Cushman SHUTTLE 2+2 G User manual

OWNER’S GUIDE
642586
GAS SHUTTLE 2+2
REVISED NOV 2015ISSUED JAN 2015

WELCOME
Thank you for purchasing this vehicle. Before you drive the vehicle, read this Owner’s Guide. This guide contains mainte-
nance and operation information. The illustrations can show items that are optional for your vehicle.
You can do most of the service procedures in this guide with common, automotive hand tools. If necessary, contact your
service representative for information about how to service the vehicle as shown in the Periodic Service Schedule.
Repair or replacement parts are available from your E-Z-GO dealer or E-Z-GO Service Parts Department.
When you contact E-Z-GO about service or parts for your vehicle, the information below is needed.
Vehicle Model: ___________________________________________________________
PIN, VIN or Serial Number: _________________________________________________

Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its stability or increase the speed
beyond the factory specifications. Such modifications can cause serious personal injury or death. E-Z-GO Division of Textron Inc. prohib-
its and disclaims responsibility for any such modifications or any other alteration which would adversely affect the safety of the vehicle.
E-Z-GO Division of Textron Inc. reserves the right to incorporate engineering and design changes to products in this manual, without obli-
gation to include these changes on units sold previously.
The information contained in this manual may be revised periodically by E-Z-GO, and therefore is subject to change without notice.
E-Z-GO DISCLAIMS LIABILITY FOR ERRORS IN THIS MANUAL, and SPECIFICALLY DISCLAIMS LIABILITY FOR INCIDENTAL AND CONSE-
QUENTIAL DAMAGES resulting from the use of the information and materials in this Manual.
These are the original instructions as defined by 2006/42/EC.
CONTACT US:
E-Z-GO Division of Textron Inc.
1451 Marvin Griffin Road.
Augusta, Georgia, USA 30906-3852
North America:
Technical Assistance & Warranty PHONE: [phone] FAX: [phone]
Service Parts PHONE: 1-888-GET-EZGO (1-888-438-3946) FAX: [phone]
International:
PHONE: [phone] FAX: [phone]
i
OWNER’S GUIDE
GAS POWERED VEHICLE
SHUTTLE 2+2
STARTING MODEL YEAR 2015
CALIFORNIA Proposition 65 Warning
WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known
to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids con-
tained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to
cause cancer and birth defects or other reproductive harm.

FORWARD
ii Owner’s Guide
This vehicle was designed and manufactured in the United States of America (USA). The
Standards and Specifications listed in the following text originate in the USA unless other-
wise indicated.
Use Original Equipment Manufacturer (OEM) approved parts to keep the warranty effective.
Overfilling battery may void the warranty.
Tampering with or adjusting the governor to permit vehicle to operate at above factory spec-
ifications will void the vehicle warranty.
When servicing engines, all adjustments and replacement components must be per original
vehicle specifications in order to maintain the United States of America Federal and State
emission certification applicable at the time of manufacture.
BATTERY PROLONGED STORAGE
The batteries discharge over time. The rate of discharge changes according to the ambient
temperature, the age and condition of the batteries.
Completely charged batteries will not freeze in winter temperatures unless the temperature
is less than -75°F (- 60°C).
BATTERY DISPOSAL
Lead-acid batteries are recyclable. Return discarded batteries to distributor, manufacturer
or lead smelter for recycling. For neutralized spills, put residue in acid-resistant containers
with absorbent material, sand or earth and discard according to local, state and federal reg-
ulations for acid and lead compounds. Contact local or state environmental authorized peo-
ple for the disposal information.

