STI Stopper Station Series Quick guide

We protect the things that protect you.
Stopper Station Series
SS-2002F P sh B ttons
Key-to-Reset
ADA
Compliant

Installation and Service Instructions
STOPPER STATION SERIES SS-2002F PUSH BUTTON
SAFETY NOTICE TO INSTALLERS AND USERS
This push button has been tested according to UL38 and UL2017. Manual fire alarm stations are
listed in UL category U IU and non-fire alarm initiating devices are listed in UL category UEHX. It
is important to read, understand and follow all instructions provided with this product. It is the
installer’s responsibility to comply with FPA72 and 101, EC, mounting specifications according
to ADA and other applicable fire and electrical codes. After installation and testing are complete,
provide a copy of this manual to all personnel responsible for testing and maintenance of this
product. To avoid electrical shock, DO OT attempt to install this product when power is on. For
outdoor usage, STI-6525 or STI-6535 Mini Weather Stopper Cover is required.
II. CONTENTS LIST
QTY. DESCRIPTION
1 Push Button Housing Assembly
1 18061 Reset Key
1 19001 Allen Head Screw #8-32 x 3/8 in.
1 19015 Allen Wrench 3/32 in.
4 19068 Screw 3.5mm x 13mm
2 19060 Screw #6-32 x 1 in.
1 19021 Ground Screw
4 19039 #6 x 1 1/4 in. SS SMS
4 19018 Plastic Screw Anchor
1 71100A Surface Backbox
I. GENERAL
Product Dimensions See page 7
Switc Rating 2 Form C contacts
125/250 VAC, 10 A, 1/2 HP
30 VDC, 6 A
III. INSTRUCTIONS
Housing Removal ...................................................................... Page 2
Backbox Preparation ................................................................ Page 3
Wire Connections ...................................................................... Page 4
Installation ................................................................................ Page 5
Key Reset Procedure.................................................................. Page 6
Product Dimensions .................................................................. Page 7

- 2 -
BUTTON AND SWITCH ASSEMBLY
10271 RED
SWITCH HOUSING
19015 WRENCH
(1) PROVIDED
19001 SCREW ALLEN HEAD
#8 - 32 X 3/8 in. (1) PROVIDED
HOUSING REMOVAL
REMOVE SCREW. PULL BOTTOM OF HOUSING OUT AND LIFT UP UNTIL
TABS ARE RELEASED FROM SLOTS IN BUTTON AND SWITCH ASSEMBLY.

- 3 -
BACKBO PREPARATION
(NOT INCLUDED WITH FLUSH MOUNT COVERS)
J
J
J
J
HSWITCH BACKPLATE
MOUNTING HOLES
BOX MUST BE INSTALLED WITH
ARROWS POINTING UPWARD
THESE HOLES MUST BE
DRILLED OUT USING A
5/32 in. DRILL BIT
H
J
OUNTING HOLESM
T
CKPLA
ATE
ACH BWITS
H
J
ALLED WITHTT BE INSUSX MOB
TE
ALLED WITH
J
J
WS POINTING UPWOARR
ALLED WITHTT BE INSUSX MOB
5/32 in. DRILL BIT
DRILLED OUT USING A
T BEUSTHESE HOLES M
H
ARDWS POINTING UPW
ALLED WITH
5/32 in. DRILL BIT
DRILLED OUT USING A
T BE
J
DRILL POINT LOCATIONS PROVIDED
TOP AND BOTTOM FOR 1/2 in.
CONDUIT FITTINGS.
DRILL AS NEEDED
D
S NEEDEDDRILL A
ONDUIT FITC
OP AND BT
DRILL POINT L
S NEEDED
.TINGSONDUIT FIT
OR 1/2 in.M FOTTOOP AND B
VIDEDOTIONS PROCADRILL POINT L
FIELD DRILLING FOR CONDUIT ENTRY IS
REQUIRED. LOCATIONS SHOWN ALSO
APPLY TO OPPOSITE, PARALLEL SIDE.

- 4 -
COM
NO
NC
CONTACT
SET 1
INCORRECT METHOD OF
INSERTING MULTIPLE LEADS
(BOTH WIRES ON
ONE SIDE OF SCREW)
CORRECT METHOD OF
INSERTING MULTIPLE LEADS
(1 WIRE EACH
SIDE OF SCREW)
WIRE CONNECTIONS
STRIP
3/8 in. (9mm)
COM
NO
NC
NC
NO
1.56 in.
