Aqua-Cleer
MFP 4–44 MD
Model 400-800-1200
1600-2200-2800-3300
USER’S
TECHNICAL MANUAL
MEDICAL DEVICE
0434

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP 4-44 - MD – User
Symbols given in this manual and their meaning:
ATTENTION
VERY IMPORTANT INFORMATION REGARDING THE SAFETY OF
THE PATIENT OR OPERATOR, OR INDICATIONS PROVIDED IN
ORDER TO PREVENT EQUIPMENT FAILURES. READ CAREFULLY
BEFORE USING THE EQUIPMENT.
N.B. (NOTA BENE)
Important information regarding correct operation of the
equipment. Read carefully before operating on the equipment.
ATTENTION
This instruction manual is an integral part of the equipment and is
intended for the user.
Culligan declines any liability for the consequences of operations not
complying with that given in this manual or carried out by unauthorized
persons.
ATTENTION
Any installation, maintenance or repair work on the systems must be carried out by Authorized Culligan Service
Center personnel.
The room where the systems, ancillary material and consumable products are located must meet the safety, use and
storage requirements of the current regulations.
The water produced by every unit must only be used for its specifically intended purpose. Culligan declines any
liability for the consequences of improper use of the water produced by its equipment.
Any equipment operation fault not envisaged in this manual must be promptly reported to the Authorized Culligan
Service Center. Culligan declines any liability for the consequences of prolonged use of a unit having faults that were
not reported.
When necessary, the choice, dosing and handling of chemicals must be carried out according to the instructions given
in this manual and in compliance with the Technical Safety Sheets of the single products used. Culligan declines any
liability for the consequences of using different products or, for those given in this manual, in concentrations
different from those specified.
Do not tamper with the equipment. Any maintenance or repair work not envisaged in this manual is likewise
prohibited.
Packing, consumable materials, etc., and waste produced by the equipment must be disposed of in compliance with
the current regulations.

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP 4-44 - MD – User
CONTENTS
- GENERAL INFORMATION Page 3
- OPERATING LIMITS AND TECHNICAL CHARACTERISTICS ” 3
- DESCRIPTION OF SUPPLY “ 4
-LABELING AND IDENTIFICATION “ 4
-INSTALLATION “ 6
-DESCRIPTION OF ELECTRONIC PANEL
KEYBOARD ” 6
-OPERATION FOR USER WATER PRODUCTION ” 6
-CONTROLS AND ADJUSTMENTS ” 7
- SANITIZATION “ 7
- ALARMS “ 7
- PROGRAMMING “ 8
- MAINTENANCE “ 8
-DISPOSAL “ 8
-TABLES “ 9
- TROUBLESHOOTING “ 10
-MAINTENANCE SCHEDULE “ 11

