CrimeStopper Gargoyle CS-2001FC II Series Manual

CS-2001FC
REMOTE CONTROL ALARM SYSTEM
INSTALLATION & OPERATING INSTRUCTIONS
INTRODUCTION
CONGRATULATIONS on your choice of a Gargoyle™ Remote Alarm System by Crimestopper Security
Products Inc. This booklet contains the information necessary for installing, using, and maintaining your alarm
system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the
Tech Support number below.
*IMPORTANT INFORMATION: Primary and Optional Features:
-PRIMARY: These are features that must be connected in order for the system to operate properly; i.e. the
Siren, L.E.D., +12V Power, Ground, Doorpin, Override/Program/Valet Button etc.
-OPTIONAL: These are features to be connected if desired or agreed upon by the installing dealer. These
features may also require additional parts and/or labor fees. Consult with your installer beforehand; i.e. Door
Locks, Flashing Lights, Starter disable, Hood/Trunk trigger, and Auxiliary Remote Outputs etc.
TECH SUPPORT
Mon-Fri 8:00 AM-4:30 PM Pacific Time
[phone]
This device complies with FCC Rules part 15. Operation is subject to the following
two conditions: 1) This device may not cause interference, and (2) this device
must accept any interference that may be received, including interference that may
cause undesired operation. The manufacturer is not responsible for any radio or
TV interference caused by unauthorized modification to this equipment. Such
modification could void the user's authority to operate the equipment.

TABLE OF CONTENTS
Installation Cautions & Warnings…….………………………………………………………………………………2
Control Module Mounting………….……………………………………………..……………………….…………..3
Component Mounting………….…………………………………………………………….…………………..……..3
Wiring……..……………………………………………………………………………………………………….…….4-5
Power Door Lock Wiring...……………………………………………………….………..…………………………5-7
Transmitter Programming………………………………………………………………………………………………8
Option Programming…………………………………………….……………………………….………………….9-11
Custom Override……...………………………………………….……………………………….……………………11
Remote Control……………………………………..……………………………………………………….………….12
Operating Instructions………………………..……………………………………………………………..…….12-14
2 Vehicle Operation……….……………………………………………………………………………………………15
Car Jack Protection……………………………………………………………………………………………………15
System Wiring Diagram……………………………………………………………………………………….………16
INSTALLATION CAUTIONS & WARNINGS
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR
BAGS, ABS BRAKES, ENGINE COMPUTERS, BATTERY etc.).
WE RECOMMEND the use of a VOLT/OHM METER to test and verify wiring circuits. Test lights or illuminated
probes can cause damage to on-board computer or engine management systems.
DO NOT exceed maximum output ratings or damage may occur. Electrical current limits for this alarm are
listed where applicable on the system diagram (Pg. 16). If you are unsure about the current load, of a specific
circuit on your vehicle, measure the load first with an amp-meter before connecting.
WE RECOMMEND that the MAIN SYSTEM FUSE be REMOVED before jump starting, using a battery
charger, or changing the battery. A voltage surge or high boost condition could damage alarm circuits.
DO NOT ROUTE ANY WIRING THAT MAY BECOME ENTANGLED with brake, and gas pedals, steering
column, or any other moving parts in the vehicle.

