The dual purpose PRO SUB801-70VIndoor/Outdoor Constant

Voltage Distribution speaker is the perfect choice for either main

listening or sound reinforcement applications.It can be used in

household applications or commercial distributed public address

and sound systems.It is the choice of casinos.This full range

speaker supplies serious sound.It is provided with aswitchable

8ohm or 70 Volt input with adjustable wattage taps.If used with

100 volt systems the wattage taps will be 30 and 15 watts.DO

NOT use the 70 volt 30 watt tap on 100 volt systems. See Chart

on Page 2.

The 8” Injection Molded Carbon Fiber woofer cone and butyl

rubber surround are virtually impervious to the weather and

insects.It delivers shock and awe.

The speaker is housed in apainted steel back-can with aSafety

Tether connection.The back of the can houses the protected

wiring connections and switchable wattage taps or 8ohm knob.

This speaker color offered is white.It can be painted to match

any décor.The speaker enclosure is adurable UV-resistant

material that allows for both indoor and outdoor installations.

The perforated powdered coated steel alloy grill is long lasting,

corrosion resistant.

Electrical connection via aBX style connector in a½” conduit

hole is available on the back cover.Up to 16 gauge wire, is

made by constant tension spring loaded terminals via a½”

knock out terminal cover.An external switch on the back-can

allows selectable wattage taps of 60-30-15-7.5 or pass thru 8Ω.

With our limited Lifetime warranty you are assured years of

superior trouble free operation.

PRO SUB801-70V Indoor/Outdoor Speaker User’s Installation Guide

www.currentaudio.com

1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181

SPECIFICATIONS PRO SUB801-70V

Driver 8” Injection Molded Carbon Fiber

Frequency Response 35Hz-300kHz

Power Handling 8Ω

Power Handling 70Volts 5-150 Watts @ 8Ω

60-30-15-7.5 Watts @ 70Volts

SPL @ 1 Watt/1 meter 90db

Impedance 8 ohm Nominal Fixed Crossovers

Retrofit Cutout Diameter 9 7/16” (240 mm)

Height X Width X Can Depth 8"(203.2mm) X 10"(273mm) X

7.5”(190.5mm)

Color White. Black Special Order

Part Number 93200 SUB801-70V

Manual URL www.currentaudio.com

Accessories 92084 TB8 Tile Support Bracket

Specifications subject to change without notice. SUB801-70V RPA 062811

8.0” 8 ohm/70Volt, Indoor/Outdoor

In-Ceiling Subwoofer

SUB801-70V Side SUB801-70V Back

SUB801-70V BackSUB801-70V Front

Packaging and Enclosed Parts

Please inspect your pack for damagedor missing parts. Notify your supplierif any discrepanciesoccur.

The SUB801-70VSpeakers are packaged one to abox and sold as each.

Each box includes (1) Speaker, (1) Grille(1) ½” knockout cover plate and (1) Hardwood Tree planted in the National Forest.

Specifications subject to change without notice.

Install

1. Decide if you want standard 8ohm or distributed 70/100volt speaker sound.Then chose 8ohm or 70Volt. The PRO SUB801-70Vcan do either.This speaker may

also be used on 100 volt systems but with derated taps.See chart below

2. Chose locations for your speakers. I suggest one Pro SUB801 every 275 sqft

3. Chooseyour wiring method:Home Run or Daisy chain.Suggest apigtail if daisy chain from one speaker to the next.Use Home Run wiring in 8 ohm applications.

4. Bury your conduit or wire 18”below grade to prevent damage by tillers or shovels when planting. Prewire before hardscape concrete.

5. Insure there is enough room above to place the SUB801-70Vin the ceiling or tile.

6. Use aone piece TB8 Tile Support Bracket to prevent sag.See YouTube for video install instructions.Cut on inside of TB8diameter

7. For proper phasing identify the (+) and (-) on each cable.

8. If using as 70 volt the speakers they can be Daisy Chained from one speaker to the next.

9. How do Iknow what size 70 volt amp to use? Rule of thumb -add up all the wattage taps of the speakers then divide by .75 for safety factor.Example, suppose you

have 5speakers with the wattage tap of 30,the total wattage would be 150 watts. Divide150W/.75 =200W. Now select an amp of 200Wor higher.

10. For 8ohm hook-up select the 8Ωposition on the Tap switch on the rear of the back-can.

11. Before connectingthe wires to the amplifier check the impedance with amulti-meteron the resistancescale.It should read about 6.5 ohms in the 8ohm position.

12. If multi-meterreading is OK, observe polarities then connect to amplifier.

Limited Lifetime Warranty

Current Audio speakers are warranted to be free from defects in materials and or workmanship to the original retail purchaser provided the speaker was

purchased and installed from a Current Audio Authorized Dealer.

In the event of defective materials and or workmanship, Current Audio, LLC will, without change, repair or replace, at its option, the defective product. In

order to make claim under this Warranty and to obtain performance of any obligation under warranty, please contact Current Audio LLC. Instructions will be

given on how to return the defective product to Current Audio. Returned products must be shipped prepaid. Proof of purchase must be provided with the

product.

The Warranty does not apply to damage not resulting from defective materials and or workmanship while in the possession of the original consumer or due to

unreasonable use by the original consumer, which includes but not limited to improper installation, negligence, unauthorized repair or modification, aesthetic

deterioration from the environment. Products purchased by unauthorized sources will void the warranty and not be honored.

Current Audio ,LLC is not liable for any incidental or consequential damages, so the above limitations or inclusion may not apply to you. This warranty gives
