Cuisinart CTG-00-SPI4 Service manual

Instruction and Recipe Booklet
CTG-00-SPI4
FOOD SPIRALIZER
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.

2
CONTENTS
Important Safeguards......................................... 3
Assembly.................................................... 4
Using the Spiralizer ........................................... 5
Cutting Options .............................................. 6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Recipes .................................................. 8–11
Product Registration ......................................12–15

3
IMPORTANT SAFEGUARDS
SAVE AND READ THESE
INSTRUCTIONS
CAUTION: THE CUTTING
BLADES HAVE VERY SHARP
EDGES.
Basic safety precautions should always be taken, including the
following:
1.
READ ALL INSTRUCTIONS, including these
important safeguards.
2. Close supervision is necessary when this spiralizer is used by or
near children or individuals with certain disabilities.
3. Blades are extremely sharp. Handle carefully when in use or
cleaning.
4. Be certain clear protective cover is securely locked in place before
using.
FOR HOUSEHOLD USE ONLY
BEFORE USING
Wash all parts of the spiralizer with warm, soapy water, rinse, and wipe
dry. Use caution when handling the cutting table where the blades are
located – the blades are sharp!

4
ASSEMBLY
1. Insert the shaft into the hole of the protective cover. Screw the
handle clockwise onto the stainless steel shaft to tighten
2. Screw the food holder to the bottom of the stainless steel shaft so
that the teeth are pointed downward.
3. Set the cutting surface on the collection bowl (as shown in diagram)
and turn clockwise to lock into collection bowl.
Handle knob
Stainless steel sha
Center pin
Ribbon blade dial
Collection bowl
Julienne blade
dial
Food holder
Handle
Protective cover
Cutting surface
Collection bowl
Collection bowl

5
USING THE SPIRALIZER
1. Begin by cutting your fresh, raw food (vegetable/fruit) at least 1" in
diameter and 1" to 3.5" in length. Make sure the top and bottom
ends of your food pieces are cut straight and flat so that they can
be held firmly in place by the teeth on the holder and the center pin
on the cutting surface.
2. Move the Julienne blade dial from “Safe” position to the desired
thick or thin julienne (refer to Cutting Options on page 6). Turn the
Ribbon blade dial marked “Cut” out of safe mode, into the cut mode,
where the blade will be visible.
3. Position one of the flat ends of the food on the center pin of the
cutting surface. Apply enough pressure to stabilize the food item on
the center pin.
4. The center pin keeps your food in place while you adjust the shaft
and position the Cuisinart®Food Spiralizer’s food holder so it is
centered over the food item. As you turn the protective cover
clockwise, the teeth of the holder will grip the food, holding it
securely. Turn clockwise until protective cover locks into place.
5. Your food is now securely held in place between the teeth of the
holder and the center pin on the cutting surface.
6. To start using your Cuisinart®Food Spiralizer, rotate the handle
clockwise while applying downward pressure with the palm of your
hand.
WARNING
Please remember to set all blades to the SAFE position (no blades or
teeth will be visible on the cutting surface) before unlocking the
collection bowl to retrieve food or before cleaning the unit.
The Cuisinart®Food Spiralizer is not recommended for harder foods,
e.g., butternut squash. Keep food spiralizer blades away from children.

6
CUTTING OPTIONS
Ribbon Slice (Figure 1) – Only the flat blade is being used. Adjust the
Ribbon blade dial to Cut. Turn the Julienne blade dial to the Safe
position, so that no julienne blade will be visible.
Thin Julienne (Figure 2) – Turn the Ribbon blade to the cut position.
Turn the Julienne blade dial so that the thinly spaced blades (teeth) are
visible.
Thick Julienne (Figure 3) – Turn the Ribbon blade to the cut position.
Turn the Julienne blade dial so that the widely spaced blades (teeth)
are visible.
2 3
Closed
julienne
blade
dial
Open thin
julienne
blade
dial
Open thick
julienne
blade
dial
Open ribbon
blade dial
Open ribbon
blade dial
Open ribbon
blade dial
Ribbon Slice Thin Julienne Thick Julienne
USE AND CARE
Dishwasher-safe unit and parts.
1

