CUE keyboardCUE-S User manual

User Manual
Small Keyboards
Version 02
CUE, a.s., K Nouzovu 6, 143 00 Praha 4, Czech Republic
Phone: [phone], Fax: [phone]
www.cuesystem.com, [email protected]

User Manual Small Keyboards
UM022_02, 21.05.2007
Copyright © CUE, a.s., Praha, Czech Republic 1990 - 2007.
All rights reserved. Specifications are subject to change without prior notice.

Table of Contents
1. Introduction.................................................................................................................................... 4
1.1. Overview .......................................................................................................................................................................4
1.2. Models...........................................................................................................................................................................4
1.3. Features........................................................................................................................................................................4
1.4. Programming.................................................................................................................................................................4
2. Front Panel..................................................................................................................................... 5
3. Button Labels................................................................................................................................. 6
4. Addressing..................................................................................................................................... 7
4.1. Addressing of keyboardCUE-S (serial number up to CS0174.0128) and keyboardCUE-S /w .....................................7
4.2. Addressing of keyboardCUE-S (serial number CS0174.0129 and above) ...................................................................8
4.2.1. Setting-up of ADDRESS......................................................................................................................................9
4.2.2. Troubleshooting...................................................................................................................................................9
4.2.3. Display ADDRESS...............................................................................................................................................9
4.2.4. Display Firmware version ....................................................................................................................................9
5. Mounting....................................................................................................................................... 10
5.1. keyboardCUE-S ..........................................................................................................................................................10
5.2. keyboardCUE-S /w......................................................................................................................................................10
6. Connecting................................................................................................................................... 11
6.1. keyboardCUE-S ..........................................................................................................................................................11
6.2. keyboardCUE-S /w......................................................................................................................................................11
7. Specifications and Mechanical Drawings................................................................................. 12
7.1. keyboardCUE-S ..........................................................................................................................................................12
7.2. keyboardCUE-S /w......................................................................................................................................................13
8. Software and Firmware License................................................................................................. 14
9. Warranty Conditions ................................................................................................................... 15
10. CE Declaration of Conformity..................................................................................................... 16
11. FCC................................................................................................................................................ 17
User Manual Small Keyboards
www.cuesystem.com
Page 3 of 18

1. Introduction
1.1. Overview....................................................................
The elegant and innovative wired keyboardCUE-S is a tabletop programmable control panel that is
available in varieties of solid wood finishes with stainless steel trim. The keyboardCUE-S provides 8
buttons supported with backlighting and user changeable button labels that can be directly printed on
a laser printer and inserted into the switch caps. The full-function console keyboard may be used as a
dedicated wired controller for audio, video and environmental functions.
The wired keyboardCUE-S /w is a programmable control panel device designed to be built into a table.
Available in a metal enclosure, the keyboardCUE-S /w provides 8 buttons supported with backlighting.
User changeable button labels can be directly printed on a laser printer and inserted into the switch
caps. The full-function console keyboard may be used as dedicated wired controller for audio, video
and environmental functions.
1.2. Models........................................................................
Model Product code Description
keyboardCUE-S CS0174 Tabletop keyboard, (8) buttons
keyboardCUE-S /w CS0146 Built-in keyboard, (8) buttons
1.3. Features .....................................................................
•Backlight buttons
•Programmable feedback indication (tabletop model only)
•User changeable button labels
•Stainless steel front panel and wooden enclosure (tabletop model)
•Tabletop or built-in installation
•System connection by CUEwire
1.4. Programming .............................................................
All keyboards are programmed using Cue Director programming tool. Control commands are
described in the Programming Manual CPL References, chapter Keyboards.
User Manual Small Keyboards
www.cuesystem.com
Page 4 of 18

2. Front Panel
The front panel is equipped with (8) buttons and (8) indication LEDs (tabletop model only) - see
picture.
(8) buttons
(8) button LEDs
(8) buttons
Button LEDs are controlled by special programming commands from a control unit.
User Manual Small Keyboards
www.cuesystem.com
Page 5 of 18

3. Button Labels
The separate labels for each button can be printed on a transparency foil using laser or inkjet printer.
Dimension of the label are
•6.5 mm x 12 mm for normal button
•6.5 mm x 29 mm for double button.
It is necessary to disassembly the control panel to change a label.
Steps are
1. Put the control panel on a table face down.
2. Unscrew the screws.
3. Dismount the bottom of the control panel with electronic board.
4. Install new label.
5. Assembly the control panel.
User Manual Small Keyboards
www.cuesystem.com
Page 6 of 18

