INSTRUCTION/
RECIPE BOOKLET
Smart Stick®Hand Blender
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
CSB-77

IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should
always be followed including the following:
1. READ ALL INSTRUCTIONS.
2. To protect against electrical shock, do not put the motor body,cord
or electrical plug of this hand blender in water or other liquid. The
detachable blending shaft of this appliance has been designed for
immersion into water or other liquids. Never submerge any other
portion of this unit. If hand blender falls into liquid, remove immediately.
Do not reach into the liquid without unplugging the unit first.
3. This appliance should not be used by children. To avoid possible
accidental injury, close supervision is necessary when any appliance
is used by or near children.
4. Unplug from outlet when not in use, before putting on or taking
off parts, and before cleaning. To unplug, grasp plug and pull
from electrical outlet. Never pull cord.
5. Avoid contacting moving parts.
6. During operation keep hands, hair, clothing, as well as spatulas and
other utensils away from attachments and any mixing container, to
reduce risk of injury to persons, and/or damage to the appliance.
A spatula may be used, but must be used only when the unit is
not operating.
7. Do not operate any appliance with a damaged cord or plug, or after
the appliance has malfunctioned or has been dropped or damaged in
any way or is not operating properly. Return the appliance to the
nearest Cuisinart Repair Center for examination, repair, or
mechanical or electrical adjustment.
8. Remove detachable shaft from the blender before washing the blades
or shaft.
9. Blades are SHARP. Handle carefully when removing, inserting
or cleaning.
10. When mixing liquids, especially hot liquids, use a tall container or
make small quantities at a time to reduce spillage, splattering and
possibility of injury from burning.
11. To reduce the risk of injury, never place chopper/grinder attachment
cutting blade on base without first putting prep bowl properly in place.
12. Be certain the chopper/grinder attachment cover is securely locked in
place before operating appliance. Do not attempt to remove cover
until blade has stopped rotating.
13. Check prep bowl for presence of foreign objects before using.
2

14. The use of attachments or accessories not recommended by
Cuisinart may cause fire, electrical shock, or risk of injury.
15. Do not use outdoors, or use for other than intended use.
16. Do not let any cord hang over the edge of the table or counter.
Do not let cord contact hot surfaces, including stovetop.
17. Make sure the appliance is off, the motor has stopped completely,
and the appliance is unplugged from outlet before putting on or taking
off attachments, and before cleaning.
18. To reduce the risk of fire or electrical shock, do not operate any
heating appliance beneath the mounting unit.
19. Maximum rating of 200W is based on the chopper/grinder
attachment that draws the greatest power.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
NOTICE
This appliance has a polarized plug (one blade is wider than the other).
As a safety feature, this plug will fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to defeat this safety feature.
TABLE OF CONTENTS
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tips and Hints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Whisk Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Blending Attachment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chopper/Grinder Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Reversible Blade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Whisk Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Blending . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Whisking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chopping/Grinding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Frequent Uses for Chopper/Grinder . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Recipes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3

INTRODUCTION
This Cuisinart®Smart Stick®Hand Blender is designed to handle a variety
of basic tasks, like blending, mixing, chopping, grinding, whipping,
pureeing – even processing bread crumbs – to give you time for more
creative culinary undertakings! Elegant brushed stainless steel houses a
powerful motor, and the handy “stick” design lets you blend in a pot, bowl,
or pitcher. Operation is easy and cleanup is quick. What could be better?
UNPACKING INSTRUCTIONS
Place the package containing the Cuisinart®Smart Stick®Hand Blender
on a sturdy surface. Unpack the Smart Stick®Hand Blender from its box
by removing the upper protective insert. Gently slide the unit from the
box. Remove all support materials from the box and replace the upper
insert. Save packaging for possible repacking of the unit.
Note: The blending blade is extremely sharp. Use caution when
removing and unpacking the storage stand. The blending blade is
stored in the storage stand.
Before using the Cuisinart®Smart Stick®Hand Blender for the first time,
we recommend that you wipe the unit with a clean, damp cloth to remove
any dirt or dust. Dry it thoroughly with a soft absorbent cloth. Handle
carefully; wash each individual blade attachment, mixing container and
detachable shaft by hand or in the dishwasher. Dry thoroughly before use.
Read all instructions completely for detailed operating procedures.
FEATURES AND BENEFITS
1. One Touch On/Off Button: Allows you to activate the hand
blender at the touch of a button. Simply press and hold down on the
toggle switch to blend or pulse. Once the button is released, blending
will stop.
2. Comfort Handle: The handle allows you to control the hand blender
with ease.
3. Motor Body Housing
4. Detachable Shaft: By pressing the release button on the back of the
unit, the shaft will detach for easy cleaning.
5. Blending Attachment with Stainless Steel Blade and Blade
Guard: This attachment easily snaps into the motor body housing.
The stainless blade is partially covered by a stainless housing that
keeps splashing to a minimum.
6. Whisk Attachment: Whisk attachment snaps into the motor body
housing. This attachment is great for whipping cream, egg whites
and other delectable treats.
4