CONTROL MODULE MOUNTING
DO NOT Mount the control unit in the engine compartment!
DO NOT Mount the control unit or wiring harness where they can become entangled with moving parts
such as brake/gas/clutch pedals, or the steering column!
The alarm control module should be mounted in a concealed location. The Placement of the module will
affect the distance from which the remote transmitter can control the unit. The antenna wire should be routed
away from any metal if possible. Do not alter the length of the antenna wire or route it with other wires. Do
not ground the antenna wire. Fasten the module to a bracket or wire harness using the cable ties provided.
Underdash Mounting: If you are locating the control unit underdash, mount it as high as possible, not easily
located by an intruder.
Driver’s Side Underdash mounting provides an easy location for wiring most of the system’s connections,
however this is a common location for an intruder to check for an alarm after breaking into the vehicle. The
left side of the vehicle may contain more metal and or wiring that will create interference and decrease the
operating range of the system.
Passenger Side underdash is a good location, however some extra wiring may be needed to extend wires
across from the driver’s side.
Under-seat / Center Console mounting is also a possibility, but NOT RECOMMENDED. The system’s
transmitter range will be reduced by the metal structures of the seat or center console and the unit may also
be exposed to moisture from spilled drinks etc. Moisture or water damage is not covered under the warranty
and will be subject to repair charges. Under seat or console mounting will create more difficulty if you need to
access the unit for service or want to add-on features or connections later. Use this location as a last resort.
COMPONENT MOUNTING
SIREN: Mount the siren under the hood to an inner fender-well, wheel-well, or other body surface with the open end
facing downward. Run the red siren wire through the firewall using a rubber grommet. Ground the black to the body
metal near the siren or you can use one of the siren’s mounting screws for a ground.
LED: Mount the red LED in a visible location on the dashboard or console.
Shock Sensor: Mount the included shock sensor with wire ties to an under dash wire harness or fasten with screws to
firewall or side paneling. Use the adjustment screw to set the sensitivity of the sensor. One screw adjusts both
Valet/Override/Program Button: Mount the Valet/Override/Program push-button in a hidden but accessible location.
It is REQUIRED for emergency disarm, programming, and valet mode.

WIRING
RED WIRE: +12V POWER INPUT (15 amp fuse)
Connect to +12 Volt source with supplied fuse & holder. Recommended location for this connection is at the vehicle
battery positive terminal.
BLACK WIRE: SYSTEM CHASSIS GROUND
The Black wire MUST be connected the CHASSIS METAL of the vehicle. Scrape away any paint or debris from the
connection point and use a star washer to ensure a good connection. Keep the ground wire short.
YELLOW WIRE: IGNITION SWITCHED “ON” AND “START” +12 VOLTS
Connect to an IGNITION wire (or fuse in the fuse box) that shows +12 Volts when the key in both “On” and “Start”
(WHEN CRANKING) positions.
ORANGE WIRE: STARTER KILL / NEGATIVE ARMED OUTPUT (500mA Ground, Optional)
This wire becomes a (-) Ground output when system is armed. This output is used for disabling the starter or to
activate optional devices such as extra sensors, LED’s, window roll-up modules, voice modules etc. For starter kill, cut
starter wire and connect between 87A and 30 on relay. Connect orange wire to 85 and connect 86 to an Ignition
source that has voltage in the ON and CRANKING position. (See wiring diagram for relay configuration-Pg. 16)
WHITE WIRE: +12V FLASHING PARKING LIGHT OUTPUT
Connect to switched parking light wire at back of light switch. If this is not possible, connect directly to one of the
parking lights at the front of the vehicle. European vehicles require separate right and left circuits. Use a dual relay or
2 diodes to separate the output signal.
BROWN WIRE: (+) SIREN OUTPUT (3 Amp Max.)
Connect to RED siren wire from the Siren in the engine compartment.
BLUE WIRE: (-) HOOD/TRUNK TRIGGER (Optional)
Input trigger for a grounding hood or trunk pin switch. Connect to existing hood and trunk pin switches that read
ground when open. If no existing switches are available, install new pin switches if desired. Note: DO NOT mount
new pin switches in water pathways.
GREEN WIRE: (-) DOOR TRIGGER
Identify the wire that reads ground when any door is open and 12 volts when all doors are closed. Some vehicles may
have isolated door triggers. In this case you may need to run additional wires from other doors or go directly to the
wire that triggers the vehicle’s interior dome light. Sometimes newer vehicles contain a separate body control module
(BCM) where the door trigger circuit can be located. One vehicle will not require the use of BOTH door trigger wires.
VIOLET WIRE: (+) DOOR TRIGGER
Same as the GREEN wire above except this wire is used for vehicles that show a positive voltage (12 volts) when the
door is open and a ground when doors are closed as in many Ford, Lincoln, and Mercury vehicles.

