CTI COM Express PMC/XMC Lite Carrier User manual
COM Express PMC/XMC Lite Carrier
Connect Tech Inc. Tel: 519-836-1291
42 Arrow Road Toll: 800-426-8979 (North America only)
Guelph, Ontario Fax: 519-836-4878
N1K 1S6 Email: sales@connecttech.com
www.connecttech.com support@connecttech.com
CTIM-00440 Revision 0.04 2017-09-11
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 2 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Table of Contents
Table of Contents...................................................................................................................................2
Preface...................................................................................................................................................4
Disclaimer .......................................................................................................................................................4
Customer Support Overview...........................................................................................................................4
Contact Information ........................................................................................................................................4
Limited Product Warranty...............................................................................................................................5
Copyright Notice.............................................................................................................................................5
Trademark Acknowledgment..........................................................................................................................5
ESD Warning ..................................................................................................................................................6
Revision History ....................................................................................................................................6
Introduction...........................................................................................................................................7
Product Features and Specifications................................................................................................................7
Part Numbers / Ordering Information .............................................................................................................7
Product Overview..................................................................................................................................8
Block Diagram ................................................................................................................................................8
Connector Summary........................................................................................................................................9
Jumper Summary.............................................................................................................................................9
Detailed Feature Pinouts and Functional Descriptions .........................................................................10
Serial/GPIO...................................................................................................................................................10
J7 Jumper –GPIO-V ..........................................................................................................................10
VGA Video ...................................................................................................................................................11
COM Express Module...................................................................................................................................11
LVDS Video..................................................................................................................................................12
J1 Jumper –LVDS PANEL................................................................................................................12
miniPCIe/mSATA Slots................................................................................................................................13
Dual Function miniPCIe/mSATA Slots .............................................................................................13
J4A,J4 Jumper –mSATA/miniPCIe...................................................................................................13
Half and Full Length miniPCIe/mSATA module Installation............................................................14
SIM Socket.........................................................................................................................................15
External SATA..............................................................................................................................................16
CPU Fan........................................................................................................................................................17
System and Miscellaneous Connector...........................................................................................................18
HD Audio Connector ....................................................................................................................................19
Software Support for the CS4207.......................................................................................................19
USB 2.0 Connector .......................................................................................................................................19
DisplayPort Connector ..................................................................................................................................20
DisplayPort-HDMI/DVI Switching....................................................................................................20
10/100/1000 Ethernet (GBE).........................................................................................................................21
USB 3.0/2.0 Connector .................................................................................................................................21
microSD CARD Connector...........................................................................................................................22
J8 Jumper –USB................................................................................................................................22
Input Power and Control ..............................................................................................................................23
J6 Jumper –Shutdown........................................................................................................................23
J6 Jumper –Power Control.................................................................................................................23
RTC Battery ..................................................................................................................................................24
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 3 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
J2 Jumper –RTC Battery ...................................................................................................................24
J3 Jumper –RTC Battery ...................................................................................................................24
XMC 25
PMC 26
Typical Hardware Installation Procedure ............................................................................................27
On-board Indicator LEDs..............................................................................................................................27
Thermal Details ...................................................................................................................................28
Mechanical Details...............................................................................................................................28
Cables and Cable Kit Information .......................................................................................................29
Cable Kits......................................................................................................................................................29
CKG028 –“Full” Cable Kit ...............................................................................................................29
CKG021 –“Starter” Cable Kit ...........................................................................................................29
Additional Available Cables...............................................................................................................29
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 4 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Preface
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is
subject to change without notice.
Connect Tech assumes no liability for any damages incurred directly or indirectly from any technical or
typographical errors or omissions contained herein or for discrepancies between the product and the user’s
guide.
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the Connect Tech
reseller from which you purchased the product. In most cases the reseller can help you with product
installation and difficulties.
In the event that the reseller is unable to resolve your problem, our highly qualified support staff can assist
you. Our support section is available 24 hours a day, 7 days a week on our website at:
www.connecttech.com/sub/support/support.asp. See the contact information section below for more
information on how to contact us directly. Our technical support is always free.
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Email/Internet
www.connecttech.com
Note:
Please go to the Download Zone or the Knowledge Database in the Support Center on the Connect Tech
website for product manuals, installation guides, device driver software and technical tips.
Submit your technical support questions to our customer support engineers via the Support Center on the
Connect Tech website.