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP4-44 - MD – User 3
GENERAL INFORMATION
The Aqua-Cleer MFP 4-44 MD MD is designed to produce very pure
water for hemodialysis use in conjunction with artificial kidneys; it must
therefore be fed with water to be treated, having characteristics at least
suitable for potable use and treated through a prefiltration process
specially developed and created by Culligan, on the basis of appropriate
chemical analyses.
For the quality of product water, the Aqua-Cleer MFP 4-44 MD is
compatible with all artificial kidneys which, for the qualitative
characteristics of the inlet water, adopt AAMI standards. For the quantity
of product water it is compatible with all artificial kidneys which, overall,
are able to receive an equivalent water flow.
Due to its design, the Aqua-Cleer MFP 4-44 MD can only be used for
hospital dialysis by medical and/or auxiliary medical personnel.
OPERATING LIMITS AND TECHNICAL
CHARACTERISTICS
OPERATING ENVIRONMENT
ATTENTION
THE AQUA-CLEER MFP 4-44 MD IS DESIGNED
FOR USE IN THE ELECTROMAGNETIC
ENVIRONMENT GIVEN BELOW; THE USER
MUST THEREFORE ENSURE THAT THE
EQUIPMENT IS USED IN SUCH AN
ENVIRONMENT AND CONSIDER THIS
WHENEVER INTENDING TO INSTALL NEW
EQUIPMENT IN CONJUNCTION WITH THE
AQUA-CLEER.
THE TABLES SECTION GIVES THE
ELECTROMAGNETIC CHARACTERISTICS THE
ENVIRONMENTS MUST COMPLY WITH FOR
CORRECT OPERATION OF THE MFP 4-44 MD..
ALSO, PORTABLE AND MOBILE RADIO
COMMUNICATION EQUIPMENT CAN AFFECT
THE OPERATION OF THE AQUA-CLEER MFP 4-
44 MD.
OVERALL DIMENSIONS
- Width: see Table 1
- Depth: see Table 1
- Total height: see Table 1
- Shipping weight: see Table 1
ATTENTION
NEVER PLACE ANYTHING ON THE EQUIPMENT
OR PARTS OF IT.
CHARACTERISTICS OF WATER TO BE TREATED (permissible
values)
ATTENTION
THE AQUA CLEER MFP 4-44 MD IS DESIGNED
TO PRODUCE VERY PURE WATER; IT MUST
THEREFORE BE FED WITH RAW WATER,
WHOSE CHARACTERISTICS (NOT SPECIFIED
BELOW) ARE AT LEAST THOSE MAKING IT
SUITABLE FOR POTABLE USE.
-Max. salinity Aqua-Cleer MFP 4-44 MD model from 400 to 1600: 3000
mg/l (= TDS in ppm)
-Max. salinity Aqua-Cleer MFP 4-44 MD model from 2200 to 3300:
1500 mg/l (= TDS in ppm)
- Temporary hardness: 35°f
- S.D.I.: 3
- pH: 7 1
- Chlorine: 0.2 ppm
- Iron: 0.1 ppm
-Manganese: 0.05 ppm
-Calcium Sulfate: concentration in reject water below the solubility
limit
-Calcium Carbonate: Langelier index negative in reject water
-Silica: concentration in reject water below the solubility limit.
N.B.:
Calcium Sulfate, Calcium Carbonate and Silica:
the limits specified refer to the need to prevent
encrustant precipitation.
- Limit water temperature: 535°C
ATTENTION
AT TEMPERATURES BELOW OR ABOVE THE
FIXED LIMITS THE MEMBRANES MAY
UNDERGO PERMANENT PHYSICAL DAMAGE
- Feed water pressure: min. 29 psi (2 bar)
max. 43 psi (3 bar)
- Available feed flow rate: see Table 1
CHARACTERISTICS OF TREATED WATER INTENDED FOR THE
USER (SERVICE)
N.B.:
The user treated water flow rate parameter is
obtained as a function of various parameters:
temperature, operating pressure and recovery
ratio are the main ones.
The flow rates given above in the table are
obtained at a water temperature of approx. 20°C,
with a pressure of approx. 261 psi and 200 psi
(18 and 14 bar) according to the models,
recovery ratio of 75% and new osmosis module.
- Flow rate in normal operation: see Table 1
- Removal of salinity: ~ 96%
- Removal of organic matter
with molecular weight 200: ~100 %
- Removal of bacteria and pyrogens: ~99%
CHARACTERISTICS OF WATER TO BE SENT TO DRAIN
N.B.:
The drain water flow rate parameter is also
obtained as a function of various parameters:
temperature, operating pressure and recovery
ratio are the main ones:
The above flow rates are obtained at a water
temperature of approx. 10°C, with a pressure of
approx. 200 or 261 psi (14 or 18 bar) according
to the models, recovery ratio of 45% and no
longer new osmosis module.
- Max. flow rate: see Table 1
CHARACTERISTICS OF EQUIPMENT PLUMBING CONNECTIONS
(Figure 1)
The following plumbing connection fittings are arranged on the back
of the system:
-INLET (FEED INLET)
Raw water inlet: 1”G female
-PRODUCT (PRODUCT OUTLET)
Outlet for osmosed water intended for user (service): ¾”G female
-DRAIN (REJECT OUTLET)
Drain water outlet: ¾”G female
EQUIPMENT ELECTRICAL CHARACTERISTICS
- Power supply: see Table 1
-Max. input: see Table 1
- Absorption: see Table 1
- Protection rating: IP 54