WIRING
GRAY WIRE: (-) AUX REMOTE OUTPUT 1 (Optional, may require a relay)
Connect to the Negative trunk release circuit or to the activation circuit of an auxiliary module or device. If the circuit
requires +12V, then a relay is required. RELAY WIRING: Connect the Gray wire to terminal 85, connect relay terminals
86 and 87 to +12V constant power. Connect terminal 30 of the relay to the +12V positive device/circuit to be activated.
WHITE/RED WIRE: (-) AUX REMOTE OUTPUT 2 (Optional, may require a relay)
This wire connects the same way as Remote Output 1 see GRAY WIRE above.
BLACK/WHITE WIRE: (-) DOME LIGHT ILLUMINATION OUTPUT (Optional, may require a relay)
Negative Dome Light System: Connect directly to dome light activation circuit.
Positive Dome Light System: Connects to terminal 85 of a relay. Connect terminals 86 & 87 to +12V Constant.
Connect terminal 30 to the dome light activation circuit.
NOTE: A relay may still be required on Negative Dome Light Systems if there are many dome lights to turn on.
(Minivans, SUV’s & Luxury vehicles) Follow the relay wiring steps for positive, but connect terminal 87 to Ground.
BROWN/WHITE WIRE: (-) HORN PULSE / CHIRP OUTPUT (Optional, may require a relay)
Connect to the Negative Horn Trigger wire usually located near the steering column. If the vehicle horn circuit requires
+12V, then a relay is required. RELAY WIRING: Connect the Brown/White wire to terminal 85, connect relay terminals
86 and 87 to +12V constant power. Connect terminal 30 of the relay to the +12V positive device/circuit to be activated.
BLUE/WHITE WIRE: (-) PASSENGER(S) DOOR UNLOCK OUTPUT (Optional, requires relay)
Connects to unlock circuit for passenger door(s) when using separate driver’s door unlock option. See SEPARATE
DRIVER’S DOOR UNLOCK WIRING for configuration options.
2 PIN PLUG (BLUE): PROGRAM/OVERRIDE PUSH BUTTON
2 PIN PLUG (RED): LED INDICATOR (RED FLASHING LIGHT)
4 PIN SENSOR PLUG: WHITE Wire: Negative Pre-Warning,
BLUE Wire: Negative Trigger, BLACK Wire: Sensor
Ground, RED Wire Sensor +12V Power
POWER DOOR LOCK WIRING
3 PIN DOOR LOCK PLUG (Optional):
GREEN: (-) Negative pulse for LOCK
RED: +12V Coil Power for using relays.
BLUE: (-) Negative pulse for UNLOCK
HINT: Relays are required for all types
of lock systems EXCEPT for Negative.
DETERMINING DOOR LOCK TYPE: We recommend determining the
type of locking system the vehicle has before connecting any wires.
Incorrect connection could result in damage to the alarm and/or t
he
vehicle’s locking system. There are several types of door lock systems
in today’s vehicles. See the list on the next page of many types of
common door locking systems. This list serves as a guide only and
your vehicle may differ.
SHOCK SENSOR: The s
ensor supplied with
this system does not require any additional
wiring. Simply mount the sensor in a suitable
location, plug it in, and adjust the sensitivity.

POWER DOOR LOCK WIRING
Negative trigger: Many Imports; Late Fords, GM’s Positive trigger: Many GM; Some Chrysler/Dodg/Plym
Reverse Polarity: Many Fords, Chrysler/Dodge/Plymouth; GM trucks
One wire dual voltage: Late /Chrysler/Dodge/Plymouth Stratus, Cirrus. Minivans; Ford Probe, Some Mazda’s.
Semi automatic: Older Saab and Volvo Electric Vacuum: Pre-‘95 Mercedes-Benz, Some Audi
NEGATIVE TRIGGER DOORLOCK WIRING POSITIVE TRIGGER DOORLOCK WIRING
GREEN
GREEN FUSED
RED +12VRED BLUE +
BLUE
86
858685 8787 3087A30
87A
FACTORY
FACTORY
LL
POWER
POWER LOCKING
LOCKING
UL UL
RELAYS RELAYS
ADDING AFTERMARKET DOOR LOCK MOTORSREVERSE POLARITY DOOR LOCK WIRING
GREEN
GREEN FUSED
FUSED RED
RED +12V
+12V BLUE
BLUE +
+
86858685
86858685 8787
8787 3087A3087A
3087A3087A
+L
CUT
UL
CUT
MASTER
SWITCH