(40mm)
12-18 AWG
CLOSE ON
ALARM
SINGLE DEVICE
TO NEXT DEVICE
OR EOL DEVICE
DRILL (4)
5/32 in. DIA.
HOLES
19039 SCREW
#6 x 1 1/4 in.
(4) PROVIDED
71100A RED
SURFACE BOX
19021 GROUND SCREW
19018 ANCHOR
(4) PROVIDED
BUTTON AND SWITCH ASSEMBLY
19068 SCREW
SELF TAPPING
(4) PROVIDED
BUTTON AND SWITCH ASSEMBLY
10271 RED
SWITCH HOUSING
19015 WRENCH
(1) PROVIDED
19001 SCREW ALLEN HEAD
#8 - 32 X 3/8 in. (1) PROVIDED
4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm)
3.18 in.
(81mm)
1.56 in.
(40mm)
PUSH 4.87 in.
(124mm)
3.25 in.
(82mm)
NC
NO
COM
CONTACT
SET 2
1.62 in.
(41mm) 1.25 in.
(32mm)
WITH ALL SWITCH STATIONS
VIEW SHOWING SWITCH INSTALLATION
WITH STI'S SURFACE MOUNT BACK BOX. THE COLOR
MATCHED SURFACE BOX COMES STANDARD
TYPICAL FLUSH MOUNT
SINGLE GANG OUTLET BOX
SURFACE BOX NOT REQUIRED FOR THIS INSTALLATION.
TO TYPICAL EXISTING SINGLE GANG BOX.
VIEW SHOWING SWITCH INSTALLATION
19021 GROUND SCREW
VIEW SHOWING RESET PROCEDURE
ON UNDERSIDE OF BUTTON
AVIEW IN DIRECTION OF ARROW
COM
NO
NC
A
SWITCH ASSEMBLY AND BACK PLATE
WITH MOLDED-IN STAINLESS STEEL INSERT
(ALL FASTENERS SHOWN PROVIDED)
GREEN, OR WHITE.
CHOOSE RED, YELLOW, BLUE,
MOLDED OF POLYCARBONATE.
SWITCH HOUSING
OR WHITE. (ALL FASTENERS PROVIDED)
CHOOSE RED, YELLOW, BLUE, GREEN,
BACK BOX. MOLDED OF POLYCARBONATE,
FULLY ENCLOSED SURFACE
(4 PROVIDED)
MOUNTING ANCHORS
(PROVIDED)
WRENCH.
SCREW &
RETAINING
HOUSING
SWITCH
A
SWITCH ASSEMBLY AND BACK PLATE
WITH MOLDED-IN STAINLESS STEEL INSERT
(ALL FASTENERS SHOWN PROVIDED)
DRILL (4)
5/32 in. DIA.
HOLES
SWITCH HOUSING
MOLDED OF POLYCARBONATE
CHOOSE RED, GREEN, YELLOW
WHITE OR BLUE
SWITCH HOUSING
(RETAINING SCREW AND
WRENCH PROVIDED)
PUSH
NC
NO
COM
4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm) 1.25 in.
(32mm)
BUTTON AND SWITCH ASSEMBLY
19060 #6 - 32 x 1 in.
SCREW (2) PROVIDED
BUTTON AND SWITCH ASSEMBLY
10271 SWITCH HOUSING
AVAILABLE IN RED, GREEN,
YELLOW, WHITE OR BLUE
19015 WRENCH
(1) PROVIDED
19001 SCREW ALLEN HEAD
#8 - 32 X 3/8 in. (1) PROVIDED
19039 SCREW
#6 x 1 1/4 in.
(4) PROVIDED
71100A SURFACE BOX
AVAILABLE IN RED, GREEN,
YELLOW, WHITE OR BLUE
19021 GROUND SCREW
19018 ANCHOR
(4) PROVIDED
BUTTON AND SWITCH ASSEMBLY
19068 SCREW
SELF TAPPING
(4) PROVIDED
PUSH 4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm)
3.18 in.
(81mm)
2.375 in.
(60mm)
.75 in.
(19mm)
1.5 in.
(38mm)
.75 in.
(19mm)
THIS SIDE
CONTACT SET 2
THIS SIDE
CONTACT SET 1
COM
NC
NO
1.56 in.
