OWNER’S GUIDE
646592
LSV 800 INTL
ISSUED MAY 2015

WELCOME
Thank you for purchasing this vehicle. Before driving the vehicle, we ask you to spend some time reading this Owner’s
Guide. This guide contains the information that will assist you in maintaining this highly reliable vehicle. Some illustrations
may show items that are optional for your vehicle. This guide covers the operation of several vehicles; therefore, some
illustrations may not represent your vehicle. Physical differences in controls will be illustrated.
Most of the service procedures in this guide can be accomplished using common, automotive hand tools. Contact your ser-
vice representative on servicing the vehicle in accordance with the Periodic Service Schedule.
Repair or replacement parts are available through your CUSHMAN retailer.
The following information is needed when ordering service or parts for your vehicle:
Vehicle Model ____________________________________________________________________________
VIN Number______________________________________________________________________________
Manufacturing Date Code __________________________________________________________________
The Cushman LSV800 INTL (LSV 800 International) is a motor vehicle that can only be operated by a licensed driver,
and must be driven in accordance with all local laws.
The LSV 800 International complies solely with American National Standards Institute (ANSI) Z135 for Personal Transport Vehicles
(PTV). For clarity, the 2Five International is NOT certified for on-road use in accordance with U.S. Federal Motor Vehicle Safety stan-
dard 571.500. On-road use of the 2Five International outside of the United States is subject to applicable laws and regulations of the
jurisdiction in which the 2five International is operated. As such, E-Z-GO does not warranty or certify that the 2Five International can
be legally operated on-road in jurisdictions outside of the United States. Users should consult their local authorities as to the legality of
using the LSV 800 International as an on-road vehicle.

Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its stability or increase the speed
beyond the factory specifications. Such modifications can cause serious personal injury or death. E-Z-GO Division of Textron, Inc.
prohibits and disclaims responsibility for any such modifications or any other alteration which would adversely affect the safety of the
vehicle.
E-Z-GO Division of Textron, Inc. reserves the right to incorporate engineering and design changes to products in this manual, without
obligation to include these changes on units sold previously.
The information contained in this manual may be revised periodically by E-Z-GO Division of Textron, Inc., and therefore is subject to
change without notice.
E-Z-GO Division of Textron, Inc. DISCLAIMS LIABILITY FOR ERRORS IN THIS MANUAL, and SPECIFICALLY DISCLAIMS LIABILITY FOR
INCIDENTAL AND CONSEQUENTIAL DAMAGES resulting from the use of the information and materials in this Manual.
TO CONTACT US
CUSHMAN
1451 Marvin Griffin Road.
Augusta, Georgia, 30906-3852
USA
E-mail: Cushmanc[email protected]
North America:
Technical Assistance & Warranty PHONE: [phone] FAX: [phone]
Cushman Genuine Parts & Accessories PHONE: [phone] FAX: [phone]
International:
PHONE: [phone] FAX: [phone]
i
OWNER’S GUIDE
48 V ELECTRIC POWERED
LOW-SPEED VEHICLE
LSV 800 INTL
STARTING MODEL YEAR 2016

NOTES
ii Owner’s Guide
This vehicle was designed and manufactured in the United States of America (USA). The
standards and specifications listed in the following text originate in the USA unless other-
wise indicated.
Use Original Equipment Manufacturer (OEM) approved parts to keep the warranty effective.
If you do not correctly maintain the batteries, you will cancel the warranty. Refer to the
MAINTENANCE section for instructions on the correct maintenance of the batteries.
BATTERY PROLONGED STORAGE
The batteries discharge over time. The rate of discharge changes according to the ambient
temperature, the age and condition of the batteries.
Completely charged batteries will not freeze in winter temperatures unless the temperature
is less than -75°F (- 60°C).
For winter storage, the batteries must be clean, completely charged and disconnected from
any electrical drain.
The battery charger can remain connected to the vehicle to keep a full charge on the batter-
ies as long as the charger is connected to an active electrical supply. If the power to the
electrical supply is disconnected or interrupted, the battery charger will continuously check
the charge on the battery pack. The continuous check of the battery pack will pull power
from the battery pack and eventually drain the batteries.
The batteries must be checked and charged again as required or at a minimum of 30-day
intervals.
Check and maintain correct fluid level in all battery cells during the storage period. Correct
fluid level is necessary for maximum battery performance.
BATTERY DISPOSAL
Lead-acid batteries are recyclable. Return discarded batteries to distributor, manufacturer
or lead smelter for recycling. For neutralized spills, put residue in acid-resistant containers
with absorbent material such as sand. Dispose in accordance with local, state and federal
regulations for acid and lead compounds. Contact local or state environmental authorized
people for the disposal information.