SEPARATE DRIVER’S DOOR UNLOCK WIRING
NEGATIVE TRIGGER DOOR LOCKS
BLUE/WHITE
GREEN
RED
BLUE
DRIVER'S
DOOR MOTOR
8685 LL
87 ULUL
87A
30
FACTORY LOCK
RELAYS
+12V
+FUSED
UNLOCK WIRE CUT
WIRING FOR REVERSE POLARITY DOOR LOCKS
BLUE/WHITE
GREEN FUSED
RED +12V
BLUE +
MASTER
86858685
SWITCH
8685 8787
87 30
87A
30
87A
30 87A
+
L
CUT
UL
CUT
CUT
UNLOCK WIRE
LOCK WIRE

TRANSMITTER PROGRAMMING
1. Turn Ignition ON and OFF 3 times quickly, leaving it ON the 3rd time. (ON/OFF, ON/OFF, ON) You should hear (3)
chirps.
2. Press the Program/Override Button 5 times and you should hear 5 light flashes and 5 siren chirps.
3. Press #1 (LOCK) on the new transmitter. Siren chirps one time for Code-learn confirmation. Press #1 Button on a
second or third remote at this time. (If needed)
4. Turn off Ignition. Siren will chirp 3 times and lights will flash 3 times for exit confirmation
Note 1: This system will learn a total of 3 transmitters max.
Note 2: If you are using this identical alarm system in two vehicles, you can program button 4 (PANIC) from the other
vehicle’s remote to Arm/Disarm THIS alarm system. Follow steps above, but press the other vehicle’s remote Button
#4 (PANIC) in step 3. The other vehicle’s remote transmitter will only ARM/DISARM with Button 4 and not perform any
auxiliary or special features on THIS system.
DIAGRAM:
IGN
OFF
PANIC
TURN IGN. ON
3 TIMES:
ON, OFF
ON, OFF
ON.
5 CHIRPS
PRESS
BUTTON
5 TIMES
PRESS LOCK
BUTTON
1 CHIRP
5 FLASHES
(CODE LEARNED)
IGN
OFF
PRESS LOCK
ON ANOTHER
REMOTE
OR
3 CHIRPS

OPTION PROGRAMMING
PROGRAMMABLE OPTIONS
1. Turn the Ignition ON and press the Override/Program button 5 times. You should hear a long confirmation chirp.
2. Within the next few seconds, press the Override/Program button [again] the number of times that corresponds to
the feature list below. The siren will chirp for each button press. DO NOT LOSE COUNT!!
3. When you get to the desired option number, press the appropriate button on the transmitter according to the chart
below. Turn Ignition off. See Below for Option numbers, descriptions, and values. (Button 1 gives a single light
flash/chirp, Button 2 gives two light flashes/chirps, and Button 3 gives three light flashes/chirps.)
4. Change ONE option at a time repeating steps 1-3 as needed. When you are finished customizing options, check
operation to see if the option(s) have changed.
PROGRAMMING OPTIONS CHART * = Default
Option # Option Description BUTTON 1
LOCK BUTTON 2 UNLOCK BUTTON 3 TRUNK
1. Factory Horn Chirps / Pulses Pulse with
trip only Arm/Disarm Chirps & Pulse with trip Arm/Disarm/Warn Chirp & Pulse with trip *
2. Passive Arming /
Passive Chirp Countdown ON OFF* Chirp Countdown
3. Passive Lock / Cust. Override ON OFF* Custom Override
4. Ignition controlled Locks ON* OFF Ignition Lock Only
5. 10/60 Sec. Door Open
Warning 10 Sec. 60 Sec.*
6. Active Re-Arm ON* OFF
7. Double Unlock Pulse OFF* ON
8. Silent Arm/Disarm
(Chirp Defeat) OFF* ON
9. Parking Lights on with disarm ON* OFF
10. Disarm with trunk pop OFF ON*
11. Silent Arm/Disarm with
Remote (Button 3) ON* OFF
12. Door Lock Pulse Time 0.7 Sec.* 3 Sec.
13. Type of Carjack Protection ACTIVE* PASSIVE FULL-TIME
14. Carjack Enable/Disable DISABLE* ENABLE
NOTE: Options can be instantly restored to Factory Default Values: To restore default values: Perform step #1 above,
then press button #3 (Trunk). The siren will chirp 4 times and lights will flash 4 times. Turn OFF Ignition. All
programming options should be restored to “*” values (See chart above).

