowstheyoursystemtokeepyourvehiclerunningfor1to5minutes[selectively]
afteryou removethekey,exitthevehicle,and lock thedoorsremotely[ifyouownaTurboorTurbo
Diesel]. ThisishandyforturbocooldownwithouttheneedforexpensiveTurboTimers.
1)Engineshouldberunningwiththekey.Press andholdthebrakepedal.
2)Press your“TurboTimer”button1to5timesforeachminuteofruntimeyoudesire. (1press=1min.)
3)Releasethebrakepedaland your systemwill confirmbyflashing thelightsthesamenumber oftimesthe
button waspressed.
4)Turn IgnitionswitchOFF,removekeyand exitthevehicle.Remotelockyourdoorsfor safety.The engine
shouldremainrunning fortheselected numberof minutes.
CAUTION!!IFYOUPRESS THETURBO TIMERBUTTONWHENENGINEISNOTRUNNING ITWILL
TRIGGERAREMOTESTART!MAKEANOTEOFTHISIFYOUHAVE CHILDREN.CONSIDERTHIS
WHENCHOOSING ALOCATIONFORYOUR TURBOTIMERBUTTON.
REMOVEKEY
PRESSTURBO
FLASH1-5X
EXIT VEH.
PRESS
ANDHOLD
BRAKE
TIMERBUTTON
1-5TIMES
RUNNING RELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5MIN.

15
ANTI CARJACK PROTECTION
REMOTEOPERATEDCARJACK PROTECTION
Thisfeature providesActiveCarjackprotection throughtheremotecontrol.When the Ignitionison (vehicleis
running),pressandholdthe #1LOCKButtonand#3TRUNKButtonfor3seconds.Theparkinglightswill
flash2timesand the LEDwill begintoflashrapidlytoconfirmthe beginningofaCarjackcountdown.30
Secondslater,theunitwill beginaCarjackCycleconsistingof 20secondsofpre-warning chirpsturningintoa
full systemactivationwithsiren/flashing lightpulsesforup to5min.IftheIgnitionisturned off during a
Carjacktrigger thesiren and lightsstop butCarjackprotectionisstill active.The Siren and Lightswill resume
ifthe Carjacker triestoturn the Ignition backON.TORESET:Press Button #2(UNLOCK)ontheremoteand
the sirenwill chirponce,orturn thekeyon andpressandholdtheoverridebutton forat least 5seconds.
SWITCH-CONTROLLED&FULLTIMECARJACK (PINK WIRECONFIGURATION)
ThisfeaturecanprovidePassiveorManualcontrolCarjackprotection depending on the configuration ofthe
PinkCarjackwireofthealarmsystem.The systemmustbe programmed forthe Pinkwire tobeusedasa
Carjacktrigger atProgrammingOption#20intheInstallationManual.Oncethe Pinkwireisprogrammed to
serveasaCarjacktrigger,itcan beconfiguredindifferentwaystoprovide differentlevelsofprotection.It can
be connectedtoahidden+12Vtoggle/momentaryswitchorto+12VIgnition Power.See installationmanual.
Readthesectionsbelowforfurtherdescriptions.
HIDDENSWITCH CONTROLLEDCARJACK:
Thisconfigurationwill enablethe vehicleowner toactivateaCarjackcountdownbypressing ahidden
push-button (notincludedwithkit)during aCarjacksituation.ACarjackcountdownwill beginunder the
following conditions:Ignition isON(vehicleisrunning),the push-buttonispressed,and the door
opens/closes. Uponthese3events, inthatorder,thealarmwill start aCarjackcountdown. Afteradelayof
one minute,the systemwill beginchirping for20 secondsthentriggerintoafull cycleforup to5minutes.
ToresetthisCarjackmode,Ignition mustbe ONthenpress andholdtheoverride/valetbuttonfor 5
seconds(until LEDgoesout.)
FULL-TIME[Permanent] CARJACKWITHIGNITIONON:
Werecommend thatthisconfigurationonlybe usedinserioussituations.When theIgnition ison (vehicle
isrunning),anytime adoorisopenedtheCarjackcountdownsequencewill be initiated.Therewillbe2
lightflashesand the LEDwill change fromsolidtoquickpulsing asconfirmation ofacountdownsequence.
ToresetFULLTIMECarjack,the Ignition hastobe ON,thenpress andholdthe override/programbutton 5
secondsuntil LEDstopspulsing.The LEDwill beon SOLIDwheninthismode anytimethe Ignition isON
(or whiledriving)asareminderthat Carjackiswaiting foradoor toopen.

16
TRANSMITTERPROGRAMMING
Note:RemotesTransmitterscomepre-programmedfromtheFactory.Whenre-learningremotesor
adding remotes,ALL yoursystem’sremotecodes must belearnedat timeofprogramming!! This
systemallowsstorageofupto4differentremotecodes inmemory.
1.Turn keytothe ONposition.(Startingthe vehicleisnotnecessary.)
2.Press Program/Valetbutton4times. After afewseconds, theunitwill flashtheparking lights4times.
3.Press Button #1(Lock)&#2 (Unlock)button[at thesame time]ofthetransmitter tobe learned.Youshould
get2lightflashesindicating thecode-learn.Press theLockandUnlockButtonson asecond,thirdor
fourthremote.If all 4codesarelearned,theunitwill automaticallyexitcode learningmode,otherwiseturn
keyOFFand closethehood.
NOTES:When learning pager remotes,waitfor abeepconfirmation tone fromthe remotebeforelearning
anotherremote.When learning1-way“Sidekick”remotes,youdonothavetowait.Thesystemwillnotflash
the lightsafterlearning the4thremotecode.
IGN
OFF
WAITFOR
4FLASHES
PRESS 4X's
FLASH2, 3, or4X's
2-WAYREMOTES
IGN
OFF
PRESSTOGETHER
LOCK &
UNLOCK
"SideKick"REMOTES
COMPLETE
OR
PRESS TOGETHER
LOCK &
UNLOCK

