CUE touchCUE-5 User manual

Wired Touch Panels
User Manual

 
 
3 Overview
3 Models and Accessories
3 Main Features
3 Programming
 
4 Tabletop Models
4 Built-In Models
 
5 Tabletop Models
5 Built-In Models
 
6 Tabletop Models
7 Built-In Models
9 Part Description
 
10 Tabletop Models
10 Built-In Models
 
 
12 Ethernet
13 Direct PC Connection
 
 
15 Overview
15 Using Cue Visual Composer
16 Using Admin Web
 
 
18 Access On Screen Display
18 Startup Menu
18 Settings
18 Status
19 IP Settings
19 Date/Time
20 Applications
20 Calibration
20 Exit
 
21 Access Admin Web
21 Login
21 Conguration
23 Date and Time
24 Applications
24 File Storage
25 E-mail
25 Settings
26 System
27 Password
27 Backup
28 Reset
28 License
 
 
UM052_01_Wired_Touch_Panels
04.03.2016
Copyright © CUE, a.s., Praha, Czech Republic 1990 - 2016
All rights reserved. Specifications are subject to change without prior notice.


Wired Touch Panels
3
© CUE, a.s. | All Rights Reserved.

Overview
Thewiredtouchpanelproductlineoers4.3”,7”and12”screensizes.Foreachscreensizetabletopand
built-inmodelsareavailable.Allmodelscombinefunctionalitysuchasmultimediaintegration,lighting
automation,securitymonitoring,entertainmentintegration,andmeeting&presentationcontrol.The
activematrixtouchscreendisplayoersresolution800x480pixelsfor4.3”and1280x800pixelsfor7”
and12”screensize.Allmodelsproducestunningtruecolourimages.WiredEthernetconnectionprovides
easynetworkintegration.AlltouchpanelsareequippedwithPoweroverEthernet(PoEfor4.3”,7”and
PoE+for12”)-technologyenablinganEthernetnetworkcabletodeliverbothdataandpower.Fully
compatiblewithCUEcontrollers,thesetouchpanelsprovidetheultimateone-touchsolutionformeeting
rooms,conferencerooms,boardroomsandhigh-techhomes.

Model   
touchCUE-5 CS0371 Wiredtabletoptouchpanel4.3”
touchCUE-7 CS0451 Wiredtabletoptouchpanel7”
touchCUE-12 CS0466 Wiredtabletoptouchpanel12”
touchCUE-5-B CS0372 Wiredbuilt-intouchpanel4.3”
touchCUE-7-B CS0452 Wiredbuilt-intouchpanel7”
touchCUE-12-B CS0467 Wiredbuilt-intouchpanel12”

• Wired tabletop and built-in touch panels
• 4.3”,7”and12”activematrixtouchscreendisplayes
• Resolution800x480pixelsfor4.3”,1280x800pixelsfor7”and12”
• Colors32-bit(TrueColor),transparency8-bitAlphablending
• Wired Ethernet communication
• Power over Ethernet power supply
• Built-in microphone and speakers
• Built-in light and proximity sensors
• Realtimeclock(RTC)forschedulingapplications
• Aluminiumenclosure,aluminiumfrontpanelforbuilt-inmodels
• Bi-directionalcontrolofanyIPenabledproductsthroughEthernetport
• WebserverandAdminWebforsetupthroughastandardwebbrowser
Programming
AlltouchpanelshavetobeprogrammedusingCueVisualComposer.Thesemodelsarenotcompatible
withCueSystemDirector.

Wired Touch Panels
4
© CUE, a.s. | All Rights Reserved.


touchCUE-5 touchCUE-7 touchCUE-12
Touch panel touchCUE-5 1
Touch panel touchCUE-7 1
Touch panel touchCUE-12 1
PoE Adapter 1 1
PoE+ Adapter 1
Ethernet cable 1 1 1
Power cable 1 1 1
Cleaning tissue 1 1 1
DeclarationofConformity 1 1 1
Data Sheet 1 1 1
Cue System Connector Wiring 1 1 1

touchCUE-5-B touchCUE-7-B touchCUE-12-B
Touch panel touchCUE-5-B 1
Touch panel touchCUE-7-B 1
Touch panel touchCUE-12-B 1
Wall Mount Adapter 1 1 1
PoE Adapter 1 1
PoE+ Adapter 1
Ethernet cable 1 1 1
Power cable 1 1 1
Cleaning tissue 1 1 1
DeclarationofConformity 1 1 1
Data Sheet 1 1 1
Cue System Connector Wiring 1 1 1