Aqua-Cleer MFP 4-44 - MD – User M006-06 – Rev. 01 – 05/2012
4
Table 1
Model
MFP 4-
44 MD
MD
Min. flow
rate, inlet
water l/h
Max.
flow
rate,
treated
water
(1) l/h
Max.
flow
rate,
drain
water
(2) l/h
Membrane
max. feed
water
pressure
psi (bar)
Electrical connections Dimensions in mm Approx.
shipment
weight
in kg
Voltage
in V
3 L
+N
+PE
Frequency
in Hz
Max.
input
in KW
Max.
absorpt
ion
(Imax)
A
Width Depth
Heigh
t
400 2000 400 1685 200 (14) 380-415 50 1.6 3.5 500 660 1550 115
800 2000 800 1370 200 (14) 380-415 50 1.6 3.5 500 660 1550 140
1200 3600 1200 2655 200 (14) 380-415 50 2.3 5 500 660 1550 170
1600 3600 1600 2340 200 (14) 380-415 50 2.3 5 500 660 1550 190
2200 5500 2000 3925 261 (18) 380-415 50 4.2 8.5 500 660 1800 220
2800 5500 2400 3610 261 (18) 380-415 50 4.2 8.5 500 660 1800 250
3300 5500 2800 3295 261 (18) 380-415 50 4.2 8.5 500 660 1800 280
(1) Average values calculated according to the following conditions: water temperature 20°C; operating pressure 200 or 261 psi (14 or 18 bar);
recovery ratio 75%; raw H2O salinity 500 ppm NaCl; product H2O pressure 0 bar; new modules.
(2) Max. values calculated according to the following conditions: water temperature 10°C; operating pressure 200 or 261 psi (14 or 18 bar) according
to the models; reject recirculation completely closed and no longer new modules.
DESCRIPTION OF SUPPLY
Components:
1 main unit
4 vibration dampers
8 plain washers
4 nuts
3 fuses for phase change
Photo No. 1
LABELING AND IDENTIFICATION
The equipment to which this instruction manual belongs is identified
by the indications given on the labels.
Two types of labels are used, i.e. the two placed on the outside of
the equipment packing (on opposite sides), and the one placed on
the outside of the frame on the back.
Given below are the photos showing the position of the labels and
examples of labels used, with the meaning of the data or symbols
on them.
Photo No. 2: Position of identification label on packing
Figure 1: Example of identification label on outside of packing
Meaning of data and symbols given on the identification label on
outside of packing:
1. manufacturer's mark,
2. name and address of manufacturer,
3. name and model of equipment,
4. manufacturer's equipment model catalogue number,
5. date of manufacture,
6. manufacturer's univocal serial number identifying the equipment,
7. symbol indicating storage information,
8. equipment min. and max. storage temperature in °C,
9. symbol indicating storage information,
10. type of marking.

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP4-44 - MD – User
5
Photo No. 2A: Position of label on right side of frame
Figure 2:Label on equipment
Meaning of data and symbols given on the identification label on
outside of packing:
1. manufacturer's mark,
2. name and address of manufacturer,
3. name and model of equipment,
4. symbol indicating “ATTENTION, SEE INSTRUCTIONS FOR
USE”,
5. manufacturer's univocal serial number identifying the
equipment,
6. manufacturer's equipment model catalogue number,
7. symbol indicating water temperature operating limits,
8. date of manufacture,
9. type of marking.
10. equipment operating voltage,
11. equipment operating frequency,
12. number of phases necessary for equipment operation,
13. equipment max. absorption during operation,
14. equipment max. power input during operation,
15. equipment protection rating,
16. equipment class,
17. symbol indicating type of equipment,
Photo No. 3: Danger of electrocution yellow label placed on the
electronic control panel at the cover which, if removed, enables
access to dangerous live parts.
Photo No. 4: “Reject Recirculation Flow” label
Photo No. 5: “Reject Circulation Flow Adj.” label
Photo No. 6: “Reject Flow Adj.” label