B
TABLE OF CONTENTS
iii
Owner’s Guide
SAFETY
GENERAL......................................................................................................................... 1
NOTICES, CAUTIONS, WARNINGS AND DANGERS .................................................... 1
GENERAL OPERATION................................................................................................... 3
MAINTENANCE................................................................................................................ 4
VENTILATION................................................................................................................... 5
LABELS AND PICTOGRAMS........................................................................................... 6
LABELS AND PICTOGRAMS........................................................................................... 7
GENERAL SPECIFICATIONS
VEHICLE DIMENSIONS................................................................................................. 10
TURNING DIAMETER AND INCLINE INFORMATION .................................................. 11
INTRODUCTION
FEATURES..................................................................................................................... 13
General Information ........................................................................................... 13
Key and Light Switch .......................................................................................... 13
Fuel Gauge with Low Oil Pressure Indicator...................................................... 13
12-Volt Power Outlet.......................................................................................... 13
Direction Selector............................................................................................... 13
Choke................................................................................................................. 14
Accelerator Pedal .............................................................................................. 14
Brake and Parking Brake Pedal......................................................................... 14
Horn ................................................................................................................... 14
Turn Signal Switch ............................................................................................. 14
Front Seat .......................................................................................................... 14
Front Hip Restraint............................................................................................. 14
Glove Box Doors (if equipped)........................................................................... 14
Cup Holder......................................................................................................... 14
Steering Wheel................................................................................................... 14
Brake Light and Turn Signal............................................................................... 15
Rear Seat and Cargo Platform .......................................................................... 15
Rear Hand Rail................................................................................................... 15
Rear Handle....................................................................................................... 15
Weather Enclosure (if equipped)........................................................................ 15
Rear View Mirror (if equipped) ........................................................................... 15

B
iv
TABLE OF CONTENTS
Owner’s Guide
OPERATING PROCEDURES
SERIAL NUMBER LOCATION........................................................................................ 17
BEFORE INITIAL USE..................................................................................................... 18
HOW TO OPERATE THE VEHICLE ............................................................................... 18
Key and Headlight Switch Operation .................................................................19
Direction Selector Operation ..............................................................................20
Accelerator Pedal Operation ...............................................................................20
Brake and Parking Brake Operation ...................................................................20
Horn Operation ...................................................................................................20
Rear Seat and Cargo Platform Operation ..........................................................21
12-Volt Power Outlet ...........................................................................................21
STARTING AND DRIVING.............................................................................................. 22
Run-In .................................................................................................................22
Starting Vehicle On A Hill ....................................................................................23
Coasting ..............................................................................................................24
FUEL................................................................................................................................ 24
FUEL TANK..................................................................................................................... 24
Early Production Fuel Tank .................................................................................24
Late Production Fuel Tank ..................................................................................25
BATTERY ........................................................................................................................ 25
LABELS AND PICTOGRAMS.......................................................................................... 25
SUN TOP AND WINDSHIELD (IF EQUIPPED)............................................................... 26
MAINTENANCE
VEHICLE CLEANING AND CARE................................................................................... 27
ENVIRONMENTAL CONCERNS .................................................................................... 27
Battery Disposal ..................................................................................................27
LIFTING THE VEHICLE................................................................................................... 28
WHEELS AND TIRES...................................................................................................... 29
Tire Repair ..........................................................................................................29
Wheel Installation ................................................................................................30
LIGHT BULB REPLACEMENT........................................................................................ 31
Headlight .............................................................................................................31
Taillight ................................................................................................................31
FUSE REPLACEMENT ................................................................................................... 31
VEHICLE WITH A DISCHARGED BATTERY ................................................................. 32