Wired Touch Panels
5
© CUE, a.s. | All Rights Reserved.


touchCUE-5 touchCUE-7 touchCUE-12
Product code CS0371 CS0451 CS0466
Display type Color IPS LCD with LED backlit Color a-Si TFT LCD with LED backlit Color a-Si TFT LCD with LED backlit
Displaysize 4.3”(109mm)diagonal 7”(177.8mm)diagonal 12.1”(307.3mm)diagonal
Resolution 800 x 480 pixels 1280 x 800 pixels 1280 x 800 pixels
Viewing angle ±80°horizontal,±80°vertical ±80°horizontal,±80°vertical ±80°horizontal,±80°vertical
Touch overlay Projectedcapacitive,edge-toedge
glass
Projectedcapacitive,edge-toedge
glass
Projectedcapacitive,edge-toedge
glass
Sensors Light and proximity Light and proximity Light and proximity
Audio Microphone and speakers Microphone and speakers Microphone and speakers
Memory RAM512MB,
microSDCardmin.8GB
RAM512MB,
microSDCardmin.8GB
RAM512MB,
microSDCardmin.8GB
Network Wired 10/100 BaseT Ethernet Wired 10/100 BaseT Ethernet Wired 10/100 BaseT Ethernet
Power supply PoE,IEEE802.3af/Class0 PoE,IEEE802.3af/Class0 PoE+,IEEE802.3at/Class4
Enclosure Aluminium,glass
Integrated tabletop stand
Aluminium,glass
Integrated tabletop stand
Aluminium,glass
Integrated tabletop stand
Dimensions 136 x 81 x 73 mm 199 x 115 x 97 mm 320 x 192 x 153 mm
Weight 0.4kg 0.8kg 2.4kg
Included accessories PoEpowersupply,
Ethernet cable
PoEpowersupply,
Ethernet cable
PoE+powersupply,
Ethernet cable

touchCUE-5-B touchCUE-7-B touchCUE-12-B
Product code CS0372 CS0452 CS0467
Display type Color IPS LCD with LED backlit Color a-Si TFT LCD with LED backlit Color a-Si TFT LCD with LED backlit
Displaysize 4.3”(109mm)diagonal 7”(177.8mm)diagonal 12.1”(307.3mm)diagonal
Resolution 800 x 480 pixels 1280 x 800 pixels 1280 x 800 pixels
Viewing angle ±80°horizontal,±80°vertical ±80°horizontal,±80°vertical ±80°horizontal,±80°vertical
Touch overlay Projectedcapacitive,edge-toedge
glass
Projectedcapacitive,edge-toedge
glass
Projectedcapacitive,edge-toedge
glass
Sensors Light and proximity Light and proximity Light and proximity
Audio Microphone and speakers Microphone and speakers Microphone and speakers
Memory RAM512MB,
microSDCardmin.8GB
RAM512MB,
microSDCardmin.8GB
RAM512MB,
microSDCardmin.8GB
Network Wired 10/100 BaseT Ethernet Wired 10/100 BaseT Ethernet Wired 10/100 BaseT Ethernet
Power supply PoE,IEEE802.3af/Class0 PoE,IEEE802.3af/Class0 PoE+,IEEE802.3at/Class4
Enclosure Aluminium,glass
Compatible with standard electrical
wall box
Aluminium,glass
Compatible with standard electrical
wall box
Aluminium,glass
Compatible with standard electrical
wall box
Dimensions 136 x 81 x 37 mm 199 x 120 x 39 mm 320 x 200 x 47 mm
Weight 0.3kg 0.6kg 2.0kg
Included accessories PoEpowersupply,
Ethernetcable,
Wall mounting adapter
PoEpowersupply,
Ethernetcable,
Wall mounting adapter
PoE+powersupply,
Ethernetcable,
Wall mounting adapter

Wired Touch Panels
6
© CUE, a.s. | All Rights Reserved.



Speakers
LCD display
with touch sensor
136 mm
Microphone
73 mm
81 mm
Network connector
Network cable
Button System Default
Integrated tabletop stand
Light sensor
Proximity sensor

102 mm
115 mm
Network connector
Button System Default
Integrated tabletop stand
Speakers
LCD display
with touch sensor
199 mm
Microphone
Light sensor
Proximity sensor

Speakers
Light sensor
LCD display
with touch sensor
320 mm 153 mm
192 mm
Network connector
Microphone
Button System Default
Integrated tabletop stand
Proximity sensors

Wired Touch Panels
7
© CUE, a.s. | All Rights Reserved.