(40mm)
12-18 AWG
CLOSE ON
ALARM
SINGLE DEVICE
TO NEXT DEVICE
OR EOL DEVICE
DRILL (4)
5/32 in. DIA.
HOLES
19039 SCREW
#6 x 1 1/4 in.
(4) PROVIDED
71100A RED
SURFACE BOX
19021 GROUND SCREW
19018 ANCHOR
(4) PROVIDED
BUTTON AND SWITCH ASSEMBLY
19068 SCREW
SELF TAPPING
(4) PROVIDED
BUTTON AND SWITCH ASSEMBLY
10271 RED
SWITCH HOUSING
19015 WRENCH
(1) PROVIDED
19001 SCREW ALLEN HEAD
#8 - 32 X 3/8 in. (1) PROVIDED
4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm)
3.18 in.
(81mm)
1.56 in.
(40mm)
PUSH 4.87 in.
(124mm)
3.25 in.
(82mm)
NC
NO
COM

- 5 -
WITH ALL SWITCH STATIONS
VIEW SHOWING SWITCH INSTALLATION
WITH STI'S SURFACE MOUNT BACK BOX. THE COLOR
MATCHED SURFACE BOX COMES STANDARD
TYPICAL FLUSH MOUNT
SINGLE GANG
OUTLET BOX
SURFACE BOX NOT REQUIRED FOR THIS INSTALLATION.
TO TYPICAL EXISTING SINGLE GANG BOX.
VIEW SHOWING SWITCH INSTALLATION
19021 GROUND SCREW
COM
NO
NC
CHOOSE RED, YELLOW, BLUE,
MOLDED OF POLYCARBONATE.
(PROVIDED)
WRENCH.
SCREW &
RETAINING
HOUSING
SWITCH
A
Y AND BACK PLATE
AINLESS STEEL INSERT
WN PROVIDED)
DRILL (4)
5/32 in. DIA.
HOLES
(RETAINING SCREW AND
WRENCH PROVIDED)
PUSH
NC
NO
COM
4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm)
1.25 in.
(32mm)
BUTTON AND SWITCH ASSEMBLY
19060 #6 - 32 x 1 in.
SCREW (2) PROVIDED
19039 SCREW
#6 x 1 1/4 in.
(4) PROVIDED
71100A SURFACE BOX
AVAILABLE IN RED, GREEN,
YELLOW, WHITE OR BLUE
19021 GROUND SCREW
19018 ANCHOR
(4) PROVIDED
BUTTON AND SWITCH ASSEMBLY
19068 SCREW
SELF TAPPING
(4) PROVIDED
1.62 in.
(41mm)
3.18 in.
(81mm)
2.375 in.
(60mm)
.75 in.
(19mm)
1.5 in.
(38mm)
.75 in.
(19mm)
1.56 in.
(40mm)
12-18 AWG
CLOSE ON
ALARM
SINGLE DEVICE
TO NEXT DEVICE
OR EOL DEVICE
INSTALLATION
3.18 (81mm)
1.62 (41mm)
3.25 (82mm)
4.87
(124mm)
PNEUMATIC OPERATED TIMER, OPENS
OR CLOSES CIRCUIT AFTER TIME DELAY.
NO ELECTRICITY TO OPERATE
10 AMP, FOR C CONTACTS
IDEAL FOR SECURITY APPLICATIONS
CORROSION RESISTANT BODY
ADJSTABLE TIME RANGE
PRODUCT DIMENSIONS
CAN BE INSTALLED ON ANY
EXISTING SINGLE GANG BOX
FAST
SLOW
TIME RANGE ADJUSTMENT SCREW
TURN COUNTER CLOCKWISE TO
INCREASE TIMER SPEED.
ADJUSTMENT RANGE - 2 TO 60 SECONDS
FACTORY SETTING - 25 TO 45 SECONDS
SWITCH DATA
RESOLUTION: 2 TO 60 SECONDS
ACCURACY: 10% REPEAT ACCURACY
POWER: NONE TO OPERATE, SWITCHES
UP TO 10 AMPS @ 240 VOLTS
RESET: AT CYCLE END
LIFE CYCLES: 1,000,000
NC
NO
PNEUMATIC TIMER
SWITCH ASSEMBLY
FAST
SLOW
NC
NO
PNEUMATIC TIMER
SWITCH ASSEMBLY
BACKPLATE WITH MOLDED-IN
STAINLESS STEEL INSERT
SWITCH HOUSING MOLDED OF
POLYCARBONATE. CHOOSE RED,
GREEN, YELLOW, WHITE OR BLUE.