B
TABLE OF CONTENTS
iii
Owner’s Guide
SAFETY
GENERAL......................................................................................................................... 1
NOTICES, CAUTIONS, WARNINGS AND DANGERS .................................................... 1
GENERAL......................................................................................................................... 2
GENERAL OPERATION................................................................................................... 2
MAINTENANCE................................................................................................................ 4
VENTILATION................................................................................................................... 4
SEAT BELTS .................................................................................................................... 5
Seat Belt Operation .............................................................................................. 6
LABELS AND PICTOGRAMS........................................................................................... 7
REPORTING SAFETY DEFECTS.................................................................................... 8
GENERAL SPECIFICATIONS
VEHICLE DIMENSIONS................................................................................................. 12
TURNING DIAMETER AND INCLINE INFORMATION .................................................. 13
INTRODUCTION
FEATURES..................................................................................................................... 15
General Information ........................................................................................... 15
Parking Brake ..................................................................................................... 15
OPERATING PROCEDURES
SERIAL NUMBER LOCATION ....................................................................................... 23
VEHICLE IDENTIFICATION NUMBER (VIN)................................................................. 23
VEHICLE DATA PLATE.................................................................................................. 24
BEFORE INITIAL USE.................................................................................................... 24
BRAKE BURNISHING PROCEDURE ............................................................................ 25
SEAT BELT OPERATION............................................................................................... 25
ON-BOARD CHARGER WITH DC TO DC CONVERTER.............................................. 26
Understand the Charger ..................................................................................... 26
Maintenance Instructions ................................................................................... 27
HOW TO OPERATE THE VEHICLE............................................................................... 27
Regenerative Braking ......................................................................................... 28
Pedal-Up Braking ............................................................................................... 29
Parking Brake ..................................................................................................... 29
High Pedal Disable Feature ............................................................................... 29
Starting and Driving ............................................................................................ 29

B
iv
TABLE OF CONTENTS
Owner’s Guide
Starting Vehicle on a Hill .....................................................................................29
Coasting ..............................................................................................................29
Labels and Pictograms .......................................................................................29
Canopy Top and Windshield ...............................................................................30
Towing Gradability ..............................................................................................30
Truck Bed Operation ...........................................................................................30
Manual Lift Bed Operation ..................................................................................31
Tailgate Operation ..............................................................................................32
MAINTENANCE
VEHICLE CLEANING AND CARE................................................................................... 35
ENVIRONMENTAL CONCERNS .................................................................................... 35
Battery Disposal ..................................................................................................36
LIFTING THE VEHICLE................................................................................................... 36
WHEELS AND TIRES...................................................................................................... 37
Tire Repair ..........................................................................................................38
Wheel Installation ...............................................................................................38
LIGHT BULB REPLACEMENT........................................................................................ 39
Headlight Bulb Replacement ..............................................................................39
Turn Signal Bulb Replacement ...........................................................................39
Taillight/Brake Light Bulb Replacement ..............................................................39
FUSE REPLACEMENT ................................................................................................... 39
TRANSPORTING VEHICLE............................................................................................ 40
Hauling ................................................................................................................40
In Case of Total Power Loss ...............................................................................40
SERVICE AND MAINTENANCE ..................................................................................... 41
ROUTINE MAINTENANCE.............................................................................................. 42
Tire Inspection ....................................................................................................42
Rear Axle ............................................................................................................42
Brake Master Cylinder ........................................................................................42
ERROR AND WARNING CODES................................................................................... 43
HARDWARE.................................................................................................................... 43
CAPACITIES AND REPLACEMENT PARTS.................................................................. 44
BATTERY CHARGING AND MAINTENANCE................................................................ 44
Battery .................................................................................................................45
Battery Maintenance ...........................................................................................45