4. Addressing
4.1. Addressing of keyboardCUE-S (serial number up to
CS0174.0128) and keyboardCUE-S /w
The ADDRESS of the keyboardCUE-S and keyboardCUE-S /w can be set in the range 0 to 9 by the
firmware. Standard keyboards have address 0, addresses 1 to 9 are delivered on a special order.
The BUTTON_ID transmitted by a panel and BUTTON_LED_ID (tabletop model keyboardCUE-S only)
are numbers used in the programming for button and bargraph identification. Both values depend on a
button position and it depends on a keypad ADDRESS too. Both values are calculated according
formulas
BUTTON_ ID = Offset + Button Code
BUTTON_LED_ID = Offset + Button Code
Offset = 32 * ADDRESS
The lowest BUTTON_ID is generated by a button in the upper left corner the highest BUTTON_ID is
generated by a button in the lower right corner - see example for ADDRESS = 0 on the picture below.
12
34
56
78
12
34
56
78
Button LED Code = 1 Button Code = 1 Button Code = 1
In the table below there is Button ID range for each address.
ADDRESS BUTTON_ID range = BUTTON_LED_ID range
0 1 8
1 33 40
2 65 72
3 97 104
4 129 136
5 161 168
6 193 200
7 225 232
8 257 264
9 289 296
User Manual Small Keyboards
www.cuesystem.com
Page 7 of 18

4.2. Addressing of keyboardCUE-S (serial number
CS0174.0129 and above)
The ADDRESS of the keyboardCUE-S can be set in the range 0 to 255. Default keyboard ADDRESS
is 0.
The BUTTON_ID transmitted by a panel and BUTTON_LED_ID (tabletop model keyboardCUE-S only)
are numbers used in the programming for button and bargraph identification. Both values depend on
a button position and it depends on a keyboard ADDRESS too. Both values are calculated according
formulas
BUTTON_ ID = Offset + Button Code
BUTTON_LED_ID = Offset + Button Code
Offset = 32 * ADDRESS
The lowest BUTTON_ID is generated by a button in the upper left corner the highest BUTTON_ID is
generated by a button in the lower right corner - see example for ADDRESS = 0 on the picture below.
In the table below there is Button ID range for some addresses.
ADDRESS BUTTON_ID range = BUTTON_LED_ID range
0 1 8
1 33 40
2 65 72
… … …
9 289 296
User Manual Small Keyboards
www.cuesystem.com
Page 8 of 18

4.2.1. Setting-up of ADDRESS
SW9
1. Unscrew two screws on bottom side of the keyboard and remove bottom cover.
2. Push switch SW9 on PCB bottom side; backlight LED’s are switched Off to indicate Set
Address Mode.
3. Button LED’s indicate ADDRESS in binary code – Button 1 bit 0, Button 2 bit 1 etc… Push
buttons to toggle address bits to requested value of ADDRESS (see examples on the picture
below).
4. Push switch SW9 to save ADDRESS to non-volatile memory and to enter keyboard Standard
Mode - backlight LED’s are switched On to indicate Standard Mode.
5. Assembly the control panel.
4.2.2. Troubleshooting
Flashing backlight LED’s means non-volatile memory ERROR. Try Power OFF – Power ON sequence
to restart device and set ADDRESS again.
4.2.3. Display ADDRESS
Press and hold Button 1 while powering On. Button LED’s indicate ADDRESS in binary code –
Button 1 bit 0, Button 2 bit 1, .... After 10 sec keyboard continues normal operation.
4.2.4. Display Firmware version
Press and hold Button 2 while powering ON. All LED’s flashes 5 times – FW version 1.05. After 10 sec
keyboard continues normal operation.
User Manual Small Keyboards
www.cuesystem.com
Page 9 of 18

5. Mounting
5.1. keyboardCUE-S...........................................................
The keyboardCUE-S is a tabletop model. There are no special mounting requests.
5.2. keyboardCUE-S /w .....................................................
The keyboardCUE-S /w can be mounted to the table or to the wall box (not delivered).
User Manual Small Keyboards
www.cuesystem.com
Page 10 of 18