OPTION PROGRAMMING
1. HORN CHIRPS / PULSES
This option controls the system’s Factory Vehicle Horn output. There are 3 selections: Button 1 (Lock) = Horn Pulse
only when alarm is tripped. Button 2 (Unlock) = Horn Chirps for Arm / Disarm and Pulse when tripped. Button 3
(Trunk) = Horn Chirps for Arm, Disarm, and Pre-warning protection while it still pulses when tripped.
2. PASSIVE ARMING / CHIRP COUNTDOWN
This option controls the Passive (Automatic) Arming feature. If ON, arming will occur 30 Seconds after the ignition is
turned off and the last door has been closed. The LED will begin flashing rapidly while counting down. If a door is
reopened, the system will wait (LED solid) for the door or zone to close before arming. The unit will chirp once and
flash the lights once. Doors will lock if passive locking is selected. Factory default setting is OFF. If Passive Chirp
countdown is selected, the System will produce a siren chirp every 2 seconds during countdown until the system arms.
3. PASSIVE LOCKS / CUSTOM OVERRRIDE (SEE CUSTOM OVERRIDE SECTION, NEXT PAGE)
PASSIVE LOCKS: This option controls whether the doors will lock when Passive Arming occurs. Note: May increase
the risk of locking keys in the vehicle. When selected ON the alarm will passively lock the doors when passive arming.
4. IGNITION-CONTROLLED LOCKS
This option controls whether the locks are controlled by Ignition. There are 3 selections: Button 1 (Lock) = Lock/Unlock
with vehicle Ignition. Button 2 (Unlock) = No ignition locks. Button 3 (Trunk) = Ignition lock only. Doors will not lock if
they are open to prevent locking the keys in.
5. 10/60 Sec. DOOR OPEN WARNING
This setting changes the delay time in which the alarm system begins to monitor the Door circuit. This option can
prevent the alarm from giving warning chirps on vehicles with a delayed dome light.
6. ACTIVE RE-ARMING
Active Re-arming allows the system to re-arm itself 30 seconds after disarmed with the transmitter if a door has not
been opened. This is handy if the vehicle is accidentally disarmed (via the Transmitter in your pocket) without you
knowing it. If Chirp Countdown selected the system will chirp every 2 seconds during the 30 second count down to
active re-arming.
7. DOUBLE UNLOCK PULSE
The unit will send 2 unlock pulses when the #2 Unlock button is pressed. This feature may be required for interfacing
this alarm with an existing Factory Keyless Entry or Alarm system in a vehicle. These systems are found on some
Nissan, VW, Toyota, and Lexus vehicles.
8. SILENT ARMING /DISARMING (CHIRP DEFEAT)
With this feature, the system can be programmed to Arm and Disarm without the siren chirp using the regular
Lock/Unlock Buttons. Flashing parking lights will be the only Arm/Disarm confirmation.

