Crosley Furniture CF101569-R User manual

Upper Front Rail Lower Front Rail

Step 1. Attach upper front rail (part ZA) to top panel (part U) using wood dowels
(part #2) and lock the hardware.
Reference the images above any time the instructions state "lock the hardware".
Be sure to check all hardware is locked when complete.

Step 2. Attach lower front rail (part ZB) to bottom panel (part V) using wood dowels
(part #2) and lock the hardware.
Step 3. Attach slats (parts Y & Z) to right panel (part X) using wood dowels
(part #2) and lock the hardware.

Step 4. Attach assembled unit (parts V & ZB) to assembled unit (parts X, Y & Z) using
wood dowels (part #2) and lock the hardware.
Step 5. Attach left panel (part W) to assembled unit (parts V & ZB) using wood dowels
(part #2) and lock the hardware.

Step 6. Attach top panel (part U) to assembled unit (parts W & X) using wood dowels
(part #2) and lock the hardware.
Step 7. Attach back panel (part ZD) to assembled unit (parts U, V, W & Z) using screws
(part #1) and phillips head screwdriver.

ZC
Step 8. Carefully turn unit upright. Place shelf holders (part #3) into desired position
and then slide adjustable shelf (part ZC) into place.