B
TABLE OF CONTENTS
v
Owner’s Guide
TRANSPORTING VEHICLE ........................................................................................... 32
Towing ................................................................................................................ 32
Neutral Lock ....................................................................................................... 32
Hauling ............................................................................................................... 33
SERVICE AND MAINTENANCE..................................................................................... 33
ROUTINE MAINTENANCE............................................................................................. 34
Four Cycle Engine .............................................................................................. 34
Checking the Oil Level ....................................................................................... 34
Changing the Oil ................................................................................................ 35
Starter Generator Belt Tension .......................................................................... 37
Adjusting the Belt ............................................................................................... 38
Battery Cleaning ................................................................................................. 38
TIRE INSPECTION......................................................................................................... 39
BRAKES ......................................................................................................................... 39
Periodic Brake Test ............................................................................................ 40
LUBRICATION................................................................................................................ 40
CAPACITIES AND REPLACEMENT PARTS................................................................. 41
HARDWARE ................................................................................................................... 41
AIR INTAKE AND COOLING FINS................................................................................. 42
REAR AXLE ................................................................................................................... 42
Checking the Lubricant Level ............................................................................. 42
Cleaning the Air Filter Element ......................................................................... 43
LUBRICATION................................................................................................................ 43
SPARK PLUGS............................................................................................................... 43
PERIODIC SERVICE SCHEDULE
PERIODIC SERVICE SCHEDULE ................................................................................. 45

B
vi
TABLE OF CONTENTS
Owner’s Guide

SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
1
Owner’s Guide
SAFETY
GENERAL
For any questions about material in this manual, contact an authorized representative.
Read and understand all labels on the vehicle. Always replace any damaged or missing labels.
Steep hills allow the vehicle to move at faster speeds than speeds on a flat surface. To prevent the loss of vehicle control
and possible injury, speeds must be controlled to the maximum level ground speed indicated in the GENERAL SPECIFI-
CATIONS section. Apply the brake to control the speed.
If you operate the vehicle above the maximum specified speed, you can damage the drivetrain components. The dam-
age caused by speeds more than the maximum specified can cause a loss of vehicle control, is abusive, and will not be
covered under the warranty.
Use caution when you tow the vehicle. Towing the vehicle at above the recommended speed can cause personal injury
or damage to the vehicle and other property.
If the vehicle is used in a commercial environment, signs must be in position to inform of possible conditions that can be
dangerous. Examples shown below.
.
NOTICES, CAUTIONS, WARNINGS AND DANGERS
Read the NOTICES, CAUTIONS, WARNINGS and DANGERS. The person who services a vehicle needs the mechani-
cal skill and experience to see possible hazardous conditions. Incorrect service or repairs can cause damage to the vehi-
cle or make the vehicle dangerous to operate.
A NOTICE indicates and describes information not related to personal injury.
A CAUTION indicates a dangerous condition that can cause injury that is not life threatening.
A WARNING indicates a dangerous condition that can cause death or serious injury.
A DANGER indicates a dangerous condition that will cause death or serious injury.

2Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Engine exhaust from this product contains chemicals known, in certain quantities, to cause can-
cer, birth defects, or other reproductive harm.
The exhaust emissions of this vehicles engine complies with regulations set forth by the Environmental Protection
Agency (EPA) of the United States of America (USA) at time of manufacture. Significant fines could result from modifi-
cations or tampering with the engine, fuel, ignition or air intake systems.
Battery posts, terminals and related accessories contain lead and lead compounds. Wash hands
after handling.
This spark ignition system meets all requirements of the Canadian Interference-Causing Equipment Regulations.
This manual contains recommended maintenance procedures from the manufacturer. Follow these procedures and fault
isolation information to get the best service from the product. To decrease the risk of personal injury or property damage,
obey all the information in this manual.
Certain replacement parts can be used independently and/or in combination with other accessories to modify
an E-Z-GO-manufactured vehicle to permit the vehicle to operate at or in excess of 20 mph. When an E-Z-GO-
manufactured vehicle is modified in any way by the Distributor, Dealer or customer to operate at or in excess
of 20mph, UNDER FEDERAL LAW the modified product will be a Low Speed Vehicle (LSV) subject to the stric-
tures and requirements of Federal Motor Vehicle Safety Standard 571.500. In these instances, pursuant to
Federal law the Distributor or Dealer MUST equip the product with headlights, rear lights, turn signals, seat
belts, top, horn and all other modifications for LSV’s mandated in FMVSS 571.500, and affix a Vehicle Identifi-
cation Number to the product in accordance with the requirements of FMVSS 571.565. Pursuant to FMVSS
571.500, and in accordance with the State laws applicable in the places of sale and use of the product, the
Distributor, Dealer or customer modifying the vehicle also will be the Final Vehicle Manufacturer for the LSV,
and required to title or register the vehicle as mandated by State law.
E-Z-GO will NOT approve Distributor, Dealer or customer changes that change an E-Z-GO product into a Low Speed
Vehicle (LSV).
Anyone who operates this vehicle must be A LICENSED DRIVER AND OPERATE THE VEHICLE ACCORDING TO
APPLICABLE STATE REQUIREMENTS. This rule is important to the SAFE USE AND OPERATION of the product. All
customers must obey this SAFETY RULE.
Information on FMVSS 571.500 is found at Title 49 of the Code of Federal Regulations, section 571.500. For information
online, go to www.ecfr.gov.
Vehicles are used for different purposes, so it is not possible to know and inform of every possible occurrence. Be careful
when you drive to prevent avoidable personal injury or damage to the vehicle.All users must read and obey this manual.
Make sure you give special attention to the CAUTIONS, WARNINGS and DANGERS.
For questions about this vehicle, contact your E-Z-GO/CUSHMAN dealer or write to the address on the back cover of this
publication, Attention: Customer Care Department.

