Crivit KH 260 User manual

KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH260-10/09-V2
4C PEDOMETER
Pedometer
Operating instructions
KH 260
Mjeračkoraka
Upute za upotrebu
Števec korakov
Navodila za uporabo
CV_KH260_DIE43209_LB4C.indd 1-3CV_KH260_DIE43209_LB4C.indd 1-3 18.11.2009 16:34:06 Uhr18.11.2009 16:34:06 Uhr

1 2
3
4
5
6
7
8
9
0
w
q
CV_KH260_DIE43209_LB4C.indd 4-6CV_KH260_DIE43209_LB4C.indd 4-6 18.11.2009 16:34:06 Uhr18.11.2009 16:34:06 Uhr

- 1 -
CONTENT PAGE
Intended use 3
Safety instructions 4
Items supplied 5
Functions 6
Technical Data 6
Description of the device 8
Wearing the pedometer 9
Determining your pace length 9
Commissioning 10
Programming your pace length 10
Programming your weight 11
Programming the time 12
Using the stopwatch 13
Using the countdown function 13
KH260_43209_LB4C.indb Abs1:1KH260_43209_LB4C.indb Abs1:1 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 2 -
Before using the device for first time, please read these
operating instructions carefully and keep this instruction
manual in a safe place for later reference. Pass this manual
on to whoever might acquire the device at a future date.
Adjusting the measurement units 15
Checking the distance covered and calorie
consumption 16
Returning the data to null 17
Radio operation 17
Changing the batteries 19
Cleaning and care 20
Troubleshooting 21
Disposal 22
Warranty and Service 23
Importer 25
KH260_43209_LB4C.indb Abs1:2KH260_43209_LB4C.indb Abs1:2 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 3 -
Intended use
This pedometer is fastened to your trouser waistband or
belt and serves to record the number of steps taken when
walking or jogging etc. Additionally, VHF radio can be
received with the device.
This device is intended exclusively for use in domestic environ-
ments, it is not intended for commercial applications.
Usage other than as described here is not permitted
and could lead to damage or injury. No liability will be
accepted for damage resulting from abusive or improper
handling, the application of violence or unauthorised
modification. The technical features of this device enable
an adjustable reception capability that exceeds the
permitted frequency range of 87,5 - 108 MHz. In some
countries, different national regulations may apply to the
assigned radio frequency ranges. Please note that infor-
mation received outside of the assigned radio frequency
ranges may not be used, passed on to third parties or
otherwise misused.
KH260_43209_LB4C.indb Abs1:3KH260_43209_LB4C.indb Abs1:3 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 4 -
Safety instructions
• Before using the device for first time, please read these
operating instructions carefully and keep this instruction
manual in a safe place for later reference. Pass this
manual on to whoever might acquire the device at
a future date.
To avoid damage, do not allow liquids to permeate• the device and do not submerse it in water.
Avoid also a possible penetration by foreign objects.• Never open the housing, except the battery compart-• ment to change batteries, there are no user-serviceable
elements inside
To avoid damage, never touch the display with• pointed objects and do not exert any pressure on it.
In the event of malfunction or apparent damage, make• contact with our Customer Services.
If you do not intend to use the device for an extended• period, remove the batteries - batteries can discharge
themselves and then leak.
KH260_43209_LB4C.indb Abs1:4KH260_43209_LB4C.indb Abs1:4 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 5 -
Should the batteries leak: Put on protective gloves and• clean the battery compartment with a dry cloth.
Use ONLY the type of new battery detailed in the• Technical Data as replacements for discharged batteries.
Do not throw the batteries into a fire. Do not short• circuit the batteries. Do not attempt to recharge the
batteries. There is the risk of an explosion!
Keep batteries away from small children. Children could• put batteries into their mouths and swallow them.
If a battery is swallowed, seek medical assistance
IMMEDIATELY. There is a risk to life!
Items supplied
Before using the device for the first time, check to ensure
that it is complete and free of visible damage.
Pedometer
Headphone Type KH260E
2 x CR2032 Batteries
This operating manual
KH260_43209_LB4C.indb Abs1:5KH260_43209_LB4C.indb Abs1:5 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 6 -
Functions
This pedometer has the following functions available:
12/24 Time (CLOCK)• Stopwatch (STW)• Countdown Function (TIMER)• Pace counter (STEP)• Distance covered (DIST)• Calorie counter (KCAL)• Fat burner (FAT B.)• VHF radio with Auto-Scan function•
Technical Data
Radio:
Power supply: 1 x 3 V Type CR2032
Frequency range : 87.5 - 108 MHz
Output level: 100 mW
Max. Output voltage
at headphone socket: ≤ 150 mV
KH260_43209_LB4C.indb Abs1:6KH260_43209_LB4C.indb Abs1:6 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 7 -
Headphone impedance: 32 Ω
Sensitivity: 97dB +/- 3dB bei 1 kHz
Nominal output: 30 mW
Broadband-Recognition.
(WBCV): 400 mV
Pedometer:
Power supply: 1 x 3 V Type CR2032
Stopwatch: 0 – 99h, 59 min, 59 s
Countdown function: 99h, 59 min, 59 s
Pace length: 30 -180 cm
Weight: 10 -150 kg
Pedometer: 0 – 99999 Paces
Distance: 0 – 199,99 km
Fat burning: 0 – 999,9 g
Calorie consumption: 0 – 99999 kcal
Operating temperature: -10°C – 40°C
Storage temperature: -20°C – 60°C
Dimensions: 5.7 x 3.1 x 5.9 cm
Weight: 54 g approx.
(including batteries and
headphone)
KH260_43209_LB4C.indb Abs1:7KH260_43209_LB4C.indb Abs1:7 26.11.2009 15:16:12 Uhr26.11.2009 15:16:12 Uhr

- 8 -
Description of the device
1LCD-Display (two-line display with various display
modes and background illumination)
2Indicator LED (glows green with switched-on radio)
3Button (Radio on and off switch)
4VOL+/VOL– (Increase/decrease sound volume)
5RESET (Return the device to factory settings)
6Belt clip (To secure the pedometer onto a belt or the
waistband)
7Screw for the battery compartment cover
8MODE button (For switching between various display
modes)
9SET button (Recall adjustment mode)
0UP button (Carry out adjustments, start/stop for
countdown function and stopwatch)
qSEEK+/SEEK- button (Search frequency range,
up or down, for radio stations )
wHeadphone connection socket