ALLEN HEAD
LOCKING SCREW
AND WRENCH
ALSO CAN BE INSTALLED ON ANY
EXISTING SINGLE GANG BOX
BUTTON AND SWITCH ASSEMBLY
19015 WRENCH
(1) PROVIDED
FIGURE C
SURFACE BOX
INSTALLATION
19011 SCREW ALLEN HEAD
#8-32 x 3/8 (1) PROVIDED
10271 SWITCH HOUSING
RED, GREEN, YELLOW,
WHITE AND BLUE
1.62 in.
(41mm)
3.25 in. (82mm)
4.87 in.
(124mm)
PRODUCT DIMENSIONS
1.58 in.
(40mm)
1.375 in.
(35mm)
1.62 in.
(41mm)
3.25 in.(82mm)
4.87 in.
(124mm)
PRODUCT DIMENSIONS
1.56 in.
(40mm)
"A"
TO PROVIDE ADEQUATE CLEARANCE FOR CONTACTS,
(#0, #1, #3, #4) INSTALLATION
MAY REQUIRE: SUB-102722-COLOR SPACER
1.62 in.
(41mm)
3.25 in.(82mm)
4.87 in.
(124mm)
1.58 in.
(40mm)
"A"
19021 GROUND SCREW
BUTTON AND SWITCH ASSEMBLY
19060 SCREW #6-32 x 1 in.
(2) PROVIDED
19039 SCREW #6 x 1-1/4 in.
(4) PROVIDED
71100A-COLOR SURFACE BOX
19018 ANCHOR
(4) PROVIDED
DRILL (4) 3/16 in.
DIA HOLES
J
J
J
J
HSWITCH BACKPLATE
MOUNTING HOLES
BOX MUST BE INSTALLED WITH
ARROWS POINTING UPWARD
THESE HOLES MUST BE
DRILLED OUT USING A
5/32 in. DRILL BIT
H
DRILL POINT LOCATIONS PROVIDED
TOP AND BOTTOM FOR 1/2 in.
CONDUIT FITTINGS.
DRILL AS NEEDED
DRILL POINT LOCATIONS PROVIDED
TOP AND BOTTOM FOR 1/2 in.
CONDUIT FITTINGS.
DRILL AS NEEDED
71100A BOX (SURFACE MOUNT)
RED, GREEN, YELLOW, WHITE AND BLUE
19039 SCREW #6 x 1-1/4 in.
(4) PROVIDED
PNEUMATIC TIMER MODEL
WITH PROVIDED
SURFACE BACKBOX
19060 SCREW #6-32 x 1 in.
(2) PROVIDED
BUTTON AND SWITCH ASSEMBLY
19021 GROUND SCREW
19018 ANCHOR
(4) PROVIDED
THIS VIEW FOR PAGE 6
DRILL (4)
3/16 DIA. HOLES
DRILL POINT LOCATIONS PROVIDED
TOP AND BOTTOM FOR 1/2 in.
CONDUIT FITTINGS.
DRILL AS NEEDED
71100A BOX (SURFACE MOUNT)
RED, GREEN, YELLOW, WHITE AND BLUE
19039 SCREW #6 x 1-1/4 in.
(4) PROVIDED
PNEUMATIC TIMER MODEL
WITH PROVIDED
SURFACE BACKBOX
19060 SCREW #6-32 x 1 in.
(2) PROVIDED
BUTTON AND SWITCH ASSEMBLY
19021 GROUND SCREW
19018 ANCHOR
(4) PROVIDED
THIS VIEW FOR PAGE 6
DRILL (4)
3/16 DIA. HOLES
BACKPLATE WITH MOLDED-IN
STAINLESS STEEL INSERT
SWITCH HOUSING MOLDED
OF POLYCARBONATE. CHOOSE
RED, GREEN, YELLOW,
WHITE OR BLUE.
ALLEN HEAD
LOCKING SCREW
AND WRENCH
DRILL POINT LOCATIONS PROVIDED
TOP AND BOTTOM FOR 1/2 in.
CONDUIT FITTINGS.