OPTION PROGRAMMING
9. PARKING LIGHTS ON WITH DISARM
Keeps parking lights on instead of 2 flashes when system is disarmed to assist in locating your vehicle in a crowded
parking lot or structure. Light will stay on for 30 Sec. or until Ignition is turned on.
10. DISARM WITH AUX. OUTPUT 1 (TRUNK POP)
Controls whether the system will or will not DISARM when the trunk pop or AUX. feature is used. When the feature is
turned on the unit will DISARM when opening trunk or using an auxiliary device controlled by the Gray output wire.
11. SILENT ARM / DISARM WITH REMOTE BUTTON #3 (SHORT PRESS)
With this feature, the system can be programmed to Arm and Disarm without a siren chirp using a short press and
release of Button #3 (TRUNK) on the remote transmitter.
12. DOOR LOCK/UNLOCK PULSE TIME
Controls the amount of time (0.75 sec. or 3 sec.) for the lock/unlock pulse. The 3 sec. setting may be required for
1980’/90’s European Vehicles that require a long pulse to do Vacuum door lock systems.
13. ACTIVE, PASSIVE, or FULL-TIME CARJACK PROTECTION
This feature controls the type of Carjack protection the alarm will provide. There are 3 selections: Button 1 (Lock) =
Active protection. Button 2 (Unlock) = Passive protection. Button 3 (Trunk) = Full-Time protection. Option number 14
must be enabled to allow Carjack functions to operate. See Operation : Carjack.
14. CARJACK FEATURES
This option controls the unit’s Car Jack features. Enable or Disable Carjack (Turn ON or OFF) with this option.
CUSTOM OVERRIDE
Custom override allows the user to set a specific number of button presses (2-15) required to perform an emergency
override/disarm of the alarm system. This increases the level of security of the system, but you MUST MEMORIZE
how many button presses you have changed your system to use or the unit will not disarm in an emergency.
1. Enter programming mode. (See step #1 on page 9)
2. Press program button three times to go to option #3 “Passive Locks/Custom Override”.
3. Press the Button #3 (TRUNK) on the remote transmitter.
4. Press and release the program again the number of times you desire in order to perform emergency disarm on this
alarm system. Press the program button 2-15 times only.
To test feature: Trip alarm system, turn key ON, press the program/valet button 2-15 times as programmed above
then continue to HOLD DOWN valet button on the LAST PRESS for 5 seconds. Alarm should disarm. If system does
not disarm, then disarm with the remote transmitter and try again. If system still does not disarm, then repeat steps
above.

REMOTE CONTROL
4 BUTTON REMOTE TRANSMITTER:
#3
#1 #2
#4
PANIC
ARM
TRUNK PANIC
DISARM
(LOCK) (UNLOCK)
REMOTE
POP
OPERATING INSTRUCTIONS
ACTIVE ARMING
To arm the alarm and lock the doors, press the #1 (Lock Symbol) button on the transmitter. You will hear a single
siren chirp and the lights will flash once. The system will arm, the doors will lock and the starter will be disabled if these
optional features are installed. The red LED in the vehicle will start flashing after 15 seconds. After a short delay to
allow vehicle and electronics to stabilize the system will be completely armed.
ALARM TRIGGERING
If there is an intrusion into the vehicle or hard impact to the body will sound the alarm and flash the lights for 45
seconds. After 45 seconds the system will automatically shut off and re-arm to continue to protect the vehicle. If a
door is left open, the unit will cycle a second time and still continue to protect the other un-tampered zones.
DISARMING
To disarm the alarm and unlock the doors, press the #2 (Unlock Symbol) button on the transmitter. You will hear 2
siren chirps and the lights will flash twice. The dome light turns on and the dash LED stops flashing.
TRUNK/HATCH POP (REMOTE AUX. OUTPUT 1, OPTIONAL)
To pop the trunk (if optional feature is installed), press Button #3 (Trunk Symbol) on the transmitter for at least 1 ½
seconds. If the system is armed, pressing Button #3 may or may not trip the alarm system when opening the trunk
depending on programming option (10). See page 9.
REMOTE PANIC PROTECTION
To sound the alarm upon command (panic), press and hold the Button #4 (Panic) for at least 2 seconds until the siren
sounds. Press Button #2 (Unlock) to reset panic mode.