Aqua-Cleer MFP 4-44 - MD – User M006-06 – Rev. 01 – 05/2012
6
Photo No. 7: “Pressure Pump Adj.” label
INSTALLATION
ATTENTION
THE EQUIPMENT MUST ONLY BE INSTALLED
BY AUTHORIZED CULLIGAN SERVICE
CENTER TECHNICIANS.
THE AQUA-CLEER MFP 4-44 MD SHOULD NOT
BE PLACED NEAR OR ON OTHER
EQUIPMENT; HOWEVER, IF IT HAS TO BE
USED NEAR OR ON OTHER EQUIPMENT, THE
AQUA-CLEER MFP 4-44 MD MUST BE
WATCHED OVER TO CONTROL ITS NORMAL
OPERATION IN THE CONFIGURATION USED.
FOR ALL PREINSTALLATION AND PLUMBING
AND ELECTRICAL INSTALLATION
INSTRUCTIONS, REFER TO THE RELEVANT
SECTION IN THE SERVICE PART.
DESCRIPTION OF ELECTRONIC PANEL
KEYBOARD
(unless otherwise specified, see fig. 3)
Figure 3:
The following keys are at the operator's disposal:
- MAIN SWITCH (Item 13 of Figure 3)
Turn to position (O) to disconnect the equipment power supply. Turn
to position (I) to enable the power supply.
EQUIPMENT ON STANDBY
Press to start the equipment operation cycle. Press this key again to
stop it.
RESETTING ALARMS (Reset)
In alarm status, whatever the cause, press this key to silence the
beep. The alarm message remains on the display.
ATTENTION SANITIZATION
KEY FOR FUNCTIONS TO BE CARRIED OUT
EXCLUSIVELY BY AUTHORIZED SERVICE
CENTER TECHNICIANS.
-DISPLAY
The MFP 4-44 MD has a multifunction display able to provide the user
with all useful information on machine operation in real-time.
ATTENTION
UP and DOWN
KEYS FOR FUNCTIONS TO BE CARRIED OUT
EXCLUSIVELY BY AUTHORIZED SERVICE
CENTER TECHNICIANS.
OPERATION FOR USER (SERVICE) WATER
PRODUCTION
(unless otherwise specified, see fig. 3)
When the main switch located on the side of the electronic panel is in
position “1”, the display shows:
Standby mode
Press to start the cycle.
The display now shows
OPERATE Mode initializing
after about 15 seconds the pump starts, then if the feed pressure
remains above the minimum setting level the equipment will continue
regular operation.
The display then shows on page 1
OPERATE mode Prod. Cd. -----
 S
value indicating product water conductivity.
By pressing the key it is also possible to display the following
pages in sequence:
on page 2 OPERATE mode FeedCd----S
value indicating feed water conductivity;
on page 3 OPERATE mode SaltRej. ----%
value indicating salt removal percentage;
on page 4 OPERATE mode Product ---- l/h
value indicating user product water flow rate in l/h;
on page 5 OPERATE mode Reject ---- l/h
value indicating drain water flow rate in l/h;
on page 6 OPERATE mode RecRatio.----%
value indicating recovery ratio percentage;
To go back to page 1 from page 6, press in sequence .