DRILL AS NEEDED
71100A BOX (SURFACE MOUNT)
RED, GREEN, YELLOW, WHITE AND BLUE
19039 SCREW #6 x 1-1/4 in.
(4) PROVIDED
PNEUMATIC TIMER MODEL
WITH PROVIDED
SURFACE BACKBOX
19060 SCREW #6-32 x 1 in.
(2) PROVIDED
19021
GROUND SCREW
19018 ANCHOR
(4) PROVIDED
DRILL (4)
3/16 DIA. HOLES
.728 in.
(18.49mm)
2.4 in.
(60.96mm)
3.218 in.
(81.74mm)
4.132 in.
(104.95mm)
4.83 in.
(122.68mm)
1.578 in.
(40.08mm)
(104.95mm)
4.132 in.
3.25 in.(82mm)
(40mm)
1.58 in.
1mm)(4
1.62 in.
OP AND BT
DRILL POINT L
DRILL (4)
OR 1/2 in.M FOTTOOP AND B
VIDEDOTIONS PROCADRILL POINT L
4.83 in.
(81.74mm)
3.218 in.
(60.96mm)
2.4 in.
(40.08mm)
1.578 in.
(81.74mm)
3.218 in.
(60.96mm)
2.4 in.
(40.08mm)
1.578 in.
(124mm)
4.87 in.
3.25 in.(82mm)
"A"
(40mm)
1.56 in.
3.25 in.(82mm)
(41mm)
1.62 in.
(40mm)
1.56 in.
3/16 DIA
S NEEDEDDRILL A
ONDUIT FITC
OP AND BT
RED
71100A B
. HOLES3/16 DIA
DRILL (4)
S NEEDED
.TINGSONDUIT FIT
OR 1/2 in.M FOTTOOP AND B
UEO
OUNT)CE MAX (SURFO71100A B
CE BASURF
WITH PR
TIC TIMER MPNEUMA
VIDEDO(4) PR
1/4 in.-19039 SCREW #6 x 1
VIDEDO(2) PR
32 x 1 in.-19060 SCREW #6
XOCKBACE B
VIDEDOWITH PR
ODELTIC TIMER M
32 x 1 in.
(18.49mm)
.728 in.
ACCURACY: 10% REPEAT ACCURACY
RESOLUTION: 2 TO 60 SECONDS
SWITCH DATA
FACTORY SETTING - 25 TO 45 SECONDS
ADJUSTMENT RANGE - 2 TO 60 SECONDS
INCREASE TIMER SPEED.
TURN COUNTER CLOCKWISE TO
TIME RANGE ADJUSTMENT SCREW
ACCURACY: 10% REPEAT ACCURACY
RESOLUTION: 2 TO 60 SECONDS
SWITCH DATA
FACTORY SETTING - 25 TO 45 SECONDS
ADJUSTMENT RANGE - 2 TO 60 SECONDS
INCREASE TIMER SPEED.
TURN COUNTER CLOCKWISE TO
TIME RANGE ADJUSTMENT SCREW
SLOW
FAST
SLOW
FAST
3.18 (81mm)
(124mm)
4.87
3.25 (82mm)
1.62 (41mm)
OO PRT
(124mm)
4.87 in.
"A"
CER OLC-102722-: SUBQUIRE
TIONALLAT, #4) INS, #3, #1(#0
,SCTAONTOR CARANCE FTE CLEAQUVIDE ADEO
VIDEDO(4) PR
19018 ANCHOR
VIDED
19018 ANCHOR
OUND SCREW19021 GR
S
CH AWITON AND STBUT
GE 6
THIS VIEW F
LIFE CYCLES: 1,000,000
RESET: AT CYCLE END
UP TO 10 AMPS @ 240 VOLTS
POWER: NONE TO OPERATE, SWITCHES
ACCURACY: 10% REPEAT ACCURACY
SWITCH ASSEMBLY
PNEUMATIC TIMER
NO
NC
LIFE CYCLES: 1,000,000
RESET: AT CYCLE END
UP TO 10 AMPS @ 240 VOLTS
POWER: NONE TO OPERATE, SWITCHES
ACCURACY: 10% REPEAT ACCURACY
NC
ADJSTABLE TIME RANGE
CORROSION RESISTANT BODY
IDEAL FOR SECURITY APPLICATIONS
10 AMP, FOR C CONTACTS
NO ELECTRICITY TO OPERATE
OR CLOSES CIRCUIT AFTER TIME DELAY.
