Current Audio OC525 Troubleshooting guide

The dual purpose Indoor/Outdoor cabinet speaker is the perfect choice
for either main listening or sound reinforcement applications. Get ready
for serious sound with this ported bass reflex speaker. The OC525
makes a great choice when used as satellite speakers.
The graphite mica mineral impregnated polypropylene woofer cone and
butyl rubber surround are virtually impervious to weather and insects.
The 1” titanium tweeter delivers clear crisp high frequencies to provide
high performance high fidelity sound and it is the work horse of the line.
This speaker color is offered in both white and black. The white is a
close match to Frazee White Shadow 181. It can be painted to match
any décor. The speaker enclosure is a durable UV-resistant material
that allows for both indoor and outdoor installations. The perforated
powered coated aluminum alloy grill is long lasting, corrosion resistant
and rust free.
Included in the package is a universal heavy gauge mounting kit. The
kit includes a rust proof U bracket and large easy to install positive
locking serrated knobs. The knobs are attached to the matching
serrated area on the zero balanced point of the enclosure via threaded
studs. This allows the speaker to easily be positioned to place the
sound where you want it. Hand tightening the knobs will clamp the
speaker in place. The speaker may be mounted either horizontally or
vertically.
Electrical connection, up to 12 gauge wire, is made by gold plated
constant tension spring loaded terminals.
This speaker is also offered in a Pro 70Volt version with various
wattage taps and a ½” knock out terminal cover.
One Hardwood Tree is planted in the National Forest to offset the
Styrofoam packaging on each pair.
OC525 OC65 Indoor/Outdoor Speaker User’s Installation Guide
www.currentaudio.com
©2009 Current Audio LLC
1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181
SPECIFICATIONS
OC525
OC65
Driver
5.25” Mica Filled Polypropylene
5.25” Mica Filled Polypropylene
Tweeter, 1” (25.4mm) Dome
Titanium
Titanium
Frequency Response
52Hz-20kHz
47Hz-20kHz
Power handling
5-100 Watts
5-125 Watts
SPL @ 1 Watt/1 meter
89db
90db
Impedance 8 ohm Nominal
Fixed Crossovers
Fixed Crossovers
Height X Width X Depth
9.88"(251m) X 6.75"(172mm) X 6.75”(149mm)
12.13"(308m) X 8.5"(216mm) X 14.75”(200mm)
Color
Black or White
Black or White
Part Number 92041 OC525W White, 92042 OC525B Black
92039 OC65W White, 92040 OC65B Black
Manual URL www.currentaudio.com
Accessories Volume Control ZL45R, ZL60S
Specifications subject to change without notice. OC525 and OC65 RPA 060210
OC525 OC65 ” 2-Way, Indoor/Outdoor
Dual Purpose, Full Range Loudspeaker
OC65B Top OC65W BackOC65W Front

Packaging and Enclosed Parts
Please inspect your pack for damaged or missing parts. Notify your supplier if any discrepancies occur.
The OC525 and OC65 Cabinet Speakers are packaged (2) to abox and sold in pairs.
Each box includes (2) Speaker, (2) U Bracket, and (4) Knobs and (1) Hardwood Tree planted in the National Forest.
Specifications subject to change without notice.
Gold Plated Constant Tension Spring
Loaded Terminals
Red (+)
Black (-)
Install
1. Decide on your location for standard two speaker stereo sound. Observe the rules for speaker placement and listening area.
2. Chose locations for your speakers. If using two separate speakers, keep in mind your “sweet stop” the area where you will spend most of your time.
3. Choose your wiring method: Wall Mount, PVC conduit or Direct Burial cable.14 or 12 gauge low voltage Malibu direct burial cable works fine and is
readily available.
4. Bury your conduit or wire 18” below grade to prevent damage by tillers or shovels when planting. Prewire before hardscape concrete.
5. Insure there is enough room to place the OC525 or OC65 to enable aiming and rotation. Bracket can be mounted vertically or horizontally.
6. Mount the U-Bracket first then attach the speakers with the (2) positive locking knobs. Aim the speaker then tighten the knobs to secure in place.
7. The knobs are a male ¼-20 thread that mate to the 1/4 -20 insert on the speaker. This accommodates other mounts and tamper proof screws.
8. Carefully identify Left and Right cables at both ends . For proper phasing identify the (+) and (-) on each cable.
9. Connect the amplifier Left wire to the to the Red and Black Speaker Terminals on the LEFT OC525 or OC65 speaker. Observe polarity.
10. Connect the amplifier Right wire to the to the Red and Black Speaker Terminals on the RIGHT OC525 or OC65 speaker. Observe polarity.
11. Before connecting the wires to the amplifier check the impedance with a multi-meter on the resistance scale. It should read about 6.5 ohms.
12. If multi-meter reading is OK then connect to amplifier.
13. If using a volume control I suggest placing it inside the house for easy control and to protect it from the elements.
Limited Lifetime Warranty
Current Audio speakers are warranted to be free from defects in materials and or workmanship to the original retail purchaser provided the speaker was
purchased and installed from a Current Audio Authorized Dealer.
In the event of defective materials and or workmanship, Current Audio ,LLC will, without change, repair or replace, at its option, the defective product. In
order to make claim under this Warranty and to obtain performance of any obligation under warranty, please contact Current Audio LLC. Instructions will be
given on how to return the defective product to Current Audio. Returned products must be shipped prepaid. Proof of purchase must be provided with the
product.
The Warranty does not apply to damage not resulting from defective materials and or workmanship while in the possession of the original consumer or due to
unreasonable use by the original consumer, which includes but not limited to improper installation, negligence, unauthorized repair or modification, aesthetic
deterioration from the environment. Products purchased by unauthorized sources will void the warranty and not be honored.
Current Audio ,LLC is not liable for any incidental or consequential damages, so the above limitations or inclusion may not apply to you. This warranty gives
you specific legal rights, and you may have other rights, which vary from state to state within the United States.
OC525 or OC65 Wiring Scheme
OC525 OC65 Indoor/Outdoor Speaker User’s Installation Guide
OC525 and OC65 RPA 060210
OC525 10” 2.1”
U Bracket
Serrated Groves
U Bracket
Speaker Serrated Groves Knob in PlaceMount Kit
OC65 12.5”
OC525 5.3”
OC65 6.55”
¼-20
¼-20