Telephone/Facsimile
Technical Support representatives are ready to answer your call Monday through Friday, from 8:30 a.m. to
5:00 p.m. Eastern Standard Time. Our numbers for calls are:
Toll Free: 800-426-8979 (North America only)
Telephone: 519-836-1291 (Live assistance available 8:30 a.m. to 5:00 p.m. EST,
Monday to Friday)
Facsimile: 519-836-4878 (on-line 24 hours)
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 5 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Limited Product Warranty
Connect Tech Inc. provides a two-year Warranty for the COM Express®PMC/XMC Lite Carrier. Should
this product, in Connect Tech Inc.'s opinion, fail to be in good working order during the warranty period,
Connect Tech Inc. will, at its option, repair or replace this product at no charge, provided that the product
has not been subjected to abuse, misuse, accident, disaster or non-Connect Tech Inc. authorized
modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business
partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc. must
be pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number marked on
the outside of the package and sent prepaid, insured and packaged for safe shipment. Connect Tech Inc.
will return this product by prepaid ground shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product. This is
defined as the period during which all components are available. Should the product prove to be
irreparable, Connect Tech Inc. reserves the right to substitute an equivalent product if available or to retract
the Warranty if no replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no circumstances will
Connect Tech Inc. be liable in any way for any damages, including any lost profits, lost savings or other
incidental or consequential damages arising out of the use of, or inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech Inc. shall
not be liable for errors contained herein or for incidental consequential damages in connection with the
furnishing, performance, or use of this material. This document contains proprietary information that is
protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced,
or translated to another language without the prior written consent of Connect Tech, Inc.
Copyright
2016 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred to in this
document as the property of their respective owners. Not listing all possible trademarks or copyright
acknowledgments does not constitute a lack of acknowledgment to the rightful owners of the trademarks
and copyrights mentioned in this document.
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 6 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any circuit
board assemblies including Connect Tech COM Express
carrier assemblies, it is recommended that ESD safety
precautions be observed. ESD safe best practices include,
but are not limited to:
Leaving circuit boards in their antistatic packaging
until they are ready to be installed.
Using a grounded wrist strap when handling circuit
boards, at a minimum you should touch a grounded
metal object to dissipate any static charge that may be
present on you.
Only handling circuit boards in ESD safe areas, which
may include ESD floor and table mats, wrist strap
stations and ESD safe lab coats.
Avoiding handling circuit boards in carpeted areas.
Try to handle the board by the edges, avoiding contact
with components.
Revision History
Revision
Date
Changes
0.00
2015-04-02
Original
0.01
2016-06-07
Revised Warranty Policy
0.02
2016-11-28
Update format, jumpers information place in respective feature
section. Added RTC battery information.
0.03
2017-07-12
Added cable drawing links, removed drawings from doc
0.04
2017-09-11
Corrected title
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 7 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Introduction
Connect Tech’s PMC/XMC Lite Carrier is an extremely small carrier board featuring rugged, locking
connectors and offers the ultimate durability. The PMC/XMC Lite Carrier is ideal for space constrained
applications, harsh environments, demanding conditions and supports extended temperature ranges of -
40°C to +85°C.
Product Features and Specifications
Specifications
COM Express Compatibility
COM Express® Type 6 (PCIMG COM Express® COM.0 R2.1)
MiniPCIe Expansion / mSATA
(Switchable)
2 slots (with PCIe, USB and SATA connections)
2 mSATA slots (capable of SATA III)
PMC Expansion
2 PMC (PCI) Expansion ports for additional I/O expansion
XMC Expansion
2 x8 lane XMC (PCIe) Expansion ports for additional I/O expansion
DisplayPort++
2 outputs from COM Express (Can be used for HDMI, DVI or VGA)
VGA Video
1 Analog CRT VGA Port
LVDS Video
18-24-bit LVDS
Gigabit Ethernet
2 x 10/100/1000 Ethernet Ports
USB 2.0
2 USB 2.0 Ports
USB 3.0
4 USB 3.0 Ports (Can also function as USB 2.0 ports)
HD Audio
1 stereo input, 1 stereo output
RS-232
1 COM Express console port
GPIO
8 -bits (Buffered 4in/4out, +3.3V or +5V selectable)
Ext SATA
2 external SATA connectors (capable of SATA III)
SD Card
1 micro SD Card slot (from USB Host controller, with bootable option)
System Interfaces
I2C, SMBus, S3 Power Level Output, Reset Output
I/O Connector Type
Rugged Locking Positive Latching 2mm Pitch Connectors
Input Power
Single wide input rage +12V to +48V DC
RTC Battery
On-board 3V 48mAh (BR1125A )
Option to connect external RTC battery.