PNEUMATIC OPERATED TIMER, OPENS
PRODUCT DIMENSIONS
3.25 in. (82mm)
(40mm)
1.58 in.
1mm)(4
1.62 in.
PRODUCT DIMENSIONS
S NEEDEDDRILL A
ONDUIT FITC
OP AND BT
DRILL POINT L
S NEEDED
.TINGSONDUIT FIT
OR 1/2 in.M FOTTOOP AND B
VIDEDOTIONS PROCADRILL POINT L
PNEUMA
X
OCKBACE BASURF
VIDEDOWITH PR
ODELTIC TIMER MPNEUMA
SWITCH ASSEMBLY
PNEUMATIC TIMER
NO
3.25 in. (82mm)
(40mm)
(124mm)
4.87 in.
1mm)(4
3/16 DIA
S NEEDEDDRILL A
ONDUIT FITC
OOP AND BT
DRILL POINT L
71100A B
X
OCKBACE BASURF
(4) PR
19039 SCREW #6 x 1
. HOLES3/16 DIA
DRILL (4)
T
TEEL INSERS SAINLESTS
-IN OLDED
AB
S NEEDED
.TINGS
OR 1/2 in.M FOTTO
VIDEDOTIONS PROCADRILL POINT L
UE
O
, GREEN, YELL
OUNT)CE MAX (SURFO71100A B
VIDEDO(4) PR
1/4 in.-19039 SCREW #6 x 1
32 x 1 in.-19060 SCREW #6
CE B
WITH PR
TIC TIMER MPNEUMA
. HOLES3/16 DIA
DRILL (4)
PRODUCT DIMENSIONS
S NEEDEDDRILL A
.TINGSONDUIT FITC
OR 1/2 in.M FOTTOOP AND BT
VIDEDOTIONS PROCADRILL POINT L
XOCKBACE B
VIDEDOWITH PR
ODELTIC TIMER M
(35mm)
1.375 in.
PRODUCT DIMENSIONS
CH AWITON AND STBUT SCH A
O(4) PR
19018 ANCHOR
VIDEDO
19018 ANCHOR
OUND SCREWGR
19021
AND WRENCH
OCKING SCREWL
ADALLEN HE
WHITE OR BL
OF POL
CH HOUSING MWITS
OUND SCREW
VIDEDO(2) PR
AND WRENCH
OCKING SCREW
AD
.UEWHITE OR BL
O, GREEN, YELL
. CHOOSETEONACARB
OLDEDCH HOUSING M
VIDEDO(4) PR
19018 ANCHOR
S
O, GREEN, YELLRED
OUNT)CE MAX (SURFO71100A B
VIDEDO(4) PR
1/4 in.-19039 SCREW #6 x 1
TTEEL INSERS SAINLESTS
-IN OLDEDTE WITH MCKPLAAB
UE, WHITE AND BL
OUNT)
1/4 in.
VIDEDO(2) PR
32 x 1 in.-19060 SCREW #6
RED
10271 S
UEWHITE AND BL
O, GREEN, YELLRED
CH HOUSINGWIT10271 S
VIDEDO32 x 3/8 (1) PR-#8
AD19011 SCREW ALLEN HE
VIDEDO(1) PR
19015 WRENCH
EXISTING SINGLE GANG BOX
CAN BE INSTALLED ON ANY
EXISTING SINGLE GANG BOX
CAN BE INSTALLED ON ANY
OR PTHIS VIEW F
OUND SCREW19021 GR
CH AWITON AND STBUT
GE 6
.UEOGREEN, YELL
TEONACARB
OLDED OF CH HOUSING MWITS
OUND SCREW
S
CH A
AND WRENCH
OCKING SCREWL
ADALLEN HE
AND WRENCH
OCKING SCREW
AD
J
OUNTING HOLESM
ACH BWITS
H
J
ALLED WITHTT BE INSUSX MOB
TE
ALLED WITH
(4) PR
19018 ANCHOR
DIA HOLES
DRILL (4) 3/16 in.
