Cubii Total Body+ User manual
ADJUSTING THE RESISTANCE
Cubii Total Body+ has 12 resistance levels. Adjust
your workout intensity by pressing the plus (+) or
minus (-) button on the built-in display monitor, or via
the Cubii app. Level 1 is the lowest intensity and level
12 is the highest. We recommend you begin at Level 1
and increase the intensity gradually over time.
GETTING YOUR GROOVE
You can use your Cubii Total Body+ in short intervals throughout the day or
for long periods of time. We recommend you begin with a ve minute session,
see how your body feels afterwards, and increase your session length gradually
over time. You can also go forwards or backwards on the Cubii Total Body+
to work different muscle groups.
USING THE RESISTANCE HANDLES
Before using, rmly grasp the handles and place your feet on the pedals or
the base plate of your Total Body+ elliptical. Pull the handles up and out of the
elliptical to a neutral position, and begin your exercise routine. Once nished,
return the handles to their resting position on the elliptical body.
CARRYING AND STORING YOUR TOTAL BODY+
•To store Cubii, simply keep it in a clean dry place.
•Cubii Total Body+ is approximately
20.9”L x 17.6”W x 10.1”H
(53.2cm x 44.7cm x 25.7cm)
• Hold the handle to move Cubii.
For additional support, place your
other hand under the base. Do not
use the pedal arms to move Cubii.
Ask someone for help if you nd
it too heavy to lift.
READING THE DISPLAY CONSOLE
CONTACT
1-844-282-4401
cubii.com/help
support@mycubii.com
Quick Start Guide
Using Your Cubii Total Body+™
Follow the guidelines below to enhance your experience.
Please Note: Cubii Total Body+ is only to be used while sitting. Do not stand on the unit.
v1
User Options:Press the USER button to switch
between User 1, User 2, and Guest. Current selection
indicated by triangle.
Top Row:The top row displays your total number of
strides. A “stride” is the equivalent of one full rotation
of the pedaling motion.
Middle Row: The middle row displays the resistance
level through both a resistance meter and the
resistance level number. For example, when you are at
full resistance, the resistance meter will be completely
solid and the number will read “12”.
Bottom Row: The bottom row displays the metrics:
Press the MODE button to switch between metrics. Use the SCAN mode
to automatically toggle between metrics every 7 seconds.
Bluetooth® Wireless Technology Features: The Bluetooth® symbol
ashes when available to connect to a device. The symbol remains solid
when connected to the Cubii app. The elliptical must be charged to
pair with a device.
Battery Indicator: The number of bars in the battery symbol indicates
battery charge remaining. The symbol will ash for 20 seconds when unit
requires recharging. The symbol ashes while charging and remains solid
when charging is complete. The symbol disappears when not plugged in.
Distance Metric Toggle: To switch between miles and kilometers, use the
MODE button to select the DISTANCE metric, then hold the MODE button
for 6 seconds.
Manual Data Reset: Manually reset workout data for any prole by selecting
the prole, then hold MODE for 3 seconds. This resets data displayed on the
screen for the selected prole.
See the included Owner’s Manual for more features, such as creating a “Smart Reset” to
automatically reset workout data each night, or for info on unlinking proles from the console.
TM
TIME elapsed during active workout
DISTANCE (mi or km) pedaled
CALORIES burned
RPM rotations per minute
(pedaling speed)
WARNING: The maximum recommended extension of the resistance handles is four feet
when using both handles together, and eight feet when using just one. Please do not extend
beyond this threshold. Please only use resistance handles while seated.
The Cubii App
BLUETOOTH®* APP FEATURES
The app supports many features such as:
•Personalize your prole and workout goals
•Track activity and see your progress
•Digitally adjust resistance
•Create or participate in group leaderboards
•Chat with friends and socialize in our
one-of-a-kind Cubii Communitii™
• and much more!
*The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Fitness Cubed Inc is under license.
Other trademarks and trade names are those of their respective owners.
INSTALLING THE CUBII APP
The Cubii app is currently available on your app store by searching for
“Cubii”. For more detailed information on downloading, installing,
or using the Cubii app, see the included Total Body+ Owner’s Manual.
PAIRING WITH THE CUBII APP
To pair with the Cubii app, please follow these instructions:
1. Start pedaling to trigger the Bluetooth® signal. You’ll see the
Bluetooth® symbol glow and start blinking on the display console.
2. Conrm that you’ve enabled Bluetooth® Wireless Technology in
your device’s settings.
3. The app will detect your Cubii elliptical via Bluetooth® Wireless
Technology. Select your elliptical in the app.
4. Once successfully paired, the Bluetooth® symbol will stop blinking.
5. Select if you would like to become User 1, User 2, or proceed as Guest.
6. Start your workout and enjoy your Cubii experience
From here on, every time you launch the app, it will search for all Cubii
devices in your vicinity and automatically connect with an elliptical that it has
already paired with. If it does not automatically reconnect, you can manually
reconnect in the app.
Remove all of the components from the Cubii Total Body+ box.
Included you should nd:
Assembly Guide
Cubii Total Body+ Compact Elliptical
Anchor Hole
Wheel Stopper
Find the seat conguration that suits you most. If you feel there
is not enough room between your knees and the desk, push your
Cubii Total Body+ away from you and lower the chair height.
SECURING YOUR CHAIR
If you’re using Cubii Total Body+ while sitting in a chair with wheels or casters,
follow the steps below:
1. Find the Wheel Stopper that is included with your Total Body+.
2. Lift up the back of your Cubii Total Body+ and place the interfacing
portion of the wheel stopper under the base plate. The nub goes
through the anchor hole.
3. Roll one wheel from your chair onto the circle of the stopper until
it is snug in place.
4. If you feel you are too close to your Cubii, the wheel stopper can be
detached from the base plate and positioned in the location that is best
for your needs.
Find Your Comfort Zone
STEP 1 — Align
Align the right pedal with
the right arm. Insert the
bottom of the pedal into
the two small holes.
STEP 2 — Flip
For maximum support,
make sure you ip the
pedal you are assembling
so it is at the bottom and
close to the base.
STEP 3 — Screw
With a screwdriver,
screw in the pedal until
tight. Make sure it does
not wobble.
STEP 4 — Repeat
Repeat steps 1-3 with
the left pedal.
CHARGING YOUR TOTAL BODY+
The charge port is located above the
crossbar near the front of the unit. Once
plugged in, the screen will power on and the
lightning bolt symbol will ash to indicate the
unit is charging. The symbol will remain solid
when it is fully charged.
A
B
C
D
CUBII TOTAL BODY+ MAIN BODY
LEFT AND RIGHT PEDALS
CHAIR WHEEL STOPPER
SCREWS (X4)
E
F
SCREWDRIVER
CHARGING CABLE
AC POWER ADAPTER
G
A
CD
F
E
B
G
Find detailed product manual, assembly instructions,
and warranty details at cubii.com/manuals
