Crye Precision RANGE BELT User manual

RANGE BELT™ OPERATOR’S MANUAL

EQUIPMENT INFORMATION
INTRODUCTION .........................................................1
INCLUDED COMPONENTS...........................................2
DONNING THE LRB™
PANT BELT CONFIGURATION.................................................. 5
BUCKLE REMOVAL .....................................................7
MRB™ OUTER BELT CONFIGURATION ................................. 9
DUTY BELT CONFIGURATION ................................................. 11
NOTES FOR PROPER USE......................................................... 15
CONTENTS

1RANGE BELT™
INTRODUCTION
The Crye Precision RANGE BELT™ is a stable and comfortable platform that works
great as a duty/gun/gear belt; exible for comfort but sturdy enough to support a
holster and other heavy gear. Wear alone, over a VELCRO®inner belt, or use as an
insert in our MRB™.
FEATURES
Quick release hardware allows for easy don and doff
Pre-curved shaping for better t and added comfort
Low prole padding adds comfort for long term wear
Belt width: 1.75”
3 ways to wear: wear alone, over a VELCRO®belt or as an insert in our MRB™
Lined with low prole VELCRO®for integration with our MRB™ INNER BELT
NOT LOAD RATED. DO NOT USE FOR RAPPELLING OR AS A SAFETY RESTRAINT OF
ANY KIND. IF YOU NEED A LOAD RATED BELT, CHECK OUT OUR LRB™. CRITICAL
USE AND SAFETY WARNINGS ARE CONTAINED IN THE PRODUCT MANUAL
ACCOMPANYING THIS PRODUCT. FAILURE TO ADHERE TO THOSE USE AND
SAFETY WARNINGS MAY RESULT IN SERIOUS INJURY OR DEATH.
If you need a load-rated belt, check out our LRB™

2EQUIPMENT INFORMATION
INCLUDED COMPONENTS
1RANGE BELT
1

DONNING THE RANGE BELT™

5RANGE BELT™
PANT BELT CONFIGURATION
This belt can be used with most pants with standard-sized belt
loops. Install as you would a normal belt by passing the RANGE
BELT™ through your pant belt loops, the buckle should be
positioned left-center.
To secure the RANGE BELT™, connect the male and female ttings.
If the hardware doesn’t positively lock, the male portion may be
upside down.
1
2

6DONNING THE RANGE BELT™
NOTE: This is the smallest sizing conguration, as the belt
is closer to your body than the other congurations. Some
overlapping ends can occur. If the slack retainer elastic impedes
adjustment, you can re-route the webbing around the elastic for an
additional 1.5” of adjustment.
Excess webbing should be routed through the pant belt loops, or
rolled and stowed under the RANGE BELT™ slack retainer elastic.
3
A

7RANGE BELT™
Slotted holsters and pouches can be utilized with this belt though
you may need to remove the male hardware to allow the belt to
pass through the slots. To remove buckle, push webbing from the
bottom to create loop on top of buckle.
Pull the webbing free and remove the buckle. Use the running end
to route the belt through slots on a holster.
BUCKLE REMOVAL
1
2

8DONNING THE LRB™
Pass the webbing back through the hardware, over the tensioning bar.
Position holster at desired location. Pass running end of webbing
through the front portion of the male hardware. Ensure the
chamfered portion of hardware is facing the standing end of the
adjustment webbing.
3
4

9RANGE BELT™
MRB™ OUTER BELT CONFIGURATION
Remove the MRB™ OUTER BELT from the MRB™ OUTER COVER by
removing the buckle(s) from either side and pulling the belt out
completely to separate it from the OUTER COVER.
Remove male adjustment buckle from the RANGE BELT™ (see page
6) and use running the running end to pass belt through the MRB™
OUTER COVER.It will be a tight t, and you may need to pass the
end of the adjustment webbing through the channel rst and pull
the belt through.
1
2
MRB™ OUTER BELT
MRB™ OUTER COVER

10
Drop-style holsters can be used in this conguration by opening
the drop holster pocket, exposing the RANGE BELT™ and passing
the holster webbing around the belt.
This can also be accomplished while inserting the RANGE BELT™
into the MRB™ OUTER COVER.
NOTES
A
DONNING THE RANGE BELT™

11 RANGE BELT™
DUTY BELT CONFIGURATION
Pass the MRB™ INNER BELT through your pant belt loops and secure
as you normally would.
Attach holster and/or pouches to RANGE BELT™.
NOTE: For best results, leave some portions of the inner hook
exposed to secure to the MRB™ INNER BELT.
1
2

12
Wrap the belt around your hips, ensuring the VELCRO®is making
contact and secure hardware.
4
Lift the belt from the ends and secure back center VELCRO® on the
MRB™ INNER BELT.
3
DONNING THE RANGE BELT™

NOTES FOR PROPER USE

15 RANGE BELT™
NOTES FOR PROPER USE
Usage instructions must be read prior to each use.
INSPECTION
Inspect each bartack to ensure the threads are still intact on the front and back of belt, and that they are not burned or abraded.*
The RANGE BELT™ is NOT intended for horizontal positioning, restraint, rappelling, or fall protection.*
Inspect the entire belt for chemical contamination or excessive UV light exposure. Look for discolored, faded, or degraded components
that may indicate exposure to corrosive elements.*
Inspect the hardware to ensure there are no cracks or burs that could compromise the webbing.*
If your belt fails inspection, it must be destroyed to prevent further use.
*Perform inspection before each use
CARE INSTRUCTIONS
You can hand wash your belt with mild soap and warm water. Never use bleach as that can degrade the materials. Allow to air dry away
from direct sunlight. Do not store damp.
Always keep your RANGE BELT™ away from sharp objects or any other objects that could damage your belt.
Normal use allows for a 3 year life of this belt. Due to natural degradation of materials, any RANGE BELT™ that is 7 years old should be
destroyed, even if unused.

16NOTES FOR PROPER USE
WARNING
The RANGE BELT™ is NOT intended for horizontal positioning, restraint, rappelling, or fall protection, and should NEVER be used for any
of these activities! It is designed to be used as a duty belt or as a substitute for the Outer Belt of the MRB™.
DO NOT
Expose your belt to open ame or excessive heat
Attempt to modify or repair the belt in any way
Throw away insert card/hang tag
THIS BELT IS NOT FLAME RESISTANT.
FAILURE TO COMPLY WITH ANY OF THE NOTES FOR PROPER USE OR WARNINGS FOUND
ON THESE PAGES WILL RESULT IN BELT FAILURE, WHICH SUCH FAILURE MAY RESULT IN
SERIOUS INJURY OR DEATH.

17 RANGE BELT™
NOTES
