700W MINI
OIL FILLED RADIATOR
INSTRUCTION MANUAL
C7MOR10
Thank You for purchasing your new Currys Essentials
700W Mini Oil Filled Radiator.
We recommend that you spend some time reading this instruction
manual in order to fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
(P.N.: C7MOR10-002)
SPECIFICATIONS
Power supply : 230V~ 50Hz
Power Consumption : 700W
No. of Fins : 7
Specications and features may change without prior notice.
SAFETY FIRST!
Please follow all the safety precautions listed below for safety and to reduce
the risk of injury or electrical shock.
• Read this Instruction Manual carefully to maximise this appliance’s
performance and keep for future reference.
• This appliance is not intended for commercial use or any other uses than its
intended use.
• Always ensure that your power supply voltage matches this appliance’s
rating label.
• Do not kink or wrap the mains cable and plug around the appliance, as this
may cause the insulation to weaken and split, particularly where it enters
the appliance.
• Ensure the mains cable is fully extended before use and arrange it so that it
is not in contact with any part of the appliance.
• Do not pull on the mains cable. Never move, carry or hang the appliance by
the mains cable.
• Always position the appliance with the mains plug in an accessible position
and avoid the use of an extension cables as they may overheat and create a
potential re risk.
• Never position the appliance below a mains socket.
• The appliance must have a minimum 50 cm clearance around all sides of
the appliance.
• Ensure that the unit is used on a stable and level surface. If the oor surface
is uneven there is a risk that the appliance could tip over. Also, excessive
vibration and noise may occur. If the appliance should be accidentally
tipped over, please immediately disconnect from the power supply.
• Do not use the appliance in wardrobes or near fabrics or clothing. Do not
stand the appliance on deep pile carpets.
• Do not use the appliance in areas where petrol, paints or other ammable
substances are used or stored.
• Do not use in very dusty areas as dust may accumulate on the heating
elements and cause overheating.
• Do not use if there are any visible signs of damage to the appliance.
• Do not operate the appliance in direct sunlight, near heat sources, humid
environments or in places near water or other liquids such as bathrooms,
shower or swimming pool.
• Do not operate with wet hands or spill water or other liquids on to the
appliance, the mains cable or plug.
• Children should be supervised to ensure that they do not play with the
appliance. Do not place the appliance in places that are easy to reach by
children.
• Always unplug the appliance when not in use.
• For safety reasons a broken or damaged mains cable may only be replaced
by the manufacturer or a similarly qualied person.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instructions
concerning the use of the appliance by a person responsible for their
safety.
• This appliance is lled with a precise quantity of special oil. Repairs
requiring the opening of the oil container are only to be performed by an
authorised, qualied technician who should be contacted if there is an oil
leakage.
• When disposing the appliance, follow the local regulations concerning the
disposal of oil.
WARNING: In order to avoid overheating, do not cover the
appliance.
NOTE: If you require a replacement for any of the items listed below,
please quote their corresponding part numbers:
Replacement Part
Front Foot
Rear Foot
AI1117H08R
AI1087H08R
Part Number
• Do not use the appliance with a programmer, timer or any other device
that switches the appliance on automatically. A re risk exists if the
appliance is covered or positioned incorrectly.
C
M
Y
CM
MY
CY
CMY
K
C7MOR10_IB_110615.pdf 1 15/06/2011 12:03 PM

GB-1 GB-2
UNPACKING
Remove all packaging from the unit. Retain the packaging. If you
dispose of it please do so according to any local regulations.
The following items are included:
PRODUCT OVERVIEW
CONTROL PANEL
Do not operate without both feet attached. Only operate the radiator in
an upright position (feet on the bottom, controls on the top), any other
position could create a hazardous situation.
Do not immerse the radiator in water. Do not use any cleaning chemicals
such as detergents and abrasives. Do not allow the interior to get wet as
this could create a hazard.
GB-3
OVERHEAT PROTECTION SYSTEM
The power to the radiator will automatically cut off if the temperature of
the heater exceeds a certain limit. In the event of overheating, the radiator
will stop operating. Switch the radiator off and allow it to completely cool.
The radiator will then operate again as normal.
CLEANING AND STORAGE
1. Always remove the mains plug
from the mains socket and allow
the radiator to cool down before
cleaning the radiator.
2. Wipe the radiator with a soft damp
(not wet) cloth.
3. Store the radiator in a clean dry
place.
H I N T S & T I P S
My radiator does not work when I turn it on
1. Check that your radiator is plugged in and the power is turned on at the
mains socket.
2. Set the temperature to the highest setting.
3. Check if the thermostat setting is too low.
4. Try replacing the BSI or ASTS approved 13 Amp BS1362 fuse in the plug.
5. If the radiator still doesn’t work, do not try to repair the radiator
yourself.
If your radiator’s power is automatically cut o follow the steps
below:
1. Unplug your radiator and allow it to cool down.
2. Inspect your radiator.
3. Plug-in the radiator and switch it on again. If it cuts off again, move the
radiator to a better ventilated location.
4. If there is any sign of physical damage (e.g. melting, or burning of the
case), do not attempt to use your radiator. Please leave all maintenance
work to qualied personnel.
ASSEMBLY
1. Unpack the radiator and remove all the parts from the packaging.
2. Place the radiator body upside-down on a scratch-free surface, making
sure it is stable and will not fall.
3. Insert the front foot horizontally into the bottom of the front cover until
it clips into place.
4. Insert the rear foot vertically along the rear n and press it down until it
is rmly tted .
OPERATION
1. Position the radiator upright on the oor away from curtains, furniture or
wallcovering before plugging your radiator into the mains socket.
2. Switch the Power Switch to the ON position.
3. Turn the Thermostat Control to the desired position. It is recommended
to rotate to “MAX” position to get the radiator to pre-heat. It will take
5-10 minutes for the radiator to pre-heat.
4. When the room reaches the desired temperature, turn the Thermostat
Control slowly anti-clockwise until the power indicator goes off with a
“click” sound. The radiator will temporarily go off.
5. If the room temperature falls below the desired temperature, the
radiator and power indicator will turn on again until the room tempera-
ture reaches the desired temperature.
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
The Main Unit
Rear Foot
(P.N.: AI1087H08R)
Instruction Manual
(P.N.: C7MOR10-002)
I
0
MIN MAX
POWER
Front Foot
(P.N.: AI1117H08R)
700W MINI
OIL FILLED RADIATOR
INSTRUCTION MANUAL
C7MOR10
ThankYoufor purchasing your new Currys Essentials
700WMini Oil Filled Radiator.
Werecommend that you spend some time reading this instruction
manualin order to fully understand all the operational features it offers.
Readall the safety instructions carefully before use and keep this
instructionmanual for future reference.
I
0
MIN MAX
POWER
I
0
MIN MAX
POWER
Radiator Fins
Front Foot
Front Cover
Pilot Light
Carry Handle
Rear Foot
0 I
MIN MAX
Thermostat
Control
Power Switch