7. Chopper/Grinder Attachment: Chop, mince and grind with
the Cuisinart®Chopper/Grinder attachment. Chopper/Grinder
attaches to the blender motor body in place of the blender shaft or
whisk attachment.
8. Mixing Beaker: 2-cup mixing beaker is microwave- and dishwasher
safe. Use this container to blend drinks, shakes, salad dressings and
more. Designed for easy gripping and drip-free pouring.
TIPS AND HINTS
1. Liquid should come within an inch of where the shaft attaches to the
motor housing.
2. Some spices may scratch the chopper/grinder attachment.
3. When using with a nonstick cooking surface, be careful not to scratch
the coating with the hand blender.
4. Do not immerse motor body housing, chopper/grinder cover, or whisk
gearbox in water or any other liquid.
5. Cut most solid foods into 1⁄2" cubes for easy blending. Suggestion: use
chopper/grinder for chopping and grinding solid foods.
6. Pour liquid ingredients into the mixing container first, unless recipe
instructs otherwise.
7. To avoid splashing, don’t turn the hand blender on until the blade is
beneath the surface of the mixture and do not pull the hand blender
out of the mixture while blender is running.
8. Do not let hand blender stand in a hot pot on stove while not in use.
9. Do not put fruit pits, bones, or other hard material into the blending
mixture, as these are liable to damage the blades.
10. Do not fill mixing containers too full. The level of mixture will rise when
blending, and can overflow.
11. Adding liquids that are warm, not cold, facilitates blending solids
with liquids.
12. For recipes calling for ice, use crushed ice (not whole cubes) for
best results.
13. Using a gentle up-and-down motion is the best way to blend and
incorporate ingredients uniformly.
14. To avoid spatter, turn the hand blender off and let the blade stop
completely before lifting the unit out of the mixture you are processing.
15. To whip air into a mixture, always hold the blade just under
the surface.
16. To make a soup creamy in texture, use the hand blender to purée
the soup solids to the desired consistency using a gentle up-and-down
5

motion right in the saucepan. You can quickly change your soup into a
thick and creamy blend.
17. If you are making a dip or spread, it is not necessary to process
completely into a smooth purée; leave some texture for interest.
18. When making compound butters, remove the butter from the
refrigerator and let it come to room temperature before blending
the ingredients.
19. The hand blender is perfect for frothing milk for cappuccino or lattes.
20. Use the hand blender to make smooth gravies and pan sauces.
21. For best results when adding celery to a recipe, use a vegetable
peeler to remove tough outer strings from the celery before slicing.
WHISK TIPS
Use the whisk attachment for beating heavy cream or egg whites. It may
also be used for whisking eggs for scrambled eggs or fluffy omelets.
BEATING EGG WHITES
When beating egg whites use a very clean metal or glass bowl, never
plastic. Plastic can contain hidden oils and fats that can ruin the delicate
egg white foam. To help stabilize the egg whites add 1/8 teaspoon of
cream of tartar per egg white prior to beating them. (If using a copper
bowl omit the cream of tartar). Beat the egg whites until soft peaks form
that do not droop over. Beating the egg whites longer causes them to dry
out and become even less stable. When adding sugar to beaten egg
whites add it slowly when soft peaks just begin to form and then continue
beating to form soft peaks that don’t droop over.
BEATING HEAVY CREAM
When beating heavy cream, if possible and time allows, use a chilled
bowl, and chill the whisk attachment. The best shaped bowl for whipping
cream is one that is deep with a rounded bottom. The cream should come
out of the refrigerator just before whipping. Hold the Whip attachment so
that it is just skimming the surface, and whip until the cream begins
to thicken and develop some body; then immerse the whisk totally into
the cream. Whipped cream may be used at either soft or firm peaks
depending on preference. It may be flavored as desired. For best results,
whip cream just before using.
If it must be whipped ahead, add a whipped cream stabilizer such as
Oetker®’s Whip It™.
Oetker®is a registered trademark owned by Dr. August Oetker Nahrungsmittel, KG, LP.
6