LCD display with touch sensor
Microphone
Network connector
Front View Rear View
Top View
Button System Default
Speakers
Bottom View Fixing screw
136 mm
81 mm11 26 mm
88 mm
Wall adapter
72 mm
Light sensor
Proximity sensor

LCD display with touch sensor
Microphone
Network connector
Front View Rear View
Top View
Button System Default
Speakers
Bottom View
Fixing screw
199 mm
120 mm13 26
160 mm
Wall adapter
106 mm
Light sensor
Proximity sensor

Wired Touch Panels
8
© CUE, a.s. | All Rights Reserved.

Light sensors
LCD display
with touch sensor
Microphone
Network connector
Front View Rear View
Top View
Button System Default
Speakers
Bottom View
Fixing screw
320 mm
200 mm21 26
180 mm
Wall adapter
184 mm
Proximity sensors

Wired Touch Panels
9
© CUE, a.s. | All Rights Reserved.


Themicrophoneispreparedforfutureuse.Thefunctionalitydependsonarmwareversion.

TheMotionsensorresumestouchpanelfromBacklightSavermode.Thisfunctionalitycanbeenabled/
disabledusingOnScreenDisplayorAdminWeb.

TheLightSensorautomaticallyadjustsdisplaybacklightaccordingambientlightlevel.Thisfunctionhas
tobeenabledusingOnScreenDisplayorAdminWeb.

Touch-screendisplaywithactivematrixcolorLCDandresistivemembranetouchoverlay.

Thebuilt-instereospeakersallowstoplaysoundsstoredinthetouchpanels.

Whenpressedthefactorydefaultfunctionisperformed.ForfactorydefaultvaluesseechapterFactory
DefaultandSystemDefault.Athinscrewdriverisneededforpressofthisbutton.

The10/100BaseTLANisastandardnetworkconnectionequippedwithPoweroverEthernetusingRJ-45
connector.FormoredetailsseechapterConnection.

Wired Touch Panels
10
© CUE, a.s. | All Rights Reserved.


Desktopmodelscanbeplacedonanyatsurface.Installationstepsareasfollows
1. Don’tforgettoprepareproperbushingforthecableincludingstandardconnector.Aminimum
diameterofthebushingforEthernetconnectorisapprox.20mm.
2. Installthenetworkcableasdescribedonthefollowingpictureandconnectthenetworkconnector.
Network connector
Network cable
3. Placethetouchpanelonatable.

All built-in models are compatible with standard European/UK electrical wall boxes as described in the
followingpicture.
Electrical wall box
Wall adapter
Touch panel
Step 1
Step 2
Step 3 Fixing screw
Electrical wall box
screws
!Four screws for additional fixing
(touchCUE-12-B only)
Installationstepsareasfollows
1. Installwalladapterontheelectricalwallboxandprovideadditionalxingbyfourdeliveredscrews
andfasteners.
!AdditionalxingisstrictlyrecommendedfortouchCUE-12-B.
!Usedeliveredscrewsorkeepmaximumscrewdimensionsasdescribedbelow.
Max. Ø 5.5 mm
max. 1.7 mm
2. Connectnetworkcableandputthetouchpanelonthewalladapter.
3. Carefullytightenthexingscrewtoxtouchpanelonthewall.

Wired Touch Panels
11
© CUE, a.s. | All Rights Reserved.

Youshouldcleanthetouchpanelscreenoverlayaftereachday’suse.
Materialsrequiredare
1. Twoclean,softtexturecloths(cotton).
2. Spraybottleofcleaningsolutionwithoutalcohol(windowcleaner).
3. Aluminiumpartsshouldbecleanedusingaspecialcleaningsolution.
Steps are
1. Turnthetouchpanelo.
2. Sprayasmallamountofthecleaningsolutionontooneofthecloths.
3. Cleanthetouchpaneloverlaywiththedampcloth.
4. Wipethetouchpaneloverlaywiththedrycloth.

Wired Touch Panels
12
© CUE, a.s. | All Rights Reserved.