B
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
3
Owner’s Guide
E-Z-GO has the right to change the design of the vehicle. There is no responsibility to make the changes on units pur-
chased before changes were made. The information in this manual can change without notice.
E-Z-GO IS NOT LIABLE FOR ERRORS IN THIS MANUAL. E-Z-GO IS NOT LIABLE FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES THAT RESULT FROM THE USE OF THE MATERIAL IN THIS MANUAL.
This vehicle meets the current applicable standard for safety and performance requirements.
These vehicles are for off-road use. They DO NOT meet the federal Motor Vehicle Safety Standards of the United States
ofAmerica (USA) and are not for operation on the public streets. Some areas allow the operation of the vehicles on their
streets according to local codes.
Refer to GENERAL SPECIFICATIONS for capacity of the vehicle.
Do not change the vehicle in any manner that changes the weight distribution, decreases stability,
increases speed or extends the necessary distance to stop more than the factory specification.
Such changes can cause personal injury or death.
Do not change the vehicle in any manner that changes the weight distribution, decreases stability, increases speed or
extends the necessary distance to stop more than the factory specification. E-Z-GO is not responsible for changes that
cause the vehicle to be dangerous.
Do not let anyone below the height of 59 inches (150 cm) operate the vehicle.
GENERAL OPERATION
Read the following warnings before attempting to operate the vehicle.
When you leave the vehicle, turn the key to the OFF position and remove the key from the vehicle.
Drive the vehicle only as fast as terrain and conditions allow. Consider the terrain and traffic condi-
tions. Consider environmental conditions that change the terrain and your ability to control the
vehicle.
Do not drive fast downhill. Sudden stops or change of direction can cause a loss of control. Use
the brake to control the speed of the vehicle when you drive down a slope.
When possible, stay in approved areas and do not drive on steep slopes.
Always keep feet, legs, hands and arms inside vehicle.
Do not drive on rough terrain.
Before you drive in the reverse direction, make sure the area behind the vehicle is clear.
Make sure the direction selector is in the correct position before you press the accelerator pedal.
Decrease speed before and during turns.
Make sure you completely stop the vehicle before you move the direction selector.
See GENERAL SPECIFICATIONS for the vehicle load and seat capacity.

4Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Read the following text and warnings before you service the vehicle.
Normal use, age, wear or abuse can cause some components on the vehicle to fail. The manufacturer can not know all
possible component failures or the methods that failures can occur.
A vehicle in need of repair does not operate correctly and can be dangerous.
Be careful when you service the vehicle. Be aware of your safety and the safety of other people in the area.
Some components are heavy, spring loaded, corrosive, explosive, can cause high amperage or get hot. Battery acid and
hydrogen gas can cause injury. Do not put your hands, face, feet or body in a location that can expose them to injury if an
unexpected situation occurs.
Always use the correct tools shown in the tool list and wear safety equipment.
Remove all jewelry before you service the vehicle.
Do not allow loose clothing or hair to contact the moving parts.
Do not touch hot objects.
When you service the vehicle, always wear eye protection. Be careful
when you do work around batteries or you use solvents or compressed
air.
ALWAYS:
• Use the vehicle with responsibility and keep the vehicle in safe condition for operation.
• Read and obey all warnings and operation instruction labels on the vehicle.
• Follow all safety rules in the area where the vehicle is operated.
• When there is a risk of lightning, leave the vehicle and look for a safe location to wait until the lightning has stopped.
• Drive the vehicle only as fast as terrain and conditions allow.
• Apply service brake to control the speed on steep grades.
• Keep enough distance between vehicles.
• Decrease speed in wet areas.
• Be careful when you make sharp turns, or turns you are not familiar with.
• Be careful when you drive on loose terrain.
• Be careful when you operate the vehicle around people.
MAINTENANCE
ALWAYS:
• Replace damaged or missing warning, caution or information labels.
• Service the vehicle according to the periodic service schedule in this manual.
• Make sure that approved and qualified personnel do all repairs.

B
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
5
Owner’s Guide
• Follow the manufacturers maintenance procedures.
• Use insulated tools within the battery area to prevent sparks or battery explosion.
• Use specified replacement parts, DO NOT use replacement parts of less quality.
• Use recommended tools.
• Make sure that tools and procedures not specified by the manufacturer will not be a safety risk to personnel or oper-
ation of the vehicle.
• Support the vehicle with wheel chocks and jack stands. NEVER get below a vehicle that is supported by a jack. Lift
the vehicle according to the manufacturers instructions.
• Make sure you service the vehicle in an area away from open flame or sparks.
• Know that a vehicle in need of repair does not operate correctly and can be dangerous to operate.
• After you do the repairs or maintenance, test the vehicle in a safe area that is without vehicle and person traffic.
• Make sure you record and keep all of the maintenance history of the vehicle.
Vehicles are used for different purposes, so it is not possible to know and inform of every possible occurrence. Be careful
when you drive to prevent avoidable personal injury or damage to the vehicle.All users must read and obey this manual.
Make sure you give special attention to the CAUTIONS, WARNINGS and DANGERS.
People who do maintenance or repairs on the vehicle must have skill and experience to identify and prevent conditions
that can cause personal injury or death and damage to the vehicle.
VENTILATION
Always store gasoline vehicles in an area with good ventilation. Good ventilation prevents the accumulation of gasoline
fumes within an enclosed area.
Never put fuel in a vehicle in an area that is subject to flame or spark. Pay particular attention to natural gas or propane
water heaters and furnaces.
Never work around or operate a vehicle in an environment that does not allow ventilation of exhaust gases from the area.
Carbon monoxide is a dangerous gas that can cause unconsciousness and is potentially lethal.

6Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
LABELS AND PICTOGRAMS
H
O
R
N
OFF
ON
71131-G01
71131G01
608527
LOCATED ON GOVERNOR COVER
H O
2
123
P
P
P
P
P
P
74093-G01
74093G01
NEGATIVE
GROUND
BATTERY
CLEAN GASOLINE SPILLS WITH WATER
BEFORE STARTING ENGINE
DO NOT SPILL
FUEL ON HOT
ENGINE
NO TAMPERING
KEEP HANDS
OUT
DO NOT
EXPOSE
TO FLAME
GROUND
FUEL
PUMP
SHORTING BATTERY
TERMINALS MAY
CAUSE EXPLOSION
610631
MAX SIDE
SLOPE 14°
DO NOT RIDE
ON LOAD BED
HIGH CENTER
OF GRAVITY MAY
CAUSE TIP OVER
WARNING READ THE MANUAL
SECURE LOAD
MAX BED WEIGHT
250 LBS or 110 KG
MAX CENTER OF
GRAVITY HEIGHT
4” OR 10 CM
ABOVE FLOOR
REMAIN SEATED
AND HOLD ON
TO HAND RAIL