7
Motor
Body Housing
Detachable
Blending Shaft
Blade
Guard
Stainless
Steel
Blending
Blade
Chopper/Grinder
Attachment
Cord
Wrap
On/Off
Button
Comfort
Handle
Whisk Attachment
Detachable
Gearbox
Chopper/
Grinder
Cover

ASSEMBLY
BLENDING ATTACHMENT
1. Align the motor body with the blending attachment and slide the
pieces together until you hear and feel the pieces click together.
It may be helpful to press the release button when assembling.
CHOPPER/GRINDER ATTACHMENT
8
A. Chopper/Grinder
Prep Bowl
B. Cover Slots (3)
for Attaching
Cover
C. Metal Blade
Assembly Shaft
D. Rubber Feet
E. Blade Assembly
F. Blade Ring
G. Plastic Blade
Sheath
H. Chopper/Grinder
Cover
I. Lift Tabs
J. Chopper/Grinder
Spline
A
B
C
D
J
HIE
F
G

9
REVERSIBLE BLADE
The Cuisinart®Smart Stick®Hand Blender chopper/grinder attachment is
equipped with a reversible blade. This blade is sharp on one side and
blunt on the other. The blade is attached to a plastic ring which slides
over the blade assembly shaft, so it can be easily turned over to select
the appropriate blade. A guide for proper blade selection follows in the
section, Frequent Uses for Chopper/Grinder (page 15.)
Before you process any food, assemble the parts.
1. Place the prep bowl on a flat, dry, stable surface. It should be close to
an electrical outlet of the same voltage as stated on the rating plate on
the Smart Stick®Hand Blender.
2. The metal blade assembly shaft is attached to the bottom of the prep
bowl. If not already in place, slide the fully assembled blade assembly
over the top of the blade assembly shaft.
2a. Putting together the blade assembly:
Connect the blade ring (F) to the plastic blade sheath (G). Line up the
blade ring opening with the plastic sheath. Let the blade ring slide to
the bottom of the plastic sheath. HOLD THE BLADE RING BY THE
CENTRAL HUB HOLDING RIBS (grips)(K) ONLY. DO NOT TOUCH
THE RAZOR-SHARP BLADES.
Note these important features of the blade ring. The blade ring can be
placed over the plastic blade sheath in two different ways:
If you hold it this way (A), you will see the word “Sharp” on the blade.
Assemble the blade this side up to use the sharp edge. (see the section
on processing food for information about when to use the sharp edge.)
If you hold it this way (B), you will see no writing on the blade.
Assemble the blade this side up to use the blunt edge.
(See the section on processing food, for information about when
to use the blunt edge.)
N
F
G
K
2a
A. SHARP SIDE
B.
BLUNT SIDE UP

There are notches (C) on opposite sides of the interior of the hub.
These fit over ridges on the sides of the plastic blade sheath.
Pick up the blade ring by its hub holding ribs (grips) and line up the
notches in the interior of the blade ring hub with the ridges on the sides
of the plastic blade sheath. Let the blade ring slide down to the bottom
of the plastic blade sheath. The lower blade should almost touch the
bottom of the prep bowl.
Lift the prep bowl, holding it firmly from the bottom. Pick up the blade
ring by its hub holding ribs (grips) and turn it very slightly clockwise.
This locks it in place on the plastic blade sheath and prevents it from
sliding up during processing.
3. Connect the Smart Stick®Hand Blender
motor body to the top of the
chopper/grinder attachment cover.
Align the spline in the chopper/grinder
cover’s drive shaft with the ribbed
opening on the underside of the motor
body. When aligned properly, slide the
two pieces together until they mate.
You will feel and hear a slight click.
It may be helpful to press the rubber
release button when sliding these
pieces together.
4. With the hand blender in place,
locate the chopper/grinder cover
and place it on top of the prep bowl.
4a. Be sure that the 3 ridges at the top of the blade assembly
line up with the 3-arm propeller gear in the underside of the
chopper/grinder cover, and that the cover is seated all around the
top of the prep bowl.
4b. To properly seat the cover, you must line up the three molded
pins from the cover with the 3 slots at the top of the prep bowl.
Rotate cover counterclockwise to secure it to the prep bowl.
Rotate the cover until the pins are in the far left position in
the slots.
10
3.
Motor
Body Bottom and
Chopper/Grinder
Cover Top View
C. NOTCH