OPERATING INSTRUCTIONS
PRE-WARNING SHOCK PROTECTION & SENSOR ADJUSTMENT
If a low-level shock to the vehicle is detected, pre-warning protection will activate sounding 6 quick siren chirps
and 1 light flash. If a hard impact is detected the shock sensor should trip the alarm system. Once it is
mounted, adjust the sensor as needed by turning the adjustment screw clockwise to increase or counter-
clockwise to decrease the sensitivity. The sensor is also equipped with 2 small indicator lights to ease the
adjustment process. Green light = Pre-warning disturbance (6 siren chirps). Red light = A full alarm trip.
ARMING WITHOUT SHOCK SENSOR PROTECTION
To arm the alarm without Shock sensor protection, press button #1 as normal then press Button #4 (Panic) within 2
seconds. You will hear an extra siren chirp indicating shock sensor bypass.
SILENT ARM/DISARM THROUGH REMOTE (BUTTON #3)
This system can be armed and disarmed without siren chirps on an “as needed” basis. Press and quickly
release Button #3 (TRUNK) to Arm and Disarm system without chirps. NOTE: If Button #3 is pressed too long,
then trunk pop may activate (If optional Trunk-pop feature is connected to the system).
PROGRAMMABLE SILENT ARM/DISARM MODE
The system can be silently armed and disarmed as normal with Lock/Unlock Buttons, but no siren chirp. See
alarm programming option (8) to enable or disable this feature.
EMERGENCY OVERRIDE / DISARM
If you have lost the transmitter or it stops working for any reason and the Alarm is armed, you will have to
open the door with the key, which will activate the alarm. Turn the ignition on and press the override/program
button 4-5 seconds (until siren stops). The Alarm will disarm and enter the Valet mode, which allows you to
use the vehicle until you can repair/replace the remote transmitter or have the alarm system checked.
EMERGENCY DISARM WITH CUSTOM OVERRIDE
If you have programmed your system for Custom Override, follow the same steps above (Emergency
Override) while pressing the valet button 2-15 times as you have programmed. Continue to hold the button on
the last press for 5 seconds. The Alarm will disarm and enter the Valet mode, which allows you to use the
vehicle until you can repair/replace the remote transmitter or have the alarm system checked.
VALET MODE
To disable the Alarm system for vehicle service or otherwise, turn the ignition on and press the
override/program button 4-5 seconds until the dash LED turns on solid and you hear (1) siren chirp. Repeat
the process to exit VALET mode and the system will chirp (2) times and the LED will turn off. Lock/Unlock and
AUX features will still operate in when in VALET mode.

OPERATION
PASSIVE ARMING / PASSIVE LOCK MODES / PASSIVE CHIRP COUNTDOWN
If programmed, passive (Automatic) Arming will occur 30 Seconds after the ignition is turned off and the last door has
been closed. The LED will begin flashing rapidly while counting down. If a door is reopened, the system will wait (LED
solid) for the door or zone to close before arming. The unit will chirp once and flash the lights once. Doors will lock if
passive locking is selected. May qualify for insurance discounts-check with your agent or proprietor. When the Unit is
programmed for Passive Chirp Countdown, the siren will chirp during passive countdown, as an audible warning that
arming will occur. This siren will emit a chirp every 2 seconds as soon as the last door is closed until the system arms
30 seconds later.
PRIOR INTRUSION ALERT
If the system was tripped in your absence, the dash LED will be flashing rapidly. When the system is disarmed you will
hear 3 chirps (and 3 light flashes). Carefully inspect your vehicle to see if there is any damage or a theft has occurred.
DOME LIGHT ILLUMINATION (OPTIONAL)
This feature turns on the vehicles dome light upon disarm for 30 seconds or until the key is inserted and turned on.
This will provide illuminated entry to your vehicle at night or in dimly lit areas for safety and security.
OPEN ZONE ALERT/BYPASS
If the system detects a faulty or open zone (Door left open) when the system is ACTIVELY ARMED, the siren will chirp
4 times along with 4 light flashes. The faulty zone will be automatically bypassed.
IGNITION-CONTROLLED DOORLOCKS
The doors will automatically lock when the ignition is turned on and will unlock when the ignition is turned off. This
feature can be programmed on, off, or to lock the doors only. Doors will not lock if they are open to prevent locking
the keys in.
ACTIVE RE-ARMING (FAIL-SAFE PROTECTION)
Active Re-arming means that the system will re-arm itself 30 seconds after disarmed with the transmitter if a door has
not yet been opened. This is handy if the vehicle is accidentally disarmed (via the transmitter in your pocket) without
you knowing it. This feature can also be turned off in programming option (4).If programmed for Passive Chirp
Countdown, the unit will emit a chirp every 2 seconds until the system Active Re-arms.
2nd AUX. OUTPUT (REMOTE AUX. OUTPUT 2)
To activate the Second auxiliary output press Button #1 (Lock) and hold for more than (2) seconds. This output can be
used to control optional add-on accessories such as Remote Engine Start Modules, Window Roll up/down modules,
etc.