B
TABLE OF CONTENTS
v
Owner’s Guide
At Each Charging Cycle ..................................................................................... 45
Monthly ............................................................................................................... 45
Electrolyte Level and Water ............................................................................... 45
Battery Charging ................................................................................................ 47
Battery Removal and Installation ....................................................................... 48
Battery Cleaning ................................................................................................. 49
Battery Disposal ................................................................................................. 50
Prolonged Storage ............................................................................................. 50
AC Voltage ......................................................................................................... 50
Fault Diagnosis .................................................................................................. 51
Hydrometer ........................................................................................................ 51
Using A Hydrometer ........................................................................................... 52
Battery Charger Maintenance ............................................................................ 52
PERIODIC SERVICE SCHEDULE...........................................................................55
REGISTRATION AND WARRANTY.........................................................................57

vi
TABLE OF CONTENTS
Notes:
Owner’s Guide

SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
1
Owner’s Guide
SAFETY
GENERAL
For any questions about material in this manual, contact an authorized representative.
Read and understand all labels on the vehicle. Always replace any damaged or missing labels.
Steep hills allow the vehicle to move at faster speeds than speeds on a flat surface. To prevent the loss of vehicle control
and possible injury, speeds must be controlled to the maximum level ground speed indicated in the GENERAL SPECIFI-
CATIONS section. Apply the brake to control the speed.
If you operate the vehicle above the maximum specified speed, you can damage the drivetrain components. The dam-
age caused by speeds more than the maximum specified can cause a loss of vehicle control, is abusive, and will not be
covered under the warranty.
Use caution when you tow the vehicle. Towing the vehicle at above the recommended speed can cause personal injury
or damage to the vehicle and other property.
If the vehicle is used in a commercial environment, signs must be in position to inform of possible conditions that can be
dangerous. Examples shown below.
.
NOTICES, CAUTIONS, WARNINGS AND DANGERS
Read the NOTICES, CAUTIONS, WARNINGS and DANGERS. The person who services a vehicle needs the mechani-
cal skill and experience to see possible hazardous conditions. Incorrect service or repairs can cause damage to the vehi-
cle or make the vehicle dangerous to operate.
A NOTICE indicates and describes information not related to personal injury.
A CAUTION indicates a dangerous condition that can cause an injury that is not life threatening.
A WARNING indicates a dangerous condition that can cause death or serious injury.
A DANGER indicates a dangerous condition that will cause death or serious injury.

2Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
This manual contains recommended maintenance procedures from the manufacturer. Follow these procedures and fault
isolation information to get the best service from the product. To decrease the risk of personal injury or property damage,
obey all the information in this manual.
THE LSV 800 INTL SHALL BE OPERATED ONLY BY PERSONS WITH VALID DRIVERS LICENSES, AND IN
ACCORDANCE WITH APPLICABLE LOCAL REQUIREMENTS. THIS IS A LEGAL REQUIREMENT AND IS
IMPORTANT TO THE SAFE USE AND OPERATION OF THE PRODUCT.
All customers should adhere to this SAFETY RESTRICTION, in connection with the use of all E-Z-GO products, new and
used, in personal transportation applications.
Vehicles are used for different purposes, so it is not possible to know and inform of every possible occurrence. Be careful
when you drive to prevent avoidable personal injury or damage to the vehicle. All users must read and obey this manual.
Make sure you give special attention to the CAUTIONS, WARNINGS and DANGERS.
GENERAL
If you have any questions regarding this vehicle, contact your CUSHMAN dealer or write to the address on the back
cover of this publication, Attention: Customer Care Department.
E-Z-GO reserves the right to make design changes without obligation to make these changes on units previously sold.
The information contained in this manual is subject to change without notice.
E-Z-GO IS NOT LIABLE FOR ERRORS IN THIS MANUAL. E-Z-GO IS NOT LIABLE FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES THAT RESULT FROM THE USE OF THE MATERIAL IN THIS MANUAL.
Be sure that all electrical accessories are grounded directly to the battery (-) post. Never use the chassis or body as a
ground connection.
Refer to GENERAL SPECIFICATIONS for vehicle seating capacity.
Do not change the vehicle in any manner that changes the weight distribution, decreases stability,
increases speed or extends the necessary distance to stop more than the factory specification.
Such changes can cause personal injury or death.
Do not change the vehicle in any manner that changes the weight distribution, decreases stability, increases speed or
extends the necessary distance to stop more than the factory specification. E-Z-GO is not responsible for changes that
cause the vehicle to be dangerous.
Do not let anyone below the height of 59 inches (150 cm) operate the vehicle.
Vehicles that are capable of higher speeds must limit their speed to no more than the speed of other vehicles when used
in a golf course environment. Additionally, speed should be further moderated by the environmental conditions, terrain
and common sense.
GENERAL OPERATION
Read the following warnings before you operate the vehicle.