17
PAGERREMOTEBATTERYREPLACEMENT
CS-2012DP-TW1PAGER(LOWBATTERYWARNING)
The CS-2012DP-TW1Pager LEDhasalowbatterywarningsystem.
When the batteryvoltageislow,theOrange&GreenLEDsflash6
timeswithanybuttonthatispressed.Werecommend replacingthe
batteryforproperoperation.Toreplacethebattery,simplyunlock
and slide openthe batterydooronthe backoftheLEDremote.
Carefullyremovethelowbattery,theninsertanewbattery(AAA)
using the outline on thebutton ofthebatterycompartmentasaguide.
Your remotewill beep 3timeswhenthebatteryisinsertedcorrectly.
NOTE:
Carefullyinsertthe newbattery.If donecorrectlythe remotewill beep
3Xwhenthe newbatteryinstalled.Ifthe remotedoesnotbeep or
respondafterreplacingthebattery,removethebatteryandre-insert.
FLASH6X
ORANGE
AND
GREEN

18
TROUBLESHOOTING:“BEFOREYOUCALL SECTION”
Beforecallingyour dealerorCrimestopper, readthefollowingfor tipsthat mayremedytheproblem.
RANGEQUESTIONS(2-WayPager/Remote):
Your CS-2012DP-TW1systemusesAm&FMHigh-Frequencysignalstosend/receivedatabetweenthe
pager andthe vehicleand fromthevehicletotheremoteforstate-of-the-artoperation.
1)Undernormaloperation,the distancefromthe vehicle-paging-the-remotewill be greaterthan thatfromthe
remote-to-the-vehicle.Thisisduetopowersupplies.Themaincontrolmodule(brain)inthe vehicleis
connected tothe electricalwiringreceiving powerfromthevehiclebattery,whereastheremote/pageris
operating froma1.5vAAA battery. Thisisanormalfeaturefora2-Waypagingsystem.
2)Your systemisdesignedtoalwaysoperatewithmaximumefficiency,however range maybeaffectedby
the followingcircumstances:PhysicalDistance,Obstructions,and RF/ElectronicInterference.(On
US/Domesticsystems, poweroutput islimited byGovt. FCC Regulations/Specifications.)
3)ThisCS-2012DP-TW1systemdoesNOTuse“Paging”or“Cellular” antenna service.There arenomonthly
feesassociatedwithitsoperation.TheCS-2012DP-TW1unitinthevehiclesendsapagingsignaldirectly
toyourpager/remotefromitsownantennamountedinside thevehicle.
SYSTEMISUNSUCCESSFULATREMOTESTARTDURINGEXTREMECOLDCONDITIONS:
Pleasebe aware thatduringsub-freezing conditionsyour remotestarter maytakemore thatone attemptto
start,or itmaynotsuccessfullystartthevehicleafter 3attempts.During theseconditionsthevehiclemaynot
properlystarteven usingthe key,thereforetryingtostart bytheremotewouldalsobe unsuccessful.
SYSTEMLEDFLICKERSWHENPRESSING REMOTECONTROLBUTTONS:
Thisisnormaloperation.Theremaybeaslightflicker visiblefromthe LEDwhen pressing the remoteasthe
systemisauthorizingthecodefromthe remotecontrol.There isnothingwrongwithyour system.
UNITCHIRPS 3X,FLASHES LIGHTSONCE, BUTWILLNOTATTEMPTAREMOTESTART:
1.The systemmaysenseafaultifthe vehiclehoodisup or open(Bluewire grounded).[Assumingyouare
usingagroundinghooppinor switchthatisconnected totheBluewireofthe system.Thisisasafety
featureoftheunit. Makesurehoodisclosedorthat theBlue hood pinwireisnot shortedtoGround.
2.The systemmaysenseafaultattheBrake(Whitewire isactive)checkinstallation for faultsandverifythe
+12VBrakeinput isnot activeunless thebrakeispressed.

19
TROUBLESHOOTINGcont.
UNITFLASHES THELIGHTSONCEAND WILLNOTATTEMPTAREMOTESTART:
The systemisinValetmode.Checkthe systemsLEDlightandifitison solidRed LED(withdoorsclosed)
thenthe systemisinVALETmode.ToexitVALET,turntheIgnition on,press andholdvalet/programming
button for about5secondsuntil LEDgoesout. Unitisnowoutofvaletmode and shouldperformaremote
start.
SYSTEMDOES NOTRESPOND TOTHEREMOTECONTROL:
1.Checkforproperpower/ground wiringconnectionsof the alarm.
2.CheckAntennaModuleconnection.The antennaincludedwiththissystemmustbepluggedinto
send/receivesignalsasthe AntennaModulegetsvoltagefromthemaincontrolmodule.Seeantenna
diagramsection inInstallationManual.NOTEthe color ofthe antennaharness connectorsmustmatch
withthe colorsof thesocketsi.e. Blueplug intotheBluesocket and Blackplugintothe Blacksocket.
3.The Remotemayneed anewbatteryorneedtobereprogrammed tooperatethesystem.See
“Transmitterprogramming”formoreinformation.

20
www.crimestopper.com
[e-mail]
Phone [phone]
FAX[phone]
©2007 CrimestopperSecurityProducts
ONLINETECHNICALSUPPORT
www.crimestopper.com
