Custom Dynamics ProBEAM PB-TL-INT-TW-R User manual

Package Contents:
- ProBEAM® Integrated Taillight Assembly (1)
- Nylon Washers (1 pair)
- Gasket (1)
We thank you for purchasing the Custom Dynamics® ProBEAM® Integrated LED Taillight! Our LEDs oer maintenance
free service and higher visibility. Our ProBEAM® product line ulizes the latest technology and automove grade
components to ensure the highest level of reliable service. Custom Dynamics® oers one of the best warranty pro-
grams and customer support in the industry. If you have any quesons during the installaon of this product please
call us at 1(800) 382-1388.
Custom Dynamics®
ProBEAM® Integrated LED
Taillight Installaon Instrucons
US Patents: D807545, D807546, D808050.
China Patent: ZL201730257957.9
DO NOT OVERTIGHTEN! Overghtening screws during installaon can crack the
lens at the screw holes and void the warranty.
Do NOT use thread lock such as Loc-Tite™ with this product, it will weaken the
plasc at the screw holes causing cracks and will void the warranty.
Important: DOT & SAE Compliant run and brake. Integrated turn signals are in-
tended for use as auxiliary lighng only. Integrated turn signals are NOT intended
to replace any original equipment lighng installed on the vehicle and should not
be used for that purpose. This product must be wired so that it does not interfere
with any original equipment lighng.
ATTENTION
Please read all Informaon below before Installaon
Fitment: 1999-2013 Harley-Davidson® Sportster models
(Except XL1200N, XL1200X, XL1200V or XL883N); 2014-
2019 XL883L &XL1200T, 1999-2017 Dynas® (Except 2009-
2017 FXDB, 2010-2017 FXDWG), 1999-2017 Soails®
(Except FXS, FLS, FXSB, FXSBSE, FLSTN, FLSTNSE, FXCWC, 2010
FLSTSE2), 2018-2020 Heritage Classic (FLHC), 1999-2013 Electra
Glide, Ultra Classic, Ultra Limited models (including CVO™), Road
King Classic (FLHRC), Road Glide Ultra (FLTRU), Road Glide Ultra
CVO™ (FLTRUSE), 1999-2009 Road Glide Standard (FLTR), 2006-
2009 Street Glide (FLHX), 1999-2020 Road King® (FLHR), 2014-
2015 Limited CVO™, 2015 Road Glide® Ultra CVO™ (FLTRUSE),
2019-2020 Electra Glide® Standard (FLHT).
Replaces: OEM Squareback Taillight PN:68245-03
Not Recommended for: inverted installaon on
01 FXDWG2, 02 FXDWG3, 99-08 FXDWG, 2008-2013 FXDF, 99-09
FXSTB, 08-11 FLSTSB, 99-10 FXSTC, 99-07 FXST, 99-06 FXSTS, 09-
12 XR1200 & XR1200X
Note: Not compable on Trike models, on models with Run/
Brake/Turn module installed or on CanBus models with Brake/
Turn BCM programming
Part Number:
Installaon:
1. Remove stock taillight by removing the 2 Phillips
head screws, save for use with the new LED tail-
light.
2. Unplug the taillight connector from the terminal
block in the taillight base.
3. Make sure the new ProBEAM® LED taillight
base is clean and free of debris.
4. Remove white paper from back of gasket and
apply gasket to the new ProBEAM® LED taillight
assembly. (Note: Gasket on the new unit will
need to make clean contact with the taillight
base all the way around.)
5. Locate the left and right 2 pin turn signal con-
nectors. Press down release tab on the top of
connector to unplug both. (See Figure 1 on
Page 2)
Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
05-2020
RED: PB-TL-INT-TW-RPB-TL-INT-BW-RPB-TL-INT-NW-R
SMOKED: PB-TL-INT-TW-SPB-TL-INT-BW-SPB-TL-INT-NW-S

Installation Instructions - Page 2
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
05/2020
Instructions Continued:
6. Plug the 2 pin turn signal plugs from
new taillight into the same connectors,
brown is right turn, purple is left turn.
Make sure they lock in place. (See fig-
ure 1)
7. If you are continuing to use the stock
turn signals, plug the them into the 2 pin
connectors on the tail light. Brown is
right, purple is left. Make sure they lock
in place.
(See figure 2)
8. Tuck connectors into the center space in
the center of the base. Make sure there
is enough space to allow installation of
the taillight.
(See Figure 3)
9. Fit the new ProBEAM® LED taillight into
the taillight base, insert right Phillips
head screw, with nylon washer, and
tighten 1 turn. Insert left Phillips head
screw, with nylon washer, and tighten 1
turn.
10.To ensure proper fit, take top of
ProBEAM® LED taillight and tip it down-
ward so that the top of the taillight as-
sembly goes under the lip of the taillight
base. While holding in this position,
tighten both left and right screws equally
until taillight is fully seated and screws
are snug. DO NOT OVERTIGHTEN!
Overtightening screws will crack the
lens at the screw holes and void warran-
ty.
11.Check Operation of taillight in run, turn,
and brake modes.
Figure 1: 2 Pin Turn Connectors
Figure 2: Plugging in Stock Turns
Figure 3: Tuck wiring connectors