2 VEHICLE OPERATION
2 VEHICLE CONTROL
Your remote control can be programmed to Arm/Disarm a second vehicle with an identical Crimestopper
system installed. Follow transmitter programming steps on the second vehicle. Instead of pressing the #1
Lock at step 3, press Button #4 (Panic) on YOUR existing remote. Your remote will now have arm/disarm
control of the second vehicle with a quick press and release of your Button #4 (Panic). Don’t press the Panic
button for too long or YOUR alarm system will trip. You can only arm/disarm the second vehicle.
CARJACK PROTECTION
ACTIVE CARJACK
This feature provides Active Carjack protection and must be enabled before use through Alarm programming
option (14) See page 9. When the Ignition is on (vehicle is running), press button #4 (Panic). Parking lights
will flash TWICE to confirm the Carjack countdown sequence. 90 Seconds later, the unit will begin a Carjack
Cycle consisting of 15 seconds of pre-warning chirps turning into a full system activation with siren/flashing
light pulses for up to 5 min. To reset Active Carjack, IGNITION MUST BE ON, then press Button #4.
PASSIVE CARJACK
This feature provides Passive Carjack protection and must be enabled before use through Alarm programming
options (13) & (14). See page 9. We recommend this mode should only be used in serious situations. When
the Ignition is on (vehicle is running), and a door is opened, the Carjack countdown sequence will be initiated.
90 Seconds later, the unit will begin a Carjack Cycle consisting of 15 seconds of pre-warning chirps turning
into a full system activation with siren/flashing light pulses for up to 5 min. To reset Passive Carjack,
IGNITION MUST BE ON AND DOORS MUST BE CLOSED, then press the override/program button (3) times.
FULL-TIME CARJACK
Use in case of extreme Carjack threat only. This feature provides full-time Carjack protection and must be
enabled before use through Alarm programming options (13) & (14). See page 9. EVERY TIME the Ignition
is turned ON or a door is opened, then closed with the Ignition ON, a Carjack countdown sequence will be
initiated. 90 Seconds later, the unit will begin a Carjack Cycle consisting of 15 seconds of pre-warning chirps
turning into a full system activation with siren/flashing light pulses for up to 5 min. You must reset the unit
every time the IGNITION is turned on or a door is opened and closed when the ignition is on. To reset
IGNITION MUST BE ON AND DOORS MUST BE CLOSED, then press override/program button (3) times.
NOTE: When FULL TIME CARJACK is in effect, it must be reset every time the key is turned on, Door is
opened, before entering VALET mode, and before Programming options or transmitters. It is always in effect
each time the Ignition is turned on and/or a door is opened with Ignition on.

+-
+
BLACK(GROUND)
WHITE(WARNING)
RED (+)
BLUE (TRIGGER)
RED
WHITE
BROWN
BLUE/WHITE
WHITE/RED
ORANGE
BLACK/WHITE
BLUE
GRAY
YELLOW
BLACK
VIOLET
GREEN
LED
OVERRIDE/
PROGRAM
BUTTON
BATTERY
(-) LOCK OUTPUT
+12 VOLT FOR RELAYS
(-) UNLOCK OUTPUT
GREEN
BLUE
RED
CS-2001FC
(-) NEG. DOOR
PIN SWITCH
(+) POSITIVE DOOR
PIN SWITCH
FUSE
BOX
IGN.
SW
(-) REMOTE OUTPUT 1
(-) HOOD/TRUNK TRIGGER
(-) DOOR TRIGGER
(+) DOOR TRIGGER
CHASSIS GROUND
(+) SWITCHED IGN "ON"
SIREN
PARKING
NEG. ARMED OUTPUT
(STARTER DISABLE)
OPT.
RELAY
8586
8730 87a
8586
30
87A
8586
8730 87a
10A MAX
3A MAX
LIGHTS
FUSE
15A
CUT
START WIRE
IGNITION
"ON & START"
STARTER
(-) REMOTE OUTPUT 2
8586
8730 87a
SHOCK SENSOR
(-) NEG.
PIN SWITCH (-) DOME LIGHT OUTPUT
+12V POWER
(-) PASSENGER
UNLOCK OUTPUT
ACTIVATES ON
SECOND PRESS
OF UNLOCK BUTTON
+OR
DOME LIGHT
BROWN/WHITE
(-) HORN HONK
OUTPUT
OPT.
RELAY