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP4-44 - MD – User 7
ATTENTION
DURING NORMAL OPERATION ALWAYS KEEP
PAGE 1 DISPLAYED, OTHERWISE THE
PRODUCT HIGH CONDUCTIVITY ALARM WILL
BE INACTIVE!
N.B.:
With every restart, the display automatically
shows page 1 again, regardless of the page
displayed before the stop.
N.B.:
To modify factory-set parameters, contact the
authorized Culligan service center..
Save for any adjustments to be made following the checks
described in the specific section, the equipment is now ready to
supply water to the user.
ATTENTION
FOR CORRECT OPERATION OF THE SYSTEM,
EVEN IN THE MOST UNFAVORABLE
CONDITIONS (E.G. HIGH TEMPERATURE), THE
NOMINAL FLOW RATES MUST NOT BE
EXCEEDED. IF NECESSARY, REDUCE THE
FEED PRESSURE BY MEANS OF THE
PRESSURE REDUCER INSTALLED AHEAD OF
THE EQUIPMENT.
CONTROLS AND ADJUSTMENTS
ATTENTION
DESPITE CAREFUL FACTORY-SETTINGS, A
FUNCTIONAL CHECK OF THE EQUIPMENT
MUST BE CARRIED OUT (BY AUTHORIZED
CULLIGAN SERVICE CENTER TECHNICIANS)
BEFORE INSTALLATION AND WHENEVER IT
IS USED AGAIN AFTER AN IDLE PERIOD OF
MORE THAN 3-4 DAYS
SANITIZATION
This is the series of operations carried out to eliminate the proliferation
of bacterial loads that can be created when the water remains stagnant
for certain period.
ATTENTION
FOR THE SANITIZATION OPERATIONS,
CONTACT THE AUTHORIZED CULLIGAN
SERVICE CENTER.
SANITIZATION FREQUENCY
It is advisable to carry out this operation at least once a month.
Sanitization must be always carried out in the following cases:
A) At first start-up and after every replacement of the osmosis
modules.
B) Before every dialysis session when done at home.
C) When the treated water intended for the user is contaminated by
bacteria (ascertained through special analyses by hospital
personnel).
D) In case of public or private health service facilities, when deemed
appropriate by the doctor in charge of dialysis
E) Before every equipment stop for periods of more than 3-4 days.
F) Regularly every 6 months when not done for one of the above
reasons and the equipment has not been operated continuously.
RECOMMENDED SANITIZING CHEMICALS AND THEIR
CONCENTRATION
PERESAL with max. permissible concentration of 0.2% in at least
softened water.
ALARMS
LOW FEED WATER PRESSURE
the display shows
WARNING..Low Pressure Alarm
with a continuous beep and the high pressure pump stops
automatically.
To silence the alarm, press the key , otherwise it stops
automatically after 2 minutes.
When the min. pressure is restored, the alarm is cancelled
automatically and the equipment recommences the start-up
procedure. The display continues to show the message:
WARNING..Low Pressure Alarm
until the key is pressed
THERMAL ALARM
In case of pump-motor unit overheating, the unit stops and the display
shows: WARNING Thermal Alarm
and a continuous beep sounds.
To silence the acoustic alarm, press the key , otherwise it stops
automatically after 2 minutes.
N.B.:
In this stage the equipment will remain shut
down. To eliminate the fault, contact the
authorized Culligan service center..
HIGH CONDUCTIVITY OF USER WATER
It is possible to set a product water max. conductivity threshold and
the corresponding alarm activation delay when the set threshold is
exceeded; to change the factory-setting, refer to section 4.
The display will show:
WARNING Prod Cond Alarm
and a continuous beep sounds.
To silence the acoustic alarm, press the key otherwise the alarm
will continue until the conductivity falls below the max. set threshold.
Even if the alarm resets automatically, the display will continue to show
the message: WARNING Prod Cond Alarm
until the key is pressed.
If a second alarm is activated before the last displayed alarm message
has been cancelled, the second will be superimposed over the first and
so on. Cancellation will occur in sequence starting from the last alarm
activated, by repeated pressing of the key .
ATTENTION
DESPITE THE ALARMS, THE EQUIPMENT WILL
CONTINUE PRODUCING WATER.
THIS WATER WILL BE WILL BE WITH HIGH
CONDUCTIVITY BUT WILL NOT IN ANY WAY
COMPROMISE THE DIALYTIC SESSION IF IN
PROGRESS.
IN ANY CASE IT IS UP TO THE DOCTOR TO
DECIDE WHAT TO DO, ALSO DUE TO THE
POSSIBLE CHANGE OF OTHER
ENVIRONMENTAL PARAMETERS AND THE
GENERAL SITUATION CREATED.
TO ELIMINATE THE CAUSE OF THIS ALARM,
CONTACT THE AUTHORIZED CULLIGAN
SERVICE CENTER..

Aqua-Cleer MFP 4-44 - MD – User M006-06 – Rev. 01 – 05/2012
8
PROGRAMMING
ATTENTION
EQUIPMENT PROGRAMMING CAN ONLY BE
CARRIED OUT BY AUTHORIZED CULLIGAN
SERVICE CENTER TECHNICIANS.
FOR INFORMATION REGARDING THE
VARIOUS PROGRAMMING POSSIBILITIES,
CONTACT THE LATTER. CULLIGAN DECLINES
ANY LIABILITY FOR MALFUNCTIONING OR
DAMAGE DUE TO PROGRAMMING CARRIED
OUT BY UNAUTHORIZED PERSONNEL.
MAINTENANCE
ATTENTION
ANY MAINTENANCE OPERATIONS CARRIED
OUT BY THE USER WILL INVALIDATE ALL
WARRANTIES AND RELIEVE CULLIGAN OF
ANY LIABILITY. IN THIS WAY CULLIGAN ALSO
GUARANTEES THE USE, WHEN NECESSARY,
OF ORIGINAL REPLACEMENT PARTS, WHICH
ARE THE ONLY ONES ALLOWED FOR
CORRECT OPERATION OF THE EQUIPMENT.
THE OWNER OF THE EQUIPMENT IS ADVISED
TO STIPULATE SPECIFIC MAINTENANCE
CONTRACTS WITH CULLIGAN ITALIANA
S.p.A. OR AUTHORIZED SERVICE CENTERS
INDICATED BY THE LATTER.
N.B.:
The User must carry out the checks indicated in
Table E.
DISPOSAL
Operations for disposing of the equipment or its parts must be carried
out in compliance with the requirements of Decree 152-2006.
Regarding the packing, plastic, elastomer and metal parts must be
eliminated as differentiated and/or disposal waste.
The osmosis membrane must be regarded as hazardous or non-
hazardous special waste, depending on the substances treated by it.
The electrical-electronic components must be disposed of in
compliance with the requirements of Leg. Decree 151-2005

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP4-44 - MD – User 9
TABLES
TABLE A (Table 201 Standard CEI EN 60601-1-2)
GUIDE AND MANUFACTURER'S DECLARATION – ELECTROMAGNETIC EMISSIONS
The AQUA-CLEER MFP 4-44 MD is designed to operate in the electromagnetic environment specified below. The AQUA-CLEER MFP 4-44 MD user must ensure that it is used in such an environment
Emission test Conformity Electromagnetic environment
CISPR 11
RF emissions Group 1 The AQUA-CLEER MFP 4-44 MD uses RF energy only for its internal operation. Since its
emissions are very low and probably do not cause any interference in nearby electronic
equipment.
CISPR 11
RF emissions Class B The AQUA-CLEER MFP 4-44 MD is suitable for use in all places connected to a low-voltage
public network (including domestic environments and those directly connected) that supplies
buildings used for domestic purposes.
Harmonic emissions
CEI EN 61000-3-2 Class A
Flicker/voltage fluctuation emissions
CEI EN 61000-3-2 C
TABLE B (Table 202 Standard CEI EN 60601-1-2)
GUIDE AND MANUFACTURER'S DECLARATION – ELECTROMAGNETIC IMMUNITY
The AQUA-CLEER MFP 4-44 MD is designed to operate in the electromagnetic environment specified below. The AQUA-CLEER MFP 4-44 MD user must ensure that it is used in such an environment.
Immunity test Test level
CEI EN 60601-1-2 Conformity level Electromagnetic environment
Electrostatic discharge
(ESD)
CEI EN 61000-4-2
6kV in contact
8kV in air 6kV in contact 8kV in air
Floors must be in wood, concrete or ceramic. If the floors are
covered with synthetic material, the relative humidity must be at least
30%
Transients/fast electric
trains
CEI EN 61000-4-4
2kV for power lines 2kV for power lines The quality of the mains voltage should be that of a typical
commercial or hospital environment
1kV for input/output lines 1kV for input/output lines
Overvoltages
CEI EN 61000-4-5 1kV differential mode
2kV common mode 1kV differential mode 2kV common mode The quality of the mains voltage should be that of a typical
commercial or hospital environment
Voltage dips, brief outages and
voltage variations in the power
supply input lines
CEI EN 61000-4-11
<5 % UT (>95 % dip in UT) for 0.5 cycles <5 % UT (>95 % dip in UT) for 0.5 cycles The quality of the mains voltage should be that of a typical
commercial or hospital environment. If the equipment user requires
continuous operation also during a mains power failure, it is in any
case advisable to power the equipment through an UPS unit or with
batteries
40 % UT (60 % dip in UT) for 5 cycles 40 % UT (60 % dip in UT) for 5 cycles
70 % UT (30 % dip in UT) for 25 cycles 70 % UT (30 % dip in UT) for 25 cycles
<5 % UT (>95 % dip in UT) for 5 s <5 % UT (>95 % dip in UT) for 5 s
Magnetic field at mains frequency
(50/60Hz)
CEI EN 61000-4-8 3 A/m 3 A/m Magnetic fields at mains frequency should have levels characteristic
of a typical commercial or hospital environment.
TABLE C (Table 204 Standard CEI EN 60601-1-2)
RECOMMENDED SEPARATION DISTANCE BETWEEN PORTABLE AND MOBILE RADIO COMMUNICATION EQUIPMENT AND
THEAQUA-CLEER MFP 4-44 MD
THEAQUA-CLEER MFP 4-44 MD is designed to operate in an electromagnetic environment where radiated RF interference is under control. The AQUA-CLEER MFP 4-44 MD user must help prevent
electromagnetic interference by ensuring a minimum distance between RF mobile and portable communication equipment (transmitters) and theAQUA-CLEER MFP 4-44 MD as recommended below, in
relation to the maximum output power of the radio communication equipment.
Specified max. output power of
transmitter (W)
Separation distance at transmitter frequency (m)
150 kHz 80 MHz P
V
d