Dimensions
190mm x 195mm
Download 3D Model Here (28MB)
Weight
254g
Operating Temperature Range
-40°C to +85°C
Part Numbers / Ordering Information
Part Number
CCG016
Standard Model
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 8 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Product Overview
Block Diagram
DisplayPort/HDMI 0
VGA
LVDS
10/100/1000
Ethernet Port-0
10/100/1000
Ethernet Port-1
USB 3.0/2.0 Port-0
Audio
Input / Output
mSATA/mini PCIe
Slot-0
1 x RS-232
GPIO / RS-232
Console Port
USB 2.0 Port 0
USB 2.0 Port 1
GBE Controller
Intel 82574L
HD Audio Codec
Cirrus Logic CS4207
PCIe x1
HDA
PCIe x1
SATA2
USB
mSATA/mini PCIe
Slot-1
PCIe x1
SATA3
USB
SIM Card
Socket
SD Card
SDIO
GPIO
TX0/RX0
DDI-1
DDI-2
GBE
GBE
SATA1
SATA1
SATA0
USB 3.0/2.0 Port-1
USB 3.0/2.0 Port-2
USB 3.0/2.0 Port-3
DisplayPort/HDMI 1
USB-to-SDIO
Host Controller
Microchip USB2244I
USB
+12V to +48V
Input
On-Carrier ATX
Compliant Power Supply
12V/5VSB
PCI Bridge
PLX 8112
PCIe x1
XMC 0
XMC 1
COM Express Type-6
CPU Module
PCIe x8
PCIe x8
PMC 1
PMC 0
Ind.SATA NAND
(optional)
SATA0
SATA0
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 9 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Connector Summary
Designator
Connector
Description
J15A
XMC 0
XMC connector (x8 PCIe)
J15B
XMC 1
XMC connector (x8 PCIe)
J11A/J12A
PMC 0
PMC connector (PCI Bus)
J11B/J12B
PMC 1
PMC connector (PCI Bus)
P13
SERIAL/GPIO
RS-232 Serial Port with GPIO
P19
VGA
VGA Display Connector
P1
COM Express
COM Express Type 6 Connector
P6
LVDS
LVDS Display Connector
P7A
miniPCIe/mSATA 0
miniPCIe/mSATA Slot 0
P7B
miniPCIe/mSATA 1
miniPCIe/mSATA Slot 1
P14A
EXT SATA 0
External SATA Plug 0
P14B
EXT SATA 1
External SATA Plug 1
P16
CPU FAN
CPU Fan Connector
P17
SYSTEM/MISC
System Header Connector
P15
SIM CARD
SIM Card Connector (Connects to P7A)
P5
AUDIO
HD Audio Connector
P2
USB PORT 6-7
USB 2.0 Ports 6 and 7
P4A
GBE 0
Gigabit Ethernet 0
P4B
GBE 1
Gigabit Ethernet 0
P18A
USB2.0/3.0 Ports 0-1
USB 2.0 and USB 3.0 Ports 0 and 1
P18B
USB2.0/3.0 Ports 2-3
USB 2.0 and USB 3.0 Ports 2 and 3
P3A
DP/HDMI 0
COM Express DisplayPort 0
P3B
DP/HDMI 1
COM Express DisplayPort 1
P20
SD CARD
microSD Card Connector
P11/P12
Power Output (+12V,+5V)
Power output for SATA and/or LVDS
P10
PWR
Vertical Screw Terminal Power Connector
Jumper Summary
Designator
Jumper
Description
J1
LVDS PANEL
selection for the LVDS PANEL VCC (Can be +3.3V, +5V or +12V)
J2
BAT
selection for on-board RTC battery or external RTC battery
J3
RTC
selection to Enable RTC battery or Clear
J4
mSATA/miniPCIe
selection for either MiniPCIe or mSATA
J5
Power Control
selection for Power Good signal, or +3.3V Stand By override
J6
Shutdown Control
COM Express shutdown functionality enable/disable.
J7
GPIO-V
selection for the GPIO VCC (Can be +3.3V or +5V)
J8
USB
selection for USB 2.0 Port 7. Used to select Client USB or SD Card.
