PRO 70V Indoor/Outdoor Speaker User’s Installation Guide
6.5”/5.25” 2-Way 70Volt, Indoor/Outdoor
Loudspeaker
The OC65/OC525 70V Indoor/Outdoor Constant Voltage
Distribution speaker is the perfect choice for either main listening or sound
reinforcement applications. It can be used in household applications or commercial
distributed public address and sound systems. This ported bass reflex speaker
supplies serious sound.

The graphite mica mineral injected polypropylene woofer cone and butyl rubber
surround are virtually impervious to the weather and insects.

This speaker color is offered in black. It can be painted to match any décor. The
speaker enclosure is a durable UV-resistant material that allows for both indoor and
outdoor installations. The perforated powdered coated aluminum alloy grill is long
lasting, corrosion resistant and rust free.

Included in the package is a universal heavy gauge mounting kit. The kit includes
a rust proof serrated U bracket and large easy to install positive locking knobs. The
knobs are attached to the matching serrated area on the zero balanced point of
the enclosure via threaded studs. This allows the speaker to easily be positioned
to place the sound where you want it. Hand tightening the knobs will clamp the
speaker in place. The speaker may be mounted either horizontally or vertically.

Electrical connection, up to 14 gauge wire, is made by a detachable four screw
loaded terminal block for speaker IN/OUT via a ½” knock out terminal cover.
With our limited 5 year warranty you are assured years of excellent sound and
trouble free operation.
SPECIFICATIONS OC65B-70V OC525B-70V OC525W-70V
Driver 6.5” Mica Filled Polypropylene Cone
with Butyl Rubber Surround
5.25” Mica Filled Polypropylene Cone
with Butyl Rubber Surround
5.25” Mica Filled Polypropylene Cone
with Butyl Rubber Surround
Tweeter 1” (25mm) Silk Dome 5/8” (13mm) Polycarbonate Dome 5/8” (13mm) Polycarbonate Dome
Frequency Response 47Hz - 20kHz 52Hz - 20kHz 52Hz - 20kHz
Power Handling 70Volts Single Tap 30 Watts @ 70Volts Single Tap 30 Watts @ 70Volts Single Tap 30 Watts @ 70Volts
SPL 90 dB 1W/1m 89 dB 1W/1m 89 dB 1W/1m
Height X Width X Depth 8 ½ (215 mm) x 7 11/16 (194 mm)
x 11 7/8 (301 mm)
7 5/16 (185mm) x 6 ½ (165mm) x 9
7/8 (249 mm)
7 5/16 (185mm) x 6 ½ (165mm) x 9
7/8 (249 mm)
Color Black Black White
Part Number 93208 OC65B-70V
93206 OC525B-70V
93207 OC525W-70V
www.currentaudio.com
8141 Center St, La Mesa, CA 91942 • 866-927-7181
©2016 Current Audio - All Rights Reserved.
Rev. 01, 09/16 1

www.currentaudio.com
8141 Center St, La Mesa, CA 91942 • 866-927-7181
©2016 Current Audio - All Rights Reserved.
Rev. 01, 09/16
2
Packaging and Enclosed Parts
Install
• Choose locations for your speakers. If using two separate speakers, keep in mind your “sweet spot” the area where you will spend most of your time.
• Choose your wiring method: Wall Mount, PVC conduit or Direct Burial cable.14 gauge low voltage Malibu direct burial cable works ne and is readily
available.
• Bury your conduit or wire 18” below grade to prevent damage by tillers or shovels when planting. Prewire before hardscape concrete.
• Insure there is enough room to place the PRO OC65-70V or PRO OC525-70V to enable aiming and rotation.
• Mount the U-Bracket rst then attach the speakers with the (2) positive locking knobs. Aim the speaker then tighten the knobs to secure in place.
• The knobs are a male ¼-20 thread that mate to the 1/4 -20 insert on the speaker. This accommodates other mounts and tamper proof screws.
• Carefully identify IN and OUT cables at both ends . For proper phasing identify the (+) and (-) on each cable.
• 70 volt speakers can be Daisy Chained from one speaker to the next.
• How do I know what size 70 volt amp to use? Rule of thumb- add up all the wattage taps of the speakers then divide by .75 for safety factor. Example,
suppose you have 10 speakers with the wattage tap of 15, the total wattage would be 150 watts. Divide 150W/.75 = 200W. Now select an amp of
200W or higher.
• Connect the amplier Output wire to the IN on the green connecting block of the PRO OC-70V speaker. Observe polarity. Then connect the OUT to the
next speaker till the end.
• Before connecting the wires to the amplier check the impedance with a multi-meter on the resistance scale. Make sure there are no shorts. (0 resistance)
• If multi-meter reading is OK then connect to amplier.
Limited 5-Year Warranty
Current Audio, LLC speakers and accessories are warranted to be free from defects in materials and or workmanship to the original retail purchaser for a
period of 5 years provided the equipment was purchased and installed from a Current Audio, LLC Authorized Dealer.
In the event of defective materials and or workmanship, Current Audio,LLC will, without charge, repair or replace, at its option, the defective product. In
order to make claim under this Warranty and to obtain performance of any obligation under warranty, please contact Current Audio LLC. Instructions will
be given on how to return the defective product to Current Audio. Returned products must be shipped prepaid. Proof of purchase must be provided with the
product. Suggest saving original packaging for shipping. Current Audio will not be responsible for any return shipping damage.
The Warranty does not apply to damage not resulting from defective materials and or workmanship while in the possession of the original consumer or
due to unreasonable use by the original consumer, which includes but not limited to improper installation, negligence, unauthorized repair or modication,
aesthetic deterioration from the environment. Products purchased by unauthorized sources will void the warranty and not be honored.
Current Audio, LLC is not liable for any incidental or consequential damages, so the above limitations or inclusion may not apply to you. This warranty
gives you specic legal rights, and you may have other rights, which vary from state to state within the United States.
PRO 70V Indoor/Outdoor Speaker User’s Installation Guide
Please inspect your pack for damaged or missing parts. Notify your supplier if any discrepancies occur.
The OCB65/525-70V Cabinet Speakers are packaged two to a box and sold as a pair. Each OC65/525-70V box includes (1:2) Speaker, (1:2) U
Bracket, and (2:4) Knobs and (1:2) ½” knockout cover plate