6. Connecting
6.1. keyboardCUE-S...........................................................
This model of the keyboard is connected to the system by CUEwire. The keyboard is equipped with 3
m length or 10 m length cable with 4-pin connector. Pin connection of the CUEwire connector is
described in the following table.
CUEwire, 4-pin connector
Pin 1 +24 VDC
Pin 2 GND
Pin 3 A+
1 432
Pin 4 B-
6.2. keyboardCUE-S /w .....................................................
This model of the keyboard is connected to the system by CUEwire.
The keyboard is equipped with 4-pin terminal which is located on the rear side of the keyboard - see
picture below.
PCB
+24 VDC
Ground
A+
B- CUEwire terminal
User Manual Small Keyboards
www.cuesystem.com
Page 11 of 18

7. Specifications and Mechanical Drawings
7.1. keyboardCUE-S...........................................................
Buttons layout......................................(8) buttons
Indication .............................................(8) LEDs
System connection..............................CUEwire (RS-485), 4-pin connector
Power supply.......................................24 VDC (+/- 20%), 3 W
Enclosure.............................................Wood - stainless steel panel
Dimensions (WxHxD)..........................86 mm (3.4”) x 98 mm (3.9”) x 27 mm (1.1”)
Weight..................................................0.4 kg / 1.1 lb
All dimensions are in mm.
User Manual Small Keyboards
www.cuesystem.com
Page 12 of 18

7.2. keyboardCUE-S /w .....................................................
Buttons layout......................................(8) single buttons or (4) double buttons
System connection..............................CUEwire (RS-485), screw terminals
Power supply.......................................24 VDC (+/- 20%), 3 W
Enclosure.............................................Metal, black panel
Dimensions (WxHxD)..........................100 mm (3.9”) x 100 mm (3.9”) x 30 mm (1.2”)
Weight..................................................0.15 kg / 0.4 lb
All dimensions are in mm.
User Manual Small Keyboards
www.cuesystem.com
Page 13 of 18

8. Software and Firmware License
END-USER NOTICE AND LICENSE AGREEMENT FROM CUE, spol. s r.o.
NOTICE TO END-USER
CAREFULLY READ THE FOLLOWING LEGAL AGREEMENT (THIS "LICENSE"). INSTALLATION OR USE OF THE
ENCLOSED CUE, spol. s r.o. SOFTWARE PROGRAMS (COLLECTIVELY, "SOFTWARE") ON YOUR COMPUTER
SYSTEMS OR HARDWARE DEVICES CONSTITUTES YOUR ACCEPTANCE OF THESE TERMS. IF YOU DO NOT AGREE
TO THE TERMS OF THIS LICENSE, PROMPTLY DELETE THE SOFTWARE FROM YOUR COMPUTER SYSTEMS AND
HARDWARE DEVICES, DESTROY ANY COPIES YOU MADE OF THE SOFTWARE OR ANY INSTALLATION MEDIA OF THE
SOFTWARE INCLUDED WITH YOUR SYSTEM, AND DISPOSE OF ALL WRITTEN MATERIALS IN YOUR POSSESSION
REGARDING THE SOFTWARE.
License Grant
CUE grants to You, as an individual, a license to install and use one (1) copy of the Software on a single computer at a time;
provided, however, that You may make copies of the Software solely for Your development of applications for CUE hardware
and demonstration versions of such applications. Any applications created with the Software may only be used with Cue
hardware. Your license to use the Software is conditioned upon Your compliance with the terms of this License. A License is
required for each end-user of the Software. A license is required for each installation of the Software. You may make one (1)
copy of the Software for archival purposes only. You may use this Software only in connection with CUE hardware. You must
have acquired the Software directly in connection with the purchase of CUE hardware from CUE or from a CUE approved
reseller for this license to be effective. If You have purchased a Site License, You may complete only the number of
installations specified in the License Agreement accompanying the Software.
Copyright
The Software and software built into CUE hardware ("Firmware") are protected by copyright law and international treaty
provisions. You acknowledge that no title to the intellectual property in the Software and Firmware is transferred to You. You
further acknowledge that title and full ownership rights to the Software and Firmware will remain the exclusive property of CUE,
and You will not acquire any rights to the Software and Firmware except as expressly set forth in this License. You agree that
any copies of the Software will contain the same proprietary notices which appear on and in the Software.
Prohibited Uses
Without obtaining prior written permission from CUE, You may not (a.) use, copy, modify, alter, or transfer the Software or
documentation except as expressly provided in this License; (b.) translate, disassemble, decompile, reverse program or
otherwise reverse engineer the Software and Firmware; (c.) sublicense or lease the Software or its documentation (d.) use this
Software with any hardware other than products produced by CUE or in connection with applications being developed for CUE
hardware; or (e.) use the Software in a multi-user, network, or multiple computer environment or in a rental, time sharing or
computer service business. Without prejudice to any other rights, CUE may terminate this License if You fail to comply with its
terms and conditions. In such event, You must immediately destroy all copies of the Software.
No Other Warranties
CUE DOES NOT WARRANT THAT THE SOFTWARE AND FIRMWARE IS ERROR FREE. CUE DISCLAIMS ALL
WARRANTIES WITH RESPECT TO THE SOFTWARE AND FIRMWARE, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT OF THIRD PARTY RIGHTS. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED
WARRANTIES OR LIMITATIONS OF HOW LONG AN IMPLIED WARRANTY MAY LAST, OR THE EXCLUSION OF
LIMITATION OF INCIDENTAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM JURISDICTION TO JURISDICTION.
No Liability for Consequential Damages
IN NO EVENT SHALL CUE BE LIABLE TO YOU FOR ANY CONSEQUENTIAL, SPECIAL, INCIDENTAL, OR INDIRECT
DAMAGES OF ANY KIND ARISING OUT OF THE PERFORMANCE OR USE OF THE SOFTWARE, EVEN IF CUE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Label on Hardware
Use of this hardware and the software programs controlling this hardware is subject to the terms of the Software and Hardware
License Agreements (the “License Agreements”). You should not use the software and hardware until you have read the
License Agreements. By using the software and hardware, you signify that you have read the Licenses Agreements and accept
their terms. The “License Agreement” is available at www.cuesystem.com.
Trademark Notice
CUE and the CUE logo are trademarks of CUE spol. s r.o. in the United States and in other countries.
User Manual Small Keyboards
www.cuesystem.com
Page 14 of 18

9. Warranty Conditions
Warranty Duration
CUE provides warranty for all CUE products for a period of 3 years from the day of purchase. The provided warranty for touch
screens is 2 years from the day of purchase. CUE accepts reclamation of 5 not properly working dots and more (2 dots join – 1
counts). The warranty provided for rechargeable accumulators is 6 months from the day of purchase
Liability
CUE is not liable for any consequential damage caused by CUE products including any loss of profits, incidental or
consequential damages or any claims made by a third parties.
General Warranty Terms
a) CUE warrants that its products are without defects in material and are fully functional for the duration of the warranty.
b) Warranty repairs are free of charge. The customer will send the damaged device to CUE at his cost.
c) All warranty repairs and after warranty services are made at CUE premises. It is strictly prohibited to repair CUE
products or to change any accessory parts, except those parts with limited service life. CUE is not liable for
consumables or parts with limited service life (lamps, batteries etc.)
d) The warranty further does not apply to the following cases
•Damages caused by operating the system not according to the conditions defined in user manual or
instruction (wrong power supply voltage, operation outside deferred temperature range, operation in humid
environment and mechanical damages).
•Damages caused by faulty service, maintenance, connection, and use of other than original connection
cable.
•Damage caused by agencies i.e. incidental or unpredictable impacts (fire, earthquake, flood, thunder,
strong electric induction, water, strong wind, theft, vandalism etc.)
After Warranty Services
a) All warranty repairs are normally on a ‘back to base’ basis, as defined in 3 c)
b) All out warranty repair costs will be fully charged to the customer.
c) In cases where our staff are called out to assist, cost of transport and time will be at customer cost
User Manual Small Keyboards
www.cuesystem.com
Page 15 of 18