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 10 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Detailed Feature Pinouts and Functional Descriptions
Serial/GPIO
The CCG016 allows access to the COM Express modules GPIO by routing them out to a GPIO header. Also
present is a direct connected RS-232 signal that utilizes the COM Express module’s UART.
Function
RS-232 Serial and GPIO
Location
P13
Type
FCI Minitek Double Row 10 x 2
P/N
98424-G06-20LF
Cable
CBG121
Pinout
Pin
Description
Pin
Description
1
GPI0
2
GPO3
3
GPI1
4
GPO2
5
GPI2
6
GPO1
7
GPI3
8
GPO0
9
GND
10
-
11
-
12
-
13
RS-232 RX
14
-
15
RS-232 TX
16
-
17
-
18
-
19
GND
20
-
J7 Jumper –GPIO-V
Function
GPIO Power
Location
J7
Modes
Position
Description
+5V
GPIO +5V
+3.3V
GPIO +3.3V
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 11 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
VGA Video
To allow for greater flexibility, the CCG016 provides a VGA Video output. Routed directly from the COM
Express Type 6, this provides additional video output formats for operation.
Function
VGA Video
Location
P19
Type
FCI Minitek Double Row 5 x 2
P/N
98424-G52-10LF
Cable
CBG120
Pinout
Pin
Description
Pin
Description
1
DAC RED
2
GND
3
DAC GREEN
4
-
5
DAC BLUE
6
SC DDC
7
HSYNC
8
SD DDC
9
VSYNC
10
GND
COM Express Module
The processor and chipset are implemented on the CCG016s COM Express Type 6 module, which connects to
the CCG016 Carrier Board via a Tyco fine pitch stacking connector.
Function
COM Express interface
Location
P1
Type
TE Connectivity Board to Board Connector
Carrier
Connector
P/N
3-6318491-6
Manufacturer: TE Connectivity
Mating
Connector
P/N
3-1827231-6
Manufacturer: TE Connectivity
Pinout
Refer to COM Express R2.0 specification,
Type-6
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 12 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
LVDS Video
The CCG016 provides dual 18 or 24 bit LVDS display channels via P9, which are connected directly from the
COM Express Type 6 module.
The external SATA power connectors can also be used to provide power to LVDS screen.
Function
LVDS Video
Location
P6
Type
Hirose Low Profile Board to Cable Connector
P/N
DF20G-40DP-1V(56)
Pinout
Pin
Description
Pin
Description
1
LVDS B0-
2
PANEL VCC[1]
3
LVDS B0+
4
PANEL VCC[1]
5
GND
6
GND
7
LVDS B1-
8
GND
9
LVDS B1+
10
LVDS A0-
11
GND
12
LVDS A0+
13
LVDS B2-
14
GND
15
LVDS B+
16
LVDS A1-
17
GND
18
LVDS A1+
19
LVDS B CLK-
20
GND
21
LVDS B CLK+
22
LVDS A2-
23
GND
24
LVDS A+
25
LVDS B3-
26
GND
27
LVDS B3+
28
LVDS A CLK-
29
GND
30
LVDS A CLK+
31
GND
32
GND
33
LVDS PPEN
34
LVDS A3-
35
-
36
LVDS A3+
37
LVDS BLT CTRL
38
LVDS BLC CLK
39
LVDS BLEN
40
LVDS BLC DAT
Note [1]: This voltage can be selected from Jumper J2 to be +3.3V, +5V, or +12V
J1 Jumper –LVDS PANEL
Function
LVDS PANEL Power
Location
J2
Modes
Position
Description
+12V
LVDS PANEL Power +12V
+5V
LVDS PANEL Power +5V
+3.3V
LVDS PANEL Power +3.3V
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 13 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
miniPCIe/mSATA Slots
Dual Function miniPCIe/mSATA Slots
The CCG016 has two special dual purpose miniPCIe/mSATA slots. Each of these slots can accept either a
miniPCIe module or an mSATA SSD module. These slots have special circuitry that allows for the selection
between connecting PCIe lanes or SATA lanes.
Each of these slots are also provided with a USB 2.0 in addition to the PCIe as per the mini PCIe specification,
see below for a block diagram of the slots functionality.
miniPCIe/mSATA Dual Functionality Diagram*
*Please note, a SIM card is only availabe on miniPCIe/mSATA slot 0
J4A,J4 Jumper –mSATA/miniPCIe
Jumper Location
Jumper ON
Jumper OFF
J4A
Slot 0 miniPCIe
Slot 0 mSATA
J4B
Slot 1 miniPCIe
Slot 1 mSATA
Function
mSATA/miniPCIe Switching[11]
Location
J4
Modes
Position
Description
A
Slot 0 (ON –MiniPCIe)
B
Slot 1 (ON –MiniPCIe)
Note [11]: See mSATA/miniPCIe Slots for detailed description of functionality
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 14 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
Half and Full Length miniPCIe/mSATA module Installation
The CCG016 comes with dual mounting solutions to allow for the population of a half and a full length
module. If you would prefer to have a single slot or both slots populated with half-length hardware at the time
of your production order please contact sales@connecttech.com for further details.
Function
miniPCIe/mSATA Slots
Location
P7A, P7B
Type
Molex Edge Card Connector
P/N
0679105700
Pinout
Pin
miniPCIe
Description
mSATA Description
1
-
-
2
+3.3V
+3.3V
3
-
-
4
GND
GND
5
-
-
6
+1.5V
+1.5V
7
CLKREQ#
-
8
UIM_PWR
-
9
GND
GND
10
UIM_DATA
-
11
PCIe CLK+
-
12
UIM_CLK
-
13
PCIe CLK-
-
14
UIM_RESET
-
15
GND
GND
16
UIM_VPP
-
17
-
-
18
GND
GND
19
-
-
20
W_DISABLE#
-
21
RESV
RESV
22
-
-
23
PCIe RX+
SATA TX+
24
+3.3V
+3.3V
25
PCIe RX-
SATA TX-
26
GND
GND
27
GND
GND
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 15 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
28
+1.5V
+1.5V
29
GND
GND
30
SMB_CLK
-
31
PCIe TX-
SATA RX-
32
SMB_DATA
-
33
PCIe TX+
SATA RX+
34
GND
GND
35
GND
GND
36
USB D-
-
37
GND
GND
38
USB D+
-
39
+3.3V
+3.3V
40
GND
GND
41
+3.3V
+3.3V
42
-
-
43
RESV
RESV
44
-
-
45
-
-
46
-
-
47
-
-
48
+1.5V
+1.5V
49
-
-
50
GND
GND
51
-
-
52
+3.3V
+3.3V
SIM Socket
Function
SIM Socket
Location
P15
Type
Molex Push-Push SIM Card Connector
P/N
0475530001
Pinout
Pin
Description
1
UIM_PWR
2
UIM_RST
3
UIM_CLK
4
-
5
GND
6
UIM_VPP
7
UIM_DATA
8
SHELL
9
SHELL
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 16 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
External SATA
The CCG016 provides two SATA plugs that are SATA-PCIe/104 switched. Please see
SATA-PCIe/104 switching description for additional details.
The CCG016 also provides power for external SATA Hard Drives and/or LVDS screens. The power
connectors can be found next the External SATA connectors.
Function
SATA
Location
P14A, P14B
Type
Molex Vertical Serial ATA Plug
P/N
0471554001
Cable
CBG090
Pinout
Pin
Description
1
GND
2
TX+
3
TX-
4
GND
5
RX-
6
RX+
7
GND
Function
SATA Power
Location
P11,P12, P21
Type
XH Low Profile Crimp Connector
P/N
B4B-XH-AM(LF)(SN)(P)
Cable
CBG090
Pinout
Pin
Description
1
GND
2
+5V
3
GND
4
+12V
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 17 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
CPU Fan
Function
CPU Fan
Location
P16
Type
Molex Solid Header with Friction Lock
P/N
22232031
Cable
Pinout
Pin
Description
1
TACH
2
+VCC
3
GND
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 18 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
System and Miscellaneous Connector
The System header can be used to connect the power button, reset button, and LED’s required to monitor the
module performance or state.
Function
System Controls
Location
P17
Type
FCI Minitek Double Row 10 x 2
P/N
98414-G06-20LF
Cable
CBG116
Pinout
Pin
Description
Pin
Description
1
+5V
2
SPEAKER-
3
-
4
+5V SB
5
RTC BAT EXT
6
GND
7
SYS RESET#
8
GND
9
PWRBTN#
10
GND
11
BATLOW#
12
GND
13
EXT S3#
14
SMB DAT
15
I2C CLK
16
CMB CLK
17
I2C DAT
18
SMB ALERT#
19
+5V
20
-
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 19 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
HD Audio Connector
The CCG016s features HD Audio capabilities with the assistance of the Cirrus Logic CS4207 Codec device.