The10/100BaseTLANisastandardnetworkconnection10/100BaseTLANusingRJ-45connector.There
isnoautosense,whichmeansitdoesnotrecognizestraightthroughcabletocross-overcable.Forthe
directPCconnectionitisnecessarytousecross-overcable;fortheconnectiontoEthernetswitchstraight
throughcable.ThelengthoftheEthernetcableconnectingtouchpaneltothenetworkmustnotexceed
100meters.
PoweroverEthernetisfullycompatiblewith
• IEEE802.3af(PoE)standardfor4.3”and7”models
• IEEE802.3at(PoEPlus)standardfor12”models.
PoweroverEthernetintegratesdataandpoweronthesamewires.Itkeepsthestructuredcablingsafe
anddoesnotinterferewithconcurrentnetworkoperation.
Power over Ethernet needs compatible Ethernet switches or injectors currently available by most leading
networkequipmentvendors.
EthernetwithoutPoEInfrastructure
Power supply
PoE Adapter
OUT IN
Ethernet cable Ethernet cable
Ethernet
EthernetwithPoEInfrastructure
Ethernet cable
Ethernet
with PoE
Connector pin out
 Pin Signal 
1 TX_D1+ and PoE White / Orange
2 TX_D1- and PoE Orange
3 RX_D2+ and PoE White/Green
4PoE +/- 48 V Blue
5 White / Blue
6 RX-D2- and PoE Green
7PoE Common White / Brown
8 Brown

Wired Touch Panels
13
© CUE, a.s. | All Rights Reserved.

AlltouchpanelmodelsareequippedwithPoEpowersupply(4.3”and7”models)orPoE+powersupply
(12”models).ThatmeansoneCatcableisusedforpowersupplyandfordata.
Make sure you use
• PoEAdapterfor4.3”and7”models
• PoE+Adapterfor12”models.
Connectionstepsareasfollows
1. AttachoneendofaRJ-45Ethernetstraight-throughcabletotheCUEnet(LAN)portontouchpanel
andattachtheotherendofthiscabletoOUTportofPoE(PoE+)Adapter.
2. AttachoneendofaRJ-45Ethernetstraight-throughcabletotheINportofPoE(PoE+)Adapterand
attachtheotherendofthiscabletoLANportofyourcomputer.
3. AttachpowersupplytothePoE(PoE+)adapter.
Power supply
PoEAdapterfor7”models
PoE+Adapterfor12”models
Ethernet cable straight-through Ethernet cable crossed-over

Wired Touch Panels
14
© CUE, a.s. | All Rights Reserved.

For Windows 7 steps are
1. StartWindows7.
2. ClickStart.
3. Enter  to the Search Box and press
Enter.Followingwindowisdisplayed.
For Windows XP steps are
1. StartWindowsXP.
2. ClickStart,thenclickControlPanelchoose
theoptiontoswitchtoClassicView.
3. Double-clickNetworkConnections.
Following steps are
1. Right-clickonnetworkadapterusedfor
connection with touch panel and then right-
clickandselectProperties.
2. SelectInternetProtocol(TCP/IP)andclick
Propertiesbutton.
3. SelectUsethefollowingIPaddressoption.
SetIPaddressto192.168.1.1(orother
addressdierentfrom192.168.1.127and
from192.168.1.128)andSubnetmask
to255.255.255.0.Leaveotheroptions
unchangedandclickOK.

Wired Touch Panels
15
© CUE, a.s. | All Rights Reserved.

Overview
User control application is dedicated to control and it is programmed by Cue Visual Composer
programmingtools.

Steps are
1. ConnecttouchpaneltoyourcomputerasdescribedinchapterPCConnection.
2. RunCueVisualComposeronyourPC.
3. OpenappropriateprojectinCueVisualComposer.It’snecessarytohaveappropriatedtouchpanel
properlyinsertedandcongured.
4. Use tool bar button FinaltoopenUploadandExportApplicationdialogbox.
5. Besureyourtouchpanelischecked.
6. Use button tostartapplicationupload.
7. Iftouchpanelrmwareisn’tactualitwillbeuploadedautomaticallyrstandthenapplicationupload
willbenished.

Wired Touch Panels
16
© CUE, a.s. | All Rights Reserved.

Steps are
1. ConnecttouchpaneltoyourcomputerasdescribedinchapterPCConnection.
2. RunCueVisualComposeronyourPC.
3. OpenappropriateprojectinCueVisualComposer.It’snecessarytohaveappropriatedtouchpanel
properlyinsertedandcongured.
4. Use tool bar button FinaltoopenUploadandExportApplicationdialogbox.
5. Besureyourtouchpanelischecked.
6. Use button toexportapplicationandstoreitinle*.cvca.
7. Run the Internet browser on your PC and type in the same touch panel IP address as you see in Cue
VisualComposerproject,windowProperties/IPaddress.
8. Gotopageandcheckcurrentrmwareversion.Incasethereisnoactualrmwareversion
intouchpanel,uploadrmwareversionthatcorrespondstormwareversionintheCueVisual
Composerproject..
9. Gotopageanduploadapplicationle*.cvca.
10.Start uploaded application using button .