B
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
3
Owner’s Guide
When you leave the vehicle, turn the key to the OFF position and remove the key from the vehicle.
Drive the vehicle only as fast as terrain and conditions allow. Consider the terrain and traffic condi-
tions. Consider environmental conditions that change the terrain and your ability to control the
vehicle.
Do not drive fast downhill. Sudden stops or change of direction can cause a loss of control. Use
the brake to control the speed of the vehicle when you drive down a slope.
When possible, stay in approved areas and do not drive on steep slopes.
Always keep feet, legs, hands and arms inside vehicle.
Do not drive on rough terrain.
Before you drive in the reverse direction, make sure the area behind the vehicle is clear.
Make sure the direction selector is in the correct position before you press the accelerator pedal.
Decrease speed before and during turns.
Make sure you completely stop the vehicle before you move the direction selector.
See GENERAL SPECIFICATIONS for the vehicle load and seat capacity.
Read the following text and warnings before you service the vehicle.
Normal use, age, wear or abuse can cause some components on the vehicle to fail. The manufacturer can not know all
possible component failures or the methods that failures can occur.
A vehicle in need of repair does not function properly and can be dangerous.
Be careful when you service the vehicle. Be aware of your safety and the safety of other people in the area.
Some components are heavy, spring loaded, corrosive, explosive, can cause high amperage or get hot. Battery acid and
hydrogen gas can cause injury. Do not put your hands, face, feet or body in a location that can expose them to injury if an
unexpected situation occurs.
Always use the tools shown in the tool list and wear safety equipment.
Remove all jewelry before you service the vehicle.
Do not allow loose clothing or hair to contact the moving parts.
Do not touch hot objects.

4Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
When you service the vehicle, always wear eye protection. Be careful when you
do work around batteries or you use solvents or compressed air.
ALWAYS:
• Use the vehicle in a responsible manner and keep the vehicle in safe condition for operation.
• Read and obey all warnings and operation instruction labels on the vehicle.
• Follow all safety rules in the area where the vehicle is operated.
• When there is a risk of lightning, leave the vehicle and look for a safe location to wait until the lightning has stopped.
• Drive the vehicle only as fast as terrain and conditions allow.
• Apply brake to control the speed on steep grades.
• Decrease speed in wet areas.
• Be careful when you make sharp turns, or turns you are not familiar with.
• Be careful when you drive on loose terrain.
• Be careful when you operate the vehicle around people.
MAINTENANCE
ALWAYS:
• Replace damaged or missing warning, caution or information labels.
• Service the vehicle according to the periodic service schedule in this manual.
• Make sure that approved and qualified personnel do all repairs.
• Follow the manufacturers maintenance procedures.
• Use insulated tools within the battery area to prevent sparks or battery explosion.
• Use specified replacement parts. DO NOT use replacement parts of lesser quality.
• Use recommended tools.
• Make sure that tools and procedures not specified by the manufacturer will not be a safety risk to personnel or oper-
ation of the vehicle.
• Support the vehicle with wheel chocks and jack stands. NEVER get below a vehicle that is supported by a jack. Lift
the vehicle according to the manufacturers instructions.
• Make sure you service the vehicle in an area away from open flame or sparks.
• Know that a vehicle in need of repair does not operate correctly and can be dangerous to operate.
• After you do the repairs or maintenance, test the vehicle in a safe area that is without vehicle and person traffic.
• Make sure you record and keep all of the maintenance history of the vehicle.
VENTILATION
• Charge the vehicle in a well-ventilated area.
• Charge in an area free of flammable liquids and items.
• Charge a vehicle in an area that is free from flame or spark, pay particular attention to natural gas or propane water
heaters and furnaces.

B
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
5
Owner’s Guide
• Use a dedicated 15-amp circuit for each battery charger, DO NOT permit other appliances to be plugged into the
receptacle when the charger is in operation.
• Operate the charger in accordance with E-Z-GO’s recommendations or applicable electrical codes.
SEAT BELTS
All occupants in the vehicle must have their seat belts properly fastened.
Be sure the seat belts are latched securely and are not twisted.
Position the shoulder belt across the top of the shoulder. Do not place the shoulder belt under the
arm.
Loose fitting safety belts significantly reduce protection. Keep belts snug and positioned low on
the hips.
Do not exceed the recommended number of occupants for the vehicle;
Each seat is designed for one occupant only.
The driver and all passengers must wear seat belts, one person per belt. The two-passenger LSV 800 has two seats and
is equipped with two safety belts, one for the driver and one for the passenger. The safety belts must be used at all times
while operating the vehicle.
This vehicle has not been tested for use with automotive style child safety seats or booster seats.
Do not use automotive style child safety seats or booster seats with this vehicle.
Inspect the safety belt webbing and hardware periodically. Check for cuts, frays or loose parts. Replace com-
ponents if excessive wear or damage is found.
Keep safety belts clean and dry. To clean, use mild soap and warm water. Do not use bleach, dye or abrasive
cleaners as this will weaken the belt webbing material.
Do not insert any objects into the retractor mechanism.
Periodically check for smooth operation and replace if the mechanism is not operating properly.
Pregnant, disabled, or injured persons should consult their doctor for specific recommendations before
using the LSV 800.

6Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Seat Belt Operation
To properly secure the seat belts, pull the metal tab from the retractor and insert into the appropriate buckle located near
the center of the seat. A click will be heard when the tab is securely latched. Position the lap belt as low as possible on
the hips; not the waist. Properly adjust and ensure a snug fit by pulling the shoulder portion upward.
The retractor locks the belt when the vehicle stops suddenly. It can also lock if the occupant leans forward quickly. Slow,
easy motion allows for free travel of the seat belt.
To release the safety belt, press the buckle release button and allow the belt to retract. If the belt does not retract, check
for twists.

B
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
7
Owner’s Guide
LABELS AND PICTOGRAMS
< 14° 25%
< 14° 25%
cm
MIN 150
ON
NF
R
OFF
O
RF
ON
OFF
I
O
R
F
ON
OFF
I
O
ON
NF
R
OFF
O
614043
F
R
OFF
O
ON
N
ON
OFF
I
O
RF
614043
READ THE MANUAL
OPERATE ACCORDING
TO LOCAL LAWS AND
REGULATIONS
USE CAUTION IN
BAD WEATHER
FORWARD OPERATION
* TURN KEY TO ‘ON’
* MOVE DIRECTION
SELECTOR TO ‘F’
* PRESS ACCELERATOR
PEDAL GENTLY
REVERSE OPERATION
* TURN KEY TO ‘ON’
* MOVE DIRECTION
SELECTOR TO ‘R’
* PRESS ACCELERATOR
PEDAL GENTLTY
PARK VEHICLE
* MOVE DIRECTION
SELECTOR TO ‘F’
* TURN KEY TO ‘OFF’
* APPLY PARKING
BRAKE
GASOLINE
VEHICLES
DO NOT DRIVE
ON HIGHWAY
DO NOT OPERATE
IF USING DRUGS
OR ALCOHOL
DO NOT OPERATE
VEHICLE WHEN
LIGHTNING IS
IN THE AREA
FORWARD OPERATION
* TURN KEY TO ‘F’
* PRESS ACCELERATOR
PEDAL GENTLY
REVERSE OPERATION
* TURN KEY TO ‘R’
* GENTLY PRESS
ACCELERATOR
PEDAL
PARK VEHICLE
* TURN KEY
TO ‘OFF’
ELECTRIC
VEHICLES
MAXIMUM RAMP
OR HILL
MAXIMUM CROSS
RAMP OR HILL
OPERATE FROM
DRIVER SIDE ONLY
DO NOT STAND UP
AND KEEP ENTIRE
BODY INSIDE VEHICLE
MINIMUM HEIGHT TO
OPERATE VEHICLE IS
150 CM
74821G07
MAX
14
o
/ 25%
MAX
300 lbs.
136 kg
MAX
5 in.
12 cm
P
P
MAX
100 lbs.
45 kg
74821G07
WARNING
READ
THE
MANUAL
HIGH CENTER OF
GRAVITY MAY
CAUSE TIP OVER
MAX SIDE
SLOPE 14°
NO PASSENGERS
IN TRUCK BED
TAILGATE
MAX WEIGHT
100 LBS or 45 KG
SECURE LOAD
MAX BED WEIGHT
300 LBS or 136KG
MAX CENTER
OF GRAVITY
HEIGHT
5 INCHES
or 12 CM
ABOVE FLOOR
MAY CAUSE
EXPLOSION
DO NOT
FILL FUEL
CONTAINER
IN TRUCK
BED

8
B
Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
REPORTING SAFETY DEFECTS
If you believe your vehicle has a defect that could cause a crash, or could cause injury or death, immediately inform E-Z-
GO Division of Textron Inc.
611233
Windshields do not
provide protection
from flying objects
611233
636607
F
R
OFF
O
ON
N
636607
636606
< 14° 25%
< 14° 25%
cm
MIN 150
ON
NF
R
OFF
O
ON
NF
R
OFF
O
636606
F
R
OFF
O
ON
N
www.ezgo.com
610990
1
2
3
41
23
4
1
2
3
4
610990
610991
610991
IF THE VEHICLE
DOES NOT MOVE
WARNING
READ THE
MANUAL
WARNING
READ THE
MANUAL
ATTACH THE TOW BAR BEFORE
TURNING THE KEY SWITCH
TO THE TOW POSITION
KEEP
HANDS
OUT
TO REDUCE THE POSSIBILITY
OF BATTERY EXPLOSION TURN
THE KEY TO THE OFF POSITION
BEFORE DICONNECTING OR
CONNECTING BATTERY WIRES
WARNING
READ THE
MANUAL
CHOCK
THE
WHEELS
CONNECT
1 TO 3
DISCONNECT
1 FROM 2
DISCONNECT
3 FROM 4
MOVE THE
VEHICLE CHOCK
THE
WHEELS
CONNECT
1 TO 2
CONNECT
3 TO 4
READ THE
MANUAL
OPERATE
ACCORDING
TO LOCAL
LAWS AND
REGULATIONS
USE CAUTION
IN BAD
WEATHER
FORWARD
OPERATION
TURN THE KEY
TO F PRESS
THE ACCELERATOR
PEDAL GENTLY
REVERSE
OPERATION
TURN THE KEY
TO R AND PRESS
THE ACCELERATOR
PEDAL GENTLY
PARK VEHICLE
TURN THE KEY
TO OFF
FOR SERVICE
MANUAL GO TO
www.ezgo.com
READ THE
LABELS
FASTEN
SEAT
BELT
MAXIMUM
RAMP
OR HILL
MAXIMUM
CROSS RAMP
OR HILL
DO NOT OPERATE
IF USING DRUGS
OR ALCOHOL
DO NOT DRIVE
ON HIGHWAY
OPERATOR
MINIMUM HEIGHT
IS 150 CM
WINDSHIELD
DOES NOT
PROTECT
AGAINST
FLYING
OBJECTS
DANGER
READ THE
MANUAL
636604
636604
617331
HIGH
VOLTAGE
WARNING
CORROSIVE
DO NOT
SMOKE
NO
SPARKS
WARNING
EXPLOSIVE
DO NOT
SHORT-CIRUIT
VEHICLE EMISSION CONTROL INFORMATION
This vehicle is certified to operate on stored electric energy. This vehicle conforms to
California regulations applicable to XXXX Model Year new ZEV passenger cars.
Test Group: YEZG00.00A02 617331

9
Owner’s Guide
Notes:
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY

10 Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Notes:

GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
11
Owner’s Guide
GENERAL SPECIFICATIONS
MODEL: LSV 800 INTL
TYPE: ELECTRIC LOW SPEED TRUCK
MODEL YEAR: 2016
Part No:. 643612G01
Programmable AC Drive System: Factory programmable to application

Solid State variable frequency AC speed controller

235 Amp AC C ontroller

Driv e-by -w ire electronic throttle control

Full torque, reduced speed rev erse

Dash mounted direction selector sw itch (Forward-N eutral-Rev erse)  Sealed H all effect throttle sensor