7
WARRANTY
LIFETIME WARRANTY (U.S. and Canada ONLY)
Cuisinart®Tools & Gadgets are warranted to be free of defects in
material and workmanship under normal home use from the date of
original purchase throughout the original purchaser’s lifetime. If your
tool/gadget should prove to be defective within your lifetime, we will
repair it (or, if we think it necessary, replace it) without charge to you,
except for shipping and handling. To obtain warranty service, please
call our Consumer Service Center toll-free at 1-800-726-0190, or write
to Consumer Service Center, Cuisinart, 150 Milford Road, East Windsor,
NJ 08520. To facilitate the speed and accuracy of your return, please
enclose $4.00 for shipping and handling of the product. Be sure to
include a return address, description of the product problem, phone
number, and any other information pertinent to the product’s return.
Please pay by check or money order made payable to Cuisinart. This
warranty excludes damage caused by accident, misuse or abuse,
including damage caused by overheating, and it does not apply to
scratches, stains, discoloration or other damage to external or internal
surfaces that does not impair the functional utility of the tool/gadget.
This warranty also expressly excludes all incidental or consequential
damages. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the foregoing limitation or
exclusion may not apply to you. This warranty gives you specific legal
rights, and you may also have other rights, which vary from state to
state.
CALIFORNIA RESIDENTS ONLY
California residents should call 1-800-726-0190 for shipping
instructions. Cuisinart will be responsible for the cost of the repair,
replacement, and shipping and handling of such nonconforming
products under warranty.

8
RECIPES
Cucumber Salad with Asian-Style Dressing
The thin and thick julienne settings are perfect for enjoying your favorite
vegetables raw in a delicate salad like this one.
Makes 3 cups
Dressing:
2 tablespoons rice vinegar
2 teaspoons reduced-sodium soy sauce
¼ teaspoon fish sauce (optional)
1 teaspoon packed light brown sugar
1 1-inch piece fresh ginger, peeled and grated
1 small garlic clove, grated
1⁄3cup grapeseed oil
Salad:
2 tablespoons packed fresh cilantro leaves, roughly chopped
2 large carrots
3 medium radishes
1 large seedless cucumber
Pinch of salt, for serving
1. Prepare dressing by combining all the ingredients in a large bowl. Fold in the
cilantro. Set aside.
2. Trim vegetables to fit into spiralizer. Prepare carrots and radishes by
spiralizing on the thin julienne setting. Add to the large bowl with the
dressing.
3. Prepare cucumber by spiralizing on the thick julienne setting. Add to the
large bowl with the carrots, radishes and dressing. Toss gently. Sprinkle with
salt before serving.
4. Serve immediately.
Nutritional information per serving (1 cup):
Calories 152 (70% from fat) • carb. 11g • pro. 1g • fat 12g • sat. fat 1g
chol. 0mg • sod. 108mg • calc. 39mg • fiber 2g

9
Crispy Potatoes and Frizzled Onions
This spiralizer isn’t just for the healthy—after all, doesn’t almost everything
taste better fried?
Serves 4 to 6 people
1 russet potato
1 sweet potato
1 medium onion
4 cups vegetable or canola oil, for frying
¾ teaspoon salt, divided
1. Trim vegetables to fit into spiralizer. Prepare vegetables by spiralizing each
on the thick julienne setting. Set aside.
2. Put vegetable oil in a medium saucepan*. Heat until oil reaches 375º F. Add
russet potato to oil in two batches. Fry until golden brown, adjusting the
heat as necessary, about 4 minutes per batch. Remove from oil and drain on
a plate lined with paper towels. Sprinkle with a pinch of the salt.
3. When the oil reaches 375º F again, add the sweet potato. Fry until golden
brown, about 4 minutes. Remove from oil and drain alongside fried russet
potato. Sprinkle with a pinch of salt. Repeat with onion. Taste and adjust
seasoning as desired.
4. Serve immediately.
*Note: When frying, oil should be several inches deep to prevent crowding.
There should also be at least 3 to 4 inches of clearance from the top of the pot
to prevent splattering.
Nutritional information per serving (1 cup):
Calories 333 (73% from fat) • carb. 22g • pro. 2g • fat 28g • sat. fat 48g
chol. 0mg • sod. 327mg • calc. 29mg • fiber 3g

10
Fresh Summer “Spaghetti”
This light, stovetop dish is full of bright flavors and couldn’t be easier to make.
Makes 5 cups
2 medium zucchini, about 1 pound total
1 large carrot (only use wide end of carrot)
2 tablespoons extra virgin olive oil
2 garlic cloves, smashed
¼ teaspoon crushed red pepper
1 pint grape tomatoes, halved
¾ teaspoon salt
¼ cup packed fresh basil leaves, sliced very thin
1. Trim vegetables to fit into spiralizer. Prepare zucchini by spiralizing on the
thick julienne or ribbon setting. Set aside. Prepare carrot by spiralizing on
the thick julienne setting. Set aside with zucchini.
2. In a large skillet, heat olive oil, garlic and crushed red pepper over medium-
high heat until hot and fragrant, about 5 minutes.
3. Add tomatoes and ¼ teaspoon salt; cook until blistered, about 6 to 8
minutes.
4. Remove skillet from heat. Remove garlic cloves. Stir in zucchini, carrot, basil
and remaining salt. Taste and adjust seasoning as desired.
5. Serve immediately.
Nutritional information per serving (1 cup):
Calories 81 (62% from fat) • carb. 7g • pro. 2g • fat 6g • sat. fat 1g
chol. 0mg • sod. 338mg • calc. 29mg • fiber 2g

11
Pear Chips
With just the right amount of sweetness, these pear chips make the perfect snack.
Makes about 50 chips
1 pear, firm
2 teaspoons ground cinnamon
1 teaspoon brown sugar
1 teaspoon granulated sugar
1. Trim pear to fit into spiralizer*. Preheat oven to 300º F. Prepare 2 baking
trays with parchment paper. Set aside. Combine cinnamon and sugars in a
small bowl. Set aside.
2. Prepare pear by spiralizing on ribbon setting. Break large pieces into single
layer rounds and place on prepared baking trays. Sprinkle pears evenly with
2 teaspoons of cinnamon sugar mixture. Turn pears over and sprinkle with
remaining cinnamon sugar.
3. Bake for 45 minutes, rotating pans halfway through baking. Remove from
oven and let pears cool so they become crunchy, at least 5 minutes.
*Note: To make fruit or vegetable chips, trim both ends of the fruit or vegetable,
making sure they are flat and even. Position tip of sharp knife over middle of
top of core and cut straight down (leaving ¼" from the bottom uncut) on one
side only. As food spiralizes, chips are pre-cut – there’s no long spiral that
needs to be cut into pieces.
Nutritional information per serving (10 chips):
Calories 56 (2% from fat) • carb. 14g • pro. 0g • fat 0g • sat. fat 0g
chol. 0mg • sod. 1mg • calc. 8mg • fiber 2g

12
REGISTER YOUR PRODUCT NOW!
Complete the two easy steps to register your product and receive
premium customer service, special offers and more!
Take a photo of your Photoregister Code below including the points
STEP 1 TAKE A PHOTO

13
SMARTPHONE US/CANADA
Text photo to 71403
EMAIL WORLDWIDE
[e-mail]
ONLINE WORLDWIDE
register.cuisinart.com
STEP 2 SEND IT IN
OR
OR
Need help? Visit Photoregister.com/help or text HELP to 71403.
W-9/026-ESP-C

14
¡REGISTRA TU PRODUCTO AHORA!
¡Completa dos pasos sencillos para registrar el proucto recibe
servicio de alta calidad, ofertas especiales y mucho más!
Saca una foto del código PhotoregisterSM debajo, incluyendo los puntos
PASO 1 SACA UNA FOTO

15
TELÉFONO MÓVIL EE. UU./CANADÁ
Envía la foto a 71403
CORREO ELECTRÓNICO DESDE CUALQUIER PARTE DEL MUNDO
[e-mail]
EN LÍNEA DESDE CUALQUIER PARTE DEL MUNDO
register.cuisinart.com
PASO 2 ENVÍALA
O
OR
¿Necesitas ayuda? Visita Photoregister.com/help o envía AYUDA a 71403.
W-9/026-ESP-C

©2017 Cuisinart
150 Milford Road, East Windsor, NJ 08520
Printed in China
17CT028218
Cuisinart offers an extensive assortment of top quality products to
make life in the kitchen easier than ever. Try some of our other
countertop appliances and cookware, and Savor the Good Life®.
www.cuisinart.com
IB-15006