B
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
7
Owner’s Guide
LABELS AND PICTOGRAMS
H
O
R
N
27653G01
EGWHL14
AUTHORIZED REPRESENTATIVE IN EC IS:
RANSOMES JACOBSEN LTD.
WEST ROAD, IPSWICH,
SUFFOLK, IP3 9TT, UK 614068
614068
FOR INFORMATION
REFER TO OWNERS
MANUAL
USE CAUTION IN
INCLEMENT WEATHER
NO PUBLIC
ROAD USE
DO NOT OPERATE
UNDER DRUG/ALCOHOL
INFLUENCE
OPERATE FROM
DRIVERS SIDE
ONLY
REMAIN SEATED
KEEP ARMS / LEGS
WITHIN VEHICLE
MAX SIDE
SLOPE 14°
READ MANUAL
FOR MAX LOAD
BED CAPACITY.
MAX INCLINE 14°
601781
P
F
R
F
< 14° 25%
N
< 14° 25%
P
P
601781
TO OPERATE VEHICLE:
- TURN KEY TO ON
- MOVE DIRECTION SELECTOR
TO F OR R
- PRESS ACCELERATOR
TO PARK VEHICLE:
- TURN KEY TO OFF
- MOVE DIRECTION SELECTOR
TO FORWARD
- ENGAGE PARKING BRAKE
FOR INFORMATION
REFER TO OWNERS
MANUAL OR
WEBSITE
WARNING
READ OWNERS
MANUAL OR
WEBSITE
OBEY LOCAL
RULES AND
REGULATIONS
USE CAUTION IN
INCLEMENT
WEATHER
NO PUBLIC
ROAD USE
DO NOT OPERATE
UNDER DRUG/ALCOHOL
INFLUENCE
LEAVE VEHICLE
IN THREAT OF
LIGHTNING
OPERATOR MUST
BE MIN 150 CM
REMAIN SEATED
KEEP ARMS / LEGS
WITHIN VEHICLE
TO OPERATE VEHICLE:
- TURN KEY TO ON
- MOVE DIRECTION SELECTOR TO
FORWARD OR REVERSE
- PRESS ACCELERATOR
TO PARK VEHICLE:
- TURN KEY TO OFF
- MOVE DIRECTION SELECTOR
TO FORWARD
- ENGAGE PARKING BRAKE
MAX SIDE
SLOPE 14°
614121
cm
MIN 150
RF
ON
OFF
I
O
ON
OFF
I
OF
R
F
ON
OFF
I
O
ON
OFF
I
OR
FON
OFF
I
O
ON
OFF
I
O
RF
< 14°25%
< 14° 25%
614121
READ MANUAL
FOR MAX LOAD
BED CAPACITY.
MAX INCLINE 14°
OPERATE FROM
DRIVERS SIDE
ONLY
608822

8Owner’s Guide
SAFETY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Notes:

GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
9
Owner’s Guide
GENERAL SPECIFICATIONS
MODEL: CUSHMAN SHUTTLE 2+2 G
TYPE: GASOLINE POWERED PERSONNEL CARRIER
MODEL YEAR: 2015
Part No:. 641356
z
z
z
z
z
z
Some items shown may be optional equipment
Engine: 13.5 hp (10.1 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.5 ci (401 cc) single cylinder, air-cooled by Kawasaki
Valve Train: Overhead valve Fuel System: Fixed oat bowl with remote pulse fuel pump
Lubrication: Pressurized oil system, spin-on oil lter Ignition: Electronic spark/magneto
Balancer: Internal counter rotating balance shaft Air Cleaner: Replaceable dry cartridge
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (425 CCA, 60 minute reserve)
Drive Train: Automatic, continuously variable transmission (CVT)
Brakes: Dual rear wheel mechanical self-adjusting drum brakes. Automatic single point park brake release with self-compensating system
Transaxle: Dierential with helical gears, ground speed governor, forward/reverse
Capacity: Seating for 4 persons. Rear Seat converts to Load Deck
Performance
Overall Length 108.5 in (276 cm) Seating Capacity 4 Persons
Overall Width 48.5 in (123 cm) Dry Weight 861 lb (391 kg)
Overall Height (No Canopy) 46.5 in (118 cm) (Top of steering wheel) Curb Weight 896 lb (406 kg)
Overall Height (w/ Canopy) 77.0 in (196 cm) (Top of Sun Canopy) Load Capacity (Load Deck) 250 lb (110 kg)
Wheel Base 65.5 in (166 cm) Load Capacity (Vehicle) 800 lb (360 kg)
Front Wheel Track 38.0 in (96 cm) Outside Clearance Circle 19 ft (5.8 m)
Rear Wheel Track 38.5 in (97 cm) Intersecting Aisle Clearance N/A
Gnd Clearance @ Dierential 4.5 in (11 cm) Speed (Level Ground) 14 mph ± 0.5 mph (22.5 kph ± 0.8 kph)
Load Bed Width 40.0 in (102 cm) Towing Capacity N/A
Load Bed Length 32.0 in (81 cm) Steering & Suspension
Vehicle Power Steering Self-compensating rack and pinion
Power Source 4 Cycle 24.5 cu in (401 cc). Low E Front Suspension Leaf springs with hydraulic shock absorbers
Valve Train Single Cylinder OHV Rear Suspension Leaf springs with hydraulic shock absorbers
Horsepower (kW) 13.5 hp (10.1 kW) Exceeds SAE J1940 Std. Service Brake Rear wheel mechanical self-adjusting drum
Electrical System Starter/Generator. Solid State Regulator Parking Brake Self-compensating, single point engagement
Batteries (Qty, Type) One, 12 Volt Maintenance Free Front Tires Pair of 18 x 8.50 - 8 (4 Ply Rated)
Key or Pedal Start Pedal
Rear Tires Pair of 18 x 8.50 - 8 (4 Ply Rated)
Air Cleaner Replaceable Dry Cartridge
Body & Chassis
Lubrication Pressurized Oil System
Frame Welded steel with DuraShield™ powder coat
Oil Filter Spin-On
Front Body & Finish Injection molded TPO
Cooling System Air Cooled
Rear Body & Finish Injection molded TPO
Fuel Capacity (Early Prod.) 6.0 Gallon (22.7 L) tank
Fuel Capacity (Late Prod.) 5.6 Gallon (21.4 L) tank
Standard Color Patriot Blue
Drive Train Continuously variable transmission (CVT)
Transaxle Dierential with helical gears
Gear Selection Forward - Reverse
Rear Axle Ratio 11.42:1 (Forward) 15.78:1 (Reverse)
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW
Dimensions

10 Owner’s Guide
GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
VEHICLE DIMENSIONS
Rear
38 in. (97 cm)
Front
38.5 in. (98 cm)
77 in.
(196 cm)
46.5 in
(118 cm)
108.5 in (276 cm)
65.5 in (166 cm)
4.5 in
(11 cm)
48.5 in
(123 cm)
RECOMMENDED MAX SIDE TILT
25% or 14o
RECOMMENDED MAX RAMP GRADE
25% or 14 MAX
o
MAX

B
GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
11
Owner’s Guide
TURNING DIAMETER AND INCLINE INFORMATION
TURNING CLEARANCE DIAMETER
19 ft (5.8 m)

12 Owner’s Guide
GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Notes:
