Current audio Or6 series Troubleshooting guide

Make your Garden and Landscape “Come Alive” with

the Most Realistic Rock Speakers on the Market!

Our Rock Speakers are „Heard But Not Seen” because they resemble

real rocks. Even the grill blends in to the rock.

The lifelike OR6 Rock Speakers have built-in designed robust high

fidelity sound that is demanded in outdoor environments. They are

great around the spa to provide a tranquil setting yet can deliver

enough power for your teenager‟s pool party.

The materials in both the enclosure and the speaker were carefully

selected to create a rock that is totally weatherized . It can withstand

sun, rain, heat, cold, fog, and coastal dew. In addition, the unit comes

with and “eye” bolt to deter theft.

The OR6 is a single stereo, stand alone speaker, with dual voice coils

and dual tweeters that deliver both left and right sound from one

package. It can also be used in conventional stereo application with two

separate speakers. In the stereo mode bridge the two speaker leads.

No need to stock two separate models. This is one speaker for two

applications.

The color choices are Tennessee Granite and California Sandstone.

Electrical connection is made by four color coded leads.

With our limited 5 year warranty you are assured years of superior

trouble free operation.

Outdoor Simulated Rock Speaker

6.5” Dual Voice Coil Woofer

Dual .75” Silk Dome Tweeter

Stereo or Mono Input

OR6 Series Outdoor Rock Speaker User‟s Installation Guide

www.currentaudio.com

1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181

SPECIFICATIONS Outdoor Rock Speakers

OR6G

OR6S

Driver with Dual Voice Coils

6.5” Mica Filled Polypropylene

Dual Tweeters, ¾” (19mm) Dome

Dual Silk Dome

Frequency Response

47Hz-20kHz

Power handling

5-125 Watts

SPL @ 1 Watt/1 meter

90db

Impedance: 8 ohm Nominal , 4 ohm Bridged

Fixed Crossovers

Approximate Height X Width X Depth

12"(304m) X 14"(356mm) X 11”(279mm)

Color

Tennessee Granite

California Sandstone

Part Number 92043 OR6G Tennessee Granite

92068 OR6S California Sandstone

Manual URL www.currentaudio.com

Accessories Volume Control ZL25R, ZL50S

Specifications subject to change without notice. OR6 RPA 072210

OR6 Series Outdoor Rock User‟s Installation Guide

Packaging and Enclosed Parts

Please inspect your pack for damaged or missing parts. Notify your supplier if any discrepancies occur.

The OR6 Rock Speakers are packaged one to a box and sold as each.

At the bottom of the speaker are two 2 conductor cables for stereo or mono hook-up.Also, two ¼” threaded holes to attach “eye” bolts for theft

deterrent .

OR6 RPA 072210

Specifications subject to change without notice.

Right Side

Red (+)

Black (-)

Left Side

Red(+)

Black (-)

Install

1. Decide if you want standard two speaker separate stereo sound or one speaker with both Left and Right stereo sound. The OR6 can do both.

2. Chose locations for your speakers. If using two separate speakers, keep in mind your “sweet stop” the area where you will spend most of your time.

3. Choose your wiring method, PVC conduit or direct burial cable.14 or 12 gauge low voltage Malibu direct burial cable works fine and is readily available.

4. Bury your conduit or wire 18”below grade to prevent damage by tillers or shovels when planting. Prewire before hardscape concrete.

5. Carefully identify Left and Right cables at both ends . For proper phasing identify the (+) and (-) on each cable.

6. Insure there is enough room to place the OR6 Rock after concrete is finished.

7. If theft is a problem use a 3‟green fence post pounded into the ground and then fasten to an “eye” bolt via a steel braided cable. (Not Supplied)

8. Connect the wires as shown on the OR6 Wiring Scheme. Use Ideal #62 Weather Proof Wire Connector or equivalent. (Not Supplied) The silicone-

based sealant protects against moisture and corrosion. Connecting all four wires to the amp Left and Right will give stereo sound from one speaker.

9. If using as stereo with two separate speakers, bridge both speaker cables. (Connect both Red and Black wires in parallel).

10. Connect the amplifier Left wire to the to the bridged red and black cables of the designated LEFT OR6. Observe polarity.

11. Connect the amplifier Right wire to the to the bridged red and black cables of the designated RIGHT OR6 speaker. Observe polarity.

12. Before connecting the wires to the amplifier check the for proper connection and make sure there are no shorts.

13. If OK then connect to amplifier.

14. If a wall is directly behind the OR6 you can face the grill into the wall. This will wash the wall with sound and further disguise the OR6.

15. If using a volume control I suggest placing it inside the house for easy control and to protect it from the elements.

Caution: Do Not hook-up more then one stereo pair to a zone. In the Bridged stereo mode the impedance is lowered.

Limited 5 Year Warranty

Current Audio, LLC speakers and accessories are warranted to be free from defects in materials and or workmanship to the original retail purchaser for a

period of 5 years provided the equipment was purchased and installed from a Current Audio, LLC Authorized Dealer.

In the event of defective materials and or workmanship, Current Audio, LLC will, without charge, repair or replace, at its option, the defective product. In

order to make claim under this Warranty and to obtain performance of any obligation under warranty, please contact Current Audio. Instructions will be given

on how to return the defective product to Current Audio. Returned products must be shipped prepaid. Proof of purchase must be provided with the product.

The Warranty does not apply to damage not resulting from defective materials and or workmanship while in the possession of the original consumer or due to

unreasonable use by the original consumer, which includes but not limited to improper installation, negligence, unauthorized repair or modification, aesthetic

deterioration from the environment. Products purchased by unauthorized sources will void the warranty and not be honored.

Current Audio, LLC is not liable for any incidental or consequential damages, so the above limitations or inclusion may not apply to you. This warranty gives