VIDEDO(4) PR
19018 ANCHOR
XOCE BAOR SURFOLC-71100A
VIDEDO(4) PR
1/4 in.-19039 SCREW #6 x 1
J
TIONALLATINS
XOCE B
FIGURE C
J
WS POINTING UPWOARR
ALLED WITHTT BE INSUSX MOB
5/32 in. DRILL BIT
DRILLED OUT USING A
T BEUSTHESE HOLES M
H
ARDWS POINTING UPW
ALLED WITH
5/32 in. DRILL BIT
DRILLED OUT USING A
T BE
SEMBLSCH AWITON AND STBUT
OUND SCREW19021 GR
Y
SEMBL
SEMBLY
VIDEDO(2) PR
19060 SCREW #6
VIDED
32 x 1 in.-19060 SCREW #6
XOTING SINGLE GANG BEXIS
ALLED ON ANYTALSO CAN BE INS ALLED ON ANY
INSTALLATION NOTE
ADA mounting compliance
requires the operable part of
the initiating device shall not
be less than 1.1m (3 1/2 ft.) or
greater than 1.37m (4 1/2 ft.)
above finished floor service.

KEY RESET PROCEDURE
- 6 -
ONCE KEY HAS BEEN INSERTED IN
SLOTS, PUSH KEY, BUTTON WILL
SPRING OUTWARD. BUTTON IS
NOW READY FOR USE.
TO RESET BUTTON, INSERT KEY
INTO THE TWO SLOTS UNDER
BOTTOM SIDE OF BUTTON
INCORRECT METHOD OF
INSERTING MULTIPLE LEADS
(BOTH WIRES ON
ONE SIDE OF SCREW)
CORRECT METHOD OF
INSERTING MULTIPLE LEADS
(1 WIRE EACH
SIDE OF SCREW)
STRIP
3/8 in. (9mm)
FIGURE F
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY
(CONCAVE SIDE UP)
WITH 2 SLOTS
UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY (CONCAVE SIDE UP)
WITH 2 SLOTS UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PART #18061
PART #18061
ONCE KEY HAS BEEN INSERTED IN
SLOTS, PUSH KEY, BUTTON WILL
SPRING OUTWARD. BUTTON IS
NOW READY FOR USE.
TO RESET BUTTON, INSERT KEY
INTO THE TWO SLOTS UNDER
BOTTOM SIDE OF BUTTON
INCORRECT METHOD OF
INSERTING MULTIPLE LEADS
(BOTH WIRES ON
ONE SIDE OF SCREW)
CORRECT METHOD OF
INSERTING MULTIPLE LEADS
(1 WIRE EACH
SIDE OF SCREW)
STRIP
3/8 in. (9mm)
FIGURE F
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY
(CONCAVE SIDE UP)
WITH 2 SLOTS
UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY (CONCAVE SIDE UP)
WITH 2 SLOTS UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PART #18061
PART #18061
ONCE KEY HAS BEEN INSERTED IN
SLOTS, PUSH KEY, BUTTON WILL
SPRING OUTWARD. BUTTON IS
NOW READY FOR USE.
TO RESET BUTTON, INSERT KEY
INTO THE TWO SLOTS UNDER
BOTTOM SIDE OF BUTTON
INCORRECT METHOD OF
INSERTING MULTIPLE LEADS
(BOTH WIRES ON
ONE SIDE OF SCREW)
CORRECT METHOD OF
INSERTING MULTIPLE LEADS
(1 WIRE EACH
SIDE OF SCREW)
STRIP
3/8 in. (9mm)
FIGURE F
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY
(CONCAVE SIDE UP)
WITH 2 SLOTS
UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY (CONCAVE SIDE UP)
WITH 2 SLOTS UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PART #18061
PART #18061
VIEW IN DIRECTION OF ARROW A
A

MODELS
WITHOUT BACKBOX
MODELS
WITH BACKBOX
PRODUCT DIMENSIONS
10/16
WARRANTY
Three year guarantee against breakage of polycarbonate in normal use
(one year on electro mechanical and electronic components).
Electronic warranty form at www.sti-usa.com/wc14.
2306 Airport Rd • Waterford, MI 48327
Phone: [phone] • Fax: [phone]
800-888-4STI (4784) • www.sti-usa.com
European Oce
Taylor House • 34 Sherwood Road • Bromsgrove
Worcestershire • B60 3DR • England • Tel: [phone]
Fax: [phone]
E-mail: [email protected]om • Web: www.sti-europe.com
PUSH
NC
NO
COM
4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm)
1.25 in.
(32mm)
1.62 in.
(41mm)
3.18 in.
(81mm)
1.56 in.
(40mm)
USA - Headquarters