1
5,3 80 MHz 800 MHz P
E
d





1
5,3 800 MHz 2.5 GHz P
E
d






1
7
0.01 0.12 0.12 0.23
0.1 0.37 0.37 0.74
1 1.17 1.17 2.33
10 3.69 3.69 7.38
100 11.67 11.67 23.33
For the transmitters specified for a maximum output power not given above, the recommended separation distance d in meters (m) can be calculated using the equation applicable to the
transmitter frequency, where P is the transmitter's maximum rated output power in Watts (W) according to the manufacturer.
Notes:
(1): At 80MHz and 800MHz, the highest frequency range is applied.
(2): These guidelines may not apply in all situations. Propagation is affected by the absorption and the reflection of structures, objects and people.
TABLE D (Table 206 ref. Standard CEI EN 60601-1-2)
GUIDE AND MANUFACTURER'S DECLARATION – ELECTROMAGNETIC IMMUNITY
The AQUA-CLEER MFP 4-44 MD is designed to operate in the electromagnetic environment specified below. The AQUA-CLEER MFP 4-44 MD user must ensure that it is used in such an environment
Immunity test Test level
CEI EN 60601-1-2 Conformity Level Electromagnetic environment Recommended separation distance
Conducted RF
CEI EN 61000-4-6 3 VRMS
150 KHz 80 MHz [3] VRMS
Portable and mobile RF communication equipment should not be used nearer to any part of the
[device / system], including the cables, than the recommended separation distance, calculated with
the equation applicable to the transmitter frequency.
Recommended separation distance
Pd 17.1
Radiated RF
CEI EN 61000-4-3 3 V/m
80 MHz 2.5 GHz [3] V/m Pd 17.1from 80 MHz to 800 MHz
Pd 33.2from 800 MHz to 2.5 GHz
P is the transmitter's max. rated output power in Watts (W) according to the manufacturer and dis the recommended separation distance in meters.
The field intensities for fixed transmitters, as determined by an electromagnetic surveyaof the site, could be lower than the conformity level in each frequency rangeb.
There may be interference near equipment marked with the symbol:
Notes:
(1): At 80MHz and 800MHz, the highest frequency range is applied.
(2): These guidelines may not apply in all situations. Electromagnetic propagation is affected by the absorption and the reflection of structures, objects and people.
A The field intensities for fixed transmitters such as base stations for radiophones and landline mobile phones, amateur radio operator equipment, AM and FM radio transmitters and TV transmitters
cannot be accurately and theoretically foreseen. To appraise an electromagnetic environment caused by RF transmitters, an electromagnetic survey of the site should be considered. If the field
intensity measured in the place where the AQUA-CLEER MFP 4-44 MD is used exceeds the above-mentioned applicable conformity level, normal operation of the AQUA-CLEER MFP 4-44 MD
should be placed under observation. In case of abnormal performance, additional measures may be necessary, such as a different orientation or positioning of the AQUA-CLEER MFP 4-44 MD
B The field intensity in the frequency range of 150 kHz to 80 MHz should be less than 3 V/m.