From the codec, 1 microphone input and 1 headphone output are available.
Function
HD Audio
Location
P5
Type
FCI Minitek Double Row 4 x 2
P/N
98414-G06-08LF
Cable
CBG118
Pinout
Pin
Description
Pin
Description
1
-
2
-
3
MIC IN R
4
MIC IN L
5
GND
6
GND
7
HP OUT R
8
HP OUT L
Software Support for the CS4207
The audio codec used on the Qseven Gen 2.0 carrier board is the CS4207 from Cirrus Logic.
Additional drivers will be needed to properly operate audio on the Qseven Gen 2.0 carrier. Some downloadable
links can be found below.
Windows XP Driver: http://www.cirrus.com/en/pubs/software/CS4207_WinXP_1-0-0-38.zip
Windows 7/Vista Driver: http://www.cirrus.com/en/pubs/software/CS4207_WinVista_Win7_32-64-bit_6-
6001-1-30.zip
Linux Driver: Included in kernels 2.6.30 and up.
USB 2.0 Connector
The CCG016 has multiple USB Ports. USB 2.0 Port 6 is sourced directly from the COM Express module. USB
2.0 Port 7 however has multiple functionality options. Using Jumper J727, Port 7 can either be a Client USB,
or it can be used to connect the SD Card to the COM Express module.
Function
USB 2.0 Ports 6 and 7
Location
P2
Type
FCI Minitek Double Row 4 x 2
P/N
98414-G06-08LF
Cable
CBG104
Pinout
Pin
Description
Pin
Description
1
PORT 6 - VBUS
2
PORT 7 –VBUS[2]
3
PORT 6 –D-
4
PORT 7 –D-[3]
5
PORT 6 –D+
6
PORT 7 –D+[3]
7
PORT 6 –GND
8
PORT 7 –GND
Note [2]: USB 2.0 Port 7 can be optionally be used as client USB. Simply remove the Jumper from J8A to enable
Note [3]: USB 2.0 Port 7 can be optionally be used to enable the SD Card. Simply remove the Jumper from J8B to enable
COM Express® PMC/XMC Lite Carrier
Users Guide
www.connecttech.com
Document: CTIM-00440
Revision: 0.04
Page 20 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2017-09-11
DisplayPort Connector
Two DisplayPort++ connections from the COM Express module are available and can be configured to output
DisplayPort, or HDMI/DVI through the use of the appropriate cable. The configuration of each interface is
setup via the COM Express module’s BIOS settings. Refer to the COM Express module’s documentation for
more details.
Function
DisplayPort Connector
Location
P3A,P3B
Type
FCI Minitek Double Row 10 x 2
P/N
98414-G06-20LF
Mating
10073599-020LF
Cable
CBG113
Pinout
Pin
Description
Pin
Description
1
DP0+
2
DP3+
3
DP0-
4
DP3-
5
GND
6
GND
7
DP1+
8
DPAUX-
9
DP1-
10
DPAUX+
11
GND
12
GND
13
DP2+
14
DP Hot Plug Detect
15
DP2-
16
GND
17
GND
18
GND
19
DP Power
20
DP AUX SEL[4]
Note [4]: Cable assembly must tie high (+3.3V) for adapter output (HDMI/DVI/VGA) and low (GND) for DisplayPort output
DisplayPort-HDMI/DVI Switching
The CCG016 DisplayPort++ connectors can be used to display outputs other than DisplayPort.
On-board switching circuitry to enable HDMI or DVI has been included. The CCG016 COM Express
DisplayPort Connectors may require a change to the COM Express BIOS to swap output formats.
Function
DisplayPort Connector (HDMI/DVI Output)
Location
P3A,P3B
Type
FCI Minitek Double Row 10 x 2
P/N
98414-G06-20LF
Mating
10073599-020LF
Cable
CBG145
Pinout
Pin
Description
Pin
Description
1
TMDS2+
2
TMDS CLK+
3
TMDS2-
4
TMDS CLK-
5
GND
6
GND
7
TMDS1+
8
DDC DATA
9
TMDS1-
10
DDC CLK
11
GND
12
GND
13
TMDS0+
14
Hot Plug Detect
15
TMDS-
16
GND
17
GND
18
GND
19
+3.3V
20
DP/TMDS SEL[5]
Note [5]: Cable assembly must tie high (+3.3V) for HDMI/DVI output
Table of contents