Wired Touch Panels
17
© CUE, a.s. | All Rights Reserved.

Everydeviceshippedfromthefactoryissetaccordingtotablebellow,FactoryDefaultcolumn.
WhenpressedSystemDefaultbutton,thesystemdefaultfunctionisperformedaccordingtotablebellow,
SystemDefaultcolumn.Themainpurposeofthisfunctionalityistoregainconnectiontotouchpanelwith
lostpasswordorunknownIPsettings.
 
 Identication Name Empty Not changed
IP settings Host name Empty Not changed
IP address 192.168.1.128 192.168.1.128
Subnet mask 255.255.255.0 255.255.255.0
Defaultgateway 192.168.1.1 192.168.1.1
DNS Primary DNS server Empty Not changed
Secondary DNS server Empty Not changed
 Date and Time Day,month,year Real Not changed
Hour,minute,second Real Not changed
Timezone (GMT+1:00CET/CEST
Belgrade,...,Prague)
Not changed
Internet clock Use Internet clock Not Not changed
Primary NTP server Empty Not changed
Secondary NTP server Empty Not changed
 Empty Not changed
 Empty Not changed
 Firmware Current version Not changed
Password Empty Empty

Wired Touch Panels
18
© CUE, a.s. | All Rights Reserved.


Themultifunctionalbuttonlocatedonfrontpanel
showsOnScreenDisplay.
StartupMenuisdisplayedautomaticallyifno
applicationisrunning.

TheStartupMenuisactivatedifnoapplicationis
running.
Applicationbuttonstartsdownloadedapplication.
On Screen Display button launches menu
describedbelow.

1 min
TheBacklightSaverwillswitchoautomatically
displaybacklight.Timeinminutescanbeset
bybuttons-and+.Timesetto0meansthat
BacklightSaverisdisabled.
LCDBacklightsetsdisplaybacklightlevel.
IfAdaptiveBrightnessisswitchedtoYes,the
light sensor automatically adjusts display
backlightaccordingambientlightlevel.
IfMotionSensorisswitchedtoYestheMotion
SensorresumestouchpanelfromBacklightSaver
modeautomatically.

Thispageshowscurrentstatusofthetouch
panel.

Wired Touch Panels
19
© CUE, a.s. | All Rights Reserved.

192.168.1.128
255.255.255.0
192.168.1.1
Thispageisusedforsettingthecommunication
parametersforyourtouchpanel.Thetouch
panelusesstandardinternetprotocol(IP)
communicationparameters.Certainparameters
canberesetbytheuser.Onstartup,thispage
willdisplaycurrentIPaddress.Carefullynotethis
addressinginformation(andanychangesyou
electtomaketotheIPaddress,subnetmask,
ordefaultgateway).Thisinformationmustbe
entered into the Cue Visual Composer program
writtenforyourspecicapplication.Forcontrol
systemswithmorethanoneunit,auniqueIP
addressmustbegiventoeachCUEunit.
Forsettingpleaseselectappropriateeldusing
Editbuttonandthenusenumerickeypad.
BesuretoclicktheApplybuttonforanychanges
tobecomeeective.

19/04/2011
17:01:25
GMT+01:00 CET/CEST
ThispageisusedforsettingDate/Time
parameters.
Thecurrentdateandtimecanbeset.Forsetting
pleaseselectappropriateeldusingEditbutton
andthenusenumerickeypad.
Thetimezoneboxcanbeselectedtoenterfrom
thelistactivatedbybuttonEdit.
Restofthepageisusedforsynchronizationof
the CUEunit’s date and time with an internet
clock.SelectYesforUseInternetclock.Next,
entertheIPaddresses(orcompleteaddress
name)oftheprimaryandsecondaryNTPservers.

Wired Touch Panels
20
© CUE, a.s. | All Rights Reserved.

TestApp_TouchPanel1.cvca
DemoApp_TouchPanel1.cvca
Thisscreenisusedforselection,startandstopof
uploadedapplications.Alluploadedapplications
arelistedonthispage.
SelectapplicationandpressbuttonStart.A
“runningag”denotestheactiveapplication.
Activeapplicationstartsautomaticallyafter
switchontheunit.Therunningapplicationcan
bestoppedviatheStopbutton.
Filesareuploadedfromapersonalcomputer
to the touch panel using Cue Visual Composer
softwareorusingAdminWeb.

touchCUE-7 CS0451.R01.000001
6.10h (Jul 30, 2015)
ClosestheOnScreenDisplay.
Onthispagetheproductname,productcodeand
currentrmwareversionaredisplayed.