10 Aqua-Cleer MFP 4-44 - MD – User M006-05 – Rev. 01 – 05/2012
TROUBLESHOOTING
PROBLEM CAUSES CURES
The equipment display is off although the cable is connected
and the “0-1” disconnecting switch is turned to ”1”. Probable momentary or prolonged power outage. Make sure the main switch or auxiliary switches (if present) are not deactivated; if disconnecting the equipment from the
power supply then reactivate the switch/es. If the switch does
not remain on, contact a qualified electrician.
If the cause is due to a power outage, wait for it to be
restored.
Probable non-activation of the high-sensitivity differential switch
required for installation. Activate the high-sensitivity differential switch.
Probable poor operation of the disconnecting switch installed on
the equipment electronic panel. Contact the Authorized Culligan Service Center that carried out installation.
Probable incorrect or only partial connection of the power cable
to the power supply terminals. Contact the Authorized Culligan Service Center that carried out installation.
Probable incorrect connection of the equipment power cable to
the electronic panel. Contact the Authorized Culligan Service Center that carried out installation.
Although the cable is connected and the “0-1” disconnecting
switch is turned to ”1”, the equipment does not display the
message: Stand-by mode
Probable panel electronic board fault. Contact the Authorized Culligan Service Center that carried
out installation.
Probable incorrect or only partial connection of the power cable
to the power supply terminals. Contact the Authorized Culligan Service Center that carried out installation.
Probable fault along the electric line supplying the terminals to
which the equipment power cable is connected. Contact a qualified electrician to check and eliminate the cause.
Although having displayed the message:
Stand-by mode
The equipment does not respond to the commands given
following the instructions in this manual.
Probable automatic shutdown of the equipment due to a lack of
water. Check that water is being supplied by the water company.
Make sure the shutoff valve required for installation and other
possible valves are open.
Make sure all the pipes are correctly connected to the
equipment without constrictions along their paths.
Probable panel electronic board fault. Contact the Authorized Culligan Service Center that carried
out installation.
The equipment is blocked and does not restart, although not
displaying alarm signals. Probable activation of the safety pressure switch (O) in Figure 1 for overpressure on the service product water supply line. Contact the Authorized Culligan Service Center that carried out installation.
Although having displayed the messages given in this manual,
the equipment no longer responds to subsequent commands.
Probable automatic shutdown of the equipment due to a lack of
water. Check that water is being supplied by the water company.
Make sure the shutoff valve required for installation and other
possible valves are open.
Make sure all the pipes are correctly connected to the
equipment without constrictions along their paths
Probable panel electronic board fault. Contact the Authorized Culligan Service Center that carried
out installation.
During setting of the controls envisaged in this manual, the
display does not show the relevant messages. Probable automatic shutdown of the equipment due to a lack of water. Check that water is being supplied by the water company.
Make sure the shutoff valve required for installation and other
possible valves are open.
Make sure all the pipes are correctly connected to the
equipment without constrictions along their paths.
Probable panel electronic board fault. Contact the Authorized Culligan Service Center that carried
out installation.
During execution of the commands given, visual and/or acoustic
alarm signals envisaged in this manual occur. Various but defined in the special "ALARMS" section of this manual. Follow the instructions given in this manual.
During the user (service) water production stage the artificial
kidney signals a lack of water and the Aqua-Cleer MFP 4-44 MD
is not in shutdown status.
Probable incorrect or non-connection of the pipe to the artificial
kidney. Make sure all the pipes are correctly connected to the equipment and the artificial kidney.
Probable constriction in the connection pipe to the artificial
kidney. Eliminate the cause.
Probable incorrect connection of the equipment internal pipes or
a constriction in them with consequent lack of or insufficient
water flow.
Contact the Authorized Culligan Service Center that carried
out installation.
Probable artificial kidney fault. With all the previous probable causes eliminated, follow
instructions of the artificial kidney supplier.

M006-06 – Rev. 01 – 05/2012 Aqua-Cleer MFP4-44 - MD – User
11
MAINTENANCE SCHEDULE
CONDUCTIVITY
CHECK
INLET
WEEKLY
Routine maintenance to be
carried out by the USER
date
signature
PRODUCT date
signature
FLOW RATE
CHECK
PRODUCT date
signature
REJECT date
signature
RECIRCULATION date
signature
CONDUCTIVITY
CHECK
INLET
MONTHLY
Main and extraordinary maintenance to be carried out by the
CULLIGAN SERVICE CENTER
date
signature
PRODUCT date
signature
REJECT date
signature
S.D.I. TEST date
signature
ELECTRIC FUNCTIONS AND
ALARMS EFFICIENCY CHECK
SIX-MONTHLY
date
signature
POSSIBLE SANITIZATION OR
DEACTIVATION date
signature
ELEC. COIL REPLACEMENT INLET
YEARLY
date
signature
POSSIBLE REPLACEMENT OF
FITTINGS AND HOSES date
signature
POSSIBLE OSMOSIS MEMBRANE
CHEMICAL WASH date
signature

12 Aqua-Cleer MFP4-44 - MD – User M006-06 – Rev. 01 – 05/2012