10. CE Declaration of Conformity
airCUE-XM8
CS0254-W, CS0254-O, CS0254-M
PED202
CS0165-1, CS0165-2
airCUE-XM8 Docking Station
CS0260-W, CS0260-O, CS0260-M
PEF150
CS0249-1, CS0249-2
analogCUE
CS0004
PEF200
CS0166-1, CS0166-2
auxCUE
CS0005
PER610
CS0167-1, CS0167-2
Back box L
CS0238-MB
PES03
CS0168
Back box M
CS0239-MB
PET102
CS0244-1, CS0244-2
Back box S
CS0241-MB
PET105
CS0245-1, CS0245-2
CUEadapter /10W
CS0184-E, CS0184-U
powerAUX
CS0016
CUEadapter /20W
CS0226-E, CS0226-U
PowerPacket
ST0026-1, ST0026-2
CUEadapter /50W
CS0185-E, CS0185-U
Rack mount panel L
CS0238-MR
CUEadapter /80W
CS0186-E, CS0186-U
Rack mount panel M
CS0239-MR
CUEwire Converter 232/422/485
CS0233
Rack mount panel S
CS0241-MR
eCUE
CS0173
rfbaseCUE
CS0171-4, CS0171-8, CS0171-9
Elite-A-M
ST0019
rfCUE 99
CS0170-*4A, CS0170-*8A, CS0170-*9A
Elite-A-XM8
ST0018-W, ST0018-O, ST0018-M
sbiCUE-DMX
CS0201
Elite-B-S
ST0020
sensorCUE
CS0265
Elite-B-SRF
ST0021-4, ST0021-8, ST0021-9
smartCUE
CS0008-R, CS0008-M
Elite-D-LV
ST0025
soundCUE
CS0009
Elite-D-M
ST0024
touchCUE-L
CS0236
Elite-G-S /b
ST0022
touchCUE-L /b
CS0238
Elite-G-SX /b
ST0023
touchCUE-L 99
CS0234-W, CS0234-O, CS0234-M
inputCUE
CS0191
touchCUE-LV
CS0236-V
ipCUE-alpha
CS0251
touchCUE-LV /b
CS0238-V
ipCUE-beta
CS0252
touchCUE-LV 99
CS0234-W-V, , S0234-O-V, CS0234-M-V
ipCUE-delta
CS0267
touchCUE-M
CS0237
ipCUE-epsilon
CS0268
touchCUE-M /b
CS0239
ipCUE-gamma
CS0253
touchCUE-M 99
CS0235-W, CS0235-O, CS0235-M
irCUE 99
CS0149-WA, CS0149-OA, CS0149-MA
touchCUE-MV
CS0237-V
irCUE Receiver 485
CS0169-C
touchCUE-MV /b
CS0239-V
keyboardCUE 99
CS0145-W, CS0145-O, CS0145-M
touchCUE-MV 99
CS0235-W-V, CS0235-O-V, CS0235-M-V
keyboardCUE-S
CS0174-W, CS0174-O, CS0174-M
touchCUE-S
CS0247
keypadCUE-1G
CS0221
touchCUE-S /b
CS0241
keypadCUE-2G
CS0222
touchCUE-S 99
CS0248-W, CS0248-O, CS0248-M
keypadCUE-3G
CS0223
touchCUE-SRF
CS0188-4, CS0188-8, CS0188-9
monitorCUE
CS0203-W, CS0203-O, CS0203-M
touchCUE-SX /b
CS0266
PEA208
CS0225-1, CS0225-2
touchCUE-V /i
CS0190
PEC25
CS0163
touchCUE-XL 99
CS0261-W, CS0261-O, CS0261-M
PED108
CS0164-1, CS0164-2
touchCUE-XLV 99
CS0261-W-V, CS0261-O-V, CS0261-M-V
1.1.2007
Jaroslav Dibitanzl
Member of Board of Directors
CE Declaration of Conformity
We, the producer CUE, a.s., K Nouzovu 6, Praha 4, Czech Republic
acknowledge our sole responsibility, that the product including accessories
Kind of equipment: Remote Control System
in accordance with EMC Directive 89/336/EEC,
is in compliance with the following norms or documents:
EN50082-1 (IEC801-2), IEC65(CO)39, DIN VDE 0839 part 82-1, DIN VDE 0843 part 4, IEC801-4, EN50081-1, EN55022 class B, DIN VDE 0839
part 81-1, EN55014, EN55011.
Type designation
(in alphabetical order)
User Manual Small Keyboards
www.cuesystem.com
Page 16 of 18

11. FCC
Caution
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Note
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio / TV technician for help.
User Manual Small Keyboards
www.cuesystem.com
Page 17 of 18

Notes
User Manual Small Keyboards
www.cuesystem.com
Page 18 of 18