Descent speed control and automatic hill hold

Full diagnostic capability (Hand held diagnostic unit)

Full-time regenerativ e braking

Dash mounted High/Low speed selector sw itch
Motor:
Battery Charger: On-board 48 VDC Pow erWise™ H igh Frequency , 120/230 VAC 50/60 Hz w ith 30 amp DC -DC C onv ertor. (U .L. & C .S.A. C ertified)
Electrical System: 48 Volt DC , four, 12 v olt deep cy cle storage batteries (60 minute minimum, 150 amp-hour @ 20 hr. discharge rate)
Drive Train: Direct motor shaft connected to transax le pinion shaft
T ransaxle:
Differential w ith rev erse helical gears
Brakes: 4-w heel hy draulic disc brakes and Induction motor. Electro-magnetic parking brake is applied automatically
Towing: Rear hitch receiv er integrated into bed support frame
Cargo Bed: Roto-molded cross-linked poly ethelene. Tilts for access to pow ertrain. Remov able hinged multi-position tailgate requires no latch mechanism
Ov erall Length in cm DC -DC Conv ertor 30 amp - Integrated into On-board C harger
Ov erall Width in cm Performance
Ov erall H eight in cm S eating C apacity & S ty le 2 Persons/Bucket Seats
Ov erall H eight (w ith Strobe) in cm Dry Weight lb kg
Wheel Base
in cm Curb Weight lb kg
Front Wheel Track in cm Bed Load Capacity lb kg
Rear Wheel Track in cm Vehicle load capacity lb kg
Gnd C learance @ Differential in cm Towing C apacity 1200 lb max (See Page 2 for Gradeability)
Cargo Box Width (inside) in cm Gross Ax le Weight Rating - F lb kg
Cargo Box Length (inside)
in cm Gross Ax le Weight Rating - R lb kg
Cargo Box Depth (inside) in cm Outside Clearance C ircle ft m
Cargo Box C apacity cu ft. m3S peed - Low (Lev el Ground) mph kph
Cargo Box M aterial Roto-molded poly ethylene Speed - High (Lev el Ground) mph kph
Vehicle Power
Speed - Rev erse
mph kph
Power Source 48 Volts DC Steering & Suspension
M otor Ty pe 48 V olts A C Steering
Double Ended Rack & Pinion - 3.69 turns to lock
Horsepower (kW) hp kW
Front Suspension
Independent A-arm w ith C oil Ov er Shock
Electrical S y stem 48 Volt
Rear Suspension
Mono-Leaf Springs with Hy draulic Shocks
Batteries (Qty , Type) Four, 12 Volt Deep C y cle Serv ice Brake 4-Wheel H y draulic Disc w ith Motor Regen
Key or Pedal Start Pedal Start Parking Brake Spring Applied Electro-magnetic
Speed Controller 235 amp Front & Rear Tires DOT Street Legal 205-50-10 Radial
Driv e Train Motor Shaft Direct Driv e
Body & Chassis
Transax le Helical Gears Frame Welded Steel w ith DuraShield pow der coat
Direction Selection Dash mounted Forw ard-N eutral-Rev erse Body & Finish Injection M olded TPO & Automotiv e Sty le Paint
Speed Selection Dash mounted H igh-Low sw itch Standard C olor Patriot Blue
Some items shown may be optional equipment
25
800
136
36.7
93
14
575
Rear Ax le Ratio
0.17
5.9
181
39.7
101
4.5
11
44.5
113
4.4
3.3
14.76:1 (F)
12.9
40.2
22.5
363
6.0
907
261
8
48.5
123
71.2
Onboard 48 VDC Pow erWise™
554
1221
893
405
75.2
191
167
Dimensions
77
108.9
277
300
2000
19.7
30.5
7.5
PRODUCT SPECIFICATION
19
Battery Charger
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW
48 Volt AC induction motor, solid copper w indings. 4.4 hp (3.3 kW) C ontinuous, 15 hp (11.2 kW) peak. AC sy stem reads motor speed for
accurate speed control in all conditions. Regenerativ e braking for max imum economy
65.9

12 Owner’s Guide
GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
VEHICLE DIMENSIONS
48.5”
(123 cm)
47.3”
(120 cm)
108.9”
(277 cm)
65.9”
(167 cm)
